Maintenance and care
143
Checking and adding power
steering fluid
Switch off the engine. With the
steering system at normal
operating temperature, the fluid
level should come up to the MAX
mark.
If the fluid level drops below the
MIN mark, add the specified fluid.
Refer to the Capacities and
specificationschapter.
Severe winter climate
If you drive in extremely cold
climates (less than -36°C [-34°F]),
it may be necessary to increase the
coolant concentration above 50%.
Refer to the chart on the coolant
container to ensure the coolant
concentration in your vehicle is
such that the coolant will not
freeze at the temperature level in
which you drive during the winter
months. Never increase the engine
coolant concentration above 60%.
Leave a 50/50 mixture of engine
coolant and water in your vehicle
year-round in non-extreme
climates.
MAX
MIN
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 143

Maintenance and care
145
Checking the automatic
transaxle fluid
With the vehicle on a level surface
and the brake fully applied, start
the engine and move the gearshift
lever through all of the gears.
Securely latch the lever in P
(Park). Set parking brake and leave
the engine running.
Wipe off the dipstick cap and pull
the dipstick out. Wipe indicator
clean. Put dipstick back into filler
tube and make sure it is fully
seated. Pull the dipstick out and
read the fluid level.
Note that your vehicle should not
be driven until some fluid has been
added if the fluid level is below the
bottom dimple on the dipstick and
the outside temperature is above
10°C (50°F). Add only enough fluid
to bring the level above the bottom
hole.
If the vehicle has not been driven
and the fluid level is above the
bottom dimple on the dipstick,
don’t add fluid. Recheck the level
after driving your vehicle
approximately 30 km (20 miles)
when the engine has reached
normal operating temperature. The
fluid level should be within the
crosshatched area on the dipstick.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 145

Maintenance and care
161 Observe the following guidelines
when handling automotive fuel:
•Extinguish all smoking materials
and any open flames before
fueling your vehicle.
•Always turn off the vehicle
before fueling.
•Make sure the fuel cap is
correctly fitted after fueling.
Failure to do so may cause the on
board diagnostic system to
illuminate the CHECK ENGINE
light.
•Automotive fuels can be harmful
or fatal if swallowed. If fuel is
swallowed, call a physician
immediately, even if no
symptoms are immediately
apparent. The toxic effects of
fuel may not be visible for hours.
•Fuels can also be harmful if
absorbed through the skin. If fuel
is splashed on the skin, promptly
remove contaminated clothing
and wash skin thoroughly with
soap and water.
•If fuel is splashed in the eyes,
remove contact lenses (if worn),
flush with water for 15 minutes
and seek medical attention.
•Be particularly careful if you are
taking “Antabuse” or other forms
of disulfiram for the treatment of
alcoholism. Breathing gasoline
vapors or skin contact could
cause an adverse reaction.
Consult a physician immediately.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 161

Maintenance and care
169 Preparing your vehicle for
inspection/maintenance (I/M)
testing
In some localities it may be a legal
requirement to pass an I/M test of
the on-board diagnostic(OBD) II
system. If your vehicle’s powertrain
system or battery has just been
serviced, the OBD II system is reset
to a condition unready for I/M
testing. To ready the OBDII system
for I/M testing, the law specifies
that additional city and highway
driving is necessary to complete
the check of the OBDII system.
The driving mode required to reach
the ready condition consists of a
minimum of 30 minutes of city and
highway driving:
•At least 20 minutes driving in
stop and go city-type traffic with
at least four idle periods.
•At least 10 minutes of driving on
an expressway or highway.
Before completing the above
driving modes, the engine must be
warmed up and at operating
temperature. Once started, the
vehicle must not be turned off
during these modes.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 169

Maintenance and care
184Cleaning the interior fabric
Remove dust and loose dirt with a
whisk broom or a vacuum cleaner.
Remove fresh spots immediately.
Follow the directions that come
with the cleaner.
Cleaning leather seats
(if equipped)
For routine cleaning, wipe the
surface with a soft, damp cloth. For
more thorough cleaning, wipe the
surface with a leather and vinyl
cleaner or a mild soap.
Cleaning the instrument panel
HM:
I0 20OFF LOPNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
POWERAUDIOAM/FM
SCAN
SEEK 312645ANSSIDE1-2EJECTVOLUME
000123000010 20 3040506070
80
90
100
110
120
130MPH20 406055
80120 100
140
160
180
200EF 1
/
2UNLEADED FUEL ONLY12
03x 1000
4
5
6
7
8NORMALBRAKE
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
MIRRORS
Clean the instrument panel with a
damp cloth, then dry with a dry
cloth.
Any cleaner or polish that
increases the gloss of the upper
portion of the instrument panel
should be avoided. The dull finish
in this area is to help protect the
driver from undesirable windshield
reflection.
CDW VA1-19Maint en C 5/15/97 8:56 PM Page 184

193
Index
APage
Accessory position on
the ignition . . . . . . . . . . . . . . . . . .27
Additives, engine oil . . . . . . . . .135
Air bag supplemental
restraint system
and child safety seats . . . . . . . .59
description . . . . . . . . . . . . . . . . .58
disposal . . . . . . . . . . . . . . . . . . .63
indicator light . . . . . . . . . . .10, 62
operation . . . . . . . . . . . . . . . . . .60
wearing safety belts . . . . . . . . .58
Air conditioning
(see Climate control system)
Alarm, activating panic . . . . . . . .42
Antenna, radio
(see Audio sytem) . . . . . . . . . . . .21
Anti-lock brake system (ABS) . .87
Anti-theft system (see Passive
Anti-Theft System) . . . . . . . . . . .44
Antifreeze (see Engine coolant)
Audio system . . . . . . . . . . . . . . . .21
Automatic transaxle
driving with . . . . . . . . . . . . . . . .92
fluid, adding . . . . . . . . . . . . . . .144
fluid, checking . . . . . . . . . . . . .145
fluid, refill capacities . . . . . . . .187
fluid, specification . . . . . . . . . .188
B
Backing up . . . . . . . . . . . . . . .92, 98
Battery
charging system warning light . .7
jumping a disabled battery . . .124
proper disposal, recycling . . . .148
replacement, specifications . .186
servicing . . . . . . . . . . . . . . . . . .146BPage
Brake fluid
checking and adding . . . . . . . .138
specifications . . . . . . . . . . . . . .188
Brake-shift interlock . . . . . . . . . .91
Brakelamps
(see Bulb replacement)
Brakes
anti-lock brake system (ABS) .87
brake warning light . . . . . . . . . .11
fluid, checking and adding . . .138
fluid, refill capacities . . . . . . . .187
fluid, specification . . . . . . . . . .188
parking . . . . . . . . . . . . . . . . . . . .89
Built-in child seat
folding up the seat . . . . . . . . . .73
inspection after a collision . . . .73
interlock safety feature . . . . . . .69
operation . . . . . . . . . . . . . . . . . .68
retractors . . . . . . . . . . . . . . . . . .69
Break-in period . . . . . . . . . . . . . . .2
Bulbs, replacing
foglamps . . . . . . . . . . . . . . . . .172
headlamps . . . . . . . . . . . . . . . .171
high-mounted brake lamp . . . .174
license plate lamp . . . . . . . . . .173
rear lamps . . . . . . . . . . . . . . . .173
specifications . . . . . . . . . . . . . .175
C
Cabin air filter . . . . . . . . . . . . . .150
Capacities for refilling fluids . . .187
Carbon monoxyde in exhaust . .166
Catalytic converter . . . . . . . . . .168
Chains, tires . . . . . . . . . . . . . . . .158
Changing a tire . . . . . . . . . . . . .119
Charging system warning light . . .7
CDW_Index_en_C 5/15/97 8:59 PM Page 193

CPage
Child safety restraints
built-in child seat . . . . . . . . . . .68
child safety seats . . . . . . . . . . . .74
children and safety belts . . .64, 66
Child safety seats
and air bags . . . . . . . . . . . . . . . .59
attaching with tether straps . . .77
automatic locking mode . . . . . .52
Childproof safety locks . . . . . . . .38
Chimes . . . . . . . . . . . . . . . . . . . . .13
Circuit breakers . . . . . . . . . . . . .112
Cleaning your vehicle
engine compartment . . . . . . . .182
exterior lamps . . . . . . . . . . . . .183
fabric . . . . . . . . . . . . . . . . . . . .184
instrument panel . . . . . . . . . . .184
plastic exterior parts . . . . . . . .183
safety belts . . . . . . . . . . . . . . .185
wheels . . . . . . . . . . . . . . . . . . .181
wiper blades . . . . . . . . . . . . . .183
Climate control system
air conditioning . . . . . . . . . . . . .24
controlling airflow . . . . . . . . . . .23
defrosting . . . . . . . . . . . . . . . . . .26
temperature . . . . . . . . . . . . . . . .23
vents . . . . . . . . . . . . . . . . . . . . . .22
Clock . . . . . . . . . . . . . . . . . . . . . .21
Clutch
operation . . . . . . . . . . . . . . . . . .96
recommended shift speeds . . . .97
Cold engine starting . . . . . . . . . .85
Controls
instrument panel . . . . . . . . . . . .17
mirrors . . . . . . . . . . . . . . . . . . . .20
power seats . . . . . . . . . . . . . . . .48
steering column . . . . . . . . . . . . .27DPage
Daytime running lights . . . . . . . .18
Defects, reporting . . . . . . . . . . .192
Defrost
rear window . . . . . . . . . . . . . . . .19
windshield . . . . . . . . . . . . . . . . .26
Dipstick, engine oil . . . . . . . . . .133
Door mounted controls . . . . . . . .37
Driving under special conditions
heavy load . . . . . . . . . . . . . . . .102
towing a trailer . . . . . . . . . . . .103
E
Electrical system
fuses . . . . . . . . . . . . . . . . . . . . .112
Emergencies, roadside
fuel pump shut-off switch . . . .110
jump starting . . . . . . . . . . . . . .124
towing . . . . . . . . . . . . . . . . . . .127
Emergency brake (see Parking
brake)
Emission control system . . . . . .166
Engine
check engine warning light . . . . .9
fuel pump shut-off switch . . . .110
lubricant specifications . . . . . .188
preparing to start . . . . . . . . . . .82
refill capacities . . . . . . . . . . . .187
starting . . . . . . . . . . . . . . . . . . . .85
Engine block heater . . . . . . . . . .86
Engine coolant
checking and adding . . . . . . . .139
disposal . . . . . . . . . . . . . . . . . .141
low coolant warning light . . . . . .8
refilll capacities . . . . . . . . . . . .187
specifications . . . . . . . . . . . . . .188
Engine fan . . . . . . . . . . . . . . . . .129
Index
194
CDW_Index_en_C 5/15/97 8:59 PM Page 194

Index
195 EPage
Engine oil
changing oil and filter . . . . . . .136
checking and adding . . . . . . . .135
dipstick . . . . . . . . . . . . . . . . . .133
disposal . . . . . . . . . . . . . . . . . .137
engine oil pressure
warning light . . . . . . . . . . . . . . .11
filter specifications . . . . . . . . .186
refill capacities . . . . . . . . . . . .187
specifications . . . . . . . . . . . . . .188
Exhaust fumes . . . . . . . . . . .81, 166
F
Fan (see Engine fan)
Flasher, hazard . . . . . . . . . .29, 110
Flashing the lights . . . . . . . . . . . .30
Floor mats . . . . . . . . . . . . . . . . . .40
Fluid refill capacities . . . . . . . . .187
Foglamps . . . . . . . . . . . . . . .18, 172
Fuel
calculating fuel economy . . . .165
capacity . . . . . . . . . . . . . . . . . .187
choosing the right fuel . . . . . .162
consumption . . . . . . . . . . . . . .109
fuel gauge . . . . . . . . . . . . . . . . .16
low fuel warning light . . . . . . . . .9
octane rating . . . . . . . . . . . . . .163
quality . . . . . . . . . . . . . . . . . . .164
running out of fuel . . . . . . . . .166
safety information relating
to automotive fuels . . . . . . . . .160
Fuel pump shut-off switch . . . .110
Fuse panels
engine compartment . . . . . . . .113
instrument panel . . . . . . . . . . .115FPage
Fuses
charts . . . . . . . . . . . . . . . .114, 117
checking and replacing . . . . . .112
G
Gas mileage (see Fuel economy)
Gauges
engine coolant temperature . . .15
fuel . . . . . . . . . . . . . . . . . . . . . . .16
odometer . . . . . . . . . . . . . . . . . .15
speedometer . . . . . . . . . . . . . . .15
trip odometer . . . . . . . . . . . . . .15
GAWR
(Gross Axle Weight Rating) . . .100
Gearshift . . . . . . . . . . . . . . . .90, 96
GVWR
(Gross Vehicle Weight Rating) .100
H
Hazard flashers . . . . . . . . . .29, 110
Head restraints . . . . . . . . . . . . . .47
Headlamps
aiming . . . . . . . . . . . . . . . . . . .176
bulb specifications . . . . . . . . .175
daytime running light . . . . . . . .18
flashing . . . . . . . . . . . . . . . . . . .30
high beam . . . . . . . . . . . . . . . . .30
replacing bulbs . . . . . . . . . . . .171
turning on and off . . . . . . . . . . .17
warning chime . . . . . . . . . . . . . .13
High beams
indicator light . . . . . . . . . . . . . . .7
operation . . . . . . . . . . . . . . . . . .30
CDW_Index_en_C 5/15/97 8:59 PM Page 195
