CLEARANCE LAMP NO. 3 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
CLEARANCE LAMP NO. 4 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
CLEARANCE LAMP NO. 5 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
CLOCKSPRING C1-6WAY
CAV CIRCUIT FUNCTION
1 Z909 20BK (DSAB ETC) GROUND
2 X20 20GY/WT (DSAB ETC) RADIO CONTROL MUX
3 V38 20VT/OR S/C SWITCH NO. 2 SIGNAL
4 V37 20VT S/C SWITCH NO. 1 SIGNAL
5 V937 20VT/BR S/C SWITCH RETURN
6 X3 20DG/VT HORN SWITCH SENSE
8W - 80 - 46 8W-80 CONNECTOR PIN-OUTSDR

CLOCKSPRING C2 - YELLOW 4 WAY
CAV CIRCUIT FUNCTION
1 R61 20LG/VT DRIVER SQUIB 2 LINE 1
2 R63 20LG/WT DRIVER SQUIB 2 LINE 2
3 R43 20LG/BR DRIVER SQUIB 1 LINE 1
4 R45 20LG/OR DRIVER SQUIB 1 LINE 2
CLOCKSPRING C3 - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 X3 20DG/VT HORN SWITCH SENSE
2 V937 20VT/BR S/C SWITCH RETURN
3 V37 20VT S/C SWITCH NO. 1 SIGNAL
4 V38 20VT/OR (DSAB ETC) S/C SWITCH NO. 2 SIGNAL
CLOCKSPRING C4-2WAY
CAV CIRCUIT FUNCTION
1 Z909 22BK GROUND
2 X20 22GY/WT RADIO CONTROL MUX
CLUTCH INTERLOCK BRAKE SWITCH-2WAY
CAV CIRCUIT FUNCTION
1 T41 20YL/DB TRS T41 SENSE
2 Z911 18BK GROUND
COIL ON PLUG NO. 1 (3.7L/4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K19 18DB/DG COIL CONTROL NO. 1
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 47

COIL ON PLUG NO. 1 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K19 18DB/DG COIL CONTROL NO. 1
COIL ON PLUG NO. 2 (3.7L/4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K17 18DB/TN COIL CONTROL NO. 2
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
COIL ON PLUG NO. 2 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K17 18DB/TN COIL CONTROL NO. 2
COIL ON PLUG NO. 3 (3.7L/4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K18 18DB/OR COIL CONTROL NO. 3
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
8W - 80 - 48 8W-80 CONNECTOR PIN-OUTSDR

COIL ON PLUG NO. 3 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K18 18DB/OR COIL CONTROL NO. 3
COIL ON PLUG NO. 4 (3.7L/4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K15 18DB/GY COIL CONTROL NO. 4
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
COIL ON PLUG NO. 4 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K15 18DB/GY COIL CONTROL NO. 4
COIL ON PLUG NO. 5 (3.7L/4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K16 18DB/YL COIL CONTROL NO. 5
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 49

COIL ON PLUG NO. 5 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K16 18DB/YL COIL CONTROL NO. 5
COIL ON PLUG NO. 6 (3.7L/4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K10 18DB/OR COIL CONTROL NO. 6
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
COIL ON PLUG NO. 6 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K10 18DB/OR COIL CONTROL NO. 6
COIL ON PLUG NO. 7 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K97 18DB/YL COIL CONTROL NO. 7
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
8W - 80 - 50 8W-80 CONNECTOR PIN-OUTSDR

COIL ON PLUG NO. 7 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K97 18BR COIL CONTROL NO. 7
COIL ON PLUG NO. 8 (4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K98 18DB/YL COIL CONTROL NO. 8
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
COIL ON PLUG NO. 8 (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT ASD RELAY OUTPUT
2 K98 18DB/YL COIL CONTROL NO. 8
COMPASS/MINI-TRIP COMPUTER (EXCEPT BASE) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
3 Z13 20BK/WT GROUND
4 A919 20RD FUSED B(+)
5 D25 20WT/VT PCI BUS
6- -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 51

CONDENSER FAN (NGC) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z823 16BK/DG GROUND
2 C123 16LB/WT CONDENSER FAN RELAY OUTPUT
CONTROLLER ANITLOCK BRAKE C1 - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 B4 20DG/GY REAR WHEEL SPEED SENSOR (+)
2 B222 20DG/WT (ETC) VEHICLE SPEED SIGNAL NO. 2
3 D25 20WT/VT PCI BUS
4 F500 20DG/PK FUSED IGNITION SWITCH OUTPUT (RUN)
5 B9 20DG/LG (ETC) LEFT FRONT WHEEL SPEED SENSOR (+)
6 Z107 12BK/DG GROUND
7 A111 14DG/RD FUSED B(+)
8 B3 20DG/YL REAR WHEEL SPEED SENSOR (-)
9 B29 20DG/WT BRAKE SWITCH SIGNAL
10 B8 20DG/TN (ETC) LEFT FRONT WHEEL SPEED SENSOR (-)
11 B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE
12 B22 20DG/YL VEHICLE SPEED SIGNAL NO. 1
13 Z127 12BK/DG (ABS) GROUND
14 A111 14DG/RD (ABS) FUSED B(+)
CONTROLLER ANTILOCK BRAKE C2 (ABS) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 B9 20DG/LG LEFT FRONT WHEEL SPEED SENSOR (+)
2 B8 20DG/TN LEFT FRONT WHEEL SPEED SENSOR (-)
3 B6 20DG/WT RIGHT FRONT WHEEL SPEED SENSOR (-)
4 B7 20DG/VT RIGHT FRONT WHEEL SPEED SENSOR (+)
CRANKSHAFT POSITION SENSOR (3.7L)-3WAY
CAV CIRCUIT FUNCTION
1 K24 20BR/LB CKP SIGNAL
2 K900 20DB/DG SENSOR GROUND
3 F855 20PK/YL 5 VOLT SUPPLY
8W - 80 - 52 8W-80 CONNECTOR PIN-OUTSDR

ELECTRIC BRAKE PROVISION-4WAY
CAV CIRCUIT FUNCTION
A A400 14TN/RD FUSED B(+)
B B40 14DG TRAILER TOW BRAKE B(+)
C L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
D Z998 18BK GROUND
ELECTRIC THROTTLE CONTROL MODULE - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 K22 18BR/OR TP NO. 1 SIGNAL
2 F855 18PK/YL 5 VOLT SUPPLY
3 K447 18TN/YL ETC MOTOR (+)
4 K122 18BR/DG TP NO. 2 SIGNAL
5 K448 18TN/OR ETC MOTOR (-)
6 K922 18BR/DB TP SENSOR RETURN
ENGINE CONTROL MODULE C1 (DIESEL) - 60 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 D72 18WT/LB CCD BUS (+)
5 D71 18WT/DB CCD BUS (-)
6 K65 18BR/LB FUEL PUMP RELAY RETURN
7 K20 18BR/GY GEN FIELD CONTROL
8- -
9- -
10 - -
11 K2 18TN/BK (A/T) ECT SIGNAL
11 K2 18VT/OR (M/T) ECT SIGNAL
12 K181 18BR/YL FUEL PUMP DRIVER
13 - -
14 K22 18BR/WT (A/T) TP SIGNAL
14 K23 18DB/WT (M/T) APPS NO. 1 SIGNAL
15 K21 18DB/LG INTAKE AIR TEMPERATURE SENSOR SIGNAL
16 - -
16 K29 18WT/BR (M/T) APPS NO. 2 SIGNAL
17 - -
18 - -
19 K31 18BR FUEL PUMP RELAY CONTROL
20 - -
21 - -
22 K24 18LB/BR (A/T) CKP SIGNAL
22 K24 18BR/LB (M/T) CKP SIGNAL
23 K914 18RD/WT (A/T) SENSOR GROUND
23 K914 18BR/WT (M/T) SENSOR GROUND
24 K44 18DB/GY CMP SIGNAL
25 K668 18LG (A/T) SUPPLY VOLTAGE
25 K688 18BR (M/T) SUPPLY VOLTAGE
