POWERTRAIN CONTROL MODULE C1 (NGC) - BLACK 38 WAY
CAV CIRCUIT FUNCTION
1 K98 18DB/YL (EXCEPT 3.7L) COIL CONTROL NO. 8
2- -
3 K97 18BR/YL (4.7L) COIL CONTROL NO. 7
3 K97 18BR (5.7L) COIL CONTROL NO. 7
4 K28 18BR/LB (EXCEPT 3.7L) INJECTOR CONTROL NO. 8
5 K26 18BR/YL (EXCEPT 3.7L) INJECTOR CONTROL NO. 7
6- -
7- -
8 B222 20DG/WT VEHICLE SPEED SIGNAL NO. 2
9 Z130 16BK/BR GROUND
10 - -
11 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
12 F1 16PK/WT FUSED IGNITION SWITCH OUTPUT (OFF-RUN-START)
13 B22 20DG/YL VEHICLE SPEED SIGNAL NO. 1
14 - -
15 - -
16 - -
17 - -
18 Z131 16BK/DG GROUND
19 - -
20 G6 18VT/GY OIL PRESSURE SIGNAL
21 C918 18BK/LB A/C PRESSURE SIGNAL
22 G31 18VT/LG AAT SIGNAL
23 - -
24 - -
25 D20 20WT/LG (5.7L) SCI RECEIVE (PCM)
25 D20 17WT/LG (EXCEPT 5.7L) SCI RECEIVE (PCM)
26 D16 18WT/OR (EXCEPT 3.7L M/T) SCI RECEIVE (TCM)
27 F856 18YL/PK 5 VOLT SUPPLY
28 - -
29 A919 20RD FUSED B(+)
30 T751 16YL FUSED IGNITION SWITCH OUTPUT (START)
31 K141 18DB/YL O2 1/2 SIGNAL
32 K902 18BR/DG O2 RETURN (UP)
33 K243 18BR O2 2/2 SIGNAL
34 - -
35 - -
36 D21 20WT/BR (5.7L) SCI TRANSMIT (PCM)
36 D21 18WT/BR (EXCEPT 5.7L) SCI TRANSMIT (PCM)
37 D15 18WT/DG (EXCEPT 3.7L) SCI TRANSMIT (TCM)
38 D25 20WT/VT PCI BUS
8W - 80 - 88 8W-80 CONNECTOR PIN-OUTSDR

RADIO C1 (EXCEPT INFINITY) - GRAY 22 WAY
CAV CIRCUIT FUNCTION
1 A114 18GY/RD FUSED B(+)
2 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
3 E14 20OR/TN PANEL LAMPS DRIVER
4- -
5- -
6- -
7 X154 18GY/YL RIGHT FRONT DOOR SPEAKER (+)
8 X156 18GY/LB RIGHT FRONT DOOR SPEAKER (-)
9 X155 18DG/LB LEFT FRONT DOOR SPEAKER (-)
10 X153 18DG/YL LEFT FRONT DOOR SPEAKER (+)
11 Z514 18BK/LG GROUND
12 A114 18GY/RD FUSED B(+)
13 - -
14 D25 20WT/VT PCI BUS
15 - -
16 - -
17 - -
18 X205 18GY/LG LEFT REAR SPEAKER (+)
19 X295 18GY/DG LEFT REAR SPEAKER (-)
20 X296 18DG/GY RIGHT REAR SPEAKER (-)
21 X206 18DG/LG RIGHT REAR SPEAKER (+)
22 Z515 18BK GROUND
RADIO C1 (INFINITY) - GRAY 22 WAY
CAV CIRCUIT FUNCTION
1 A114 18GY/RD FUSED B(+)
2 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
3 E14 20OR/TN PANEL LAMPS DRIVER
4- -
5- -
6- -
7 X56 20GY/BR RIGHT FRONT SPEAKER (+)
8 X54 20GY RIGHT FRONT SPEAKER (-)
9 X55 20DG/BR LEFT FRONT SPEAKER (-)
10 X53 20DG LEFT FRONT SPEAKER (+)
11 Z514 18BK/LG GROUND
12 A114 18GY/RD FUSED B(+)
13 X11 20DG RADIO 12 VOLT OUTPUT
14 D25 20WT/VT PCI BUS
15 - -
16 - -
17 - -
18 X51 20DG/DB LEFT REAR SPEAKER (+)
19 X57 20DG/OR LEFT REAR SPEAKER (-)
20 X58 20GY/OR RIGHT REAR SPEAKER (-)
21 X52 20GY/DB RIGHT REAR SPEAKER (+)
22 Z515 18BK GROUND
8W - 80 - 92 8W-80 CONNECTOR PIN-OUTSDR

SEAT BELT SWITCH-DRIVER-2WAY
CAV CIRCUIT FUNCTION
1 Z951 20BK GROUND
2 G10 20VT/LG SEAT BELT SWITCH SENSE
SEAT BELT TENSIONER REDUCER (STANDARD CAB)-2WAY
CAV CIRCUIT FUNCTION
1 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2 G10 20VT/LG SEAT BELT SWITCH SENSE
SEAT BELT TENSIONER-DRIVER-2WAY
CAV CIRCUIT FUNCTION
1 R55 20LG/DG DRIVER SEAT BELT TENSIONER LINE 1
2 R53 20LG/YL DRIVER SEAT BELT TENSIONER LINE 2
SEAT BELT TENSIONER-PASSENGER-2WAY
CAV CIRCUIT FUNCTION
1 R54 20LB/YL PASSENGER SEAT BELT TENSIONER LINE 2
2 R56 20LB/DG PASSENGER SEAT BELT TENSIONER LINE 1
SEAT HEATER INTERFACE MODULE - GREEN 14 WAY
CAV CIRCUIT FUNCTION
1 P7 20LG/DG DRIVER SEAT HEATER MUX SWITCH
2 P89 20LG/OR SEAT HEATER DRIVER
3 P188 18LG/VT PASSENGER SEAT TEMPERATURE SENSOR INPUT
4 A930 18RD FUSED B(+)
5 P187 18LG/BR DRIVER SEAT TEMPERATURE SENSOR INPUT
6 A930 18RD FUSED B(+)
7 P54 20OR/LG PASSENGER SEAT TEMPERATURE 5 VOLT SUPPLY
8 P53 20LG/OR DRIVER SEAT TEMPERATURE 5 VOLT SUPPLY
9 P8 20LG/WT PASSENGER SEAT HEATER MUX SWITCH
10 P82 20TN/DG PASSENGER SEAT LOW HEAT LED DRIVER
11 P84 20TN/VT PASSENGER SEAT HIGH HEAT LED DRIVER
12 P81 20TN/LB DRIVER SEAT LOW HEAT LED DRIVER
13 Z951 20BK GROUND
14 P83 20TN/WT DRIVER SEAT HIGH HEAT LED DRIVER
8W - 80 - 94 8W-80 CONNECTOR PIN-OUTSDR

SENTRY KEY IMMOBILIZER MODULE (SKIM) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 D25 20WT/VT PCI BUS
3- -
4 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
5 Z120 20BK/WT GROUND
6 A919 20RD FUSED B(+)
SIDE IMPACT SENSOR-LEFT-4WAY
CAV CIRCUIT FUNCTION
1 R13 20LG/TN LEFT SIDE IMPACT SENSOR 1 SIGNAL
2 R15 20LG/BR LEFT SIDE IMPACT SENSOR 1 GROUND
3- -
4- -
SIDE IMPACT SENSOR-RIGHT-4WAY
CAV CIRCUIT FUNCTION
1 R14 20TN/LG RIGHT SIDE IMPACT SENSOR 1 SIGNAL
2 R16 20BR/LG RIGHT SIDE IMPACT SENSOR 1 GROUND
3- -
4- -
SPEAKER-CENTER INSTRUMENT PANEL-2WAY
CAV CIRCUIT FUNCTION
1 X299 18GY/YL LEFT INSTRUMENT PANEL SPEAKER (-)
2 X208 18GY/DG RIGHT INSTRUMENT PANEL SPEAKER (+)
SPEAKER-LEFT FRONT DOOR - WHITE 3 WAY
CAV CIRCUIT FUNCTION
1 X155 18DG/LB LEFT FRONT DOOR SPEAKER (-)
2- -
3 X153 18DG/YL LEFT FRONT DOOR SPEAKER (+)
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 95

TRANSFER CASE CONTROL MODULE C1 (ELECTRIC 4x4) - 16 WAY
CAV CIRCUIT FUNCTION
A1 D25 20VT/DB PCI BUS
A2 - -
A3 - -
A4 G92 20VT/OR 4WD LOW INDICATOR
A5 G91 20VT/WT 4WD HIGH INDICATOR
A6 K977 20BR/WT MODE SELECT
A7 T885 20YL/GY MODE SENSOR GROUND
A8 Z905 18BK GROUND
A9 - -
A10 - -
A11 - -
A12 G95 20VT/BR NEUTRAL INDICATOR
A13 G2 20BR/WT IGNITION SWITCH SENSE
A14 D200 20WT/LG MODE SENSOR D
A15 - -
A16 Z905 20BK GROUND
TRANSFER CASE CONTROL MODULE C2 (ELECTRIC 4x4) - 16 WAY
CAV CIRCUIT FUNCTION
B1 D202 20WT/VT MODE SENSOR B
B2 D201 20WT/DG MODE SENSOR A
B3 - -
B4 - -
B5 - -
B6 T41 20YL/DB TRS T41 SENSE
B7 - -
B8 T313 20YL/LG 5 VOLT MODE SENSOR SUPPLY
B9 - -
B10 D203 20WT/BR MODE SENSOR C
B11 - -
B12 - -
B13 - -
B14 - -
B15 - -
B16 T322 20DG/GY 5 VOLT SELECTOR SWITCH SUPPLY
8W - 80 - 100 8W-80 CONNECTOR PIN-OUTSDR

TRANSFER CASE CONTROL MODULE C3 (ELECTRIC 4x4)-4WAY
CAV CIRCUIT FUNCTION
A Z905 16BK GROUND
B A34 16RD/WT FUSED B(+)
C T315 16YL/BR SHIFT MOTOR CONTROL A
D T316 16YL/GY SHIFT MOTOR CONTROL B
TRANSFER CASE MODE SENSOR-6WAY
CAV CIRCUIT FUNCTION
1 D200 20WT/LG MODE SENSOR D
2 T313 20YL/LG 5 VOLT MODE SENSOR SUPPLY
3 D202 20WT/VT MODE SENSOR B
4 T885 20YL/GY MODE SENSOR GROUND
5 D201 20WT/DG MODE SENSOR A
6 D203 20WT/BR MODE SENSOR C
TRANSFER CASE SELECTOR SWITCH - 12 WAY
CAV CIRCUIT FUNCTION
1 T322 20DG/GY 5 VOLT SELECTOR SWITCH SUPPLY
2 G2 20BR/WT IGNITION SWITCH SENSE
3- -
4 G95 20VT/BR NEUTRAL INDICATOR
5 K977 20BR/WT MODE SELECT
6 E11 20OR/DB PANEL LAMPS DRIVER
7 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
8 G92 20VT/OR 4WD LOW INDICATOR
9 G91 20VT/WT 4WD HIGH INDICATOR
10 - -
11 Z905 20BK GROUND
12 - -
TRANSFER CASE SHIFT MOTOR-2WAY
CAV CIRCUIT FUNCTION
1 T316 16YL/GY SHIFT MOTOR CONTROL B
2 T315 16YL/BR SHIFT MOTOR CONTROL A
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 101

TRANSMISSION RANGE SENSOR-6WAY
CAV CIRCUIT FUNCTION
1 L10 18WT/GY FUSED IGNITION SWITCH OUTPUT (RUN)
2 T117 20DG/YL TRANS RANGE SENSOR ELECTRONIC CLUSTER 5
VOLT SUPPLY
3- -
4 L1 18WT/LG BACKUP LAMP FEED
5 T917 20YL/TN TRANS RANGE SENSOR ELECTRONIC CLUSTER MUX
6 T41 20YL/DB PARK NEUTRAL POSITION SWITCH SENSE (T41)
6 T41 18YL/DB PARK NEUTRAL POSITION SWITCH SENSE (T41)
TRANSMISSION SOLENOID ASSEMBLY (48RE)-8WAY
CAV CIRCUIT FUNCTION
1 T16 18YL/OR TRANSMISSION CONTROL RELAY OUTPUT
2 F856 18YL/PK 5 VOLT SUPPLY
3 K900 20DB/DG SENSOR GROUND
3 K900 18DB/DG SENSOR GROUND
4 T38 18YL/BR GOVERNOR PRESSURE SENSOR SIGNAL
5 T118 18DG GOVERNOR PRESSURE SOLENOID CONTROL
6 T9 18DG/TN 3-4 SHIFT SOLENOID
7 T75 18YL/LB TORQUE CONVERTER CLUTCH SOLENOID CONTROL
8 T54 18DG/OR TRANSMISSION TEMPERATURE SENSOR SIGNAL
TRANSMISSION SOLENOID/TRS ASSEMBLY (NGC) - 23 WAY
CAV CIRCUIT FUNCTION
1 L10 18WT/GY FUSED IGNITION SWITCH OUTPUT (RUN)
2 T20 18DG/WT L/R SOLENOID CONTROL
3- -
4 T41 20YL/DB TRS T41 SENSE
5 T42 18DG/YL TRS T42 SENSE
6 L1 18WT/LG BACKUP LAMP FEED
7 T60 18YL/GY OVERDRIVE SOLENOID CONTROL
8 T3 18DG/DB TRS T3 SENSE
9 T1 18DG/LB TRS T1 SENSE
10 T16 18YL/OR TRANSMISSION CONTROL RELAY OUTPUT
11 T48 18BR/YL 4C PRESSURE SWITCH SENSE
12 T140 18YL/GY PRESSURE CONTROL SOLENIOD CONTROL
13 T4 18DG/LB TRS T2 SENSE
14 T50 18YL/TN LOW/REVERSE PRESSURE SWITCH SENSE
15 T147 18DG/YL 2C PRESSURE SWITCH SENSE
16 T9 18DG/TN OVERDRIVE PRESSURE SWITCH SENSE
17 T59 18YL/LB UNDERDRIVE SOLENOID CONTROL
18 T29 18YL/WT UNDERDRIVE PRESSURE SWITCH SENSE
19 T259 18YL/DG 4C SOLENOID CONTROL
20 T219 18YL/LG 2C SOLENOID CONTROL
21 T118 18DG MS SOLENOID CONTROL
22 K900 18DB/DG SENSOR GROUND
23 T54 18DG/OR TRANSMISSION TEMPERATURE SENSOR SIGNAL
8W - 80 - 102 8W-80 CONNECTOR PIN-OUTSDR

VACUUM PUMP (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1- -
2 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
3- -
4 Z936 18BK GROUND
VISTRONIC FAN DRIVE (DIESEL)-6WAY
CAV CIRCUIT FUNCTION
1 K160 18BR/OR PARK LOCKOUT SOLENOID CONTROL
2 K900 18DB/DG SENSOR GROUND
3 K161 18BR/LB FAN SPEED SENSOR
4- -
5 F856 18YL/PK 5 VOLT SUPPLY
6 F504 20GY/PK FUSED IGNITION SWITCH OUTPUT (RUN)
WASHER FLUID LEVEL SWITCH-2WAY
CAV CIRCUIT FUNCTION
1 Z932 20BK GROUND
2 W1 20BR/TN WASHER FLUID SWITCH SENSE
WASHER PUMP MOTOR-FRONT - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z945 20BK GROUND
2 W10 20BR WASHER PUMP MOTOR CONTROL
WATER IN FUEL SENSOR-2WAY
CAV CIRCUIT FUNCTION
A K914 18RD/WT (A/T) SENSOR GROUND
A K914 18BR/WT (M/T) SENSOR GROUND
B G123 18VT/LG WATER IN FUEL SENSOR SIGNAL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 103
