62 [CF03900(F )04/96]q
Remove any snow, ice or leaves from the air
intake area of your Air Conditioner (if
equipped) and Heater System which could
block the air intake. The intake area is located
at the bottom of the windshield.
% [CF13500(F )04/96]
Dual Fuel Tank Selector Switch
(If equipped)
[CF13700(F )04/96]
To choose which fuel tank that you want your
engine to draw fuel from (front or rear) you
must use this switch. Your fuel gauge will
display the amount of fuel available in the
currently selected tank.
[CF13800(F )04/96]
The fuse that protects the fuel tank selector
circuit is labeled AUX FUEL TANK SELECTOR
on your fuse panel cover.
[CF13900(F )04/96]
quarter page art:0020066-B
Fuel tank selector switch
%*
[CF14000(F )03/96]
The Interior and Exterior Lights
%*
[CF14100(FM)03/96]
Turning On the Exterior Lights
*
[CF14200(FM)01/96]
To turn on your headlamps, parking lamps,
marker lamps, license plate lamps and tail
lamps, use the headlamp switch to the left of the
steering column.
[CF14300(FM)04/96]
1. Pull the headlamp control knob toward you
to the first position. Parking lamps, tail
lamps, license plate lamps and marker lamps
are now on.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

67
*
[CF24100(FM)01/96]
Ignition
%*
[CF24110(FM)01/96]
Understanding the Positions of the Ignition
*
[CF24120(FM)01/96]
quarter page art:0020004-B
The positions of the key in the ignition lock cylinder.
*
[CF24130(FM)01/96]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[CF24140(FM)01/96]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
*
[CF24150(FM)01/96]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transmission gearshift lever.
[CF24160(F )03/96]
LOCK locks the steering wheel. It also locks the
gearshift if your vehicle's gearshift is on the
column.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

68 [CF24180(F )04/96]
RWARNING
LOCK position does not lock the gearshift
on floor-mounted gearshifts. If the
parking brake is not set and the gearshift
is moved out of Park (automatic
transmission) or out of gear (manual
transmission), your vehicle may move
unexpectedly.
*
[CF24200(F )05/96]
With the transfer case in N (Neutral), the vehicle
is free to move with either the automatic
transmission in P (Park) or with the manual
transmission in any driving gear.
*
[CF24210(F )05/96]
RWARNING
Do not leave the vehicle unattended with
the transfer case in the N (Neutral)
position. Always set the parking brake
fully and turn off the ignition when
leaving the vehicle.
*
[CF24220(FM)01/96]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
%*
[CF24230(FM)01/96]
If the key is stuck in the LOCK position, move
the steering wheel left or right until the key
turns freely.
%*
[CF24240(FM)04/96]
ACCESSORY allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running.
*
[CF24250(F )03/96]
In order to turn the key from the ON or OFF
position to the ACCESSORY position, you must
push the key release button if your vehicle's
manual transmission gearshift is mounted on the
floor.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

69 %
*
[CF24260(F )03/96]
Ignition Key Buzzer or Chime
*
[CF24270(F )05/96]
The buzzer or chime will sound if you open the
driver's door while the key is in the ignition and
in the OFF, LOCK, or ACCESSORY position.
Never leave your vehicle unattended with the
key in the ignition.
%*
[CF24280(FM)03/96]
Removing the Key From the Ignition
*
[CF24290(F )03/96]
Procedures for removing your key from the
ignition will vary, depending on the type of
gearshift your vehicle has. Gearshift levers may
be mounted on the steering column or on the
floor or console.
*
[CF24300(F )03/96]
If you have a manual transmission, you have a
key release lever which allows you to remove
your key from the ignition. The key release lever
is on the upper right of the steering column, just
above the key lock cylinder. The lever says
PUSH.
[CF24310(F )04/96]
quarter page art:0020833-A
Key release lever
*
[CF24330(F )03/96]
If your vehicle's gearshift lever is mounted
on the column:
*
[CF24350(FM)03/96]
1. Put the gearshift in P (Park).
*
[CF24360(FM)03/96]
2. Set the parking brake fully before removing
your foot from the service brake. (This will
avoid ªbindingº or ªloadingº the park gear
if you park on a grade.)
*
[CF24370(FM)03/96]
3. Turn the ignition key to LOCK.
*
[CF24380(FM)03/96]
4. Remove the key.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

71
%*
[CF26900(FM)02/96]
The Turn Signal Lever
*
[CF27000(FM)02/96]
You can use the turn signal lever on the left side
of the steering column to:
*
[CF27100(FM)02/96]
q
operate the turn signals and cornering lamps
*
[CF27200(F )03/96]
q
turn the high beams on/off
*
[CF27300(F )03/96]
q
flash the lamps
*
[CF27400(F )03/96]
q
turn the windshield wipers and washer
on/off
%*
[CF27500(FM)01/96]
Turn Signals
*
[CF27600(FM)01/96]
Move the lever up to signal a right turn. Move
it down to signal a left turn. The corresponding
indicator light in the instrument cluster will
flash.
*
[CF27700(FM)01/96]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
[CF27800(FM)04/96]
one third page art:0020081-C
Turn signal lever and functions
*
[CF27900(FM)08/95]
If the turn indicator light in the instrument
panel does not illuminate or remains on (doesn't
flash) when you signal a turn, the turn signaling
system is malfunctioning. Have this condition
corrected as soon as possible, but make sure that
you use the accepted hand signals in the
meantime.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

76
%*
[CF31400(F )03/96]
Tilt Steering (If equipped)
*
[CF31600(FM)02/96]
RWARNING
Never adjust the steering wheel when the
vehicle is moving.
[CF31700(F )04/96]
one third page art:0020089-C
Turn signal and tilt release wheel lever
*
[CF31900(FM)01/96]
To change the position of the steering
column/wheel, pull the release lever on the
column toward you. Tip the steering wheel to
the desired position. Release the lever to lock the
steering wheel in place.
*
[CF32000(FM)01/96]
Be sure the steering wheel locks in a notch. It is
not infinitely adjustable. Do not adjust the
steering wheel while the vehicle is in motion.
%
*
[CF32100(F )03/96]
Speed Control (If equipped)
[CF32600(F )04/96]
quarter page art:0020093-B
The speed control switches
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

86
*
[CF45300(F )08/95]
Fog Lamps (If equipped)
[CF45400(F )04/96]
The fog lamps rocker switch is located on the
instrument panel to the right of the steering
column.
[CF45500(F )04/96]
quarter page art:0020940-A
Fog lamp switch
*
[CF45600(F )03/96]
The fog lamps act as a supplement to the low
beam headlamps under limited visibility
conditions such as rain, snow, dust or fog and
operate only when the low beam headlamps are
on.
*
[CF45700(F )03/96]
To maximize fog lamp bulb life, it is
recommended that the fog lamp switch be
turned off after each use prior to turning off the
headlamps.
[CF45800(F )04/96]
q
To turn the fog lamps on, push the ON side
of the rocker switch. An indicator light will
glow when the lamps are on.
[CF45900(F )04/96]
q
To turn off, push the OFF side of the switch.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

139 %
*
[TO02300(FM)01/96]
Starting Your Engine
*
[TO02400(FM)01/96]
To start your engine:
*
[TO02500(FM)01/96]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[TO02600(FM)01/96]
2. Turn the ignition key to the ON position.
*
[TO02700(FM)01/96]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[TO02800(FM)01/96]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[TO02900(FM)01/96]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
%*
[TO03000(FM)01/96]
For a cold engine:
*
[TO03100(FM)01/96]
q
At temperatures10ÊF (-12ÊC) andbelow:If
the engine does not start infifteen (15)
secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you
do not flood the engine, then try again.
*
[TO03200(FM)01/96]
q
At temperaturesabove10ÊF(-12ÊC):If the
engine does not start infive (5) secondson
the first try, turn the key to OFF, wait
approximately ten (10) seconds so you do not
flood the engine, then try again.
*
[TO03300(FM)01/96]
q
Do not hold the key in the START position
for more thanfifteen (15) secondsat a time.
