1997 LINCOLN TOWN CAR belt

141
WARNING
Carefullyfollo wallof the
WARNING
Safet ybelt san dseat sca n becom ehot
WARNING
Do no tleav echildren ,unreliabl eadults,

144
3. While holding the shoulder and lap belt
portions together, route the tongue through the
child seat according to the child seat
manufacturer's instructions. See Figure 2. Be
sure that the belt webbing is not twisted.
File:06fnsst.ex
Update:Fri Jun 21 08:57:53 1996

145
Routing the lap/shoulder belt
4. Insert the belt tongue into the proper buckle
for that seating position until you hear and feel
the latch engage. See Figure 3. Make sure
tongue is latched securely to buckle by pulling
on tongue.
File:06fnsst.ex
Update:Fri Jun 21 08:57:53 1996

146Buckling the belt.
5. Grasp the shoulder portion of the belt and pull
downward until all of the belt is extracted and
a click is heard. At this time, the retractor is in
the automatic locking mode (child restraint
mode). See Figure 4.
NOTE:The dual locking mode retractor must be in
the automatic locking mode to properly restrain a
child seat.
File:06fnsst.ex
Update:Fri Jun 21 08:57:53 1996

147
Setting the retractor to automatic locking
mode
6. Allow the belt to retract. A clicking sound will
be heard as the belt retracts. This indicates the
retractor is in the automatic locking mode. Pull
on the lap belt portion across the child seat
towards the buckle and continue to pull up on
the shoulder belt portion while pushing down
on the child seat allowing the shoulder belt to
retract to remove any slack in the seat belt. See
Figures 5 and 6.
File:06fnsst.ex
Update:Fri Jun 21 08:57:53 1996

1508. Double check that the retractor is in the
automatic locking mode. Try to pull more belt
out of the retractor. If you cannot, the belt is
in the automatic locking mode. See Figure 8.
Checking the retractor
File:06fnsst.ex
Update:Fri Jun 21 08:57:53 1996

151
9. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 6 through
8.
NOTE:To remove the retractor from automatic
lock mode, allow seat belt to retract fully to its
stowed position and the retractor will automatically
switch back to the vehicle sensitive locking mode
for normal adult usage.Installing Child Safety Seats in the Rear
Outboard Seating PositionsYour rear outboard seating positions are equipped
with a cinch tongue on the safety belts. Use the
following procedure for installing a child safety seat
in these locations.
1. Grasp the belt webbing below the tongue and
pull as much of the belt out of the retractor as
possible. Hold the belt out. See Figure 1.
File:06fnsst.ex
Update:Fri Jun 21 08:57:53 1996

152NOTE:The belt webbing below the tongue is the
lap belt portion of the combination lap/shoulder
belt, and the belt webbing above the tongue is the
shoulder belt portion of the combination
lap/shoulder belt.
2. With your other hand, grasp the tip (metal
portion) of the tongue (not the cover) and slide
the tongue up the webbing as far as it will go.
See Figure 1. Release the tongue, but do not
let go of the lap portion of the belt webbing.3. While still holding the belt webbing below the
tongue in one hand, use your other hand to
grasp the tip (metal portion) of the tongue and
belt webbing together, and again pull out as
much of the belt as possible. Then, let go of
the lap portion of the belt webbing.
4. While holding the shoulder and lap belt
portions together, route the tongue and
webbing through the child seat according to the
child seat manufacturer's instructions. See
Figure 2. Be sure that the belt webbing is not
twisted.
File:06fnsst.ex
Update:Fri Jun 21 08:57:53 1996
