1997 HONDA ODYSSEY headlights

Lights

Replacing a Headlight Bulb

Your car has halogen headlight bulbs, one on each side. When
replacing a bulb, handle it by its steel
base and protect the glass fromcontact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean

cloth.

Halogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch

on the glass can cause the bulb to

overheat and shatter.
1. Open the hood.

If you need to change a bulb on

the passenger's side, remove the
air intake cover (see page 160).

2. Remove the electrical connector from the bulb by squeezing the
connector on both sides to unlock

the tab. Pull the connector straight
off.

3. Remove the rubber weather seal
by pulling on the tab.
4. Unclip the end of the hold-down
wire from its slot. Pivot it out of
the way and remove the bulb.
5. Insert the new bulb into the hole, making sure the tabs are in theirslots. Pivot the hold-down wire
back in place and clip the end into the slot.
6. Install the rubber seal over the back of the headlight assembly.Make sure it is right side up; it is

marked "TOP".

7. Push the electrical connector onto the tabs of the new bulb. Makesure it locks in place.
Turn on the headlights to test the new bulb.
8. (Passenger's side) Reinstall the air intake cover.

Maintenance

NOTICEProCarManuals.comMain Menu Table of Contents s t

If Your Engine Won't Start

Diagnosing why your engine won't
start falls into two areas, depending
on what you hear when you turn the
key to START (III):
You hear nothing, or almostnothing. The engine's starter
motor does not operate at all, oroperates very slowly.
You can hear the starter motor operating normally, or the starter
motor sounds like it is spinning
faster than normal, but the engine does not start up and run. Nothing Happens or the Starter
Motor Operates Very Slowly
When you turn the ignition switch to START (III), you do not hear the
normal noise of the engine trying to start. You may hear a clicking sound
or series of clicks, or nothing at all. Check these things:
Check the transmission interlock.
The transmission must be in Park or Neutral or the starter will not

operate.

Turn the ignition switch to ON (II).
Turn on the headlights and check their brightness. If the headlightsare very dim or don't light at all,
the battery is discharged. See

Jump Starting on page 202.
Turn the ignition switch to START
(III). If the headlights do not dim,
check the condition of the fuses. If
the fuses are OK, there is proba-
bly something wrong with the electrical circuit for the ignition
switch or starter motor. You will
need a qualified technician to determine the problem. (See
Towing on page 215.)
If the headlights dim noticeably or
go out when you try to start the engine, either the battery is dis-
charged or the connections are
corroded. Check the condition of
the battery and terminal connec-
tions (see page 164). You can
then try jump starting the car from a booster battery (see page 203).

Taking Care of the UnexpectedProCarManuals.comMain Menu Table of Contents s t

Fuses

ABS FUSE BOX

The ABS fuse box is in the engine
compartment on the right side.
Checking and Replacing Fuses

If something electrical in your car
stops working, the first thing you
should check for is a blown fuse.
Determine from the chart on pages 213 and 214 , or the diagram on the
fuse box lid, which fuse or fuses control that component. Check those
fuses first, but check all the fuses
before deciding that a blown fuse is not the cause. Replace any blown
fuses and check the component's
operation.

1. Turn the ignition switch to LOCK (0). Make sure the headlights and
all other accessories are off.
2. Remove the cover from the fuse box. 3. Check each of the large fuses in
the under-hood fuse box by
looking through the top at the wire inside. Removing these fuses
requires a Phillips-head screw-driver.

CONTINUED

Taking Care of the Unexpected
BLOWNProCarManuals.comMain Menu Table of Contents s t

Index

Break-in, New Car......................... 108
Brightness Control, Instruments... 41
Brights, Headlights......................... 40
Bulb Replacement Back-up Lights........................... 181
Brake Lights............................... 181
Ceiling Light............................... 183
Front Parking Lights................. 180
Front Side Marker Lights......... 180
Headlights.................................. 179
License Plate Lights.................. 182
Specifications............................. 221
Turn Signal Lights..................... 180
Bulbs, Halogen............................... 179

Cables, Jump Starting With.......... 203

Capacities Chart............................. 220

Carbon Monoxide Hazard.............. 29

Cargo, Loading............................... 116

Cassette Player
Care............................................. 101

Operation................................ 87, 99
CAUTION, Explanation of............... ii
CD Player ................................. 90, 102 Center Pocket.................................. 68
Certification Label......................... 218
Chains............................................. 176
Change Oil

How to......................................... 150

When to....................................... 142

Changing a Flat Tire..................... 195
Changing Engine Coolant............. 154
Charging System Indicator.... 34, 207
Checking Automatic Transmission

Fluid........................................ 157

Battery Condition...................... 164
Brake Fluid................................. 158
Drive Belts.................................. 170
Engine Coolant........................... 113

Engine Oil................................... 112

Fuses........................................... 211
Power Steering Fluid................. 159
Checklist, Before Driving............. 118
Child Safety...................................... 20
Childproof Door Locks................... 52
Cigarette Lighter............................. 69
Cleaner, Air.................................... 160

Cleaning
Aluminum Wheels..................... 187 Carpeting.................................... 188

Exterior....................................... 186

Fabric.......................................... 188

Interior........................................ 188

Seat Belts.................................... 189
Vinyl............................................ 188

Window....................................... 189

CLEAN Light................................. 101

Clock, Setting the ............................ 66

CO in the Exhaust......................... 225

Cold Weather, Starting in............. 119
Compact Spare............................... 194
Consumer Information*................ 230
Controls, Instruments and.............. 33

Coolant
Adding.........................................152

Checking..................................... 113
Proper Solution.......................... 152
Temperature Gauge.................... 38
Corrosion Protection..................... 190

Crankcase Emission Control
System......................................... 225
Cruise Control Operation............... 46
Customer Relations Office........... 231ProCarManuals.comMain Menu s t

Index

DANGER, Explanation of................. ii
Dashboard........................................ 32
Dashboard Compartment............... 68
Daytime Running Lights................. 40
Dead Battery, What to Do............ 202
Defects, Reporting Safety............. 234
Defogger, Rear Window................. 43
Defrosting the Windows................. 79 DEXRON ®
III Automatic
Transmission Fluid.................... 157
Dimensions..................................... 220
Dimming the Headlights................ 40
Dipstick Automatic Transmission........... 157

Engine Oil................................... 112

Directional Signals........................... 41
Disabled, Towing Your Car If...... 215
Disc Brake Wear Indicators......... 125
Disposal of Used Oil...................... 151 Doors Locking and Unlocking............... 50
Power Door Locks....................... 50
DOT Tire Quality Grading........... 223
Drive Belts...................................... 170
Driving............................................ 117

Economy..................................... 114

In Bad Weather.......................... 126

In Foreign Countries................. 109

Economy, Fuel............................... 114

Emergencies on the Road............. 193
Battery, Jump Starting.............. 202

Changing a Flat Tire................. 195
Charging System Indicator ...... 207
Checking the Fuses................... 211
Low Oil Pressure Indicator...... 206
Malfunction Indicator Lamp .... 208
Manually Closing Sunroof........ 209
Overheated Engine................... 204

Emergency Brake............................ 65

Emergency Flashers....................... 43
Emission Controls......................... 225
Engine

Belts............................................. 170

Coolant Temperature Gauge ..... 38
Malfunction Indicator
Lamp................................. 34, 208

Oil Pressure Indicator......... 34, 206 Oil, What Kind to Use............... 148

Overheating................................ 204

Specifications............................. 221

Ethanol in Gasoline ....................... 109

Evaporative Emission Controls.... 225

Exhaust Fumes................................ 29

Expectant Mothers, Use of Seat
Belts by......................................... 10

Exterior, Cleaning the................... 186

Fabric, Cleaning............................. 188
Fan, Interior...................................... 74
Features, Comfort and Convenience................................. 73
Filling the Fuel Tank..................... 110
Filter
Air................................................ 160

Oil................................................ 150

First Gear Position......................... 122 Flashers, Hazard Warning.............. 43
Flat Tire, Changing a.................... 195
CONTINUEDProCarManuals.comMain Menu s t

Index

Fluids Automatic Transmission........... 157

Brake........................................... 158

Power Steering........................... 159
Windshield Washer................... 156
FM Stereo Radio
Reception...................................... 97

Folding the Second Seats ............... 58
Folding the Third Seats.................. 60
Foreign Countries, Driving in...... 109

Four-way Flashers........................... 43

Front End, Towing by Emergency Wrecker...................................... 215

Fuel.................................................. 108
Fill Door and Cap....................... 110

Gauge............................................ 38

Octane Requirement................. 108

Oxygenated................................ 108

Tank, Filling the......................... 110

Fuses, Checking the...................... 211

Gas Mileage, Improving................ 114

Gasohol........................................... 108
Gasoline.......................................... 108

Gauge............................................ 38

Octane Requirement................. 108
Tank, Filling the......................... 110
Gas Station Procedures................. 110
Gauges Engine Coolant Temperature .... 38

Fuel................................................ 38

Gearshift Lever Positions............. 120

Glass Cleaning............................... 189

Glove Box......................................... 53
Halogen Headlight Bulbs.............. 179 Hazard Warning Flashers............... 43
Headlights......................................... 40 Aiming......................................... 177
Daytime Running Lights............. 40
High Beam Indicator................... 36
High Beams, Turning on............ 40Low Beams, Turning on............. 40
Reminder Chime.......................... 40
Replacing Halogen Bulbs ......... 179

Turning on....................................
40

Head Restraints...............................
56Heating and Cooling........................ 74
High Altitude, Starting at.............. 119
High-Low Beam Switch .................. 40
Hood, Opening the ........................ 111
Horn................................................... 39
Hot Coolant, Warning about........ 152
Hydroplaning.................................. 129

Identification Number, Vehicle.... 218

If Your Car Has to be Towed....... 215

Ignition
Keys............................................... 49
Switch............................................ 49
Timing Control System............. 226
Indicator Lights, Instrument
Panel..............................................33

Infant Restraint................................ 22

Inflation, Proper Tire .................... 171

Inside Mirror.................................... 64

Inspection, Tire.............................. 173
Instrument Panel............................. 33

Instrument Panel Brightness......... 41

Interior Cleaning............................ 188
Interior Lights.................................. 70ProCarManuals.comMain Menu s t
