Seating and Safety Restraints
145
[SS04800(ALL)01/96]
The seat cushion will move forward when going from the seat
to the bed position.
[SS04900(ALL)09/96]
17-1/2 pica
art:0050260-B
2nd row seat (seat position)
[SS05000(ALL)01/96]
To convert the bed to a seat:
[SS05100(ALL)01/96]1.
While in front of the seat, pull the release lever up, slightly
raise the seatback, then push the seat bottom rearward until
the seatback is in the full upright and locked position.
*
[SS05200(ALL)01/96]2.
Make sure the safety belts are free and available for use.
[SS05300(ALL)04/96]
RWARNING
The seat/bed should not be occupied while the vehicle is
moving unless it is in the upright, fully-latched position.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

154
*
[SS09400(ALL)01/96]4.
Ensure that the latch handles are fully seated in the down
position.
[SS09500(ALL)01/96]5.
(Second row bench seat only) Before you engage the safety
belt, be sure it is not twisted. A twisted safety belt may
cause the retractor to not work properly. Remove any twist,
then insert the tongue end of the safety belt into the
detachable anchor until you hear a ªsnapº and feel the latch
engage.
[SS09600(ALL)01/96]6.
To raise the seatback, pull up on the seatback latch handle.
A slight downward pressure on the seatback (bench seat
only) will reduce effort on the latch. Rotate the seatback
upward until the latch re-engages.
*
[SS09700(ALL)01/96]
RWARNING
When reinstalling a rear seat in your vehicle it must be
placed in its original position. Improper installation of
the seat will prevent correct use of the safety belts and
could increase the risk of injury. Refer to the warning
label on the seat belt.
[SS09800(ALL)01/96]
Whenever the second row bench seat is installed in the vehicle
and no one is using the outboard seating position (nearest the
sliding door), the lap/shoulder safety belt must be properly
stowed.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

Seating and Safety Restraints
169
*
[SS19500(ALL)05/96]
RWARNING
Do not place objects or mount equipment on or near the
air bag cover that may come in contact with an inflating
air bag. Failure to follow this instruction may increase
the risk of personal injury in the event of a collision.
*
[SS19600(ALL)05/96]
For further information about the proper mounting of
equipment in the front seat of this vehicle, please refer to Ford's
brochure entitledSome Important Information About Air Bag
Supplemental Restraint Systemwhich can be obtained by calling
Helm Inc. at 1-800-782-4356. Ask for brochure FPS-8602.
*
[SS19700(ALL)05/96]
For additional important safety information on the proper use of
seat belts, child seats, and infant seats, please read the other
sections of this chapter of the Owner Guide, especially sections
entitledSafety Belts for ChildrenandSafety Seats for Children.
%*
[SS19800(ALL)05/96]
How Does the Air Bag Supplemental Restraint System
Work?
*
[SS19900(ALL)05/96]
The Air Bag Supplemental Restraint System consists of the
driver and passenger air bags, impact sensors, a system
diagnostic module, a readiness light and tone, and the electrical
wiring which connects the components.
[SS20000(ALL)04/96]
The driver air bag is in the center of the steering wheel and is
indicated by the letters ªSRS.º The right front passenger seat air
bag is in the upper right-hand section of the instrument panel
ledge above the glove compartment. The letters ªSRSº appear
there. Both air bags are designed to stay out of sight until they
are activated.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

Seating and Safety Restraints
173
*
[SS20800(ALL)05/96]
To ensure that the air bag system will operate as intended in a
crash, the system is equipped with a diagnostic module, which
controls a readiness lamp and a warning tone. The diagnostic
module monitors its own circuits, the air bag electrical system,
the air bag readiness light, the air bag power and the air bag
inflators.
*
[SS20900(ALL)03/96]
The air bag supplemental restraint system uses a readiness light
and a tone to indicate the condition of the system. The
readiness light is in the instrument cluster. When you turn the
ignition key to ON, this light will illuminate for approximately
six (6) seconds and then turn off. This indicates that the system
is operating normally.NOTE:Maintenance of the air bag system
is not required.
%*
[SS21000(ALL)05/96]
A problem with the system is indicated by one or more of the
following:
*
[SS21100(ALL)05/96]
n
the readiness light will either flash or stay illuminated,
*
[SS21200(ALL)05/96]
n
or it will not illuminate immediately after ignition is turned
on,
%*
[SS21300(ALL)05/96]
n
a group of five beeps will be heard. The tone pattern will
repeat periodically until the problem and light are repaired.
[SS21400(ALL)12/95]
If any of these things happen, even intermittently, have the air
bag system serviced at your Ford or Lincoln-Mercury dealer
immediately.
%*
[SS21500(ALL)05/96]
Disposal of air bags and air bag equipped vehicles
[SS21600(ALL)12/95]
For disposal of air bags or air bag equipped vehicles, see your
local Ford or Lincoln-Mercury dealer. Air bags MUST be
disposed of by qualified personnel.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

205
Starting
%*
[TO00200(ALL)01/96]
Fuel-Injected Engines
[TO00300(ALL)07/96]
Since your vehicle has a fuel-injected engine,the most
important thing to remember is to avoid pressing down on the
acceleratorwhile cranking the engine to start. Only use the
accelerator when you have problems getting your vehicle
started.
%*
[TO00400(ALL)01/96]
Preparing to Start Your Vehicle
*
[TO00500(ALL)02/96]
RWARNING
Do not start your vehicle in a closed garage or in other
enclosed areas. Exhaust fumes can be toxic. Always open
the garage door before you start the engine.
*
[TO00600(ALL)01/96]
Before you start your vehicle, always:
*
[TO00700(ALL)01/96]1.
Make sure you and all your passengers buckle your safety
belts. SeeSafety beltsin the Index for more details.
*
[TO00800(ALL)01/96]2.
Make sure the headlamps and other accessories are turned
off when starting.
[TO00900(ALL)12/95]3.
Make sure that the gearshift lever is in Park (P) and the
parking brake is set before you turn the key.
[TO01000(ALL)07/96]
Before you start your vehicle, you should test the warning lights
on the instrument cluster to make sure that they work. Refer to
theInstrumentationchapter.
[TO01100(ALL)12/95]
Starting the Engine
[TO01200(ALL)12/95]
To start the engine:
[TO01300(ALL)07/96]1.
Follow the steps underPreparing to Start Your Vehicle.
*
[TO01400(ALL)01/96]2.
Keep your foot on the brake pedal and turn the ignition key
to ON.
File:08wntos.ex
Update:Mon Oct 7 11:45:28 1996

Starting
207
*
[TO02500(ALL)12/95]
NOTE: Your vehicle has an interlock that prevents you from
shifting out of P (Park) unless your foot is on the
brake pedal.
*
[TO02600(ALL)01/96]
If the engine still does not start after two attempts:
[TO02700(ALL)04/96]1.
Turn the key to the OFF position and wait about two
minutes.
*
[TO02800(ALL)01/96]2.
Press the accelerator all the way to the floor and hold it.
[TO02900(ALL)12/95]3.
Turn the key to the START position.
[TO03000(ALL)12/95]4.
Release the key when the engine starts.
*
[TO03100(ALL)03/96]5.
Release the accelerator gradually as the engine speeds up.
*
[TO03200(ALL)05/96]
If the engine still does not start, the fuel pump shut-off switch
may have been activated. For directions on how to reset the
switch seeFuel Pump Shut-Off Switchin the index.
[TO03300(ALL)12/95]
A computer system controls the engine's idle rpm. When you
start your vehicle, the engine's idling rpm normally runs high.
These faster engine speeds will make your vehicle move slightly
faster than when the engine is at its normal warm engine idle
speed. It should, however, slow down when the vehicle warms
up. If it does not, have the idle rpm checked.
*
[TO03400(ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in dry grass or
other dry ground cover. The emission system heats up
the engine compartment and exhaust system, which can
start a fire.
File:08wntos.ex
Update:Mon Oct 7 11:45:28 1996

211
Driving
%*
[GF00200(ALL)05/96]
Brakes
*
[GF00300(ALL)01/96]
When the foot (service) brake pedal is depressed, the
high-mount brake lamp should illuminate.
*
[GF00400(ALL)01/96]
Front Disc Brakes
[GF00500(ALL)01/96]
The front disc brakes are self-adjusting. They only require
periodic inspection for pad wear.
[GF00600(ALL)01/96]
Rear Disc Brakes (If equipped)
[GF00700(ALL)01/96]
The rear disc brakes are self-adjusting. They only require
periodic inspection for pad wear.
[GF00800(ALL)01/96]
The rear disc parking brakes need to be adjusted manually.
*
[GF00900(ALL)03/96]
Rear Drum Brakes
*
[GF01000(ALL)01/96]
The rear drum brakes are self-adjusting. Automatic adjustment
occurs through normal use of the brakes.
*
[GF01100(ALL)05/96]
Four-Wheel Anti-lock Brakes
*
[GF01200(ALL)01/96]
The Anti-lock Brake System (ABS) prevents wheels from
completely locking up by automatically releasing and
re-applying the brakes. During ABS braking, slight brake pedal
pulsations may be felt on the driver's foot. These pulsations
represent the rapid cycling of the ABS valves. The pedal
pulsations are considered normal ABS operation, and will stop
when normal braking is resumed or when the vehicle comes to
a stop.
[GF01300(ALL)09/96]
During ABS activation, a mechanical noise may be heard as the
ABS cycles. This is normal ABS operation.
[GF01400(ALL)09/96]
The ABS has self-check capabilities. The system turns on the
ABS warning light each time you start the engine. After the
engine is started and the ABS warning light turns off, the
system performs another test the first time the vehicle reaches
File:09wngfs.ex
Update:Mon Oct 7 11:46:08 1996

2124 mph (6 km/h). A mechanical noise may be heard as the ABS
performs a self test. This is a normal part of the self test feature.
If a malfunction is found during this check, the ABS warning
light will come on.
[GF01500(ALL)01/96]
6 pica art:0050147-B
The anti-lock brake system light
[GF01600(ALL)09/96]
You should always be careful when braking, even if your
vehicle has the ABS. Heavy braking on roads with loose
surfaces such as snow or gravel, or roads with severe pavement
irregularities could also cause you to lose control of your
vehicle.
*
[GF01700(ALL)03/96]
RWARNING
If the anti-lock brake system warning light remains on or
comes on while driving, have the braking system checked
by a qualified service technician as soon as possible.
*
[GF01800(ALL)03/96]
NOTE: If a fault occurs in the anti-lock system, and the brake
warning light is not lit, the anti-lock system is
disabled but normal brake function remains
operational.
*
[GF01900(ALL)01/96]
Ford Motor Company has not found any negative effects of
mobile radio transmitting equipment installed on vehicles with
the ABS system providing that the radio is installed according
to the radio manufacturer's instructions. However, if you have
had a mobile radio transmitter installed and the ABS light
comes on (at any time other than immediately after turning the
File:09wngfs.ex
Update:Mon Oct 7 11:46:08 1996
