1997 FORD WINDSTAR window

172
[SS13600(ALL)12/95]
10-1/2 pica
art:0050166-A
The shoulder belt height adjuster
[SS13700(ALL)12/95]
Combination Lap and Shoulder Belt Ð Second Row
Bench Seat
*
[SS13800(ALL)01/96]
There is a unique safety restraint system for the outside seating
position of the second row bench seat. It is very important that
you read and understand this section before anyone rides in the
outside seating position (near the sliding door) of the
two-passenger bench seat.
[SS13900(ALL)12/95]
In addition to safety belt anchorages in the floor and roof
structures, the second row bench seat has a detachable safety
belt anchor mounted to the right window side of the seat. The
safety belt should always remain attached to this anchor except
when removing this seat.
[SS14000(ALL)12/95]
The second row passenger side outboard seating position uses a
hook above the sliding door to stow the shoulder safety belt
when entering or exiting the vehicle or when it is not being
used.
[SS14100(ALL)05/96]
NOTE: When the belt is stowed using the hook, DO NOT use
the hanging belt as an assist when entering the
vehicle.
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

Seating and Safety Restraints
193
[SS24900(ALL)12/95]5.
Place the child on the child seat and position the shoulder
belts over each shoulder. Refer to Figure 4.
[SS25000(ALL)12/95]
10-1/2 pica
art:0050139-B
Figure 4: Shoulder safety belt placement on the child
[SS25100(ALL)12/95]
NOTE: Read the following steps carefully to become familiar
with the indicator windows located on each safety belt
tongue and the chest clip. When either of the tongues
or the chest clip is unbuckled, the color red appears in
the window. When the tongues or chest clip are
securely buckled, the color green appears.
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

194
[SS25150(ALL)02/96]6.
Insert either the left or right safety belt tongue into the
single opening of the crotch safety belt buckle as shown in
Figure 5. (It does not matter which tongue is inserted first.)
Then insert the other tongue. The color green must appear in
the indicator window on each tongue when buckled.
[SS25200(ALL)12/95]
27-1/2 pica
art:0050140-B
Figure 5: Fastening the crotch safety belt buckle
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

202
*
[SS29300(ALL)05/96]
Installing Child Safety Seats in the Front Seat and Rear
Window Passenger Seating Positions
[SS29400(ALL)12/95]
Your vehicle is equipped with a dual locking mode retractor on
the shoulder belt portion of the combination lap/shoulder safety
belt for the front seat passenger and for the rear window
passengers.
[SS29500(ALL)12/95]
If you choose to install a forward-facing child seat or infant
carrier in the front seating positions, move the seat as far back
as possible.
*
[SS29600(ALL)01/96]
For seating positions equipped with a dual-locking mode
retractor, use the following procedure:
[SS29700(ALL)12/95]1.
Position the child seat in the center of passenger seat.
*
[SS29800(ALL)02/96]2.
Pull down on shoulder belt, then grasp shoulder belt and lap
belt together. See Figure 1.
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

Starting
221
*
[TO04300(ALL)01/96]
Have the exhaust and body ventilation systems checked by a
qualified technician whenever:
*
[TO04400(ALL)01/96]
n
your vehicle is raised for service
*
[TO04500(ALL)01/96]
n
the sound of the exhaust system changes
*
[TO04600(ALL)01/96]
n
your vehicle has been damaged in an accident
[TO04700(ALL)12/95]
If the exhaust system has any indications of leaks it should be
repaired immediately.
*
[TO04800(ALL)01/96]
Improve your ventilation by keeping all air intake vents clear of
snow, leaves, and other objects.
[TO04900(ALL)12/95]
If the engine idles while you are stopped in an open area for
long periods of time, open the windows at least one inch. Also,
adjust the heating or air conditioning to bring in outside air.
*
[TO05000(ALL)01/96]
Read the sectionClimate Control Systemsfor instructions on
bringing fresh outside air into your vehicle. Refer to the Index.
File:08wntos.ex
Update:Thu Jul 18 11:01:04 1996

351
Accessories
[AC00500(ALL)12/93]
Ford Accessories for Your Windstar
[AC00600(ALL)11/93]
Many accessories for your Windstar are available through your
local authorized dealer. These accessories have been designed to
meet your needs and are custom designed to complement the
style and aerodynamics of your vehicle. Some of the available
accessories are listed below.
*
[AC00700(ALL)01/93]
Safety, Comfort, and Convenience
*
[AC00800(ALL)06/93]
Comfort and Convenience
[AC00900(ALL)04/95]
Engine Block Heater (Standard in Canada)
Remote Keyless Entry
*
[AC01000(ALL)01/93]
Protection and Appearance Equipment
[AC01100(ALL)04/95]
Aero Running Boards
Molded Running Boards
Carpet Floor Mats
Cleaners, Waxes and Polishes
Front End Cover
Front End Mini Cover
Lubricants and Oils
Side Window Shields
Styled Wheel Protector Locks
Rear Air Deflector
Door Edge Guards
File:15wnacs.ex
Update:Thu Jul 18 11:02:08 1996

372
Coolant (see Engine coolant) (continued)
refill capacities................... 334
specifications..................293, 335
temperature gauge................ 21,29
warnings...................... 292
Cooling fan...................... 279
Cupholder(s)...................... 99
Customer Assistance Center, Ford (U.S.)......... 342
Customer Assistance Centre, Ford of Canada...... 349
D
Daytime running light system.............. 97
Defrost
rear window..................... 93
windshield...................... 85
Dipstick....................... 287
automatic transaxle fluid............... 298
engine oil..................... 287
Disabled vehicle (see Towing)............. 278
Dispute Settlement Board............... 344
Doors........................ 121
door ajar warning light................ 16
lubricant specifications................ 335
Driving under special conditions
bad weather.................... 243
heavy load..................... 245
high speed..................... 243
high water..................... 244
slippery roads................... 243
tips for safe driving................. 242
towing a trailer................... 246
File:wnixs.ex
Update:Thu Aug 1 08:57:39 1996

381
Index
Mirrors (continued)
side view mirrors (manual).............. 129
side view mirrors (power).............. 130
vanity mirror, illuminated.............. 120
Motorcraft parts.................... 333
N
New vehicle break-in.................. 4
O
Octane rating..................... 312
Odometer
description.................... 22,31
trip odometer..................... 22
Oil filter....................... 288
Oil (see Engine oil).................. 286
Oil viscosity...................... 286
On-board diagnostic (OBD II) system.......... 321
Overdrive....................... 231
Overseas offices.................... 347
P
Panic alarm feature, remote entry system........ 141
Parking brake
operation...................... 226
warning light..................... 11
Parts (see Motorcraft Parts)............... 333
PCV valve, specifications................ 333
Power door locks................... 124
Power features
door locks..................... 124
lumbar support................... 149
mirrors....................... 129
seats........................ 148
windows...................... 125
File:wnixs.ex
Update:Thu Aug 1 08:57:39 1996
