1997 FORD F250 key

140 %
*
[TO03400(FM)01/96]
For a warm engine:
*
[TO03500(FM)01/96]
q
Do not hold the key in the START position
for more thanfive (5) secondsat a time. If
the engine does not start within five (5)
seconds on the first try, turn the key to the
OFF position. Wait a few seconds after the
starter stops, then try again.
*
[TO03600(FM)01/96]
Whenever you start your vehicle, release the key
as soon as the engine starts. Excessive cranking
could damage the starter.
*
[TO03700(FM)01/96]
After you start the engine, let it idle for a few
seconds. Keep your foot on the brake pedal and
put the gearshift lever in gear. Release the
parking brake. Slowly release the brake pedal
and drive away in the normal manner.
%*
[TO03800(FM)05/96]
NOTE: Your vehicle is equipped with a
brake-shift interlock feature. This
feature prevents you from shifting
from P (Park) unless you have the
brake pedal depressed. (The ignition
must be in the ON position.) If you
cannot shift from P (Park) with the
brake pedal depressed:
*
[TO03900(FM)05/96]
1. Apply the parking brake.
*
[TO04000(FM)05/96]
2. Remove the key.
*
[TO04100(F )05/96]
3. Insert the key and rotate it one position
clockwise (ignition in the OFF position).
*
[TO04200(FM)05/96]
4. Apply the brake pedal and shift to N
(Neutral). (If the vehicle is shifted back to P
[Park], you must repeat the previous steps.)
*
[TO04300(FM)05/96]
5. Start the vehicle.
File:08lttof.ex
Update:Tue May 28 08:44:45 1996
ProCarManuals.com

141
*
[TO04400(FM)05/96]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledRoadside Emergenciesin
this Owner Guide for instructions on checking
and replacing fuses.
*
[TO04500(FM)05/96]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
[TO04600(FM)04/96]
For cold or warm engines:
*
[TO04700(FM)01/96]
If the engine still does not start after two
attempts:
*
[TO04800(FM)01/96]
1. Turn the ignition key to the OFF position.
*
[TO04900(FM)01/96]
2. Press the accelerator all the way to the floor
and hold it.
*
[TO05000(FM)01/96]
3. Turn the ignition key to the START position.
*
[TO05100(FM)01/96]
4. Release the ignition key when the engine
starts.
*
[TO05200(FM)03/96]
5. Release the accelerator gradually as the
engine speeds up.
*
[TO05300(FM)05/96]
If the engine still does not start, the fuel pump
shut-off switch may have been activated. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchin the index.
*
[TO05500(F )01/96]
A computer system controls the engine's idle
speed. When you start your vehicle, the engine's
idle speed normally runs higher than when it's
warmed up. These faster engine speeds will
make your vehicle move slightly faster than its
File:08lttof.ex
Update:Tue May 28 08:44:45 1996
ProCarManuals.com

154 %
*
[GF07800(FM)05/96]
NOTE: Your vehicle is equipped with a
brake-shift interlock feature. This
feature prevents you from shifting
from P (Park) unless you have the
brake pedal depressed. (The ignition
must be in the ON position.) If you
cannot shift from P (Park) with the
brake pedal depressed:
*
[GF07825(FM)05/96]
1. Apply the parking brake.
*
[GF07850(FM)05/96]
2. Remove the key.
*
[GF07875(FM)05/96]
3. Insert the key and rotate it one position
clockwise (ignition in the OFF position).
*
[GF07900(FM)05/96]
4. Apply the brake pedal and shift to N
(Neutral). (If the vehicle is shifted back to P
[Park], you must repeat the previous steps.)
*
[GF07925(FM)05/96]
5. Start the vehicle.
*
[GF07950(FM)05/96]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledRoadside Emergenciesin
this Owner Guide for instructions on checking
and replacing fuses.
*
[GF07975(FM)05/96]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
%*
[GF08000(FM)05/96]
R (Reverse)
*
[GF08025(FM)05/96]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

224
*
[ER00250(FM)03/96]
RWARNING
If you see or smell fuel, do not reset the
switch or try to start your vehicle. Have
all the passengers get out of the vehicle
and call the local fire department or a
towing service.
*
[ER00252(FM)03/96]
If your engine cranks but does not start after a
collision or substantial jolt:
*
[ER00255(FM)01/96]
1. Turn the ignition key to the OFF position.
*
[ER00260(FM)03/96]
2. Check under the vehicle for leaking fuel.
*
[ER00265(FM)01/96]
3. If you do not see or smell fuel, push the red
reset button down. If the button is already
set, you may have a different mechanical
problem.
*
[ER00270(F )01/96]
4. Turn the ignition key to the ON position for
a few seconds, then turn it to the OFF
position.
*
[ER00280(FM)03/96]
5. Check under the vehicle again for leaking
fuel.If you see or smell fuel, do not start
your vehicle again.If you do not see or
smell fuel, you can try to start your vehicle
again.
*
[ER00285(FM)03/96]
6. Check all vehicle warning lights before
driving your vehicle.
[ER00290(FM)03/96]
quarter page art:0020107-A
Reset button for fuel pump shut-off switch
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

237 %
*
[ER04200(F )02/96]
Spare Tire Location
[ER07200(F )04/96]
The spare tire for your truck is stowed at the
rear under the frame unless you have the
optional in-box spare tire mounting.
[ER07300(F )04/96]
one third page art:0020281-A
Spare tire stowage
*
[ER07400(F )01/96]
To remove the spare tire:
[ER07500(F )04/96]
1. With the tapered end of the lug nut wrench
through the eyebolt eye, loosen the bolt until
the bracket is loose from the upper support.
Be careful you do not loosen too much and
cause the spare to fall.
[ER07600(F )04/96]
2. Line up the eyebolt eye with the channel
slot, the eye toward the tire.
*
[ER07610(F )05/96]
3. Hold the socket end of the wrench parallel
to the ground. Put the tapered end into the
channel assembly tube and lift up on the
wrench. At the same time pull the eyebolt
toward the tube and push on the wrench to
pass the eyebolt through the channel
keyhole.
[ER07800(F )04/96]
4. Lower spare tire, swing the channel to the
rear and remove the lug wrench from the
channel tube.
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

259
*
[MC01900(FM)01/96]
Working with the engine off:
[MC02100(F )01/96]
1. Always set the parking brake fully and make
sure that the gearshift is securely latched in
P (Park) (automatic transmission) or in 1
(First) (manual transmission).
[MC02200(F )04/96]
2. When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if
the automatic transmission is in P (Park) or
the manual transmission is in gear. Do not
leave the vehicle unattended with the
transfer case in the N (Neutral) position.
[MC02300(F )01/96]
3. Remove the key from the ignition after you
turn the engine off.
[MC02400(F )01/96]
4. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC02500(FM)01/96]
Working with the engine on:
[MC02600(F )01/96]
1. Always set the parking brake fully and make
sure that the gearshift is securely latched in
P (Park) (automatic transmission) or in 1
(First) (manual transmission).
[MC02900(F )04/96]
2. When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if
the automatic transmission is in P (Park) or
the manual transmission is in gear. Do not
leave the vehicle unattended with the
transfer case in the N (Neutral) position.
*
[MC03000(FM)01/96]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

370 Index
Child safety restraints.......... 120
child safety belts........... 121
child safety seats........... 122
Child safety seats............ 122
and air bags............. 122
attaching with tether straps...... 133
automatic locking mode (retractor) . . . 122
in front seat............. 122
in rear outboard seat......... 122
in rear seat.............. 122
tether anchorage hardware....... 133
Chime
headlamps on.............. 21
key in ignition............. 69
safety belt............... 17
Circuit breakers
checking and replacing........ 235
see also fuses............. 225
Cleaning your vehicle.......... 312
CD player and discs........... 39
chrome and aluminum parts...... 313
engine compartment.......... 315
exterior.............312±313
exterior lamps............ 314
fabric................ 314
headlamps.............. 314
instrument panel........... 313
instrument panel lens......... 314
interior................ 314
interior lamps............. 314
mirrors................. 81
plastic parts............. 313
polishing............... 313
rustproofing............. 313
safety belts.............. 314
tail lamps.............. 314
File:ltixf.ex
Update:Tue May 28 08:56:20 1996
ProCarManuals.com

378 Index
High-mount brakelamp......... 310
description.............. 310
replacing the bulb........... 310
Hitch.................. 210
Hood.................. 260
latch location............. 260
lubrication specifications........ 324
release lever............. 260
working under the hood........ 258
Horn................... 75
I
Identification Number, Vehicle (VIN).... 7
Idle, relearning.........137, 253, 258
Ignition
chime................. 69
positions of the ignition......... 67
removing the key............ 69
Indicator lights and chimes (see Lights) . . . 12
Infant seats (see Safety seats).....120, 122
Instrument cluster, mechanical....... 15
Instrument panel
cleaning............... 314
lighting up panel and interior...... 64
registers................ 58
Interval wipers............72±73
J
Jack.................. 237
operation.............240, 243
positioning............240, 243
storage................ 237
Jump-starting your vehicle
attaching cables............ 252
disconnecting cables.......... 253
File:ltixf.ex
Update:Tue May 28 08:56:20 1996
ProCarManuals.com
