1997 TOYOTA TACOMA gas type

Publication No. OM35705U
Part No. 01999-35705
Printed in Japan 10- 9802- 05
Quick index If a service reminder indicator or warning buzzer comes on 59 . . . . .
If your vehicle will not start 139
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 142 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 143
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 144
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 152 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving during break- in period 114 . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 127
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 168
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Complete index 221
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas station information
Fuel type: UNLEADED gasoline, Octane Rating 87 (Research Octane Number
91) or higher.
See page 114 for detailed information.
Fuel tank capacity: Two- wheel drive models
57 L (15.1 gal., 12.5 Imp.gal.)
Four- wheel drive models
68 L (18.0 gal., 15.0 Imp. gal.)
Engine oil: API SH, ''Energy- Conserving II'' multigrade engine oil or ILSAC mult igrade
engine oil is recommended.
See page 182 for detailed information.
Tire information: See pages 185 through 189.
Tire pressure: See page 211. T
9
I

11 4
CAUTION!
When driving off-road or in rugged
terrain, do not drive at excessive
speeds, jump the vehicle, or strike
objects, etc. This may cause loss of
control or vehicle rollover. You are
also risking expensive damage to
your vehicle's suspension and chassis. Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break-in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of your vehicle:
Do not drive over 88 km/h (55 mph).
Run the engine at moderate speed be- tween 2000 and 4000 rpm.
Avoid full-throttle starts.
Try to avoid hard stops during the first
300 km (200 miles).
Do not drive slowly with the manual
transmission in a high gear.
Do not drive for a long time at any
single speed, either fast or slow.
Do not tow a trailer during the first 800
km (500 miles)
Four-wheel drive models with free-
wheeling hubs onlyÐ For the first 500 km (300 miles):
We recommend that you use high range,
two-wheel drive, with both free-wheeling
hubs engaged. For information on the four-wheel drive system and the front hubs, see Four-wheel drive system in Chapter 1-6. FUEL TYPE
Your new vehicle must use only un-
leaded gasoline.
To help prevent gas station mixups, your
Toyota has a new smaller fuel tank opening.
The special nozzle on pumps with unleaded
fuel will fit it, but the larger standard nozzle
on pumps with leaded gas will not.
Do not use leaded gasoline. Use of
leaded gasoline will cause the
three-way catalytic converter to lose its effectiveness and theemission control system to function improperly. Also, thiscan increase maintenance costs.
NOTICE
OCTANE NUMBER
Select Research Octane Number 91 (Oc-
tane Rating 87) or higer.
Use of unleaded fuel with an octane num- ber or rating lower than stated above will
cause persistant heavy knocking. If se-
vere, this will lead to engine damage.Fuel
Break-in period

11 7
Keep your engine in good running
order. Malfunctions in the engine
electrical system, electronic igni-tion system/distributor ignitionsystem or fuel systems could
cause an extremely high three- way catalytic converter tempera-ture.
If the engine becomes difficult to
start or stalls frequently, take your
vehicle in for a check-up as soon
as possible. Remember, your To-yota dealer knows your vehicleand its three-way catalytic con-
verter system best.
To ensure that the three-way cata-lytic converter and the engine
emission control system operateproperly, your vehicle must re-ceive the periodic inspections re-
quired by the Toyota Maintenance
Schedule. For scheduled mainte- nance information, refer to the
separate Owner's Manual Sup-
plement/Maintenance Scheduleº.
CAUTION!
Avoid inhaling the engine ex-
haust. It contains carbon monox-
ide, which is a colorless and odor-
less gas. It can cause uncon-
sciousness or even death.
Make sure the exhaust system
has no holes or loose connec-
tions. The system should be
checked from time to time. If you
hit something, or notice a change
in the sound of the exhaust, have
the system checked immediately.
Do not run the engine in a garage
or enclosed area except for the
time needed to drive the vehicle in
or out. The exhaust gases cannot escape, making this a paticularly
dangerous situation.
Do not remain for a long time in a
parked vehicle with the engine
running. If it is unavoidable, how-
ever, do so only in an unconfined
area and adjust the heating or
cooling system to force outside air into the vehicle.To allow proper operation of your
vehicle's ventilation system, keep
the inlet grilles in front of the
windshield clear of snow, leaves, or other obstructions.
If you smell exhaust fumes in the
vehicle, drive with the windows
open. Have the cause immediate- ly located and corrected.
Toyota does not recommend oc-
cupying the rear cargo area when
it is fitted with a slide-in camper,camper shell or other type cover
while the engine is running. This
caution applies to both driving
and stopped or parked situations
with the engine running. Particu-lar care should be taken to perv-
ent exhaust gases from entering
camper bodies, trailer or other en-
closures on or around your ve-
hicle. If exhaust fumes are de-
tected, open all windows and
throughly ventilate the area.
Engine exhaust cautions

163
3. Rinse thoroughly Ð dried soap can
cause streaking. In hot weather you
may need to rinse each section right
after you wash it.
4. To prevent water spots, dry the vehicle using a cl ean soft cotton towel. Do not
rub or press hard Ð you might scratch the paint.
Waxing your Toyota
Polishing and waxing is recommend-
ed to maintain the original beauty of
your Toyota's finish.
1. Always wash and dry the vehicle be- fore you begin waxing, even if you are
using a combined cleaner and wax.
2. Use a good quality polish and wax. If the finish has become extremely
weathered, use a car-cleaning polish,
followed by a separate wax. Carefully
follow the manufacturer's instructions
and precautions. Be sure to polish and
wax the chrome trim as well as thepaint.
3. Wax the vehicle again when water does not bead but remains on the sur-
face in large patches.
CAUTION
Do not wash the vehicle floor with
water, or allow water to get into the
floor when cleaning the vehicle inte-
rior or exterior. Water may get intoaudio components or other electri-cal components above or under the
floor carpet (or mat) and cause a
malfunction; and it may cause body corrosion.!
Vinyl interior
The vinyl upholstery may be easily
cleaned with a mild soap or detergent
and water.
First vacuum over the upholstery to re- move loose dirt. Then, using a sponge or
soft cloth, apply the soap solution to the vi-
nyl. After allowing it to soak in for a few
minutes to loosen the dirt, remove the dirt
and wipe off the soap with a clean damp
cloth. If all the dirt does not come off, re-
peat the procedure. Commercial foam-
ing-type vinyl cleaners are also available
which work well. Follow the manufactur-
er's instructions.Do not use solvent, thinner, gas-
oline or window cleaner on the in-
terior.
NOTICE
Carpets
Use a good foam-type shampoo to
clean the carpets.
Begin by vacuuming thoroughly to re-
move as much dirt as possible. Several
types of foam cleaners are available; some are in aerosol cans and others are
powders or liquids which you mix with wa-
ter to produce a foam. To shampoo the
carpets, use a sponge or brush to apply the foam. Rub in overlapping circles.
Do not apply water ± the best results are obtained by keeping the carpet as dry as possible. Read the shampoo instructions
and follow them closely. Seat belts
The seat belts may be cleaned with
mild soap and water or with lukewarm
water.
Use a cloth or sponge. As you are clean-
ing, check the belts for excessive wear,
fraying, or cuts.
Cleaning the interior

194
ADDING DISTILLED WATER (MAINTE-
NANCE TYPE BATTERY ONLY)
1. Remove the vent plugs.
2. Add distilled water to cells needingfluid.
If the side of your battery is covered,
check the water level by looking down di-
rectly above the cell as illustrated above.
3. Retighten the vent plugs securely
NOTICE
Do not overfill the cells. Excess electrolyte could squirt out of the
battery during heavy charging,causing corrosion or damage.
During recharging, the battery is pro-
ducing hydrogen gas. Therefore, before recharging:
1. Maintenance type batteriesÐRemove the vent plugs.
2. If recharging with the battery installed on the vehicle, be sure to disconnect the ground cable.
3. Be sure the power switch on the re- charger is off when connecting the
charger cables to the battery and
when disconnecting them.
Always charge the battery in an
unconfined area. Do not charge
the battery in a garage or closed
room where there is not sufficient ventilation.
Non-maintenance batteries: Only
do a slow charge (5A or less).
Charging at a quicker rate is dan-
gerous. The battery may explode,
causing personal injuries.
Maintenance type batteries: Be sure to remove the vent plugs be-fore recharging. CAUTION
!
NOTICE
Never recharge the battery while the
engine is running. Also, be sure all
accessories are turned off.
Battery recharging precautions

206
FOUR-WHEEL DRIVE MODELS
Model:
2RZ-FE, 3RZ-FE and 5VZ-FE
Type: 2RZ-FE and 3RZ-FE engine
4 cylinder in line, 4 cycle, gasoline
5VZ-FE engine 6 cylinder V type, 4 cycle, gasoline
Bore and stroke, mm (in.): 2RZ-FE engine
95.0 x 86.0 (3.74 x 3.39)
3RZ-FE engine
95.0 x 95.0 (3.74 x 3.74)
5VZ-FE engine 93.5 x 82.0 (3.68 x 3.23)
Displacement, cm 3
(cu. in.):
2RZ-FE engine 2438 (148.8)
3RZ-FE engine 2694 (164.3)
5VZ-FE engine
3378 (206.1)
Normal cab models Xtra-cab models
Overall length mm (in.) 4585 (180.5) 5055 (199.0)
Overall width mm (in.) 1690 (66.5) *1
1690 (66.5)
1720 (67.7) *2
1720 (67.7)*2
Overall height mm (in.) 1710 (67.3) *1,3
1700 (66.9)*1,3
1740 (68.5) *2,3
1735 (68.3)*2,3
Wheelbase mm (in.) 2625 (103.3) 3095 (121.9)
Front tread mm (in.) 1395 (54.9) *3
1460 (57.5)*4
1500 (59.1) *5
1500 (59.1)*5
Rear tread mm (in.) 1455 (57.3) *4
1455 (57.3)*4
1495 (58.9) *5
1495 (58.9)*5
Cargo weight rating kg (lb.) 500 (1100) 500 (1100) *6
317 (700) *7
*1 : With P225/75R 15 tires
*2 : With 31 x 10.5R 15 LT tires
*3 : Unladen vehicle
*4 : With steel wheels
*5 : With aluminum wheels
*6 : With 3 occupants
*7 : With 5 occupants
Engine

207
Fuel type:
Unleaded gasoline, Research Octane Number 91 (Octane Rating 87) orhigher
Fuel tank capacity, L (gal., Imp. gal.):
Two-wheel drive models
57 (15.1, 12.5) Four-wheel drive models
68 (18.0, 15.0) ENGINE
Valve clearance (engine cold), mm (in.) 2RZ-FE and 3RZ-FE engines
Intake 0.15 '0.25 (0.006 '0.010)
Exhaust 0.25 '0.35 (0.010 '0.014)
5VZ-FE engine
Intake 0.13 '0.23 (0.006 '0.009)
Exhaust 0.27 '0.37 (0.011 '0.014)
Spark plug type: 2RZ-FE and 3RZ-FE engines NIPPONDENSO K16R-U
NGK BKR5EYA
5VZ-FE engine
NIPPONDENSO K16TR11
NGK BKR5EKB11
Spark plug type: 2RZ-FE and 3RZ-FE engines
0.8 (0.031)
5VZ-FE engine
1.1 (0.043) Drive belt tension measured with Bor-
oughs drive belt tension gauge No.
BT-33-73F (used belt), Ibf: 2RZ-FE and 3RZ-FE engines
Generator belt 115 + 20
Air conditioning
compressor belt 100 + 20
Power steering pump belt 100 -15+20
5VZ-FE engine Generator belt 100 + 20
Air conditioning
compressor belt 100 + 20
Power steering pump belt 100 -15+20
Fuel
Service specifications
