Theft warning system operation
The warning system will give the following
alarm:
IThe headlights blink and the horn sounds
intermittently. In addition, the starter motor
will not operate.
IThe alarm automatically turns off after 2 to
3 minutes; however, the alarm will reacti-
vate if the vehicle is tampered with again.
The alarm is activated by:
IUnlocking the door or opening the trunk lid
without using the key or multi-remote con-
troller. (Even if the door is opened by re-
leasing the door inside lock knob or the
trunk lid is opened by operating the opener
lever/button, the alarm is activated.)
IOpening the hood.
IPushing in or pulling out of the key cylinder
on the door or trunk lid.
How to stop alarm
The alarm will stop only by unlocking a door or
trunk lid with the key or multi-remote controller.
The alarm will not stop if the ignition switch is
turned to ªACCº.
If the system does not operate as de-scribed above, have it checked by your
NISSAN dealer.
1-11
Z01.2.1/A32-DX

Lighting
Turn the switch to the ªº position:
The front clearance, side marker, tail, license
plate and instrument lights will come on.Turn the switch to the ª
º position:
Headlights will come on and all the other lights
remain on.
To select the high beam, push the lever for-
ward. Pull it back to select the low beam.
Daytime running light system
(For Canada)
The headlights automatically illuminate at a
reduced intensity when the engine is started
with the parking brake released. The daytime
running lights operate with the headlight switch
in the ªOFFº position or in the ª
º position.
Turn the headlight switch to the ªº posi-
tion for full illumination when driving at night.
If the parking brake is applied before the
engine is started, the daytime running lights do
not illuminate. The daytime running lights illu-
minate once the parking brake is released.
The daytime running lights will remain on until
the ignition switch is turned off.
When the daytime running light system
is active, tail lights on your vehicle will
not be on. It is necessary at dusk to turn
on your headlights. Failure to do so
could cause an accident injuring your-
self and others.
SIC0188
HEADLIGHT AND TURN SIGNAL
SWITCH
1-14
Z01.2.1/A32-DX

Passing signal
Pulling the lever toward you will turn on the
headlight high beam.
Turn signal
Move the lever up or down to signal the turning
direction. When the turn is completed, the turn
signals cancel automatically.
Lane change signal
To indicate a lane change, move the lever up
or down to the point where lights begin flash-
ing.
The instrument brightness control operates
when the light switch is in the ª
ºor
ªº position.
Turn the control to adjust the brightness of
instrument panel lights (except clock) and
power window switch lights.
When the control is turned to the right until a
click sound is heard, the light intensity will be
at maximum. When the control is turned to the
left until a click sound is heard, the light will be
turned off.To turn the fog lights on, turn the headlight
switch to the ªº position, then turn the
switch to the ªº position. To turn them off,
turn the switch to the ªOFFº position.
The headlights must be on for the fog lights to
operate.
IC1284MAIC1292
INSTRUMENT BRIGHTNESS
CONTROLFRONT FOG LIGHT SWITCH (If so
equipped)
1-15
Z01.2.1/A32-DX

The night position will reduce glare from the
headlights of vehicles behind you at night.
Use the night position only when neces-
sary, because it reduces rear view
clarity.
SPA0470
INSIDE MIRROR
2-40
Z01.2.1/A32-DX

If any electrical equipment does not operate
and fuses are in good condition, check the
fusible links. If any of these fusible links are
melted, replace only with genuine NISSAN
parts.
HEADLIGHTS
The headlight is a semi-sealed beam type
which uses a replaceable headlight (halogen)
bulb. A bulb can be replaced from inside the
engine compartment without removing the
headlight assembly.
High pressure halogen gas is sealed
inside the halogen bulb. The bulb may
break if the glass envelope is scratched
or the bulb is dropped.
Hold the plastic base when handling the
bulb. Never touch the glass envelope.
Removing the headlight bulb
1. Disconnect the battery negative cable.
2. Disconnect the electrical connector from
the rear end of the bulb.
3. Turn the bulb retaining ring counterclock-
wise until it is free from the headlight reflec-
tor, then remove it.
4. Remove the headlight bulb. Do not shake
or rotate the bulb when removing it.
SDI0128
SDI0129
FUSIBLE LINKS LIGHT BULBS
7-23
Z01.2.1/A32-DX

During the normal day-to-day operation of the
vehicle, general maintenance should be per-
formed regularly as prescribed in this section.
If you detect any unusual sounds, vibrations or
smell, be sure to check for the cause or have
your NISSAN dealer do it promptly. In addition,
you should notify your NISSAN dealer if you
think that repairs are required.
When performing any checks or maintenance
work, closely observe the precautions in the
ªDo-it-yourself operationsº section.
Additional information on the following
items with ª*º is found in the ªDo-it-
yourself operationsº section.
OUTSIDE THE VEHICLE
The maintenance items listed here should be
performed from time to time, unless otherwise
specified.
Tires*Check the pressure with a gauge peri-
odically when at a service station, including the
spare, and adjust to the specified pressure if
necessary. Check carefully for damage, cuts
or excessive wear.
Wheel nuts*When checking the tires, make
sure no nuts are missing, and check for any
loose nuts. Tighten if necessary.
Tire rotation*Tires should be rotated every7,500 miles (12,000 km).
Wheel alignment and balanceIf the vehicle
pulls to either side while driving on a straight
and level road, or if you detect uneven or
abnormal tire wear, there may be a need for
wheel alignment.
If the steering wheel or seat vibrates at normal
highway speeds, wheel balancing may be
needed.
Windshield wiper blades*Check for cracks
or wear if they do not wipe properly.
Doors and engine hoodCheck that all doors
and the engine hood operate smoothly as well
as the trunk lid or back hatch. Also make sure
that all latches lock securely. Lubricate if nec-
essary. Make sure that the secondary latch
keeps the hood from opening when the pri-
mary latch is released.
When driving in areas using road salt or other
corrosive materials, check lubrication fre-
quently.
INSIDE THE VEHICLE
The maintenance items listed here should be
checked on a regular basis, such as when
performing periodic maintenance, cleaning the
vehicle, etc.
Lights*Make sure that the headlights, stop
lights, tail lights, turn signal lights, and other
lights are all operating properly and installed
securely. Also check headlight aim.
Warning lights and buzzers/chimesMake
sure that all warning lights and buzzers/chimes
are operating properly.
Windshield wiper and washer*Check that
the wipers and washer operate properly and
that the wipers do not streak.
Windshield defrosterCheck that the air
comes out of the defroster outlets properly and
in good quantity when operating the heater or
air conditioner.
Steering wheelCheck that it has the specified
play. Be sure to check for changes in the
steering conditions, such as excessive play,
hard steering or strange noises.
SeatsCheck seat position controls such as
seat adjusters, seatback recliner, etc. to make
sure they operate smoothly and that all latches
lock securely in every position. Check that the
GENERAL MAINTENANCE
8-3
Z01.2.1/A32-DX

Precautions when starting and driving ........ 4-2
E
Economy hints ................................................ 4-15
Emission control information label .................. 9-11
Emission control system warranty .................. 9-19
Engine ............................................................... 9-8
Before starting the engine ........................... 4-6
Changing engine coolant ............................ 7-6
Changing engine oil .................................... 7-8
Checking engine coolant level .................... 7-5
Checking engine oil level ............................ 7-7
Engine coolant temperature gauge ............. 1-4
Engine cooling system ................................ 7-5
Engine oil..................................................... 7-7
Engine oil and oil filter
recommendation .......................................... 9-4
Engine serial number ................................ 9-11
Starting the engine ...................................... 4-6
Exhaust gas (Carbon monoxide) ...................... 4-2
Explanation of maintenance items.................. 8-10
F
Flat tire .............................................................. 5-2
Fluid
Automatic transmission fluid ..................... 7-10
Brake and clutch fluid................................ 7-12
Power steering fluid................................... 7-11
Window washer fluid ................................. 7-12
FM/AM radio with cassette player .................. 3-12
FM-AM radio with cassette player .................. 3-16FM-AM radio with cassette player and
compact disc player ........................................ 3-22
F.M.V.S.S. certification label........................... 9-11
Foldable outside mirrors ................................. 2-39
Front fog light switch (If so equipped) ............ 1-15
Front personal light ......................................... 1-23
Fuel
Capacities and recommended
fuel/lubricants .............................................. 9-2
Fuel filler cap ............................................. 2-10
Fuel filler lid lock ....................................... 2-10
Fuel gauge .................................................. 1-5
Fuel recommendation.................................. 9-2
Fuses .............................................................. 7-21
Fusible links .................................................... 7-23
G
Gauge
Engine coolant temperature gauge ............. 1-4
Fuel gauge .................................................. 1-5
Meters and gauges ..................................... 1-3
General maintenance ....................................... 8-3
Glove box lock .................................................. 2-8
H
Hazard warning flasher switch........................ 1-16
Head restraint ................................................. 2-15
Headlight and turn signal switch..................... 1-14
Headlights ....................................................... 7-23
Heated seats (If so equipped) ........................ 1-16
Heater operation ............................................... 3-4Hood release .................................................... 2-8
I
If your vehicle is ever stolen ........................... 1-26
If your vehicle overheats .................................. 5-9
Ignition switch ................................................... 4-4
Injured persons ............................................... 2-26
Inside mirror .................................................... 2-40
Installing license plate .................................... 9-12
Instrument brightness control ......................... 1-15
Integrated HomeLink
transmitter
(If so equipped).......................................... 1-24
Interior light ..................................................... 1-22
J
Jump starting ........................................... 5-7, 7-14
K
Key .................................................................... 2-2
L
License plate
Installing license plate ............................... 9-12
Light
Front fog light switch (If so
equipped)................................................... 1-15
Front personal light ................................... 1-23
Headlight and turn signal switch ............... 1-14
Headlights.................................................. 7-23
Interior light................................................ 1-22
10-2
Z01.2.1/A32-DX
