1 Instruments and controls
Meters and gauges ................................................. 1-3
Speedometer and odometer .................................. 1-3
Tachometer ............................................................ 1-4
Engine coolant temperature gauge ........................ 1-4
Fuel gauge ............................................................. 1-5
Compass and outside temperature display
(If so equipped) ....................................................... 1-5
Clock ....................................................................... 1-8
Warning/indicator light and buzzer .......................... 1-9
Theft warning (If so equipped) .............................. 1-13
Headlight and turn signal switch .......................... 1-15
Windshield wiper and washer switch .................... 1-16
Rear window wiper and washer switch ............... 1-17
Rear window defogger switch .............................. 1-18
Instrument brightness control ............................... 1-18
Front fog light switch ............................................. 1-19
Hazard warning flasher switch ............................. 1-19
Heated seat (If so equipped) ................................ 1-20Cigarette lighter and ash trays ............................. 1-21
Power socket ......................................................... 1-22
Coin tray ................................................................ 1-22
Cup holder ............................................................. 1-23
Glasses case ......................................................... 1-23
Console box .......................................................... 1-24
Luggage board and box ........................................ 1-25
Tonneau cover ...................................................... 1-26
Power window ....................................................... 1-26
Sunroof ................................................................. 1-28
Interior light ........................................................... 1-29
Spot light ............................................................... 1-30
Inspection light ...................................................... 1-30
Vanity mirror light ................................................. 1-30
Adjustable shock absorber control
(If so equipped) ..................................................... 1-31
Integrated HomeLink
TMtransmitter
(If so equipped) ....................................................... 1-31
Z01.2.1/R50-DX

Driver's supplemental air bag (P.2-18)Cruise control
set switch
(P.4-13)
Outside mirror remote control
(P.2-37) Headlight/dimmer/turn signal switch (P.1-15)
Front fog light switch (P.1-19)Meter/gauge (P.1-3)
Windshield wiper/washer switch (P.1-16)
Hazard warning flasher switch (P.1-19)
Center ventilator (P.3-2)
Heater/air conditioner control (P.3-3)Compass/outside air temperature display (P.1-5)
Passenger supplemental air bag (P.2-18)
Side ventilator (P.3-2)
Glove box (P.2-10)
Cigarette lighter (P.1-21)
Radio/CD player (P.3-14)/clock (P.1-8)
Adjustable shock absorber control switch (P.1-31)
Rear window wiper/washer switch (P.1-17)
Rear window/outside mirror defogger switch (P.1-18)Ignition switch/steering lock (P.4-4)Heated seat switch (P.1-20)
Tilting steering wheel adjust lever (P.2-36)Hood release lever (P.2-9) Fuse box cover (P.7-21)
Coin tray (P.1-22) Theft warning light (P.1-13) Cruise control main switch (P.4-13)
Instrument brightness control
(P.1-18)
SIC0585
See the page indicated in parentheses for operating details.
1-2
Z01.2.1/R50-DX

Turn signal/hazard indicator lightsLow washer fluid warning light
(For Canada)Automatic transmission oil temperature
warning light
orBrake warning light4-wheel drive indicator lightMalfunction indicator light
High beam indicator light (Blue)CRUISE indicator lightDoor open warning light
Seat belt reminder light and buzzerAnti-lock brake warning light
(Except for Canada)Tire carrier open warning light
Engine oil pressure warning lightAnti-lock brake warning light
(For Canada)Supplemental air bag warning light
Charge warning lightOverdrive off indicator light
Low fuel warning lightAutomatic transmission park warning light
Checking bulbs
Turn the ignition key to ªONº without starting
the engine. The following lights will come on:
,,,or,
The following lights come on briefly and then
go off:
or,,
If any light fails to come on, it may indicate a
burned-out bulb or an open circuit in the elec-
trical system. Have the system repaired
promptly.
Turn signal/hazard indicator
lights
The light flashes when the turn signal switch
lever or hazard switch is turned on.
orBrake warning light
This light functions for both the parking brake
and the foot brake systems.Parking brake indicator
The light comes on when the parking brake is
applied.
Low brake fluid warning
The light warns of a low brake fluid level. If the
light comes on while the engine is running,
stop the vehicle and perform the following:
1. Check the brake fluid level. Add brake fluid
as necessary. See ªBrake and clutch fluidº
in the ªDo-it-yourself operationsº section.
WARNING/INDICATOR LIGHT
AND BUZZER
1-9
Z01.2.1/R50-DX

Key reminder buzzer
The buzzer will sound when the driver side
door is opened if the key is left in the ignition
switch. Take the ignition key when you leave
the vehicle.
Light reminder buzzer
A buzzer will sound if the driver's door is
opened with the light switch on unless the
ignition key in the ªONº position. Turn the light
switch off when you leave the vehicle.
Brake pad wear warning
The disc brake pads have audible wear warn-
ings. When a brake pad requires replacement,
it will make a high pitched scraping sound.
Have the brakes checked as soon as possible
if the warning sound is heard when the vehicle
is moving, whether or not the brake pedal is
depressed.The theft warning system provides visual and
audio alarm signals if parts of the vehicle are
disturbed.
How to activate the theft warning
system
1. Close all windows.
2. Remove the key from the ignition switch.
3. Close and lock all doors, hood, back door
and glass hatch. The doors can be locked
either with or without the key.
The system can be activated even if the
windows are open.4. Confirm that the indicator light comes on.
The light will glow for about 30 seconds and
then blink. The system is now activated. If,
during this 30 second time period, the door
is unlocked by the key or multi-remote
controller, or the ignition key is turned to
ªACCº, the system will not activate.
IC0005
THEFT WARNING (If so equipped)
1-13
Z01.2.1/R50-DX

Lighting
Turn the switch to the ªº position:
The side combination, tail, license plate and
instrument lights will come on.Turn the switch to the ª
º position:
Headlights will come on and all the other lights
remain on.
To select the high beam, push the lever for-
ward. Pull it back to select the low beam.
Daytime light system
(For Canada)
Even if the headlight control switch is off, the
headlights' high beams will illuminate after
starting the engine. The headlights will be a
little dimmer than they are with the headlight
switch in the ª
º position.
If the parking brake is applied before the
engine is started, the daytime lights will not be
illuminated. The daytime lights will illuminate
once the parking brake is released. Thereafter,
the daytime lights will not turn off when using
the parking brake at stop signals, etc.
When the daytime light system is active,
tail lights on your vehicle will not be on.
It is necessary at dusk to turn on your
headlights. Failure to do so could cause
an accident injuring yourself and others.
Passing signal
Pulling the lever toward you will turn on the
passing signal even when the headlight switch
is off.
SIC0188
HEADLIGHT AND TURN SIGNAL
SWITCH
1-15
Z01.2.1/R50-DX

Turn signal
Move the lever up or down to signal to the
turning direction. When the turn is completed,
the turn signals cancel automatically.
Lane change signal
To indicate a lane change, move the lever up
or down to the point where lights begin flash-
ing.
The windshield wiper and washer operates
when the ignition key is in the ªACCº or ªONº
position.
Push the lever down to operate the wiper.
Intermittent operation can be adjusted from 4
to 12 seconds by turning the knob.
(Type B only)
Pull the lever toward you to operate the
washer. Then the wiper will also operate sev-
eral times.
IDo not operate the washer continu-
ously for more than 30 seconds.
IDo not operate the washer if the res-
ervoir tank is dry.
SIC0176
WINDSHIELD WIPER AND
WASHER SWITCH
1-16
Z01.2.1/R50-DX

To turn the fog lights on, turn the headlight
switch to the ªº position, then turn the
switch to the ªº position. To turn them off,
turn the switch to the ªOFFº position.
The headlights must be on for the fog lights to
operate.Push the switch on to warn other drivers when
you must stop or park under emergency con-
ditions. All turn signal lights will flash.
IWhen stalled or stopped on the road-
way under emergency conditions,
move the vehicle well off the road.
IDo not use the switch while moving
on the highway unless unusual cir-
cumstances force you to drive so
slowly that your vehicle might be-
come a hazard to other traffic.ISome state laws may prohibit the use
of the hazard warning flasher switch
while driving.
ITurn signals do not work when the
switch is operating.
The flasher can be actuated with the ignition
switch either off or on.
IC1292SIC0594
FRONT FOG LIGHT SWITCH
HAZARD WARNING FLASHER
SWITCH
1-19
Z01.2.1/R50-DX

The sensor on the instrument panel helps
maintain a constant temperature. Do not put
anything on or around this sensor.
Servicing air conditioner
The air conditioning system in your NISSAN
vehicle is charged with a new refrigerant de-
signed with the environment in mind.
This new refrigerant will not harm the
earth's ozone layer.
However, special charging equipment and lu-
bricant are required when servicing your NIS-
SAN air conditioner. Using improper refriger-
ants or lubricants will cause severe damage to
your air conditioning system. See AIR CONDI-
TIONING SYSTEM REFRIGERANT AND LU-
BRICANT RECOMMENDATIONS in the
TECHNICAL INFORMATION section of this
manual.
Your NISSAN dealer will be able to service
your environmentally ªfriendlyº air conditioning
system.To turn the radio on, turn the ignition key to
ªACCº or ªONº. If you listen to the radio with
the engine not running, turn the key to the
ªACCº position.
Radio reception is affected by station signal
strength, distance from radio transmitter, build-
ings, bridges, mountains, and other external
influences. Intermittent changes in reception
quality normally are caused by these external
influences.
SAA0158
RADIO
3-14
