1997 AUDI A4 01A Transmission Clutch Release Mechanism Service Workshop Manual

30-20


Clutch release mechanism,
servicing
1 -
Transmission
2 -
Ball pivot pin
25 Nm (18 ft lb)Lubricate with MoS2 grease
3 -
Intermediate piece
4 -
Dished washer Smaller diameter (rounded side) faces
guide sleeve
5 -
O-ring Always replace
6 -
Seal for input shaft Pull out of guide sleeve using VW681
extractor lever Drive in onto stop using VW192 fitting
sleeve
7 -
Guide sleeve Before removing and installing, cover input
shaft splines with shrink-tube to protect
seal
8 -
Retaining spring
Pa
ge 1 of 12 Clutch release mechanism, servicin
g
11/19/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.TM02.30.2

Secure to clutch release lever
Pa
ge 2 of 12 Clutch release mechanism, servicin
g
11/19/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.TM02.30.2

30-21


9 -
Clutch release lever
Before installing, coat contact surface of
clutch slave cylinder plunger with thin layer
of copper grease, e.g. 381 351 TE
10 -
Torx bolt Always replace35 Nm (26 ft lb)Self-locking
11 -
Release bearing Do not wash-out bearing, wipe clean onlyReplace noisy bearings
12 -
Bolt

8DVA 000 504 socket-head bolt25 Nm (18 ft lb)

8DVA 000 505 socket-head bolt20 Nm (15 ft lb)
13 -
Clutch slave cylinder Tension clutch slave cylinder enough, so
that mounting bolts can be easily installed. Do not operate after clutch pedal has been
removed
Pa
ge 3 of 12 Clutch release mechanism, servicin
g
11/19/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.TM02.30.2

14 -
Plunger
Lubricate end of plunger with copper
grease, e.g. 381 351 TE
Pa
ge 4 of 12 Clutch release mechanism, servicin
g
11/19/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.TM02.30.2

30-22

Clutch, servicing


Special tools and equipment

3067 flywheel retainer
3176 centering mandrel

Notes:
Observe general repair instructions Page 00
-
14
.

Replace clutch plates and pressure plates
which have damaged or loose rivets.
Select the correct clutch plate and pressure
plate according to the engine code Parts
catalog

Clean input shaft splines and (in the case of
used clutch plates) the hub splines. Remove
corrosion and apply only a very thin coating of
lubricant G 000 100 to the splines. Then move
clutch plate back and forth on input shaft until
hub moves freely on shaft. Excess grease must
be removed.

Pressure plates have an anti-corrosion coating
Pa
ge 5 of 12 Clutch release mechanism, servicin
g
11/19/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.TM02.30.2

and are greased. Only the contact surface may
be cleaned, otherwise the service life of the
clutch will be considerably reduced.
If the clutch has been burned out, thoroughly
clean the bellhousing, flywheel and parts of the
engine facing the transmission to reduce the
smell of burnt clutch.
Pa
ge 6 of 12 Clutch release mechanism, servicin
g
11/19/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.TM02.30.2

30-23


CAUTION!
Clutch plates or pressure plates with loose or
damaged rivets must be replaced. - Remove transmission to work on clutch Page
34
-18
.
A - Color marking on dual-mass flywheel
White color marking -A- on dual-mass
flywheel must line up with white color
marking -B- on pressure plate
B - Color marking on pressure plateWhite color marking -A- on dual-mass
flywheel must line up with white color
marking -B- on pressure plate
Pa
ge 7 of 12 Clutch release mechanism, servicin
g
11/19/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.TM02.30.2

30-24


Repair Manual, Engine Mechanical, Repair
Group 13 1 -
Dual-mass flywheel
Make sure centering pins are in place and
seated correctly Contact surface for clutch lining must be
free of dirt, oil and grease
Removing and installing
2 -
Bolt
Always replaceWith dual-mass flywheel: 60 Nm (44 ft lb) +
1/2 turn (180 ) Without dual-mass flywheel: 60 Nm (44 ft
lb) + 1/4-turn (90 )
Pa
ge 8 of 12 Clutch release mechanism, servicin
g
11/19/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.TM02.30.2
