The Mechanical Cluster
[IS01400(ALL)12/95]
The following warning lights and gauges are on the Mechanical
Cluster. All of these indicators alert you to the status of vehicle
systems or possible problems with your vehicle. Some of the
lights listed are optional. The following section explains each of
the indicators.
[IS02100(ALL)12/95]
Warning and Indicator Lights
%*
[IS02200(ALL)03/96]
Brake System Light
[IS02300(ALL)07/96]
The warning light for the brakes indicates two things Ð that
either the parking brake is on or not fully released, or that the
brake fluid level is low in the master cylinder reservoir. If the
fluid level is low, add fluid to the reservoir as defined under
the procedure in ªMaintenance and Care.º
[IS02400(ALL)12/95]
6 pica art:0050144-B
The brake system light
[IS02500(ALL)07/96]
The BRAKE light normally comes on when you turn the
ignition key to the ON or START position to verify that the
indicator bulb is working. If the light stays on or comes on
when the engine is running and after you have released the
parking brake fully, check the brake fluid.
*
[IS02600(ALL)03/96]
RWARNING
The BRAKE light indicates that the brakes may not be
working properly. Have the brakes checked immediately.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

12
% [IS02700(ALL)12/95]
Anti-lock Brake System (ABS) Warning Light
*
[IS02800(ALL)01/96]
To check the anti-lock brake warning light, turn the ignition key
to the ON position. The ABS warning light should glow
momentarily.
*
[IS02900(ALL)01/96]
NOTE: If it does not glow at all or stays on for a long time,
have your vehicle's electrical system checked
immediately.
[IS03000(ALL)12/95]
6 pica art:0050147-B
The anti-lock brake warning light
*
[IS03100(ALL)03/96]
RWARNING
If the anti-lock brake system warning light remains on or
comes on while driving, have the braking system checked
by a qualified service technician as soon as possible.
*
[IS03200(ALL)03/96]
NOTE: If a fault occurs in the anti-lock system, and the brake
warning light is not lit, the anti-lock system is
disabled but normal brake function remains
operational.
%*
[IS03300(ALL)03/96]
Safety Belt Warning Light and Chime
*
[IS03400(ALL)03/96]
This warning light and chime remind you to fasten your safety
belt. The following conditions will take place:
[IS03500(ALL)12/95]
n
If the driver does not fasten the safety belt before the
ignition is turned to ON, the chime will sound for four (4) to
eight (8) seconds and the light will illuminate for one (1) to
two (2) minutes, or until the safety belt is fastened.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

Instrumentation
13
[IS03600(ALL)12/95]
n
If the driver fastens the safety belt before the ignition is
turned to ON, the chime will not sound and the light will
not illuminate.
[IS03700(ALL)12/95]
n
If the safety belt is buckled while the light is on and the
chime is sounding, both the light and the chime turn off.
[IS03800(ALL)12/95]
6 pica art:0050148-B
The safety belt warning light
%*
[IS03900(ALL)03/96]
Check Engine Warning Light
%*
[IS04000(ALL)05/96]
This light illuminates when the engine's Emission Control
System requires service. It will also illuminate when the ignition
key is in the ON position and the engine is off.
[IS04100(ALL)12/95]
6 pica art:0050065-B
The check engine warning light
*
[IS04200(ALL)05/96]
Modifications or additions to the vehicle may cause incorrect
operation of the OBD II system. Additions such as burglar
alarms, cellular phones, and CB radios must be carefully
installed. Do not install these devices by tapping into or running
wires close to powertrain control system wires or components.
*
[IS04300(ALL)05/96]
The light comes on briefly when you turn the ignition key to
ON, but it should turn off when the engine starts. If the light
does not come on when you turn the ignition toONor if it
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

Instrumentation
15
*
[IS04900(ALL)05/96]
After completing the three consecutive warm up cycles and on
the fourth engine start up, the Service Engine Soon Warning
Light should turn off. If the light does not go off after the
fourth engine re-start, have your vehicle serviced by your dealer
or a qualified technician.
%*
[IS05000(ALL)01/96]
Charging System Light
[IS05100(ALL)07/96]
This light indicates that your battery is not being charged. The
light illuminates briefly during the display self-test every time
you turn your ignition key to the ON position. The light will go
off when the key is turned to the START position. The light
should stay off when the self-test is done if the engine is
running and the alternator is charging.
*
[IS05200(ALL)03/96]
If the light stays on or illuminates when the engine is running,
have the electrical system checked as soon as possible.
[IS05300(ALL)12/95]
6 pica art:0050149-B
The charging system light
% [IS05400(ALL)07/96]
Oil Pressure Light
[IS05500(ALL)12/95]
6 pica art:0050150-B
The oil pressure light
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

16
[IS05600(ALL)12/95]
This light indicates the engine's oil pressure, not the oil level.
However, if your engine's oil level is low, it could affect the oil
pressure. The light should come on every time your ignition key
is turned to ON or START, and should go out when the engine
starts. If the light stays on or turns on while the engine is
running, you have lost oil pressure and continued operation will
cause severe engine damage.
*
[IS05700(ALL)07/96]
If you lose engine oil pressure:
*
[IS05800(ALL)07/96]1.
Pull off the road as soon as safely possible.
*
[IS05900(ALL)07/96]2.
Shut off the engine immediately. If you do not stop the
engine as soon as safely possible, severe engine damage
could result.
[IS06000(ALL)07/96]3.
Check the engine's oil level. (See ªChecking and Adding
Engine Oilº in theMaintenance and Carechapter of this
Owner Guide.) If you do not follow these instructions, you
or others could be injured. To ensure an accurate reading,
your vehicle should be on level ground.
[IS06100(ALL)07/96]4.
If the level is low, add only as much oil as necessary before
you start the engine again. Do not overfill. Do not operate
the engine if the light is on regardless of the oil level.
Contact your nearest dealer for further service.
%*
[IS07000(ALL)01/96]
Door Ajar Warning Light
*
[IS07100(ALL)01/96]
If the ignition switch is in the ON position and any door or the
liftgate is not completely closed, the light will illuminate.
[IS07200(ALL)12/95]
If the light illuminates, safely stop the vehicle and check and
close all doors until the light turns off.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

18
[IS08000(ALL)12/95]
If one or both of your turn signal indicators does not light up
or remains on continuously when you signal a turn, have the
turn signaling system serviced as soon as possible.
%*
[IS08100(ALL)05/96]
High Beam Light
[IS08200(ALL)12/95]
This light comes on when the headlamps are turned to high
beam or when the high beams are flashed. If your vehicle is
equipped with Daytime Running Lights (Canadian vehicles
only) and the headlamps are on when the high beams are
flashed, the high beam indicator will not light.
[IS08300(ALL)12/95]
6 pica art:0050154-B
The high beam indicator light
% [IS08400(ALL)07/96]
Low Windshield Washer Fluid Level Warning
(Optional Chime with Light)
[IS08500(ALL)07/96]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
[IS08600(ALL)07/96]
The washer fluid is only checked when the engine is started or
the windshield washers are in operation. The light will not
come on if the fluid level becomes low while you are driving
unless you turn on the windshield washers.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

Instrumentation
23
% [IS15000(ALL)04/96]
Tachometer (If equipped)
*
[IS15100(ALL)03/96]
The tachometer will show you the engine's speed measured in
revolutions per minute (RPM).
*
[IS15200(ALL)03/96]
The tachometer may move slightly when the key is placed in
the ACC or ON position, with the engine off. This is normal
and does not affect the performance of the tachometer when the
engine is running.
[IS15300(ALL)01/96]
Some vehicles are equipped with an engine speed (RPM)
limiting device that is contained within the Electronic Engine
Control Module. The purpose of this device is to maintain peak
engine speed (RPM) below a specified limit. (Engine speed
limits may vary based on engine size.)
*
[IS15400(ALL)03/96]
If you are experiencing an ªengine cut-outº condition at high
speeds, it may be the result of this limiting device. It is a
normal condition and can be avoided by reducing
vehicle/engine speed.
[IS15500(ALL)01/96]
10-1/2 pica
art:0050168-B
The tachometer
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

26
[IS15519(ALL)07/96]
This light indicates the engine's oil pressure, not the oil level.
However, if your engine's oil level is low, it could affect the oil
pressure. The light will come on briefly during the display
self-test every time you turn your key to the ON position. The
light will go off when the key is turned to the START position.
The light should stay off when the self-test is done if the engine
is running with normal oil pressure. If the light comes on while
the engine is running, you have lost oil pressure and continued
operation will cause severe engine damage.
*
[IS15521(ALL)07/96]
If you lose engine oil pressure:
*
[IS15523(ALL)07/96]1.
Pull off the road as soon as safely possible.
*
[IS15525(ALL)07/96]2.
Shut off the engine immediately. If you do not stop the
engine as soon as safely possible, severe engine damage
could result.
[IS15527(ALL)07/96]3.
Check the engine's oil level. (See ªChecking and Adding
Engine Oilº in theMaintenance and Carechapter of this
Owner Guide.) If you do not follow these instructions, you
or others could be injured. To ensure an accurate reading,
your vehicle should be on level ground.
[IS15529(ALL)07/96]4.
If the level is low, add only as much oil as necessary before
you start the engine again. Do not overfill. Do not operate
the engine if the light is on regardless of the oil level.
Contact your nearest dealer for further service.
% [IS15531(ALL)07/96]
Low Windshield Washer Fluid Level Warning Light
[IS15533(ALL)07/96]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996
