AUTOMATIC DAY/NIGHT MIRROR C1 (EXCEPT BASE)-7WAY
CAV CIRCUIT FUNCTION
1 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
2 Z13 20BK/WT GROUND
3 L1 20WT/LG BACKUP LAMP FEED
4- -
5- -
6- -
7- -
AUTOMATIC DAY/NIGHT MIRROR C2 (TELEMATICS) - 12 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 X722 20LB/DG MICROPHONE 2 IN (+)
5 X735 20BR HANDSFREE MICROPHONE SHIELD
6 X712 20DG/LB MICROPHONE 1 IN (+)
7 X793 20DG/YL HANDSFREE MICROPHONE HSD FEED
8- -
9 X730 20GY/YL VOICE RECOGNITION/PHONE SWITCH SIGNAL
10 - -
11 X835 20OR/GY SENSOR GROUND
12 X792 20LB/DG MICROPHONE IN (-)
BACKUP LAMP SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A L1 18WT/LG BACKUP LAMP FEED
B L10 18WT/GY FUSED IGNITION SWITCH OUTPUT (RUN)
BATTERY TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K25 18DB/VT BATT TEMP SIGNAL
2 K900 20DB/DG SENSOR GROUND
8W - 80 - 12 8W-80 CONNECTOR PIN-OUTSDR

BLEND DOOR ACTUATOR (SINGLE ZONE)-2WAY
CAV CIRCUIT FUNCTION
1 C34 20DB/LB COMMON DOOR DRIVER
2 C61 20DB/LG BLEND DOOR DRIVER
BLOWER MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C70 10DB/YL BLOWER MOTOR HIGH DRIVER
2 C7 10DB BLOWER MOTOR FEED
BLOWER MOTOR RESISTOR BLOCK - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 C72 16DB/OR BLOWER MOTOR M1 DRIVER
2 C70 12DB/YL BLOWER MOTOR HIGH DRIVER
3 C71 16DB/BR BLOWER MOTOR LOW DRIVER
4 C73 14DB/VT BLOWER MOTOR M2 DRIVER
BRAKE FLUID LEVEL SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE
2 Z420 20BK/OR GROUND
BRAKE LAMP SWITCH-6WAY
CAV CIRCUIT FUNCTION
1 A103 18GY/RD FUSED B(+)
2 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
3 V30 20VT/WT S/C BRAKE SWITCH OUTPUT
3 V30 20VT/WT (5.7L) FUSED IGNITION SWITCH (RUN-START)
4 V32 20VT/YL SPEED CONTROL SUPPLY
4 V32 20VT/YL (5.7L) BRAKE SWITCH NO. 2 SIGNAL
5 Z429 20BK/OR GROUND
6 B29 20DG/WT BRAKE SWITCH SIGNAL
6 B29 20DG/WT (5.7L) BRAKE SWITCH NO. 1 SIGNAL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 13

CENTER HIGH MOUNTED STOP LAMP/CARGO LAMP-4WAY
CAV CIRCUIT FUNCTION
1 L14 20WT/TN CARGO LAMP DRIVER
2 Z964 20BK GROUND
3 Z350 20BK/TN GROUND
4 L50 20WT/TN BRAKE LAMP SWITCH OUTPUT
CIGAR LIGHTER OUTLET - RED 3 WAY
CAV CIRCUIT FUNCTION
1 F984 18PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2- -
3 Z736 18BK/YL GROUND
CLEARANCE LAMP NO. 1 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
CLEARANCE LAMP NO. 2 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 45

COIL ON PLUG NO. 7 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K97 18BR COIL CONTROL NO. 7
COIL ON PLUG NO. 8 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K98 18DB/YL COIL CONTROL NO. 8
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
COIL ON PLUG NO. 8 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K98 18DB/YL COIL CONTROL NO. 8
COMPASS/MINI-TRIP COMPUTER (EXCEPT BASE) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
3 Z13 20BK/WT GROUND
4 A919 20RD FUSED B(+)
5 D25 20WT/VT PCI BUS
6- -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 51

CONDENSER FAN (NGC) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z823 16BK/DG GROUND
2 C123 16LB/WT CONDENSER FAN RELAY OUTPUT
CONTROLLER ANITLOCK BRAKE C1 - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 B4 20DG/GY REAR WHEEL SPEED SENSOR (+)
2 B222 20DG/WT (ETC) VEHICLE SPEED SIGNAL NO. 2
3 D25 20WT/VT PCI BUS
4 F500 20DG/PK FUSED IGNITION SWITCH OUTPUT (RUN)
5 B9 20DG/LG (ETC) LEFT FRONT WHEEL SPEED SENSOR (+)
6 Z107 12BK/DG GROUND
7 A111 14DG/RD FUSED B(+)
8 B3 20DG/YL REAR WHEEL SPEED SENSOR (-)
9 B29 20DG/WT BRAKE SWITCH SIGNAL
10 B8 20DG/TN (ETC) LEFT FRONT WHEEL SPEED SENSOR (-)
11 B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE
12 B22 20DG/YL VEHICLE SPEED SIGNAL NO. 1
13 Z127 12BK/DG (ABS) GROUND
14 A111 14DG/RD (ABS) FUSED B(+)
CONTROLLER ANTILOCK BRAKE C2 (ABS) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 B9 20DG/LG LEFT FRONT WHEEL SPEED SENSOR (+)
2 B8 20DG/TN LEFT FRONT WHEEL SPEED SENSOR (-)
3 B6 20DG/WT RIGHT FRONT WHEEL SPEED SENSOR (-)
4 B7 20DG/VT RIGHT FRONT WHEEL SPEED SENSOR (+)
CRANKSHAFT POSITION SENSOR (3.7L)-3WAY
CAV CIRCUIT FUNCTION
1 K24 20BR/LB CKP SIGNAL
2 K900 20DB/DG SENSOR GROUND
3 F855 20PK/YL 5 VOLT SUPPLY
8W - 80 - 52 8W-80 CONNECTOR PIN-OUTSDR

DOOR LOCK MOTOR/AJAR SWITCH-PASSENGER - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G74 20VT/WT PASSENGER DOOR AJAR SWITCH SENSE
2 Z74 20BK/WT GROUND
3 G778 18VT/LB DOOR UNLOCK DRIVER RIGHT DOORS
4 P392 18LG/DB DOOR LOCK DRIVER RIGHT DOORS
DOOR LOCK MOTOR/AJAR SWITCH-RIGHT REAR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G76 20VT/GY (VIRTUAL) RIGHT REAR DOOR AJAR SWITCH SENSE
2 Z72 20LG/BK (VIRTUAL) GROUND
3 G778 18TN/OR (VIRTUAL) DOOR UNLOCK DRIVER RIGHT DOORS
4 P392 18LG (VIRTUAL) DOOR LOCK DRIVER RIGHT DOORS
DOOR LOCK SWITCH-PASSENGER-6WAY
CAV CIRCUIT FUNCTION
1 G160 20VT/LG PASSENGER DOOR LOCK SWITCH MUX
2 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
3- -
4- -
5 Z461 20BK/DG GROUND
6- -
DRIVER BLEND DOOR ACTUATOR (DUAL ZONE)-2WAY
CAV CIRCUIT FUNCTION
1 C61 20DB/LG BLEND DOOR DRIVER
2 C34 20DB/LB COMMON DOOR DRIVER
8W - 80 - 56 8W-80 CONNECTOR PIN-OUTSDR

DRIVER DOOR MODULE C1 - BLUE 12 WAY
CAV CIRCUIT FUNCTION
1 Q612 14OR/DB RIGHT REAR WINDOW DRIVER (DOWN)
2 Q412 14OR/LB RIGHT REAR WINDOW DRIVER (UP)
3 Q16 14OR/TN MASTER WINDOW SWITCH RIGHT FRONT (UP)
4 Q411 14OR/WT LEFT REAR WINDOW DRIVER (UP)
5 Q11 14OR/LG LEFT FRONT WINDOW DRIVER (UP)
6 Q26 14OR/GY MASTER WINDOW SWITCH RIGHT FRONT (DOWN)
7 G161 20VT/DG DRIVER DOOR LOCK SWITCH MUX
8 Z421 14BK/BR GROUND
9 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 Q611 14OR/GY LEFT REAR WINDOW DRIVER (DOWN)
11 Z941 20BK GROUND
12 Q21 14OR/WT LEFT FRONT WINDOW DRIVER (DOWN)
DRIVER DOOR MODULE C2 - BLUE 8 WAY
CAV CIRCUIT FUNCTION
1 P71 18TN/DG LEFT MIRROR UP DRIVER
2 P195 18LG/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
3 A930 18RD FUSED B(+)
4 P74 18TN/OR RIGHT MIRROR LEFT DRIVER
5 Z461 20BK/DG GROUND
6 P75 18TN/LG LEFT MIRROR LEFT DRIVER
7 P72 18TN/GY RIGHT MIRROR UP DRIVER
8 Q15 14OR/LB POWER WINDOW SWITCH FEED
EGR SOLENOID (4.7L/5.7L)-6WAY
CAV CIRCUIT FUNCTION
1 K34 18DB/LG EGR SENSOR SIGNAL
2 F856 20YL/PK 5 VOLT SUPPLY
3 K900 20DB/DG SENSOR GROUND
4 Z335 18BK/WT GROUND
5- -
6 K35 18DB/VT EGR SOLENOID CONTROL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 57

ENGINE CONTROL MODULE C2 (DIESEL) - 50 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 K615 18VT/WT INLET AIR TEMPERATURE SENSE
3 K615 18BR/WT (M/T) INLET AIR TEMPERATURE SENSE
4 V35 18VT/OR (A/T) S/C VENT CONTROL
5 K176 18BR/OR INTAKE AIR HEATER RELAY NO 2 CONTROL
6 K174 18BR/YL INTAKE AIR HEATER RELAY NO 1 CONTROL
7 V32 18VT/YL (A/T) SPEED CONTROL SUPPLY
8- -
9 T41 18YL/DB (A/T) PARK/NEUTRAL POSITION SWITCH SENSE (T41)
10 K161 18BR/LB FAN SPEED SENSOR
11 B22 18DG/YL VEHICLE SPEED SENSOR SIGNAL NO. 1
12 G6 18VT/GY OIL PRESSURE SIGNAL
13 T6 18DG (A/T) TOW/HAUL OVERDRIVE OFF SWITCH SENSE
14 T118 18DG (A/T) GOVERNOR PRESSURE SOLENOID CONTROL
15 T9 18DG/TN (A/T) 3-4 SOLENIOD CONTROL
16 D21 18WT/BR SCI TRANSMIT (PCM)
16 D21 18PK (M/T) SCI TRANSMIT
17 - -
18 T38 18YL/BR (A/T) GOVERNOR PRESSURE SENSOR SIGNAL
19 D20 18WT/LG SCI RECEIVE (PCM)
20 A209 16RD FUSED B(+)
21 Z902 16BK GROUND
22 - -
23 F856 18YL/PK 5 VOLT SUPPLY
24 K900 18DB/DG SENSOR GROUND
25 T75 18YL/LB (A/T) TORQUE CONVERTER CLUTCH SOLENOID CONTROL
26 N4 18DB/WT FUEL LEVEL SENSOR SIGNAL
27 - -
28 D25 18WT/VT PCI BUS
29 T54 18DG/OR (A/T) TRANSMISSION TEMPERATURE SENSOR SIGNAL
30 A209 16RD FUSED B(+)
31 T515 18YL/DB (A/T) TRANSMISSION CONTROL RELAY CONTROL
32 F202 18PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
33 K854 18VT/BR (M/T) 5 VOLT SUPPLY
34 V36 18VT/YL (A/T) S/C VACUUM CONTROL
35 K616 18BR/YL INLET AIR PRESSURE SENSE
36 V32 18VT/YL (M/T) SPEED CONTROL SUPPLY
37 B29 18DG/WT BRAKE SWITCH SIGNAL
38 - -
39 - -
40 A209 16RD FUSED B(+)
41 C13 18LB/OR A/C CLUTCH RELAY CONTROL
42 - -
43 K160 18BR/OR PARK LOCKOUT SOLENOID CONTROL
44 T14 18DG/BR (A/T) OUTPUT SPEED SENSOR SIGNAL
45 T13 18DG/VT (A/T) SENSOR GROUND
46 V37 18VT S/C SWITCH NO. 1 SIGNAL
47 K25 18DB/VT BATT TEMP SIGNAL
48 K400 18BR/VT (M/T) APPS NO.2 RETURN
49 Z902 16BK GROUND
50 Z902 16BK GROUND
