248Information about your vehicle's emission control
system is on the Vehicle Emission Control
Information decal located on or near the engine.
This decal identifies engine displacement and gives
some tune-up specifications.How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) TestingIn some localities it may become a legal
requirement to pass an Inspection/Maintenance
(I/M) test of the On-Board Diagnostic (OBD) II
system. If the vehicle's powertrain system or its
battery has just been serviced, the OBD II system is
reset to a not ready for I/M testing condition. To
prepare for I/M testing, the law specifies that
additional city and highway driving is necessary to
complete the check of the OBD II system.
The driving modes required to reach the ready
condition consist of a minimum of 30 minutes of
city and highway driving as described below:
q
At least twenty minutes driving in stop and go,
city type traffic with at least four idle periods.
q
At least ten minutes of driving on an
expressway or highway.
Before completing the above driving modes, the
engine must be warmed up and at operating
temperature. Once started, the vehicle must not be
turned off during these driving modes.
Lights and Bulb ReplacementIt is a good idea to check the operation of the
following lights frequently:q
headlamps
q
high-mount brakelamp
q
tail lamps
q
brakelamps
q
hazard flasher
File:11fnmct.ex
Update:Mon Jun 17 13:54:56 1996

250Parts of a headlamp
Removing the headlamp bulb1. Make sure that the headlamp switch is in the
OFF position.
2. Lift the hood, open access panel above
headlamp and find the bulb in the headlamp
socket.
3. Remove the electrical connector from the bulb
by grasping the wire with a quick pull
rearward.
4. Remove the retaining ring by turning it 1/8 of
a turn to free it from the socket. Then slide the
ring off the plastic base.Keep the ring.You
must use it again to hold the new bulb in
place.
File:11fnmct.ex
Update:Mon Jun 17 13:54:56 1996

251
Installing the headlamp bulb1. With the flat side of the bulb's plastic base
facing upward, insert the glass end of the bulb
into the socket. You may need to turn the bulb
left or right to line up the grooves in the plastic
base with the tabs in the socket. When the
grooves are aligned, push the bulb into the
socket until the plastic base contacts the rear of
the socket.
2. Slip the bulb retaining ring over the plastic base
until it contacts the rear of the socket. Lock
the ring into the socket by rotating it clockwise
until you feel a ªstop.º3. Push the electrical connector into the rear of
the plastic base until it snaps, locking it into
position.
4. Turn the headlamps on and make sure that
they work properly. If the headlamp was
correctly aligned before you changed the bulb,
you should not need to align it again.
File:11fnmct.ex
Update:Mon Jun 17 13:54:56 1996

296Anti-theft system
arming the system.......... 116
description............. 116
disarming an untriggered system.... 118
disarming a triggered system...... 118
triggering............. 118
Appeals (see Dispute settlement board) . . 266
Ashtray(s)............... 73
Assistance (see Customer assistance) . . . 265
Audio system (see Electronic
sound system)............ 33
Autolamp system (see Headlamps).... 70
Automatic transmission
driving an automatic overdrive..... 173
fluid, adding............. 231
fluid, checking............ 230
fluid, refill capacities......... 258
fluid, specification.......... 259Axle
lubricant specifications........ 259
refill capacities............ 258
B
Basic vehicle warranty........... 3
Battery................ 232
battery saver............. 115
charging system warning light..... 15
disconnecting............ 232
how to service............ 232
jumping a disabled battery....... 204
maintenance-free........... 232
proper disposal, recycling....... 232
replacement, specifications....... 257
servicing.............. 232
when storing your vehicle....... 261
File:fnixt.ex
Update:Mon Jun 17 13:58:01 1996

297
Brake fluid
brake warning light.......... 12
checking and adding......... 221
description............. 221
specifications............ 259
Brakes................ 167
adjustment............. 167
anti-lock.............. 167
applying the brakes.......... 167
brake warning light.......... 11
fluid, checking and adding....... 221
fluid, refill capacities......221, 258
fluid, specifications.......... 259
master cylinder........... 221
new brake linings........... 5
noise................ 167
parking............... 168
servicing.............. 167
when storing your vehicle....... 262Break-in period.............. 5
Brights (high beams).......... 13
Bulbs, replacing............ 248
halogen............... 249
headlamps.............. 249
C
Canada, customer assistance....... 270
Canada, warranty information....... 3
Canadian Motor Vehicle Arbitration Plan
(CAMVAP).............. 271
Capacities for refilling fluids....... 258
Carbon monoxide in exhaust....... 165
Car seats for children
(see Child safety seats)........ 141
Cassette tape player (see Electronic sound
system)............... 40
Catalytic converter........... 246
Changing a tire............. 192
File:fnixt.ex
Update:Mon Jun 17 13:58:01 1996

298Charging system warning light...... 15
Childproof locks............ 96
Child safety restraints.......... 140
child safety belts........... 158
child safety seats........... 141
Child safety seats
and air bags............. 141
attaching with tether straps...... 158
automatic locking mode
(retractor)........130, 141, 143
in front seat..........141, 143
in rear outboard seat......141, 151
in rear seat............. 141
tether anchorage hardware...... 158
Chime
headlamps on............ 32
key in ignition............ 75
safety belt.............. 13
Circuit breakers, checking and replacing . . 191Cleaning your vehicle
chrome and aluminum parts...... 253
exterior............... 253
exterior lamps............ 254
fabric................ 255
headlamps.............. 254
instrument panel........... 254
interior............... 255
interior lamps............ 254
mirrors............... 90
plastic parts............. 254
polishing.............. 253
rustproofing............. 254
safety belts............. 254
tail lamps.............. 254
upholstery and interior trim...... 255
washing............... 253
waxing............... 253
wheels............... 255
File:fnixt.ex
Update:Mon Jun 17 13:58:01 1996

303
odometer.............. 21
speedometer............. 20
GAWR (Gross Axle Weight Rating)
calculating............. 178
definition.............. 177
driving with a heavy load....... 177
location............... 177
Gearshift
automatic operation......... 173
column-mounted........... 173
locking the gearshift......... 73
positions.............. 173
shifting the gears.......... 173
GVWR (Gross Vehicle Weight Rating)
calculating............. 178
definition.............. 177
driving with a heavy load....... 177
location............... 177
H
Hazard flashers............. 78
Headlamps
aiming............... 248
autolamp system........... 70
cleaning............... 254
daytime running lights........ 68
flashing............... 76
high beam............. 76
replacing bulbs............ 248
turning on and off.......... 69
warning chime............ 32
Head restraints............. 119
Heated mirrors............. 101
Heating
electronic automatic temperature control
system.............. 55
High beams
indicator light............ 13
File:fnixt.ex
Update:Mon Jun 17 13:58:01 1996

305
L
Lamps
autolamp delay system........ 70
checking.............. 248
daytime running light system..... 68
flashing the lamps.......... 76
hazard flashers............ 78
headlamps............. 69
high beams............. 76
interior lamps............ 71
replacing bulbs........... 248
Lane change indicator (see Turn signal) . . 75
Lap belts............... 134
Lights, warning and indicator
airbag............... 14
brake................ 12
charging system........... 15
check engine............ 14
door ajar.............. 32
engine oil pressure.......... 15
hazard warning light......... 78
high beam............. 13low washer fluid........... 31
oil pressure............. 15
overdrive off............. 31
safety belt.............. 13
trunk ajar.............. 32
turn signal indicator......... 17
Load limits
GAWR............... 177
GVWR............... 177
trailer towing............ 179
Lubricant specifications......... 259
Luggage compartment.......... 104
Lug nuts
anti-theft.............. 203
standard.............. 196
tightening sequence......... 194
