LINKAGE - INDEPENDENT FRONT SUSPENSION
TABLE OF CONTENTS
page page
LINKAGE - INDEPENDENT FRONT
SUSPENSION
DIAGNOSIS AND TESTING - OUTER TIE ROD
END ................................32TIE ROD END
REMOVAL - OUTER TIE ROD END..........32
INSTALLATION - OUTER TIE ROD END......33
LINKAGE - INDEPENDENT
FRONT SUSPENSION
DIAGNOSIS AND TESTING - OUTER TIE ROD
END
NOTE: If the outer tie rod end is equipped with a
lubrication fitting, grease the joint then road test
the vehicle before performing test.
(1) Raise the front of the vehicle. Place safety floor
stands under both lower control arms as far outboard
as possible. Lower the vehicle to allow the stands to
support some or all of the vehicle weight.
(2) Remove the front tires.
(3) Mount a dial indicator solidly to the vehicle
steering knuckle and then zero the dial indicator.
(4) Position indicator plunger on the topside of the
outer tie rod end.
NOTE: The dial indicator plunger must be perpen-
dicular to the machined surface of the outer tie rod
end.
(5) Position a pry bar in order to pry downwards
on the outer tie rod end.
(6) If the travel exceeds 0.5 mm (0.020 in.), replace
the outer tie rod end (Refer to 19 - STEERING/
LINKAGE/TIE ROD END - REMOVAL).
(7) If the outer tie rod end is within specs reinstall
the front tires (Refer to 22 - TIRES/WHEELS/
WHEELS - STANDARD PROCEDURE).
TIE ROD END
REMOVAL - OUTER TIE ROD END
NOTE: Do not twist the boot anytime during
removal or installation.
(1) Loosen the jam nut.
(2) Remove the outer tie rod end nut from the ball
stud.
(3) Separate the tie rod ball stud from the knuckle
with Remover 8677 (Fig. 1).
(4) Unthread the outer tie rod end from the inner
tie rod.
Fig. 1 TIE ROD SEPARATION
1 - TIE ROD END
2 - SPECIAL TOOL 8677
19 - 32 LINKAGE - INDEPENDENT FRONT SUSPENSIONDR

Inspect output shaft bearing retainer, the
U-shaped retainer must be flat and free of distortion.
Replace the retainer if the threads are damaged or if
the retainer is bent or cracked.
COUNTERSHAFT BEARINGS AND RACES
The countershaft bearings and races are machine
lapped during manufacture to form matched sets.
The bearings and races should not be interchanged.
NOTE: The bearing races are a permanent press fit
in the housings and are NOT serviceable. If a bear-
ing race becomes damaged, the front or rear hous-
ing must be replaced. A new countershaft bearing
will be supplied with each new housing for service
use.
REVERSE IDLER COMPONENTS
Inspect the idler gear, bearing, shaft, thrust
washer, wave washer and thrust plate. Replace the
bearing if any of the needle bearing rollers are worn,
chipped, cracked, flat-spotted or brinnelled. Also
replace the bearing if the plastic bearing cage is
damaged or distorted.
Replace thrust washer, wave washer or thrust
plate if cracked, chipped or worn. Replace idler gear
if the teeth are chipped, cracked or worn thin.
Replace shaft if worn, scored or the bolt threads are
damaged beyond repair. Replace support segment if
cracked or chipped and replace the idler attaching
bolts if the threads are damaged.
Shift Socket
Inspect the shift socket for wear or damage.
Replace the socket if the roll pin or shift shaft bores
are damaged. Minor nicks in the shift lever ball seat
in the socket can be smoothed down with 400 grit
emery or wet/dry paper. Replace the socket if the ball
seat is worn or cracked. Do not reuse the original
shift socket roll pin. Install anewpin during assem-
bly. The socket roll pin is approximately 33 mm
(1-1/4 in.) long.
Output Shaft And Geartrain
Inspect all gears for worn, cracked, chipped or bro-
ken teeth. Also check condition of the bearing bore in
each gear. The bores should be smooth and free of
surface damage. Discoloration of the gear bores is a
normal occurrence and is not a reason for replace-
ment. Replace gears only when tooth damage has
occurred or if the bores are brinnelled or severely
scored.
Inspect the shaft splines and bearings surfaces.
Minor nicks on the bearing surfaces can be smoothed
with 320/420 grit emery and final polished with cro-
cus cloth. Replace the shaft if the splines are dam-aged or bearing surfaces are deeply scored, worn or
brinnelled.
ASSEMBLY
NOTE: Sealers are used at all case joints. Use
Mopar Gasket Maker or equivalent for all case joints
and Mopar silicone sealer or equivalent for the
input shaft bearing retainer.
SYNCHRONIZER
(1) Slide sleeve onto the hub, leaving enough room
to install the spring in the hub and strut in the hub
groove.
(2) Install first spring in the hub, then install a
strut over the spring. Verify spring is seated in the
spring bore in the strut.
(3) Slide sleeve onto the hub far enough to hold
the first strut and spring in place.
(4) Place detent ball in the top of the strut, then
press the ball into place with a small screwdriver.
Work the sleeve over the ball to hold it in place.
(5) Repeat procedure for the remaining springs,
struts and balls. Use tape or rubber bands to tempo-
rarily secure each strut and ball as they are
installed.
(6) Verify the synchro three springs, struts and
detent balls are all in place (Fig. 49).
Fig. 49 SYNCHRONIZER COMPONENTS
1 - SLEEVE
2 - HUB SHOULDER
3 - SPRING (3)
4 - STRUT (3)
5 - DETENT BALL (3)
6 - HUB
DRMANUAL TRANSMISSION - NV3500 21 - 17
MANUAL TRANSMISSION - NV3500 (Continued)

DIAGNOSIS CHARTS
CONDITION POSSIBLE CAUSES CORRECTION
HARSH ENGAGEMENT
(FROM NEUTRAL TO
DRIVE OR REVERSE)1. Fluid Level Low. 1. Add Fluid
2. Throttle Linkage Mis-adjusted. 2. Adjust linkage - setting may be too long.
3. Mount and Driveline Bolts Loose. 3. Check engine mount, transmission
mount, propeller shaft, rear spring to body
bolts, rear control arms, crossmember and
axle bolt torque. Tighten loose bolts and
replace missing bolts.
4. U-Joint Worn/Broken. 4. Remove propeller shaft and replace
U-Joint.
5. Axle Backlash Incorrect. 5. Check per Service Manual. Correct as
needed.
6. Hydraulic Pressure Incorrect. 6. Check pressure. Remove, overhaul or
adjust valve body as needed.
7. Band Mis-adjusted. 7. Adjust rear band.
8. Valve Body Check Balls Missing. 8. Inspect valve body for proper check ball
installation.
9. Axle Pinion Flange Loose. 9. Replace nut and check pinion threads
before installing new nut. Replace pinion
gear if threads are damaged.
10. Clutch, band or planetary
component damaged.10. Remove, disassemble and repair
transmission as necessary.
11. Converter Clutch Faulty. 11. Replace converter and flush cooler and
line before installing new converter.
21 - 146 AUTOMATIC TRANSMISSION - 48REDR
AUTOMATIC TRANSMISSION - 48RE (Continued)

INTAKE AIR HEATER - OPERATION.......14-80
INTAKE AIR HEATER - REMOVAL........14-80
INTAKE AIR HEATER RELAY -
DESCRIPTION.......................14-82
INTAKE AIR HEATER RELAY -
INSTALLATION.......................14-82
INTAKE AIR HEATER RELAY -
OPERATION.........................14-82
INTAKE AIR HEATER RELAY - REMOVAL . . 14-82
INTAKE AIR TEMPERATURE SENSOR -
DESCRIPTION.......................14-30
INTAKE AIR TEMPERATURE SENSOR -
INSTALLATION.......................14-31
INTAKE AIR TEMPERATURE SENSOR -
OPERATION.........................14-30
INTAKE AIR TEMPERATURE SENSOR -
REMOVAL..........................14-30
INTAKE AIR TEMPERATURE SENSOR/
MAP SENSOR - DESCRIPTION..........14-82
INTAKE AIR TEMPERATURE SENSOR/
MAP SENSOR - INSTALLATION..........14-82
INTAKE AIR TEMPERATURE SENSOR/
MAP SENSOR - OPERATION............14-82
INTAKE AIR TEMPERATURE SENSOR/
MAP SENSOR - REMOVAL.............14-82
INTAKE MANIFOLD - CLEANING....9-160,9-226,
9-297
INTAKE MANIFOLD - DESCRIPTION . 9-159,9-225,
9-72
INTAKE MANIFOLD - INSPECTION . . 9-160,9-226,
9-297
INTAKE MANIFOLD - INSTALLATION.....9-160,
9-226,9-298,9-73
INTAKE MANIFOLD - REMOVAL....9-159,9-226,
9-297,9-73
INTAKE MANIFOLD LEAKAGE -
DIAGNOSIS AND TESTING........9-159,9-225
INTAKE MANIFOLD LEAKS - DIAGNOSIS
AND TESTING........................9-72
INTAKE SYSTEM - INSTALLATION, AIR....9-199
INTAKE SYSTEM - REMOVAL, AIR.......9-199
INTAKE/EXHAUST VALVES & SEATS -
DESCRIPTION..............9-123,9-256,9-28
INTAKE/EXHAUST VALVES & SEATS -
INSTALLATION...................9-124,9-30
INTAKE/EXHAUST VALVES & SEATS -
REMOVAL......................9-124,9-29
INTEGRATED POWER MODULE -
DESCRIPTION.....................8W-97-3
INTEGRATED POWER MODULE -
INSTALLATION....................8W-97-4
INTEGRATED POWER MODULE -
OPERATION.......................8W-97-3
INTEGRATED POWER MODULE -
REMOVAL........................8W-97-3
INTERIOR - CAUTION.................23-62
INTERLOCK - ADJUSTMENTS, BRAKE
TRANSMISSION SHIFT.........21-196,21-365
INTERLOCK - DIAGNOSIS AND TESTING,
BRAKE TRANSMISSION SHIFT . . . 21-196,21-364
INTERLOCK SYSTEM - DESCRIPTION,
BRAKE TRANSMISSION SHIFT . . . 21-196,21-364
INTERLOCK SYSTEM - OPERATION,
BRAKE TRANSMISSION SHIFT . . . 21-196,21-364
INTERNATIONAL SYMBOLS -
DESCRIPTION......................Intro.-5
INVERTED FLARING - STANDARD
PROCEDURE, DOUBLE.................5-10
IOD FUSE - DESCRIPTION...........8W-97-6
IOD FUSE - INSTALLATION...........8W-97-7
IOD FUSE - OPERATION.............8W-97-6
IOD FUSE - REMOVAL..............8W-97-7
ISO FLARING - STANDARD PROCEDURE
. . . 5-11
ISOLATORS - INSTALLATION, BODY
......23-37
ISOLATORS - REMOVAL, BODY
.........23-36
JOINT - DIAGNOSIS AND TESTING,
LOWER BALL
....................2-19,2-34
JOINT - DIAGNOSIS AND TESTING,
UPPER BALL
.....................2-27,2-36
JOINT - INSTALLATION, LOWER BALL
. 2-20,2-35
JOINT - INSTALLATION, UPPER BALL
.....2-36
JOINT - REMOVAL, LOWER BALL
.....2-19,2-35
JOINT - REMOVAL, UPPER BALL
.........2-36
JOINT-INNER - INSTALLATION, CV
........3-25
JOINT-INNER - REMOVAL, CV
............3-25
JOINT-OUTER - INSTALLATION, CV
........3-23
JOINT-OUTER - REMOVAL, CV
...........3-22JOINTS - ASSEMBLY, DOUBLE CARDAN
UNIVERSAL..........................3-17
JOINTS - DISASSEMBLY, DOUBLE
CARDAN UNIVERSAL..................3-16
JOUNCE BUMPER - INSTALLATION.......2-43
JOUNCE BUMPER - REMOVAL...........2-43
JOURNAL CLEARANCE - STANDARD
PROCEDURE, CONNECTING ROD
BEARING AND CRANKSHAFT...........9-272
JUMP STARTING - STANDARD
PROCEDURE.........................0-19
JUNCTION BLOCK - INSTALLATION,
BRAKE..............................5-24
JUNCTION BLOCK - REMOVAL, BRAKE....5-24
KEY CYLINDER - INSTALLATION.........19-12
KEY CYLINDER - REMOVAL............19-12
KEY IMMOBILIZER MODULE -
DESCRIPTION, SENTRY................8E-13
KEY IMMOBILIZER MODULE -
INSTALLATION, SENTRY...............8E-15
KEY IMMOBILIZER MODULE -
OPERATION, SENTRY.................8E-13
KEY IMMOBILIZER MODULE - REMOVAL,
SENTRY............................8E-15
KEY IMMOBILIZER MODULE (SKIM) -
DESCRIPTION, SENTRY................8Q-1
KEY IMMOBILIZER MODULE (SKIM) -
OPERATION, SENTRY..................8Q-2
KEY IMMOBILIZER SYSTEM INDICATOR
LAMP - DESCRIPTION, SENTRY..........8Q-5
KEY IMMOBILIZER SYSTEM INDICATOR
LAMP - OPERATION, SENTRY...........8Q-5
KEY IMMOBILIZER SYSTEM
INITIALIZATION, STANDARD
PROCEDURE - SENTRY................8Q-3
KEY IMMOBILIZER SYSTEM (SKIS) -
DESCRIPTION, SENTRY................8Q-1
KEY IMMOBILIZER SYSTEM (SKIS) -
OPERATION, SENTRY..................8Q-2
KEY IMMOBILIZER SYSTEM
TRANSPONDER PROGRAMMING,
STANDARD PROCEDURE - SENTRY.......8Q-4
KEY LOCK CYLINDER - DIAGNOSIS AND
TESTING, IGNITION SWITCH............19-11
KEY-IN IGNITION SWITCH -
DESCRIPTION.......................19-11
KEYLESS ENTRY MODULE -
DESCRIPTION, REMOTE................8N-7
KEYLESS ENTRY MODULE - DIAGNOSIS
AND TESTING, REMOTE................8N-7
KEYLESS ENTRY MODULE -
INSTALLATION, REMOTE...............8N-8
KEYLESS ENTRY MODULE - OPERATION,
REMOTE............................8N-7
KEYLESS ENTRY MODULE - REMOVAL,
REMOTE............................8N-7
KEYLESS ENTRY TRANSMITTER -
DIAGNOSIS AND TESTING, REMOTE......8N-8
KEYLESS ENTRY TRANSMITTER -
SPECIFICATIONS, REMOTE..............8N-9
KNOB RELEASE - INSTALLATION, TILT
LEVER.............................19-16
KNOB RELEASE - REMOVAL, TILT LEVER . . 19-16
KNOCK SENSOR - DESCRIPTION.........8I-14
KNOCK SENSOR - INSTALLATION........8I-15
KNOCK SENSOR - OPERATION..........8I-14
KNOCK SENSOR - REMOVAL............8I-15
KNUCKLE - DESCRIPTION...............2-18
KNUCKLE - INSTALLATION..........2-19,2-37
KNUCKLE - OPERATION................2-18
KNUCKLE - REMOVAL..............2-18,2-37
LABEL - DESCRIPTION, VEHICLE
CERTIFICATION....................Intro.-11
LAMP - DESCRIPTION, DOME...........8L-26
LAMP - DESCRIPTION, READING........8L-28
LAMP - DESCRIPTION, SENTRY KEY
IMMOBILIZER SYSTEM INDICATOR.......8Q-5
LAMP - INSTALLATION, CAB CLEARANCE . 8L-12
LAMP - INSTALLATION, CENTER HIGH
MOUNTED STOP.....................8L-11
LAMP - INSTALLATION, DOME..........8L-26
LAMP - INSTALLATION, FENDER
MARKER
...........................8L-18
LAMP - INSTALLATION, FOG
............8L-12
LAMP - INSTALLATION, LICENSE PLATE
. . 8L-17
LAMP - INSTALLATION, PARK/TURN
SIGNAL
............................8L-21
LAMP - INSTALLATION, READING
........8L-29LAMP - INSTALLATION, TAILGATE
MARKER...........................8L-18
LAMP - INSTALLATION, UNDERHOOD....8L-25
LAMP - OPERATION, DOME............8L-26
LAMP - OPERATION, READING..........8L-28
LAMP - OPERATION, SENTRY KEY
IMMOBILIZER SYSTEM INDICATOR.......8Q-5
LAMP - REMOVAL, CAB CLEARANCE.....8L-11
LAMP - REMOVAL, CENTER HIGH
MOUNTED STOP.....................8L-11
LAMP - REMOVAL, DOME..............8L-26
LAMP - REMOVAL, FENDER MARKER....8L-17
LAMP - REMOVAL, FOG...............8L-12
LAMP - REMOVAL, LICENSE PLATE......8L-17
LAMP - REMOVAL, PARK/TURN SIGNAL . . 8L-21
LAMP - REMOVAL, READING...........8L-28
LAMP - REMOVAL, TAILGATE MARKER . . . 8L-18
LAMP - REMOVAL, UNDERHOOD........8L-25
LAMP INDICATOR - DESCRIPTION,
CARGO.............................8J-20
LAMP INDICATOR - OPERATION, CARGO . . 8J-20
LAMP (MIL) - DESCRIPTION,
MALFUNCTION INDICATOR.............8J-31
LAMP (MIL) - OPERATION,
MALFUNCTION INDICATOR.............8J-31
LAMP OUT INDICATOR - DESCRIPTION . . . 8J-29
LAMP OUT INDICATOR - OPERATION.....8J-29
LAMP RELAY - DESCRIPTION, FOG......8L-12
LAMP RELAY - DESCRIPTION, PARK.....8L-20
LAMP RELAY - DIAGNOSIS AND
TESTING, PARK......................8L-20
LAMP RELAY - INSTALLATION, FOG......8L-13
LAMP RELAY - INSTALLATION, PARK.....8L-21
LAMP RELAY - OPERATION, FOG........8L-13
LAMP RELAY - OPERATION, PARK.......8L-20
LAMP RELAY - REMOVAL, FOG.........8L-13
LAMP RELAY - REMOVAL, PARK........8L-21
LAMP REPLACEMENT - STANDARD
PROCEDURE, MODULE................8M-3
LAMP REPLACEMENT - STANDARD
PROCEDURE, READING/COURTESY.......8M-3
LAMP SWITCH - DESCRIPTION, BACKUP . . . 8L-8
LAMP SWITCH - DESCRIPTION, BRAKE....8L-9
LAMP SWITCH - DIAGNOSIS AND
TESTING, BACKUP.....................8L-8
LAMP SWITCH - DIAGNOSIS AND
TESTING, BRAKE.....................8L-10
LAMP SWITCH - INSTALLATION, BRAKE . . 8L-11
LAMP SWITCH - OPERATION, BACKUP....8L-8
LAMP SWITCH - OPERATION, BRAKE......8L-9
LAMP SWITCH - REMOVAL, BRAKE......8L-10
LAMP UNIT - INSTALLATION, CENTER
HIGH MOUNTED STOP................8L-11
LAMP UNIT - INSTALLATION, LICENSE
PLATE .............................8L-17
LAMP UNIT - INSTALLATION,
UNDERHOOD........................8L-25
LAMP UNIT - REMOVAL, CENTER HIGH
MOUNTED STOP.....................8L-11
LAMP UNIT - REMOVAL, LICENSE PLATE . . 8L-17
LAMP UNIT - REMOVAL, UNDERHOOD . . . 8L-25
LAMPS, SPECIFICATIONS - EXTERIOR.....8L-7
LAMPS/LIGHTING - EXTERIOR -
DESCRIPTION........................8L-2
LAMPS/LIGHTING - EXTERIOR -
DIAGNOSIS AND TESTING..............8L-3
LAMPS/LIGHTING - EXTERIOR -
OPERATION..........................8L-2
LAMP/SWITCH - INSTALLATION, GLOVE
BOX ...............................8L-28
LAMP/SWITCH - REMOVAL, GLOVE BOX . . 8L-27
LASH ADJUSTER - DIAGNOSIS AND
TESTING, HYDRAULIC.............9-125,9-32
LASH ADJUSTMENT AND VERIFICATION
- STANDARD PROCEDURE, VALVE.......9-259
LATCH - INSTALLATION.....23-16,23-23,23-32,
23-47
LATCH - INSTALLATION, GLOVE BOX.....23-52
LATCH - INSTALLATION, UNDER SEAT
STORAGE BIN.......................23-80
LATCH - REMOVAL
....23-16,23-23,23-32,23-47
LATCH - REMOVAL, GLOVE BOX
.........23-52
LATCH - REMOVAL, UNDER SEAT
STORAGE BIN
.......................23-80
LATCH RELEASE CABLE/HANDLE
ASSEMBLY - INSTALLATION
............23-47
LATCH RELEASE CABLE/HANDLE
ASSEMBLY - REMOVAL
................23-47
18 INDEXDR
Description Group-Page Description Group-Page Description Group-Page

LATCH STRIKER - INSTALLATION . . 23-17,23-23,
23-33
LATCH STRIKER - REMOVAL . 23-16,23-23,23-33
LATCH STRIKER / SECONDARY CATCH -
INSTALLATION.......................23-48
LATCH STRIKER / SECONDARY CATCH -
REMOVAL..........................23-47
LD & HD EXCEPT 4X4 HD -
INSTALLATION, ALL..................19-14
LD & HD EXCEPT 4X4 HD - REMOVAL,
ALL ...............................19-14
LD FRONT - INSTALLATION, PROPELLER
SHAFT...............................3-7
LD FRONT - REMOVAL, PROPELLER
SHAFT...............................3-6
LEAD - DIAGNOSIS AND TESTING,
TIRE/VEHICLE........................22-8
LEAK - DIAGNOSIS AND TESTING,
CONVERTER HOUSING FLUID....21-144,21-318
LEAK - DIAGNOSIS AND TESTING,
ENGINE OIL................9-152,9-220,9-64
LEAK DETECTION ASSY - DESCRIPTION,
NATURAL VAC.......................25-23
LEAK DETECTION ASSY - INSTALLATION,
NATURAL VAC.......................25-25
LEAK DETECTION ASSY - OPERATION,
NATURAL VAC.......................25-23
LEAK DETECTION ASSY - REMOVAL,
NATURAL VAC.......................25-24
LEAK DETECTION PUMP - DESCRIPTION . . 25-13
LEAK DETECTION PUMP - INSTALLATION . 25-16
LEAK DETECTION PUMP - OPERATION....25-14
LEAK DETECTION PUMP - REMOVAL.....25-16
LEAKAGE - DIAGNOSIS AND TESTING,
CYLINDER COMBUSTION PRESSURE . 9-186,9-8,
9-93
LEAKAGE - DIAGNOSIS AND TESTING,
INTAKE MANIFOLD..............9-159,9-225
LEAKAGE - DIAGNOSIS AND TESTING,
PUMP.............................19-40
LEAKS - DIAGNOSIS AND TESTING,
CHARGE AIR COOLER SYSTEM.........11-16
LEAKS - DIAGNOSIS AND TESTING,
COOLING SYSTEM - TESTING.............7-5
LEAKS - DIAGNOSIS AND TESTING,
HIGH-PRESSURE FUEL LINE............14-58
LEAKS - DIAGNOSIS AND TESTING,
INTAKE MANIFOLD....................9-72
LEAKS - DIAGNOSIS AND TESTING,
REAR SEAL AREA...........9-137,9-209,9-65
LEAKS - DIAGNOSIS AND TESTING,
REFRIGERANT SYSTEM...............24-44
LEAKS - DIAGNOSIS AND TESTING,
WATER .............................23-1
LEAKS - STANDARD PROCEDURE,
REPAIRING.........................22-10
LEARN - STANDARD PROCEDURE,
DRIVE.............................8E-23
LEARN - STANDARD PROCEDURE, TCM
QUICK.............................8E-23
LEFT CYLINDER HEAD - INSTALLATION . . . 9-112
LEFT CYLINDER HEAD - REMOVAL.......9-108
LEFT REAR CABLE - INSTALLATION.......5-39
LEFT REAR CABLE - REMOVAL...........5-38
LENS REPLACEMENT - STANDARD
PROCEDURE, MODULE................8M-3
LEVEL - DIAGNOSIS AND TESTING,
EFFECTS OF INCORRECT FLUID . . 21-201,21-366
LEVEL - STANDARD PROCEDURE,
BRAKE FLUID........................5-23
LEVEL - STANDARD PROCEDURE,
ENGINE OIL.........................9-292
LEVEL - STANDARD PROCEDURE,
REFRIGERANT OIL...................24-69
LEVEL CHECK - STANDARD
PROCEDURE, COOLANT................7-17
LEVEL CHECK - STANDARD
PROCEDURE, FLUID...........21-202,21-366
LEVEL CHECKING - STANDARD
PROCEDURE, POWER STEERING FLUID
. . . 19-43
LEVEL SENDING UNIT / SENSOR -
DESCRIPTION, FUEL
..............14-57,14-6
LEVEL SENDING UNIT / SENSOR -
INSTALLATION, FUEL
..................14-7
LEVEL SENDING UNIT / SENSOR -
OPERATION, FUEL
................14-57,14-6
LEVEL SENDING UNIT / SENSOR -
REMOVAL, FUEL
......................14-7LEVEL SWITCH - DESCRIPTION,
WASHER FLUID......................8R-9
LEVEL SWITCH - INSTALLATION,
WASHER FLUID.....................8R-11
LEVEL SWITCH - OPERATION, WASHER
FLUID..............................8R-9
LEVEL SWITCH - REMOVAL, WASHER
FLUID.............................8R-10
LEVER - ADJUSTMENT, SHIFT . . . 21-446,21-481
LEVER - INSTALLATION, GEAR SHIFT.....19-12
LEVER - INSTALLATION, SHIFT . . . 21-445,21-480
LEVER - REMOVAL, GEAR SHIFT........19-12
LEVER - REMOVAL, SHIFT......21-444,21-479
LEVER KNOB RELEASE - INSTALLATION,
TILT ...............................19-16
LEVER KNOB RELEASE - REMOVAL, TILT . . 19-16
LICENSE PLATE LAMP - INSTALLATION . . . 8L-17
LICENSE PLATE LAMP - REMOVAL.......8L-17
LICENSE PLATE LAMP UNIT -
INSTALLATION.......................8L-17
LICENSE PLATE LAMP UNIT - REMOVAL . . 8L-17
LID - INSTALLATION, CENTER SEAT
BACK..............................23-79
LID - INSTALLATION, UNDER SEAT
STORAGE BIN.......................23-80
LID - REMOVAL, CENTER SEAT BACK....23-79
LID - REMOVAL, UNDER SEAT STORAGE
BIN ...............................23-80
LIFTERS/TAPPETS - CLEANING, SOLID....9-279
LIFTERS/TAPPETS - INSPECTION, SOLID . . . 9-279
LIFTERS/TAPPETS - INSTALLATION,
SOLID.............................9-280
LIFTERS/TAPPETS - REMOVAL, SOLID....9-279
LIGHT DUTY FRONT FRAME RAIL TIP
REPLACEMENT - STANDARD
PROCEDURE.........................13-4
LIGHTER OUTLET - DESCRIPTION,
CIGAR...........................8W-97-2
LIGHTER OUTLET - DIAGNOSIS AND
TESTING, CIGAR...................8W-97-2
LIGHTER OUTLET - OPERATION, CIGAR . 8W-97-2
LIMITING VALVE - DESCRIPTION, FUEL
PRESSURE.........................14-61
LIMITING VALVE - INSTALLATION, FUEL
PRESSURE.........................14-61
LIMITING VALVE - OPERATION, FUEL
PRESSURE.........................14-61
LIMITING VALVE - REMOVAL, FUEL
PRESSURE.........................14-61
LINE - DESCRIPTION, A/C DISCHARGE....24-56
LINE - DESCRIPTION, LIQUID...........24-65
LINE - DESCRIPTION, REFRIGERANT.....24-42
LINE - DESCRIPTION, SUCTION.........24-70
LINE - INSTALLATION, LIQUID..........24-66
LINE - REMOVAL, LIQUID..............24-65
LINE AND TERMINAL REPAIR -
STANDARD PROCEDURE, GRID..........8G-4
LINE COUPLER - DESCRIPTION,
REFRIGERANT.......................24-67
LINE COUPLER - INSTALLATION,
REFRIGERANT.......................24-68
LINE COUPLER - OPERATION,
REFRIGERANT.......................24-67
LINE COUPLER - REMOVAL,
REFRIGERANT.......................24-68
LINE LEAKS - DIAGNOSIS AND TESTING,
HIGH-PRESSURE FUEL................14-58
LINE PRESSURE (LP) SENSOR -
DESCRIPTION......................21-382
LINE PRESSURE (LP) SENSOR -
INSTALLATION......................21-383
LINE PRESSURE (LP) SENSOR -
OPERATION........................21-383
LINE PRESSURE (LP) SENSOR -
REMOVAL.........................21-383
LINES - DESCRIPTION, FUEL.......14-57,14-7
LINES - DESCRIPTION, VACUUM........25-22
LINES - INSTALLATION, FUEL...........14-60
LINES - OPERATION, FUEL.............14-57
LINES - OPERATION, REFRIGERANT......24-42
LINES - REMOVAL, FUEL..............14-58
LINK - INSTALLATION, DRAG...........19-36
LINK - REMOVAL, DRAG...............19-36
LINK CONNECTOR - DESCRIPTION, DATA
. . 8E-3
LINK CONNECTOR - OPERATION, DATA
....8E-3
LINKAGE - INSTALLATION
...............6-12
LINKAGE - LINK/COIL - DESCRIPTION
....19-34
LINKAGE - REMOVAL
..................6-12LINKAGE, SPECIAL TOOLS - STEERING . . . 19-35
LINK/COIL - DESCRIPTION, GEAR........19-20
LINK/COIL - DESCRIPTION, LINKAGE.....19-34
LINK/COIL - INSTALLATION, GEAR.......19-21
LINK/COIL - OPERATION, GEAR.........19-20
LINK/COIL - REMOVAL, GEAR...........19-20
LINK/COIL SUSPENSION - STANDARD
PROCEDURE, ALIGNMENT...............2-5
LIQUID LINE - DESCRIPTION...........24-65
LIQUID LINE - INSTALLATION...........24-66
LIQUID LINE - REMOVAL..............24-65
LOAD FLOOR - INSTALLATION..........23-72
LOAD FLOOR - REMOVAL..............23-71
LOAD FLOOR SUPPORT CYLINDER -
INSTALLATION.......................23-72
LOAD FLOOR SUPPORT CYLINDER -
REMOVAL..........................23-72
LOCATION - DESCRIPTION, CONNECTOR/
GROUND/SPLICE...................8W-91-1
LOCATIONS - SPECIFICATIONS, SEALER . 23-102
LOCATIONS - SPECIFICATIONS,
STRUCTURAL ADHESIVE..............23-112
LOCATIONS - SPECIFICATIONS, WELD . . . 23-120
LOCK - STANDARD PROCEDURE,
HYDROSTATIC..................9-190,9-240
LOCK CYLINDER - DIAGNOSIS AND
TESTING, IGNITION SWITCH AND KEY....19-11
LOCK CYLINDER - INSTALLATION.......23-24
LOCK CYLINDER - REMOVAL.............23-24
LOCK MOTOR - DESCRIPTION, DOOR.....8N-4
LOCK MOTOR - DIAGNOSIS AND
TESTING, DOOR......................8N-4
LOCK MOTOR - OPERATION, DOOR.......8N-4
LOCK SWITCH - DIAGNOSIS AND
TESTING, POWER.....................8N-4
LOCK SWITCH - INSTALLATION, POWER . . . 8N-4
LOCK SWITCH - REMOVAL, POWER......8N-4
LOCKING RETRACTOR - DESCRIPTION,
AUTOMATIC........................8O-14
LOCKING RETRACTOR - OPERATION,
AUTOMATIC........................8O-14
LOCKS - DESCRIPTION, POWER.........8N-1
LOCKS - DIAGNOSIS AND TESTING,
POWER.............................8N-3
LOCKS - OPERATION, POWER...........8N-2
LOOP ADJUSTER - INSTALLATION, SEAT
BELT TURNING......................8O-55
LOOP ADJUSTER - REMOVAL, SEAT
BELT TURNING......................8O-55
LOOP BRACKETS - INSTALLATION, SEAT
BACK REAR - FOOTMANS..............23-85
LOOP BRACKETS - REMOVAL, SEAT
BACK REAR - FOOTMANS..............23-85
LOW FUEL INDICATOR - DESCRIPTION . . . 8J-30
LOW FUEL INDICATOR - OPERATION.....8J-30
LOWER BALL JOINT - DIAGNOSIS AND
TESTING........................2-19,2-34
LOWER BALL JOINT - INSTALLATION . 2-20,2-35
LOWER BALL JOINT - REMOVAL.....2-19,2-35
LOWER CONTROL ARM BUSHINGS -
2WD (LD) - INSTALLATION..............2-15
LOWER CONTROL ARM BUSHINGS -
2WD (LD) - REMOVAL.................2-13
LOWER CONTROL ARM BUSHINGS -
4WD (LD) - INSTALLATION..............2-14
LOWER CONTROL ARM BUSHINGS -
4WD (LD) - REMOVAL.................2-13
LOWER SURROUND - INSTALLATION,
INSTRUMENT PANEL..................23-59
LOWER SURROUND - REMOVAL,
INSTRUMENT PANEL..................23-59
LOWER SUSPENSION ARM -
INSTALLATION........................2-38
LOWER SUSPENSION ARM - REMOVAL....2-38
LOWER TRIM - INSTALLATION,
B-PILLAR...........................23-64
LOWER TRIM - INSTALLATION,
C-PILLAR...........................23-67
LOWER TRIM - REMOVAL, B-PILLAR.....23-63
LOWER TRIM - REMOVAL, C-PILLAR.....23-66
LOW/REVERSE CLUTCH - ASSEMBLY....21-385
LOW/REVERSE CLUTCH - CLEANING
....21-385
LOW/REVERSE CLUTCH - DISASSEMBLY
. 21-384
LOW/REVERSE CLUTCH - INSPECTION
. . 21-385
LUBRICANTS - DESCRIPTION, ENGINE
OIL
.................................0-1
LUBRICATION - DESCRIPTION
.....9-150,9-220,
9-289,9-61
DRINDEX 19
Description Group-Page Description Group-Page Description Group-Page
