Electronic engine power
control (E-Gas), checking

E-Gas system, function

For E-Gas, the throttle valve is not operated by a
cable from the accelerator pedal. There is no
mechanical connection between the accelerator
pedal and the throttle valve.
The position of the accelerator pedal is
communicated to the Engine Control Module
(ECM) via two sensors for accelerator pedal
position (variable resistances; stored in one
housing) that are connected with the accelerator
pedal.
The accelerator pedal position (driver's intention)
is a main input unit for the ECM.
Operation of the throttle valve occurs via an
electric motor (throttle valve actuator) in the
throttle valve control module. This is true across
the entire engine speed and engine load
spectrum.
The throttle valve is operated by the throttle valve
actuator according to the instructions of the
ECM.
With ignition switched on and engine off, the
ECM activates the throttle valve actuator
precisely according to the sensor for accelerator
Pa
ge 1 of 41 Electronic en
gine
power control
(E-Gas
), checkin
g
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU05.24.5

pedal position. This means, if the accelerator
pedal is depressed half way, the throttle valve
actuator opens the throttle valve to the same
degree; i.e. throttle valve would be opened half
way.
Pa
ge 2 of 41 Electronic en
gine
power control
(E-Gas
), checkin
g
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU05.24.5

24-135
With engine running (under load), the ECM can
open or close the throttle valve independently of
the sensor for accelerator pedal position.
This means, for example, that the throttle valve
could be fully opened even though the
accelerator pedal has only been depressed half
way. This has the advantage of preventing
torque losses at the throttle valve.
In addition to this, it results in significantly better
values relative to emissions and consumption
under certain load conditions.
It would be incorrect to think that "E-Gas"
consists of only one or two component. E-Gas is
much more of a system containing all
components that contribute to recognizing,
controlling and monitoring the position of the
throttle valve, e.g. sensor for accelerator pedal
position, throttle valve control module, EPC
warning lamp, Engine Control Module (ECM).
Pa
ge 3 of 41 Electronic en
gine
power control
(E-Gas
), checkin
g
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU05.24.5

24-136

Electronic Power Control (EPC) warning
lamp -K132- in instrument cluster,
significance

"EPC" is an abbreviation and stands for
Electronic Power Control (E-gas).

Installation location of EPC warning lamp
Engine Control Module (ECM) checks all components that are important
for function of the E-Gas system after ignition is switched on.
The Engine Control Module (ECM) switches on the EPC warning lamp
after ignition is switched on. Shortly after engine is started, the EPC
warning lamp will go out. This requires, first of all, that the Engine Control
Module (ECM) does not detect a malfunction in the E-gas system and,
secondly, that activation of the lamp by the Engine Control Module (ECM)
is OK.
If malfunctions are recognized in the E-Gas system during operation of
the engine, the ECM switches on the EPC warning lamp in instrument
cluster. (These malfunctions are listed in the DTC table). An entry is made
in DTC memory at the same time.
Pa
ge 4 of 41 Electronic en
gine
power control
(E-Gas
), checkin
g
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU05.24.5

24-137

Electronic Power Control (EPC) warning
lamp -K132-, checking


Note:
The fault light for power accelerator activation -
K132- is also called the EPC warning lamp.

Special Tools and Equipment

VAG1594A

VAG1598/31
Pa
ge 5 of 41 Electronic en
gine
power control
(E-Gas
), checkin
g
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU05.24.5

24-138

Function test of warning lamp

- Switch ignition on.


Engine Control Module (ECM) switches EPC
lamp on.

- Start engine.

Shortly after engine is started, the EPC
warning lamp will go out if there are not
malfunctions stored in DTC memory that
relate to the E-gas system

A- Fault light for power accelerator activation
-K132- does not light up

- Connect VAG1598/31 test box at wiring harness
to ECM, do not connect ECM Page 24
-17
.

- Bridge sockets 1 and 48 of test box.

- Switch ignition on.


Warning lamp must light up.
If warning lamp does not light up:
Pa
ge 6 of 41 Electronic en
gine
power control
(E-Gas
), checkin
g
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU05.24.5

- Switch ignition off.

- Remove instrument cluster:

Repair Manual, Electrical Equipment, Repair
Group 90, Instrument cluster, removing and installing

Pa
ge 7 of 41 Electronic en
gine
power control
(E-Gas
), checkin
g
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU05.24.5

24-139

- Check the following wire connection for open
circuit and short circuit to B+:

Test box
VAG1598/31
Socket
Instrument cluster

Terminal
48 Electrical Wiring Diagrams,
Troubleshooting & Component
Locations binder

- Repair open circuit or short circuit if
necessary.
If wire connection is OK:

- Replace Engine Control Module (ECM) Page
24
-21
.
Pa
ge 8 of 41 Electronic en
gine
power control
(E-Gas
), checkin
g
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU05.24.5
