Battery
SST
R05752
SST
H00401Weighty
y
x
RS−16
− SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
1996 TOYOTA T100 (RM449U)
(d) Check functioning of SST.
SST 09082−00700
(e) Install the SST
CAUTION:
Place the disc wheel on the level ground.
(1) Connect the SST connector to the steering wheel
pad connector.
SST 09082−00700
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock. Also, se-
cure some slack for the SST wire harness inside the disc
wheel.
(2) Move the SST to at least 10 m (33 ft) away from
steering wheel pad tied down on the disc wheel.
(f) Cover steering wheel pad with cardboard box or tires.
Covering method using cardboard box:
Cover the steering wheel pad with the cardboard
box and weight the cardboard box down in 4 places
with at least 190 N (20 kg, 44 lb).
Size of cardboard box:
Must exceed the following dimensions:
x=460 mm (18.11 in.)
When dimension of the cardboard box exceeds the di-
ameter of the disc wheel with the tire which the steer-
ing wheel pad is tied to−
x=460 mm (18.11 in.) + width of tire
y= 650 mm (25.59 in.)
NOTICE:
If a cardboard box smaller than the specified size is used,
the cardboard box will be broken by the shock from the air-
bag deployment.

Downloaded from www.Manualslib.com manuals search engine R04211
Inner Diam.
Tires
(3 or More)Width
H00400
10 m (33 ft) or more
AB0166
− SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS−17
1996 TOYOTA T100 (RM449U)
Covering method using tires:
Place at least 3 tires without disc wheel on top of the
disc wheel with the tire to which the steering wheel
pad is tied.
Tire size: Must exceed the following dimensions−
Width: 185 mm (7.87 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Do not use tires with disc wheels.
NOTICE:
The tires may be marked by the airbag deployment, so use
the redundant tires.
(g) Deploy the airbag.
(1) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the battery negative
(−) terminal.
(2) Check that no one is within 10 m (33 ft) area around
the disc wheel which the steering wheel pad is tied
to.
(3) Press the SST activation switch and deploy the air-
bag.
HINT:
The airbag deploys simultaneously as the LED of the SST ac-
tivation switch lights up.
(h) Dispose of the steering wheel pad (with airbag)
CAUTION:
The steering wheel pad is very hot when the airbag is
deployed, so leave it alone for at least 30 minutes af-
ter deployment.
Use gloves and safety glasses when handling a steer-
ing wheel pad with deployed airbag.
Always wash your hands with water after completing
the operation.

Downloaded from www.Manualslib.com manuals search engine RS−18
− SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
1996 TOYOTA T100 (RM449U)
Do not apply water, etc. to a steering wheel pad with
deployed airbag.
(1) Remove the steering wheel pad from the disc
wheel.
(2) Place the steering wheel pad in a vinyl bag, tie the
end tightly and dispose of it in the same way as oth-
er general parts disposal.

Downloaded from www.Manualslib.com manuals search engine RS03N−01
− SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS−19
1996 TOYOTA T100 (RM449U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following case, replace the steering wheel pad, steering wheel or spiral cable.
If the airbag has been deployed.
If the steering wheel pad or spiral cable has been found to be faulty in troubleshooting.
If the steering wheel pad, steering or spiral cable has been found to be faulty during the check
in items (See page RS−9).
If the steering wheel pad has been dropped.
CAUTION:
For removal and installation of the steering wheel pad, see SR section. Be sure to follow the correct
procedure.

Downloaded from www.Manualslib.com manuals search engine RS03O−01
RS−20
− SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
1996 TOYOTA T100 (RM449U)
INSTALLATION
(See page SR−20 or SR−33)

Downloaded from www.Manualslib.com manuals search engine RS03P−03
− SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
RS−21
1788 Author: Date:
1996 TOYOTA T100 (RM449U)
AIRBAG SENSOR ASSEMBLY
COMPONENTS

Downloaded from www.Manualslib.com manuals search engine RS03Q−03
RS−22
− SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
1996 TOYOTA T100 (RM449U)
REMOVAL
NOTICE:
Do not open the cover or the case of the ECU and various
computers unless absolutely necessary. (If the IC termi-
nals are touched, the IC may be destroyed by static elec-
tricity.)
1. REMOVE THESE PARTS:
(a) Lower center cover
(b) Cruise control ECU
2. REMOVE AIRBAG SENSOR ASSEMBLY
(a) Disconnect the connector.
NOTICE:
Removal of the connector is done with the sensor assem-
bly installed.
(b) Using a torx wrench, remove the 3 screws and the airbag
sensor assembly.
Torx wrench: T40 (Part No. 09042−00020 or locally
manufactured tool)

Downloaded from www.Manualslib.com manuals search engine RS03R−01
R12497
− SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY
RS−23
1996 TOYOTA T100 (RM449U)
INSPECTION
1. VEHICLE NOT INVOLVED IN COLLISION
Do a diagnostic system check.
(See page DI−365)
2. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS
NOT DEPLOYED
Do a diagnostic system check.
(See page DI−365)
3. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS
DEPLOYED
Replace the airbag sensor assembly.
