ENGINE
197 ±COOLING SYSTEM
Capacity 9.2 L (9.7 qt., 8.2 Imp.qt.)
Coolant type Ethylene ± glycol coolant (Do not use alcohol type.)
±FUEL
Fuel type Only UNLEADED
Research octane number 91 (Octane Rating 87) or higher
±IGNITION SYSTEM
Spark plug ±Make NIPPONDENSO PK20TR11
NGK BKR6EKPB11
±Gap 1.1 mm (0.043 in.)
±ELECTRICAL SYSTEM
Battery ± Maintenance type battery
Specific gravity reading at 205C (685F): 1.260 Fully charged
1.160 Half charged
1.060 Discharged
Charging rates Quick charge 15A max.
Slow charge 5A max.
± Non±maintenance battery
Open voltage at 205C (685F): 12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the key is
removed with all the lights turned off]
Charging rates 5A max.
ENGINE
202
Add oil O.K. Too full
4. Pull the dipstick out and look at the oil level on the end.
If it is between the full line ( ) and the low line ( ), it
is O.K.
If the oil level is below or only slightly above the low
level mark, add engine oil of the same type already in
the engine.
Remove the oil filler cap and add engine oil a little at a time,
checking the dipstick. The approximate quantity of oil
needed to fill between the low line and the full line on the
dipstick is indicated below for reference.
When the level reaches within the correct range, return the
filler cap and turn the cap clockwise until you hear a click.
Oil quantity. L (qt., Imp.qt.) 1.5 (1.6, 1.3)
NOTICE
Avoid overfilling, or the engine could be damaged.
Check the oil level on the dipstick once again after
adding oil.
