231
*
[MC18000( ALL)12/95]
q
Reinstall the pressure cap securely.
*
[MC18100( ALL)12/95]
q
Check for leaks at the draincock.
*
[MC18200( ALL)12/95]
q
Recheck the engine coolant level, using the
recommended procedure, after one or two
occasions of vehicle use.
%
*
[MC18300( ALL)01/96]
Power Steering Fluid
*
[MC18400( ALL)01/96]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
%*
[MC18500( ALL)01/96]
Checking and Adding Power Steering
Fluid
[MC18650(M )04/96]
3.8L SFI engine (check warm)
*
[MC18700( ALL)04/96]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
*
[MC18800( ALL)01/96]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[MC18900( ALL)01/96]
3. Turn the engine off.
%*
[MC19000(MBC )01/96]
4. Check the fluid level on the dipstick (which
is highlighted in yellow in your vehicle). The
fluid level should be between the arrows in
the FULL HOT range, which is marked on
the side of the dipstick, opposite the side
marked FULL COLD. Do not add fluid if the
level is within the FULL HOT range.
*
[MC19200(MBC )01/96]
5. If the power steering fluid is low, add fluid
in small amounts, continuously checking the
level, until you reach the FULL HOT range.
Do not overfill.
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 230 of 321
232
*
[MC19400(MBC )03/96]
6. When you are finished, put the dipstick back
in and make sure that it fits snugly.
[MC19600(MBC )12/95]
half page art:0010485-C
The dipstick for power steering fluid
[MC19900( ALL)05/96]
Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX or an
equivalent.
*
[MC20000( ALL)01/96]
If the power steering fluid is low, do not drive
your vehicle for a long period of time before
adding fluid. This can damage the power
steering pump.
*
[MC20100(MBC )03/96]
If you check the power steering fluid when it is
cold, make sure that the fluid reaches the FULL
COLD range on the dipstick. The reading will
only be accurate if the fluid temperature is
approximately 50 to85ÊF (10 to 30ÊC).
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 231 of 321
![FORD MUSTANG 1997 4.G Owners Manual 233 [MC20350(M )04/96]
4.6L SFI engine (check cold)
[MC20355(M )04/96]
NOTE: The brakes on the 4.6L engine vehicles
are powered by power steering fluid
from the power steering pump. The
fluid level in FORD MUSTANG 1997 4.G Owners Manual 233 [MC20350(M )04/96]
4.6L SFI engine (check cold)
[MC20355(M )04/96]
NOTE: The brakes on the 4.6L engine vehicles
are powered by power steering fluid
from the power steering pump. The
fluid level in](/manual-img/11/5204/w960_5204-230.png)
233 [MC20350(M )04/96]
4.6L SFI engine (check cold)
[MC20355(M )04/96]
NOTE: The brakes on the 4.6L engine vehicles
are powered by power steering fluid
from the power steering pump. The
fluid level in the power steering
reservoir will rise and fall due to the
amount of charge in the brake booster
accumulator. Therefore the following is
required.
[MC20400(MBC )12/95]
1. Check the fluid level when the system is
COLD (allow at least one half hour after
driving for the power steering fluid to cool).
[MC20500(MBC )04/96]
2. Locate the power steering reservoir mounted
to the front upper left-hand corner of the
engine.
[MC20550(M )04/96]
NOTE: Brake fluid and power steering fluid
CAN NOT be mixed. Only add brake
fluid to the brake master cylinder
reservoir. Only add power steering
fluid to the power steering reservoir.
[MC20600(MBC )12/95]
3. Visually verify that the fluid level is above
the MIN line adjacent to the reservoir ªsight
window.º
[MC20700(MBC )12/95]
4. If the power steering fluid is below the MIN
line, remove the cap and add fluid in small
amounts until the level is between the MIN
and MAX lines.
[MC20800(MBC )12/95]
5. Reinstall the reservoir cap.
[MC20850(M )03/96]
It is normal for the fluid level to be above the
MAX line after the brake pedal has been pushed
several times with the engine off. (If you want
to double check it; restart engine and turn
steering wheel to full right turn, then full left
turn and then turn engine off and re-check fluid
level. It should be between MIN and MAX line.)
File:11rcmcm.ex
Update:Thu Apr 3 07:49:33 1997
Page 232 of 321
234 [MC20950(M )03/96]
half page art:0011388-AFluid level for power steering
[MC21100(MBC )05/96]
Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX or an
equivalent.
*
[MC21200(MBC )01/96]
NOTE: If the power steering fluid is low, do
not drive your vehicle for a long
period of time before adding fluid.
This can damage the power steering
pump.
%
*
[MC21300( ALL)01/96]
Automatic Transmission Fluid
*
[MC21400( ALL)03/96]
Under normal circumstances, you do not need to
check the fluid level of the transmission, since
your vehicle does not use up transmission fluid.
Refer to theMaintenance Schedulebooklet for
replacement intervals. However, if the
transmission is not working properly Ð for
instance, the transmission may slip or shift
slowly, or you may notice some sign of fluid
leakage Ð the fluid level should be checked.
