1997 AUDI A4 AHA Engine Readiness Code Workshop Manual

01-70


Readiness code

Readiness code, checking


Note:
The readiness code will be erased:

When Diagnostic Trouble Code (DTC) memory
is erased
When the Engine Control Module (ECM)
harness connector is disconnected (e.g. to
connect VAG1598/22 test box)
When the battery is disconnected

Required special tools and test equipment
VAG1551 Scan Tool (ST) with VAG1551/3
adapter cable

Checking

- Connect VAG1551/VAG1552 Scan Tool (ST)
and press buttons -0- and -1- to insert "Engine
Electronics" address word 01 (with ignition
switched on) page 01
-8 .
Rapid data transfer
HELP

Indicated on display
Pa
ge 1 of 29 Readiness code
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU03.01.2

Select function XX
- Press buttons -0- and -8- to select "Read Measuring Value Block"
function 08, and press -Q- button to confirm input.
Pa
ge 2 of 29 Readiness code
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU03.01.2

01-71

Read Measurin
g Value Block
HELP
Input display group number XXX

Indicated on display
- Press buttons -0-, -8- and -6- to input display group number 86 (086),
and press -Q- button to confirm input.
Read Measuring Value Block 86
1
2
3
4

Indicated on display (1-4 display fields)
Note:
The readiness code is generated as soon as only zeros are shown in
display field 1. - Check readiness code values in display field 1.
Specified value: 00000000
-
Press button.
Rapid data transfer
HELP
Select function XX

Indicated on display
If the readiness code was not generated, generate readiness code again
page 01
-73
. - Press buttons -0- and -6- to select "End Output" function 06, and press
-Q- button to confirm input.
- Check readiness code page 01
-70
. If DTC memory has been
erased, or ECM has been disconnected from B+, generate readiness
code again page 01
-73
.
Pa
ge 3 of 29 Readiness code
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU03.01.2

01-72
Explanation of 8-digit readiness code Readiness code is generated only when all display values = 0 1
2
3
4
5
6
7
8
Diagnosis
0 Three Way Catalytic Converter (TWC)
0 TWC heating (not applicable / always "0")
0 EVAP system and fuel tank leak detection test
0 Secondary Air Injection (AIR) system
0 Air conditioning system (diagnosis not applicable / always "0")
0 Oxygen Sensor (O2S) control
0 Oxygen Sensor (O2S) heating
0 Exhaust Gas Recirculation (EGR) system (not applicable / always "0")
Pa
ge 4 of 29 Readiness code
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU03.01.2

01-73

Readiness code, generating


Required special tools and test equipment

VAG1551 Scan Tool (ST) with VAG1551/3
adapter cable

Test requirements
No malfunctions stored in DTC memory
Engine not stopped (ignition not switched off)
during the test
Vehicle not moving
All electrical consumers switched off (coolant
fan must not run during test)

Test sequence

- Connect VAG1551/VAG1552 Scan Tool (ST)
and press buttons -0- and -1- to insert "Engine
Electronics" address word 01 (with ignition
switched on) page 01
-8 .
Pa
ge 5 of 29 Readiness code
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU03.01.2

01-74

Step 1: Check DTC memory Rapid data transfer
HELP
Select function XX

Indicated on display
- Press buttons -0- and -2- to select "Check DTC Memory" function 02,
and press -Q- button to confirm input.
No DTC reco
gnized

Indicated on display
If one or more DTCs are stored:
Safety precautions for road testing vehicle page 24
-9
If no DTCs were recognized: - Repair cause of malfunction.
- Erase DTC memory.
- Stop engine, start engine again, and road test.
- Check DTC memory again and erase.
-
Press button.
Pa
ge 6 of 29 Readiness code
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU03.01.2

01-75

Step 2: Erase DTC memory Rapid data transfer
HELP
Select function XX

Indicated on display
Note:
When erasing DTC memory, the readiness code is also erased. - Press buttons -0- and -5- to select "Erase DTC Memory" function 05,
and press -Q- button to confirm input.
Rapid data transfer DTC Memor
y is erased

Indicated on display
-
Press button.
Pa
ge 7 of 29 Readiness code
11/23/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.FU03.01.2

01-76

Step 3: Adaptation of throttle valve control
module to ECM Rapid data transfer
HELP
Select function XX

Indicated on display
- Press buttons -0- and -8- to select "Read Measuring Value Block"
function 08, and press -Q- button to confirm input.
Read Measuring Value Block
HELP
Input displa
y group number XXX

Indicated on display
- Press buttons -0-, -6- and -0- to input display group number 60 (060),
and press -Q- button to confirm input.
Read Measuring Value Block 60
1
2
3
4

Indicated on display (1-4 display fields) - Press -4- button to select "Basic Setting" function 04 (adaptation of
throttle valve control module to ECM)
System in Basic Setting 60
1
2
3
4

Indicated on display (1-4 display fields)
