1998 DODGE RAM 1500 Engine

GROUNDS
GROUND
NUMBERLOCATION FIG.
G100 Battery Ground - Left Front Engine N/S
G101 Battery Ground - Left Front Engine N/S
G102 Battery Ground - Left Front Chassis N/S
G103 Left Front Engine Compartment 22
G104 Left Front Engine Compartment N/S
G105 Right Front Chassis 21
G106 Left Rear Engine Compartment 22, 29
G107 (Gas) Right Rear Engine Compartment 4, 8, 10
G108 Diesel Auxiliary Battery Ground N/S
G109 Diesel Auxiliary Battery Ground N/S
G114 (Diesel) Right Side Engine Compartment 10
G120 Left Side Engine 10
G201 Right Side of Instrument Panel 38
G202 Center of Instrument Panel 35, 36
G203 Center of Instrument Panel 35, 36
G204 Right Side of Instrument Panel 35
G301 Left Front Body 40, 44, 46
G302 Left Front Body 40, 44, 46
SPLICES
SPLICE
NUMBERLOCATION FIG.
S101 Left Front Fender 21
S102 Left Front Fender 23
S103 Left Rear of Engine Compartment 22, 25
S104 Front Facia 35
S105 Front Facia N/S
S106 Left Rear of Engine Compartment 22
S107 Left Front Fender 23
S108 Headlamp and Dash, Left Side 22, 25
S109 Left Front Fender 23
S110 Left Front Fender 22
S111 Center Rear of Engine Compartment N/S
S112 Right Rear of Engine 3
S114 Left Rear of Engine Compartment 23
S115 Left Rear of Engine Compartment N/S
S117 Left Rear of Engine Compartment N/S
S120 Left Front Fender 23
S121 Left Front Fender 23
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 9
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

SPLICE
NUMBERLOCATION FIG.
S122 Left Front Fender 22
S123 Left Front Fender 22, 23
S124 Center Rear of Engine Compartment N/S
S125 Right Rear of Engine Compartment 4, 8
S130 Top Front of Transmission 3, 9
S132 Left Rear of Engine Compartment 3, 9
S133 Left Rear of Engine 4, 9
S134 Left Rear of Engine Compartment 3, 9
S135 Headlamp and Dash, Left Side N/S
S136 Left Front Fender 23
S137 Left Rear of Engine Compartment 21
S138 Left Rear of Engine N/S
S139 Right Front of Transmission N/S
S140 Right Rear Engine Compartment 22
S142 Left Side of Engine 3
S143 Left Side of Engine Compartment N/S
S144 Top Front of Transmission N/S
S145 Left Front Fender 23
S148 Top Front of Transmission 3
S149 Left Rear of Engine 6
S150 Top Center of Engine 3, 9
S153 Rear Engine Compartment N/S
S154 Left Top Engine N/S
S155 Left Rear Engine Compartment near T/O for Fuel Control Actuator 9
S157 Near T/O for Camshaft Position Sensor N/S
S158 Near T/O for C114 10
S159 Near T/O for Engine Control Module N/S
S160 Top Left Engine 10
S162 Left Side Engine N/S
S163 Right Side Engine N/S
S164 Near Engine Control Module C2 10
S165 Near Engine Control Module C2 10
S166 In Battery Positive Harness N/S
S168 Right Rear of Engine 3
S169 Right Rear of Engine 3, 7
S170 Left Engine 10
S171 Top Left Engine 10
S172 In T/O for Fuel Control Actuator N/S
S173 Near T/O for Engine Control Module N/S
S174 Near T/O for C114 N/S
S175 Near T/O for Engine Control Module N/S
8W - 91 - 10 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

SPLICE
NUMBERLOCATION FIG.
S176 Left Side Engine Near T/O for Fuel Control Actuator N/S
S187 Rear of Engine 7
S191 Near Integrated Power Module 23
S203 Right Side Engine Compartment 23
S204 Left Side of Instrument Panel 35
S205 Left Side of Instrument Panel 35
S206 At Steering Column N/S
S207 At Steering Column N/S
S209 Center of Instrument Panel 35
S210 Center of Instrument Panel 35, 38
S212 Left Side of Instrument Panel 31, 38
S214 Left Side of Instrument Panel 31, 38
S216 Center of Instrument Panel 35, 36
S217 Left Side of Instrument Panel N/S
S218 Left Side of Instrument Panel N/S
S219 Center of Instrument Panel N/S
S220 Center of Instrument Panel N/S
S221 Center of Instrument Panel 35, 39
S222 Center of Instrument Panel 35
S224 Right Side of HVAC N/S
S225 Center of Instrument Panel 35
S226 Right Side of HVAC N/S
S228 At Steering Column N/S
S230 Right Instrument Panel 35
S231 Left Instrument Panel 38
S232 Right Engine Compartment 23
S240 Steering Column 31, 38
S241 Center Instrument Panel 35, 36
S243 Right Engine Compartment 23
S245 Left Instrument Panel 35
S300 Left Kick Panel 40, 44, 46
S301 Center of Headliner N/S
S302 Center of Headliner N/S
S303 Middle of Roof 48
S304 Center of Headliner N/S
S305 Middle of Roof 48
S306 Left Side of Frame N/S
S307 Center of Headliner N/S
S308 Left Rear Chassis 50, 51
S309 Center Rear of Chassis 51
S311 Left Front of Body 44, 46
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 11
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 3 RIGHT SIDE ENGINE, 4.7L
8W - 91 - 14 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 4 RIGHT REAR ENGINE COMPARTMENT
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 15
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 5 RIGHT TOP ENGINE (3.7L/4.7L)
8W - 91 - 16 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 6 LEFT SIDE ENGINE (3.7L/4.7L)
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 17
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 7 LEFT SIDE ENGINE (5.7L)
8W - 91 - 18 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
