Page 147 of 1399

−
BODY ELECTRICAL BODY ELECTRICAL SYSTEM
BE−3
1996 LAND CRUISER (RM451U)
Only one side taillight does not light.
1. Taillight Bulb
2. Wire Harness−
−
Taillight does not light.
(Headlight is normal.)
1. Taillight Bulb
2. TAIL Fuse (No.2 R/B)
3. Taillight Control Relay (No.2 R/B)
4. Light Control Switch
5. Wire Harness−
BE−14
BE−14
BE−14 −
TURN SIGNAL AND HAZARD WARNING SYSTEM
SymptomSuspect AreaSee page
”Hazard” and ”Turn” do not light up.
1. Hazard Warning Switch
2. Turn Signal Flasher (No.1 R/B)
3. Wire HarnessBE−19
BE−19
−
None of blinks for hazard. (Turn is normal.)
1. Bulb
2. Turn Signal Flasher (No.1 R/B)
3. Wire Harness−
BE−19 −
Hazard warning light does not light up. (Turn is normal.)1. HAZ − HORN Fuse (No.2 R/B)
2. Wire HarnessBE−19 −
Hazard warning light does not light up in one direction.1. Hazard Warning Switch
2. Wire HarnessBE−19−
The flashing frequency is abnormal.
1. Bulb
2. Turn Signal Flasher (No.1 R/B)
3. Wire Harness−
BE−19 −
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE−19−
Only one bulb does not light up for hazard turn.1. Bulb
2. Wire Harness−
−
Turn signal does not light up.
(Combination meter, wiper and washer do not operate.)
1. Ignition Switch
2. TURN Fuse (I/P F/B)
3. Turn Signal Switch
4. Wire HarnessBE−11
BE−19
BE−19 −
Turn signal does not light up.
(Combination meter, wiper and washer are normal.)1. TURN Fuse (I/P F/B)
2. Turn Signal Switch
3. Wire HarnessBE−19
BE−19−
INTERIOR LIGHT SYSTEM
SymptomSuspect AreaSee page
Room light does not light up.
1. DOME Fuse (No.2 R/B)
2. Door Courtesy Switch
3. Front Personal Light
4. Room Light Assembly
5. Bulb
6. Wire Harness−
BE−21
BE−21
BE−21 −
−
Room light remains always on.1. Door Courtesy Switch
2. Wire HarnessBE−21
−
BACK −UP LIGHT SYSTEM
SymptomSuspect AreaSee page
Back−Up light does not light up.
1. GAUGE Fuse (I/P F/B)
2. Ignition Switch
3. Park/Neutral Position Switch (A/T)
4. Bulb
5. Wire Harness−
BE−11 −
−
−
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 934 of 1399

MA02Q−04
MA−2
−
MAINTENANCE INSIDE VEHICLE
42
Author: Date:
1996 LAND CRUISER (RM451U)
INSIDE VEHICLE
GENERAL MAINTENANCE
The owners are responsible for these maintenance and inspection items.
They can be done by the owner or they can have them done at a service sh\
op.
These items include those which should be checked on a daily basis, thos\
e which, in most cases, do not
require (special) tools and those which are considered to be reasonabl\
e for the owner to do.
Items and procedures for general maintenance are as follows.
1. GENERAL NOTES
Maintenance items may vary from country to country. Check the owner’s manual supplement in which
the maintenance schedule is shown.
Every service item in the periodic maintenance schedule must be performe\
d.
Periodic maintenance service must be performed according to whichever interval in\
the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time inter\
val (months).
Maintenance service after the last period should be performed at the same interval \
as before unless
otherwise noted.
Failure to do even one item can cause the engine to run poorly and incre\
ase exhaust emissions.
2. LIGHTS
(a) Check that the headlights, stop lights, taillights, turn signal lights, \
and other lights are all working.
(b) Check the headlights aim.
3. WARNING LIGHTS AND BUZZERS
Check that all warning lights and buzzers function properly.
4. HORN
Check that it is working.
5. WINDSHIELD
Check for scratches, pits or abrasions.
6. WINDSHIELD WIPER AND WASHER
(a) Check operation of the wipers and washer.
(b) Check that the wipers do not streak.
7. WINDSHIELD DEFROSTER
Check that air comes out from the defroster outlet when operating the heater \
or air conditioner at defroster
mode.
8. REAR VIEW MIRROR
Check that it is mounted securely.
9. SUN VISORS
Check that they move freely and mounted securely.
10. STEELING WHEEL
Check that it has the specified freeplay. Be alert for changes in steering condition, such as hard steering,
excessive freeplay or strange noises.
11. SEATS
(a) Check that all front seat controls such as seat adjusters, seatback recl\
iner, etc. operate smoothly.
(b) Check that all latches lock securely in any position.
(c) Check that the head restraints move up and down smoothly and that the lo\
cks hold securely in any latch position.
(d) For folding −down rear seat backs, check that the latches look securely.
12. SEAT BELTS
(a) Check that the seat belt system such as buckles, retractors and anchors operat\
e properly and smooth-
ly.
(b) Check that the belt webbing is not cut, frayed, worn or damaged.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 1033 of 1399

RS0P3−01
R12685
Horn Bottom Contact Plate
−
SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL PAD AND SPIRAL CABLE
RS−9
1996 LAND CRUISER (RM451U)
INSPECTION
1. VEHICLES NOT INVOLVED IN A COLLISION
(a) Do a diagnostic system check (See page DI−240).
(b) With the steering wheel pad (with airbag) installed in the vehicle, do a visual check with includes the following
items.
Check for cuts, minute cracks or marked discoloration of
the steering wheel pad top surface and grooved portion.
2. VEHICLES INVOLVED IN A COLLISION
(a) Do a diagnostic system check (See page DI−240).
(b) Do a visual check. With the steering wheel pad removed from the vehicle, do
a visual check with includes the following items.
Check for cuts and cracks in, or marked discolor-
ation of, the steering wheel pad top surface and its
grooved portion.
Check for cuts and cracks in wire harnesses, and for
chipping in connectors.
Check for deformation of the horn button contact
plate of the steering wheel.
HINT:
If the horn button contact plate of the steering wheel is de-
formed, never repair it. Always replace the steering wheel
assembly with a new one.
There should be no interference between the steering
wheel pad and the steering wheel, and the clearance
should be uniform all the way around when the new steer-
ing wheel pad is installed on the steering wheel.
CAUTION:
For removal and installation of the steering wheel pad, see
pages SR−11 and SR−19 and be sure to follow the correct
procedure.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 1034 of 1399
RS−10
−
SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL PAD AND SPIRAL CABLE
1996 LAND CRUISER (RM451U)
3. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS
DEPLOYED
Do a visual check with includes the following items with the
steering wheel pad removed from the vehicle.
Check for deformation of the horn button contact
plate of the steering wheel.
Check for damage to the spiral cable connector and
wire harness.
HINT:
There should be no interference between the steering wheel
pad and the steering wheel, and the clearance should be uni-
form all the way around when the new steering wheel pad is
installed on the steering wheel.
