1997 FORD PROBE ECO mode

43 %
*
[AS28400(ALL)01/96]
Clock Operation
*
[AS28500(ALL)08/95]
How to view the clock mode
*
[AS28650(ALL)08/95]
Press the ªCLOCKº button to alternate the
frequency and time in the display. In the clock
mode, pressing any radio function will
automatically display the radio frequency for
approximately ten seconds before changing back
to the clock mode.
*
[AS28800(ALL)08/95]
How to set the clock
*
[AS28900(ALL)08/95]
1. Turn the radio on.
*
[AS29025(ALL)04/96]
2. Press and hold in the ªCLOCKº button.
Press the ªSEEKº button left (
b) to advance
the hours and right (
a) to advance the
minutes.
*
[AS29200(ALL)09/95]
NOTE: The clock displays 12-hour time with
no AM/PM indications.
%*
[AS29250(ALL)03/96]
Radio Antenna
[AS29300(ALL)03/96]
The radio antenna is mounted on the rear
passenger side quarter panel of the vehicle. It is
a fixed mast antenna and cannot be retracted.
%*
[AS35200(ALL)04/96]
Common Radio Reception Conditions
*
[AS35300(ALL)08/95]
Several conditions prevent FM reception from
being completely clear and noise-free, such as
the following:
*
[AS35400(ALL)08/95]
1. Distance/Strength
*
[AS35500(ALL)08/95]
The strength of the FM signal is directly related
to the distance the signal must travel. The
listenable range of an average FM signal is
approximately 25 miles (40 kilometers). Beyond
this distance, the radio is operating in a fringe
area and the signal becomes weaker.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

86 [CF50300(ALL)01/96]By pressing the UNLOCK button on the
transmitter once, you can unlock the driver side
door. Pressing the UNLOCK button a second
time within five seconds of unlocking the
driver's door will unlock the other doors.
[CF50400(ALL)01/96]
You can lock all your vehicle doors by pressing
the LOCK button. If you press the LOCK button
a second time within five (5) seconds, the horn
will sound briefly to verify that the doors have
been locked.
[CF50500(ALL)01/96]
When the PANIC button is pressed, the horn
will sound and the hazard warning lamps will
flash. This will continue for up to approximately
two minutes and 45 seconds unless it is turned
off by pressing the PANIC button a second time.
The panic mode can also be cancelled by turning
the ignition key to ON or ACC.
[CF50600(ALL)01/96]
Up to four transmitters can be programmed for
your vehicle. Your vehicle comes with two
transmitters. Additional transmitters can be
ordered from your dealer.
[CF50700(ALL)05/96]
one third page art:0090226-A
Remote keyless entry transmitter
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

113 %
*
[SS16800(ALL)01/96]
Safety Seats for Children
[SS16900(ALL)01/96]
Use a safety belt that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
*
[SS17000(ALL)01/96]
Ford recommends the use of a child safety seat
having a top tether strap. Install the child safety
seat in a seating position which is capable of
providing a tether anchorage. For more
information on top tether straps seeAttaching
Safety Seats With Tether Strapsin this chapter.
*
[SS17100(ALL)05/96]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position, and make sure the tongue is securely
fastened in the buckle. For a shoulder/lap belt
combination with a sliding tongue, make sure
the retractor is in the automatic locking mode.
%*
[SS17300(ALL)05/96]
RWARNING
When using forward-facing child seats
move the passenger seat as far back from
the instrument panel as possible. Never
secure rear-facing child seats or infant
carriers in the front seat.
*
[SS17400(ALL)05/96]
The force of the rapidly inflating passenger air
bag could push the top of the rear-facing seat
against the vehicle seatback, armrests or console.
Rear-facing infant seats must always be secured
in the rear seat.
*
[SS17500(ALL)05/96]
All child restraint systems are designed to be
secured in vehicle seats by lap belts or by the
lap portion of a lap-shoulder belt.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

133
Driving
%*
[GF00300(ALL)05/96]
Brakes
%*
[GF00400(ALL)01/96]
Applying the Brakes
[GF00500(ALL)04/96]
Your vehicle may have four-wheel power
anti-lock disc brakes which adjust automatically
through everyday use.
[GF00600(ALL)04/96]
Some models have power front disc brakes and
rear drum brakes which automatically adjust as
the brake pads and linings wear down.
*
[GF00700(ALL)01/96]
If your vehicle does not have anti-lock brakes,
apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
*
[GF00800(ALL)01/96]
If your vehicle does not have anti-lock brakes,
extreme braking can make the wheels lock and
slide, causing you to lose control of the steering.
If the wheels lock, release the brake pedal and
repeat the ªsqueezeº technique.
*
[GF00900(ALL)01/96]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
*
[GF00950(ALL)02/96]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997

145
*
[GF06900(ALL)05/96]
When to use 2 (Second)
[GF07000(ALL)01/96]
Use Second (2) to help drive up moderately
steep hills or when starting on slick surfaces. It
prevents the transaxle from frequently shifting
up and down. It also gives more engine braking
than Overdrive or Drive when going down hills.
[GF07100(ALL)01/96]
Do not go faster than 64 mph (102 km/h) with
the gearshift in the Second (2) position. If you
shift from Overdrive or Drive to Second because
of hilly terrain, your transaxle will automatically
downshift in the proper sequence.
*
[GF07200(ALL)01/96]
When to use 1 (First)
[GF07300(ALL)01/96]
When your vehicle is in First (1), it gives more
engine braking to slow your car than Drive (D
with Overdrive OFF) on downgrades.
[GF07400(ALL)01/96]
Do not go faster than 32 mph (50 km/h) in this
gear. You can upshift from First (1) into D
Position at any speed. If you shift from
Overdrive or Drive to First (1) because of hilly
terrain, your transaxle will automatically
downshift in the proper sequence.
[GF07500(ALL)04/96]
Reverse
[GF07600(ALL)01/96]
In the Reverse (R) position, the vehicle moves
only backward. Your vehicle must be stopped
before shifting into Reverse (R).
[GF07700(ALL)04/96]
Neutral
[GF07800(ALL)01/96]
In Neutral (N), the wheels of the transaxle are
not locked. Your vehicle will roll freely, even on
the slightest incline, unless the parking brake or
brakes are on.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997

211 %
*
[MC26400(ALL)01/96]
Replacing the Tires
[MC26500(ALL)01/96]
We recommend that you use the same size and
type when making tire replacements. The
standard model uses P195/65 R14 tires, and the
GT model is equipped with P225/50VR16 tires.
If your standard model vehicle is equipped with
a 3-spoke aluminum wheel, you will need
P205/55H R15 tires.
*
[MC26700(ALL)01/96]
Replace any tires that show wear bands. When
your tire shows a wear band, it has only 1/16
inch (2 mm) of tread left.
*
[MC26800(ALL)01/96]
quarter page art:0060006-A
A worn-out tire
*
[MC26900(ALL)02/96]
Because your vehicle's tires may wear unevenly,
you may need to replace them before a wear
band appears across the entire tread.
*
[MC27000(ALL)01/96]
RWARNING
When replacing full size tires, never mix
radial, bias-belted, or bias-type tires. Use
only the tire sizes that are listed on the
tire pressure decal. Make sure that all tires
are the same size, speed rating, and
load-carrying capacity. Use only the tire
combinations recommended on the decal.
If you do not follow these precautions,
your vehicle may not drive properly and
safely.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

214
*
[MC28725(ALL)05/96]
RWARNING
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive
speed, underinflation, or excessive
loading, either separately or in
combination, can cause heat buildup and
possible tire failure.
%*
[MC28750(ALL)01/96]
Snow tires
*
[MC28770(ALL)01/96]
During the winter months in some climates, you
may need to use snow tires and occasionally
chains for your tires.
*
[MC28790(ALL)01/96]
RWARNING
Snow tires must be the same size and
grade as the tires you currently have on
your vehicle.
*
[MC28810(ALL)01/96]
Use chains on the tires only in an emergency or
if the law requires them where you live. If you
choose to use chains on your vehicle's tires, be
aware of the following:
*
[MC28820(ALL)01/96]
q
Tire chains may scratch or chip aluminum
wheels. IT IS RECOMMENDED THAT TIRE
CHAINS ARE INSTALLED ON STEEL
WHEELS ONLY. Be sure to remove wheel
covers (if equipped) from steel rims before
using tire chains to avoid scratches or
damage.
[MC28830(ALL)04/96]
q
Do not use tire chains if you have the GT
model.
*
[MC28840(ALL)01/96]
q
Local regulations may prohibit or restrict the
use of tire chains. Investigate the laws and
regulations in your area before installing
chains.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

220
*
[MC34350(ALL)08/95]
q
Avoid breathing vapors while refueling.
*
[MC34400(ALL)08/95]
q
If fuel is splashed on the skin, wash with
soap and water.
*
[MC34500(ALL)08/95]
q
If fuel is splashed in the eyes, remove contact
lenses (if worn), flush with water for 15
minutes, and seek medical attention.
*
[MC34600(ALL)01/96]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
*
[MC34700(ALL)01/96]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
%*
[MC34800(ALL)01/96]
Running Out of Fuel
*
[MC34900(ALL)08/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
*
[MC35000(ALL)01/96]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
%*
[MC35100(ALL)03/96]
Fuel Economy
*
[MC35150(ALL)01/96]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[MC35200(ALL)01/96]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
