1998 FORD EXPEDITION service indicator

WARNING LIGHTS AND CHIMES
Low fuel
Illuminates when the fuel level is
low. The lamp will also illuminate
when the ignition key is turned to
ON and the engine is off.
Check engine
Your vehicle is equipped with a
computer that monitors the
engine's emission control system.
This system is commonly known as
the On Board Diagnostics System
(OBD II). This OBD II system
protects the environment by
ensuring that your vehicle
continues to meet government
emission standards. The OBD II
system also assists the service
technician in properly servicing
your vehicle.
TheCheck Engineindicator light
illuminates when the ignition is
first turned to the ON position to
check the bulb. If it comes on after
LOW
FUEL
DOOR
AJAR
BRAKE
FUEL
RESET CHECK
ENGINELOW
RANGE
4 X 4
!ABS+ -
THEFTLEF
H0
0000
RPM1000X
00000
MPH
20km/h 406080
100
120
140
160
0
0 123
5
6 4
PRN 21
1020304050
60
70
80
90
100
8C 18
H
D
CHECK
SUSP
LOW
WASH
A4WD
FUEL DOOR
LOW
FUEL
CHECK
ENGINE
Instrumentation
6

Brake system warning
Momentarily illuminates when the
ignition is turned on and the
engine is off. Also illuminates when
the parking brake is engaged.
Illumination after releasing the
parking brake indicates low brake
fluid level.
Anti-lock brake system (ABS)
Momentarily illuminates when the
ignition is turned on and the
engine is off. If the light remains
on, continues to flash or fails to
illuminate, have the system
serviced immediately.
Turn signal
Illuminates when the left or right
turn signal or the hazard lights are
turned on. If one or both of the
indicators stay on continuously or
flash faster, check for a burned-out
turn signal bulb. Refer toExterior
bulbsin theMaintenance and
carechapter.
High beams
Illuminates when the high beam
headlamps are turned on.
!
BRAKE
ABS
Instrumentation
9

²Oil levels above the MAX mark
may cause engine damage. Some
oil must be removed from the
engine by a service technician.
7. Put the indicator back in and
ensure it is fully seated.
Adding engine oil
1. Check the engine oil. For
instructions, refer toChecking the
engine oilin this chapter.
2. If the fluid level is not within
the normal range, add only
certified engine oil of the preferred
viscosity. Add engine oil through
the oil filler cap. Remove the filler
cap and use a funnel to pour oil in
the opening.
3. Recheck the oil level. Make sure
the oil level is not above the MAX
mark on the dipstick.
Engine oil recommendations
Look for this certification mark.
Ford oil specification is
WSS-M2C153-G.
Use SAE 5W-30 motor oil certified
for gasoline engines by the
American Petroleum Institute.
Maintenance and care
155

BATTERY
Your vehicle may be equipped with
a Motorcraft maintenance-free
battery. If the original equipment
battery needs replacing, it may be
replaced with a low-maintenance
battery. The low-maintenance
battery normally does not require
additional water during its life of
service. However, for severe usage
or in high temperature climates,
check your battery electrolyte
level, at least every 24 months or
40,000 km (24,000 miles). Keep
the electrolyte in each cell up to
the ªlevelº indicator. Do not overfill
the battery cells.
If the electrolyte level in the
battery is low, you can add plain
tap water to the battery, as long as
you do not use hard water (water
with a high alkali content). If
possible, however, try to only fill
the battery cells with distilled
water. If the battery needs water
often, have the charging system
checked.
For longer, trouble-free operation,
keep the top of the battery clean
and dry. Also, make certain the
battery cables are always tightly
fastened to the battery terminals.
If you see any corrosion on the
battery or terminals, remove the
cables from the terminal(s) and
clean with a wire brush. You can
neutralize the acid with a solution
of baking soda and water. Reinstall
the cables when you are done
Maintenance and care
168

Aiming headlamps ....................193
Air bag supplemental restraint
system ..........................................78
and child safety seats ..............80
description ................................79
disposal ......................................83
indicator light ...........................82
passenger air bag .....................81
Air cleaner filter .......................170
Air conditioning
auxiliary heater and air
conditioner ................................29
manual heating and air
conditioning system ..23,24,26,28
Air suspension
description ..............................102
warning light .............................11
Ambulance packages ....................3
Anti-lock brake system (ABS)
description ................................99
Battery .......................................168
voltage gauge ............................16
Brake fluid
checking and adding ..............157
Brakes ..........................................98
anti-lock .....................................98
anti-lock brake system (ABS)
warning light .............................99
fluid, checking and adding ....157
Brake-shift interlock .................104
Break-in period .............................2
Bulbs, replacing ........................186
headlamps ...............................187
rear lamps ........................191,192
Changing a tire .........................138
Child safety seats ........................86
Childproof locks ..........................50
Chime
headlamps on ............................13
Cleaning your vehicle ...............194
engine compartment ..............195
fabric ........................................197instrument panel ....................197
plastic parts ............................196
safety belts ..............................197
tail lamps .................................196
washing ....................................194
waxing .....................................194
wheels ......................................195
Compass, electronic ....................42
calibration .................................44
set zone adjustment .................43
Control trac 4WD system .........108
Controls ..................................51,52
Daytime running light system ...20
Defrost
rear window ..............................22
Driving under special
conditions ..................................111
high water ...............................112
slippery roads ..................113,114
Electronic sound system ............52
Emission control system ..........183
Engine ........................................204
check engine temperature
warning, message center .......152
service points ..........................152
Engine block heater ...................96
Engine coolant
checking and adding .......158,159
disposal ....................................161
refill capacities ........................161
Engine oil ...........................153,155
changing oil and oil filter .......156
checking and adding .......153,155
Exhaust fumes ............................96
Fail safe cooling ........................162
Floor mats ...................................53
Foglamps ...................................190
Four-Wheel Drive vehicles
control trac ........................23,108
indicator light ...........................11
special driving
instructions ......................109,110
Index
208
