1998 BMW M3 Electrical Troubleshooting Manual







 $%%%%&



SPLICE LOCATION VIEWS
SPLICE HARNESS PAGE NUMBER
X10302 FRONT 8000.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X11264 FRONT 8000.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X11269 REAR 8000.0-03. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X11279 REAR, CONVERTIBLE 8000.0-04. . . . . . . . . . . . . . . . . . . . . .
X11282–X11381 FRONT 8000.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X13000 FRONT 8000.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X13002–X13011 REAR 8000.0-03. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X13002–X13011 REAR, CONVERTIBLE 8000.0-04. . . . . . . . . . . . . .
X13021–X13115 FRONT 8000.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . .
X13127–X13273 REAR, CONVERTIBLE 8000.0-04. . . . . . . . . . . . . .
X13129–X13173 REAR 8000.0-03. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X13282 FRONT 8000.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X13289 REAR 8000.0-03. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X13289 REAR, CONVERTIBLE 8000.0-04. . . . . . . . . . . . . . . . . . . . . .
X13300–X13304 FRONT 8000.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . .
X13309 REAR 8000.0-03. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X13309 REAR, CONVERTIBLE 8000.0-04. . . . . . . . . . . . . . . . . . . . . .
X13311–X13313 FRONT 8000.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . .
X18160–X18161 IHKA NOT SHOWN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X18165–X18784 FRONT 8000.0-02. . . . . . . . . . . . . . . . . . . . . . . . . . . .
X18785–X18799 REAR, CONVERTIBLE 8000.0-04. . . . . . . . . . . . . .
X19513–X19515 RADIO NOT SHOWN. . . . . . . . . . . . . . . . . . . . . . . . . . . .

SPLICE LOCATION VIEWS
FRONT HARNESS






X216
X10027
X215


X13304
X10302



SPLICE PANEL












X195
X218
X557
X1149X10009
X10064
X11282
X11283





X13115
X13282
X182
X183
X188
X191
X196
X197 X181











































X213X228
X1019
X1029
X1047
X1065
X1066
X1067
X1069X1079
X1080
X1085
X1179
X1182X10028
X10024 X10011X10008 X1225X10060
X10103 X10090
SPLICE PANEL























































X185
X186
X187
X203
X223
X238 X184
X245X246
X276
X530
X595
X1015
X1022
X1028X1036
X1068
X1073
X1076
X1077
X1152 X1233X1192 X1186
X1177
X1172 X1168X10007
X10021 X10020 SPLICE PANEL





X10100 X10055 X10022

X1055


X1163


X1164
X1258






X10123 X10120X10191
X10231
X10104 X10061 X10252
X11381 X11264X18165




X10192








X1027
X1541


X18784 X18783
X10029X11284
X13000
X13300
X13302

X1687
X1682X1686





X1689
X1691
X1693
























X13021
X13311






X13312X13313

SPLICE LOCATION VIEWS
REAR HARNESS






X13005
X1234 X461X1167
X805X13007

X465







X1284













X441
X449 X445
X444
X443
X442











X450









X462
X1299 X1235 X1212
X481
X13010 X13003
X13002
X1396 X1387
X13011 SPLICE PANEL
































X475
X1263
X453
X455X1894
X10118
X10269 X1895
X11269X13164 X13132
X13129
X13164
X13168
X13173
X13289
X13309
X313
X314
X428
X1214
X1215
X1218
X1226
X1232
X2152

SPLICE LOCATION VIEWS
REAR WIRING HARNESS – CONVERTIBLE










X461
X805X1234



X314
X13273X18799



X313
X428X1215
X13007











X441
X449 X445
X444 X443
X442
X450X453
X462 X455
X1235 X1212
X481
X475SPLICE PANEL


X1387
X10228 X10189
X10118 X1396
X10229X13002
X13003X13129
X13127 X13011
X13010X13132
X13168 X1263 X10269


















































X13173
X13309 X11279
X13289




X1214
X1218X1232
X2152








X465
X1226X13229
X18785

SPLICE LOCATION VIEWS
ENGINE HARNESS M44








X6832

X6833

X6900






X6460
X6461 X8564
X8576

X6462
X6492

X8073

X6411
X6463
X6820
X6821
X6835 X6410




























X6863
X6866X8004
X8015
X8056
X8565
SPLICE PANEL
X6860
X6891
X7845
X7846X8008
X10169

SPLICE LOCATION VIEWS
ENGINE HARNESS M3






X6411
X6459X6823
X6832
X6863






























X6867
X6868
X6869
X8000
X8007X8010
X8015
X8038
X8051
X8071
X8072X8103
SPLICE PANEL


X8565









X6822
X6835
X6860 X8004

X6820




X6458 X8564

X6819

X6900X6475

X6492
X8576
X6412
X6420X8074
X6810
X6821

X8071
SPLICE LOCATION VIEWS
ENGINE HARNESS M52











X6820
X6900






X6458
X6475X8073
X8564

X6492 X8576

X6412
X6420
X6459
X6810 X6411



































X6821
X6822X6835
X6863
X6866X8004
X8007
X8010
X8015 X6868
SPLICE PANEL




X6869











X8072
X8074
X8103
X8565 X6823
X6832
X6860
X6867X8000X8038


8500.0 CONNECTOR VIEWS $%%




%%&




/
"
& ! . # / " #  / "   %"/ "" " " % & ! ./ "% "& "! "& "#
FIG. 1FIG. 2
FIG. 4




#/
% " /
 #
"
/ #
. ! &

".#
/
"."
"#
"
"/%
""&
"!
".
%#
&
!/
."
#

FIG. 3
 " /
//"
