74
NOTICE
Be careful not to overrev the en-gine. Watch the tachometer to
keep engine rpm from going intothe red zone. The approximatemaximum allowable speed for
each position is given below foryour reference: 2º 85 km/h (52 mph). . . . . .
Lº 46 km/h (28 mph) . . . . .
Do not continue hill climbing or
hard towing for a long time in the
2º or Lº position. This maycause severe automatic trasmis-sion damage from overheating. To
prevent such damage, Dº posi- tion should be used in hill climb-ing or hard towing.
(d) Backing up
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with your foot, shift the selector lever to the
Rº position.
NOTICE
Never shift into reverse while the vehicle is moving.
(e) Parking
1. Bring the vehicle to a complete stop.
2. Pull the parking brake lever up fully to securely apply the parking brake.
3. With the brake pedal pressed down, shift the selector lever to the Pº posi- tion.
While the vehicle is moving, never
attempt to move the selector lever
into Pº position under any circum-
stances. Serious mechanical dam-
age and loss of vehicle control mayresult. CAUTION
!
(f) Good driving practice
If the transmission is repeatedly upshifted
and downshifted between third gear and
overdrive when climbing a gentle slope,
the overdrive switch should be turned off.
Be sure to turn the switch on immediately afterward.
Always keep your foot on the brake
pedal while stopped with the engine
running. This prevents the vehicle
from creeping. CAUTION
!
NOTICE
Do not hold the vehicle on an upgrade with the accelerator pedal.
It can cause the transmission to overheat. Always use the brakepedal or parking brake.
(g) Rocking your vehicle if stuck
If you rock your vehicle to make it
out when it becomes stuck in snow,
mud, sand, etc., first check that
there is no physical object or peo-
ple around the vehicle. During ope-
ration, the vehicle may suddenly
move forward or backward, causing
injury or damage to nearby people
or objects. CAUTION
!

75
NOTICE
If you rock your vehicle, observe the following precautions to prevent
damage to the transmission andother parts.
Do not depress the acceleratorpedal while shifting the selectorlever or before the transmission is
completely shifted to forward or reverse gear.
Do not race the engine and avoid
spinning the wheels.
If your vehicle remains stuck afterrocking the vehicle several times,
consider other ways such as tow-ing.
(h) If you cannot shift the selector lever
out of Pº position
If you cannot shift the selector lever from Pº position even though the brake pedal
is depressed, use the shift lock override
button. For instructions, see If you can-not shift automatic transmission slelector leverº in Part 4.
The shift pattern is as shown above.
Press the clutch pedal down fully while
shifting, and then release it slowly. Do not
rest your foot on the pedal while driving, because it will cause clutch trouble. And do not use the clutch to hold the vehicle
when stopped on an uphill gradeÐuse the
parking brake. Recommended shifting speeds
The transmission is fully synchronized
and upshifting or downshifting is easy.
For the best compromise between fuel
economy and vehicle performance, you
should upshift or downshift at the follow-
ing speeds:
gear km/h
(mph)
1 to 2 or 2 to 1 24(15)
2 to 3 or 3 to 2 40 (25)
3 to 4 or 4 to 3 64(40)
4 to 5 or 5 to 4 72(45)
Downshift to the appropriate gear if accel-
eration is needed when you are cruising
below the above downshifting speeds.
Upshift too soon or downshifting too late
will cause lugging, and possibly pinging.
Regularly revving the engine to maximum
speed in each gear will cause excessive
engine wear and high fuel comsumption.
Manual transmission

95
Heating
For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards WARM
(red zone)
Air intake -FRESH (outside air)
Air flow -FLOOR
Air Conditioning -OFF
For quick heating, select recirculated
air for a few minutes. To keep the win-
dows from fogging, select fresh afterthe vehicle interior has been warmed.
Press the A/Cº button on for dehumid-
ified heating.
Choose floor/windshield air flow toheat the vehicle interior while defrost-ing or defogging the windshield. Air conditioning For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards COLD
(blue zone)
Air intake -FRESH (outside air)
Air flow -PANEL
Air Conditioning -ON For quick cooling, move the air intake
selector to recirculate for a few min-utes.
Ventilation
For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards COLD
(blue zone)
Air intake -FRESH (outside air)
Air flow -PANEL
Air Conditioning -OFF
Defogging The inside of the windshield For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards WARM
(red zone) to heat; COLD (blue zone) to
cool
Air intake -FRESH (outside air)
Air flow -WINDSHIELD
Air Conditioning -ON
On humid days, do not blow cold air on
the windshieldÐthe difference be- tween the outside and inside tempera-
tures could make the fogging worse.
Defrosting The outside of the windshield For best results, set controls to:
Fan speed -Any setting except OFFº
Temperature - Towards WARM
(red zone)
Air intake -FRESH (outside air)
Air flow -WINDSHIELD
Air conditioning-OFF
To heat the vehicle interior while de-
frosting the windshield, choose floor/
windshield air flow.

Part 2Break-in periodFuel
101
INFORMATION
BEFORE DRIVING
YOUR TOYOTA
Break-in period
Fuel
Operation in foreign countries
Three-way catalytic converter
Engine exhaust cautions
Facts about engine oil consumption
Twin ground electrode spark plugs
Brake system
Brake pad wear limit indicators
Luggage stowage precautions
Your Toyota's idenitification
Theft prevention labels
Suspension and chassis
Types of tires
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break-in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of your vehicle:
Do not drive over 88 km/h (55 mph).
Run the engine at moderate speed be- tween 2000 and 4000 rpm.
Avoid full-throttle starts.
Try to avoid hard stops during the first
300 km (200 miles).
Do not drive slowly with the manual
transmission in a high gear.
Do not drive for a long time at any
single speed, either fast or slow. FUEL TYPE
Your new vehicle must use only un-
leaded gasoline.
To help prevent gas station mixups, your
Toyota has a new smaller fuel tank open- ing.
The special nozzle on pumps with un-
leaded fuel will fit it, but the larger stan-
dard nozzle on pumps with leaded gas will
not.
Do not use leaded gasoline. Use of
leaded gasoline will cause the
three-way catalytic converter tolose its effectiveness and the emis- sion control system to function im-properly. Also, this can increase maintenance costs.
NOTICE
OCTANE NUMBER
Select Research Octane Number 91
(Octane Rating 87) or higher.
Use of unleaded fuel with an octane num- ber rating lower than stated above will
cause persistent heavy knocking. If se-
vere, this will lead to engine damage.

108ABSº warning light
This light comes on when the ignition key is turned to the ONº position. After about
3 seconds, the light will go off.
If either of the following conditions occurs, this indicates a malfunction somewhere inthe parts monitored by the warning light
system. Contact your Toyota dealer as
soon as possible to service the vehicle.
The light does not come on as de-
scribed above, or remains on.
The light comes on while driving.
Even if the anti-lock brake system should
fail, the brake system will still operate con-
ventionally. However, when the ABSº
warning light is on (and the brake system
warning light is off), the anti-lock brake
system is not assisting brake perfor-
mance so that the wheel can lock-up dur-
ing sudden braking or braking on slippery
road surfaces. Have your vehicle checked
by your Toyota dealer as soon as pos- sible.
The brake pas wear limit indicators on your disc brakes give a warning noise
when the brake pads are worn to
where replacement is required.
If you hear a squealing or scraping noise
while driving, have the brake pads
checked and replaced by your Toyota
dealer as soon as possible. Expensive ro-
tor damage can result if the pads are not
replaced when necessary. When stowing luggage or cargo in the ve-
hicle, observe the following:
Put luggage in the trunk when at all pos -
sible. Be sure all items are secured in
place.
Be careful to keep the vehicle bal-
anced. Locating the weight as far for-
ward as possible helps maintain bal- ance.
For better fuel economy, do not carry unneeded weight.To prevent luggage or packages
from sliding forward during brak-
ing, do not stack anything in the
enlarged trunk room. Keep lug-
gage or packages low, as close to
the floor as possible.
Never allow anyone to ride in the enlarged trunk room. It is not de-
signed for passengers. They
should ride in their seats with
their seat belts properly fastened.
Otherwise, they are much more
likely to suffer serious bodily inju-
ry, in the event of sudden braking
or a collision.
CAUTION!
Brake pad wear limit indicators Luggage stowage precautions

Part 3How to start the engineÐ
(a) Before cranking
Before starting the engine
11 3
STARTING AND DRIVING
Before starting the engine
How to start the engine
Tips for driving in various conditions
Winter driving tips
Trailer towing
How to save fuel and make your
vehicle last longer, too
1. Check
the area around the vehicle be-
fore entering it.
2. Adjust seat position and seatback angle.
3. Adjust inside and outside rear view mirrors.
4. Lock all doors.
5. Fasten seat belts. 1. Apply the parking brake firmly.
2. Turn off unnecessary lights and acces-
sories.
3. Manual transmission: Press the
clutch pedal to the floor and shift the
transmission into neutral. Hold theclutch pedal to the floor until the engine
is started. A starter safety device willprevent the starter from operating if
the clutch pedal is not fully depressed.
Automatic transmission: Put the se-
lector lever in Pº. If you need to restart
the engine while the vehicle is moving, put the selector lever in Nº. A starter
safety device will prevent the starter
from operating if the selector lever is in
any drive position.
4. Automatic transmission only: De-
press the brake pedal and hold it to the
floor until driving off.

11 6
Use a washer fluid containing an anti-
freeze solution.
This product is available at your Toyota
dealer and most auto parts stores. Follow
the manufacturer's directions for how
much to mix with water.
Do not use engine antifreeze or any
other substitute because it may
damage your vehicle's paint.
NOTICE
Do not use your parking brake when there is a possibility it could freeze. When parking, put the transmission into
Pº (automatic) or into first or reverse
(manual) and block the rear wheels. Do
not use the parking brake, or snow or wa-
ter accumulated in and around the parkingbrake mechanism may freeze, making it
hard to release. Keep ice and snow from accumulating
under the fenders.
Ice and snow built up under your fenders
can make steering difficult. During bad winter driving, stop and check under the
fenders occasionally. Depending on where you are driving,
we recommend you carry some emer- gency equipment.
Some of the things you might put in the ve-
hicle are tire chains, window scraper, bag of sand or salt, flares, small shovel, jump- er cables, etc.
Toyota does not recommend towing a
trailer with your Paseo. It is not designed for trailer towing.
Trailer towing

Part 4If your vehicle will not startÐ
(a) Simple checks
11 9
IN CASE OF AN EMERGENCY
If your vehicle will not start
If your engine stalls while driving
If your vehicle overheats
If you have a flat tire
If your vehicle needs to be towed
If you cannot shift automatic
transmission selector lever
If you lose your keys
Before making these checks, make sure
you have followed the correct starting pro-
cedure given in How to start the engineº
in Part 3 and that you have sufficient fuel.
If the engine is not turning over or is
turning over too slowlyÐ
1. Check that the battery terminals are
tight and clean.
2. If the battery terminals are O.K., switch on the interior light.
3. If the light is out, dim or goes out when the starter is cranked, the battery is
discharged. You may try jump starting.
See (c) Jump startingº for further in- structions.
If the light is O.K., but the engine still will
not start, it needs adjustment or repair.
Call a Toyota dealer or qualified repair shop.
NOTICE
Do not pullÐ or push-start the vehicle. It may damage the vehicle
or cause a collision when theengine starts. Also the three-way catalytic converter may overheatand become a fire hazard.
If the engine turns over at its normal
speed but will not startÐ
1. Check that all the push-on connectors are tight. (For example, connections at the spark plugs, ignition coil and/or dis-
tributor)
2. If the connectors are O.K., the engine may be flooded because of repeated
cranking. See (b) Starting a flooded
engineº for further instructions.
