1996 NISSAN PATHFINDER turn signal

display will illuminate for ten seconds then
return to the clock mode.
After clock adjustment, the radio is in the
clock priority mode.
Radio/cassette tape priority mode
In this mode, the radio station will illuminate in
the display during radio operation. During cas-
sette tape operation, ªTAPEº will illuminate in
the display.
Selecting the desired band
Push the band select button (FM/AM) to
change from AM to FM reception.
The stereo indicator illuminates during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically
change from stereo to monaural reception.
Tuning
The radio should not be tuned while
driving in order that full attention may be
given to the driving operation.
Manual tuning
Push either manual tuning button
ª
ºorªº.
SEEK tuning
Push the SEEK/SCAN tuning button
ª
º for less than 1.5 seconds. SEEK tun-
ing begins from low to high frequencies and
stops at the next broadcasting station. Push
the button again for less than 1.5 seconds, and
the next highest broadcasting station is tuned.
Once the highest broadcasting station is
reached, the radio will continue in the ªSEEKº
mode at the lowest broadcast station.
SCAN tuning
Push the SEEK/SCAN tuning button
ª
º for more than 1.5 seconds. ªSCANº will
illuminate in the display window. SCAN tuning
begins from low to high frequencies and stops
at each broadcasting station for five seconds.Pushing the button again during this five sec-
ond period will stop SCAN tuning and the radio
will remain tuned to that station.
3-16
Z01.2.1/R50-DX

AM-FM RADIO WITH COMPACT
DISC PLAYER
The electronic tuning radio has an FM Diver-
sity reception system, which employs two an-
tennas. One is a rod type antenna; the other is
an antenna printed on the window. This sys-
tem automatically switches to the antenna
which is receiving less noise.
Radio operation
Pushthe FM/AM button to listen to the radio
and tune in the desired station.
Pushing the FM/AM button while the com-pact disc is playing will turn off the com-
pact disc player and turn on the radio.
Turnthe ON.VOL knob to adjust the volume.
Clock set (Adjustment)
Depressing the ªCLOCKº and the ªº but-
tons together will set hours. Depressing the
ªCLOCKº and ª
º buttons together will set
minutes.
Clock operation
By pressing the ªCLOCKº button, you can
alternate the clock and the radio/cassette tape
options in the display.
Clock priority mode
In this mode the clock will be shown in the
display. If any radio or CD functions are acti-
vated, the radio or CD display will illuminate for
ten seconds then return to the clock mode.
After clock adjustment, the radio is in the
clock priority mode.
Selecting the desired band
Push the AM/FM button to change from AM to
FM reception.
The FM stereo indicator ªSTº will glow during
FM stereo reception. When the stereo broad-
cast signal is weak, the radio will automatically
change from stereo to monaural reception.
Tuning
Manual tuning
Push either side of the manual tuning button
ª
º.
SCAN tuning
Push the SEEK/SCAN tuning button ª
º
for more than 1.5 seconds. SCAN tuning be-
gins from low to high frequencies and stops at
each broadcasting station for five seconds.
Pushing the button again during this five sec-
ond period will stop SCAN tuning and the radio
will remain tuned to that station.
SAA0161
3-20
Z01.2.1/R50-DX

If you have a flat tire, follow the instructions
below.
Stopping the vehicle
1. Safely move the vehicle off the road away
from traffic.
2. Turn on the hazard warning flasher.
3. Park on a level surface and apply the
parking brake. Shift the manual transmis-
sion into reverse (automatic transmission in
ªPº).
The transfer control lever must
be in the ª2Hº, ª4Hº or ª4Lº position.
Never place it in the ªNº position. Oth-
erwise, the vehicle could roll unexpect-
edly even if the manual transmission is
in gear or the automatic transmission is
in the ªPº position.
4. Turn off the engine.
IMake sure that the parking brake is
securely applied and the manual
transmission is shifted into reverse
(automatic transmission in ªPº).
INever change tires when the vehicle
is on a slope, ice or a slippery area.
This is dangerous.
INever change tires if oncoming traffic
is close to your vehicle. Wait for pro-
fessional road assistance.
IRaise the hood to warn other traffic
and to signal professional road assis-
tance personnel that you require as-
sistance.
IHave all passengers get out of the
vehicle and stand in a safe place
away from traffic and clear of the
vehicle.
Blocking wheels
Place suitable blocks at both the front and
back of the wheel diagonally opposite the flat
tire.
Be sure to block the wheel as the vehicle
may move and could cause personal
injury.
MCE0001
FLAT TIRE
5-2
Z01.2.1/R50-DX

OTHER LIGHTS
Item Wattage (W) Bulb No.
Front turn signal light 27 1156
Front fog light (H3 type) 55
Side combination light 5 168
Rear combination light
Turn signal 27 1156
Stop/Tail 27/8 1157
Back-up 27 1156
High mounted stop light 5 168
License plate light5or10
7.5168*1
89*2
Interior light 10 Ð
Vanity mirror light 1.4 Ð
Spot light 8 Ð
*1: For 5W light
*2: Option
Replacing procedures
All other lights are either type A, B, C or D.
When replacing a bulb, first remove the lens
and/or cover.
MDI0006
7-23
Z01.2.1/R50-DX

7,500 miles (12,000 km) for 2WD vehicles and
3,750 miles (6,000 km) for 4WD vehicles.
Wheel alignment and balanceIf the vehicle
should pull to either side while driving on a
straight and level road, or if you detect uneven
or abnormal tire wear, there may be a need for
wheel alignment.
If the steering wheel or seat vibrates at normal
highway speeds, wheel balancing may be
needed.
Windshield wiper blades*Check for cracks
or wear if they do not wipe properly.
Doors and engine hoodCheck that all doors
and the engine hood, operate properly. Also
ensure that all latches lock securely. Lubricate
hinges, latches, rollers and links if necessary.
Make sure that the secondary latch keeps the
hood from opening when the primary latch is
released.
When driving in areas using road salt or other
corrosive materials, check lubrication fre-
quently.INSIDE THE VEHICLE
The maintenance items listed here should be
checked on a regular basis, such as when
performing periodic maintenance, cleaning the
vehicle, etc.
Lights*Make sure that the headlights, stop
lights, tail lights, turn signal lights, and other
lights are all operating properly and installed
securely. Also check headlight aim.
Warning lights and buzzers/chimesMake
sure that all warning lights and buzzers/chimes
are operating properly.
Windshield wiper and washer*Check that
the wipers and washer operate properly and
that the wipers do not streak.
Windshield defrosterCheck that the air
comes out of the defroster outlets properly and
in sufficient quantity when operating the heater
or air conditioner.
Steering wheelCheck for changes in the
steering conditions, such as excessive free-
play, hard steering or strange noises.
SeatsCheck seat position controls such as
seat adjusters, seatback recliner, etc. to en-
sure they operate smoothly and that all latches
lock securely in every position. Check that the
head restraints move up and down smoothlyand that the locks (if so equipped) hold se-
curely in all latched positions.
Seat beltsCheck that all parts of the seat belt
system (e.g. buckles, anchors, adjusters and
retractors) operate properly and smoothly, and
are installed securely. Check the belt webbing
for cuts, fraying, wear or damage.
Accelerator pedalCheck the pedal for
smooth operation and make sure the pedal
does not catch or require uneven effort. Keep
the floor mats away from the pedal.
Clutch pedal*Make sure the pedal operates
smoothly and check that it has the proper free
travel.
BrakesCheck that the brakes do not pull the
vehicle to one side when applied.
Brake pedal and booster*Check the pedal
for smooth operation and make sure it has the
proper distance under it when depressed fully.
Check the brake booster function. Be certain
to keep floormats away from the pedal.
Parking brake*Check that the lever has the
proper travel and confirm that your vehicle is
held securely on a fairly steep hill with only the
parking brake applied.
Automatic transmission ªPark positionº
mechanismOn a fairly steep hill check that
8-3
Z01.2.1/R50-DX

Driving with manual transmission ............. 4-10
On-pavement and off-road driving
precautions .................................................. 4-3
Precautions when driving .......................... 4-23
Precautions when starting and driving ........ 4-2
E
Economy hints ................................................ 4-15
Emission control information label .................. 9-14
Emission control system warranty .................. 9-20
Engine ............................................................. 9-10
Before starting the engine ........................... 4-6
Changing engine coolant ............................ 7-5
Changing engine oil .................................... 7-8
Checking engine oil level ............................ 7-7
Engine coolant temperature gauge ............. 1-4
Engine cooling system ................................ 7-4
Engine oil..................................................... 7-7
Engine oil and oil filter
recommendation .......................................... 9-6
Engine serial number ................................ 9-13
Starting the engine .................................... 4-11
Exhaust gas (Carbon monoxide) ...................... 4-2
Explanation of maintenance items.................. 8-10
F
Flat tire .............................................................. 5-2
Fluid
Automatic transmission fluid ....................... 7-9
Brake and clutch fluid................................ 7-11
Power steering fluid................................... 7-11
Window washer fluid ................................. 7-12F.M.V.S.S. certification label........................... 9-14
Front fog light switch ...................................... 1-19
Front seats ...................................................... 2-12
Fuel
Capacities and recommended
fuel/lubricants .............................................. 9-2
Fuel filler cap ............................................. 2-11
Fuel filler lid lock ....................................... 2-10
Fuel gauge .................................................. 1-5
Fuel recommendation.................................. 9-4
Fuses .............................................................. 7-20
G
Gauge
Engine coolant temperature gauge ............. 1-4
Fuel gauge .................................................. 1-5
Meters and gauges ..................................... 1-3
General maintenance ....................................... 8-2
Glasses case .................................................. 1-23
Glove box lock ................................................ 2-10
H
Hazard warning flasher switch........................ 1-19
Head restraint ................................................. 2-15
Headlight and turn signal switch..................... 1-15
Headlights ....................................................... 7-22
Heated seat (If so equipped) .......................... 1-20
Heater and air conditioner ................................ 3-3
Heater operation ........................................ 3-4, 3-8
Hood release .................................................... 2-9I
If your vehicle is ever stolen ........................... 1-33
If your vehicle overheats .................................. 5-9
Ignition switch ................................................... 4-4
Inside mirror .................................................... 2-38
Inspection light ................................................ 1-30
Instrument brightness control ......................... 1-18
Integrated HomeLink
TMtransmitter
(If so equipped)............................................... 1-31
Interior light ..................................................... 1-29
J
Jump starting ........................................... 5-7, 7-13
K
Key .................................................................... 2-2
L
Light
Air bag warning light ................................. 2-22
Cigarette lighter and ash trays .................. 1-21
Front fog light switch ................................. 1-19
Headlight and turn signal switch ............... 1-15
Headlights.................................................. 7-22
Inspection light .......................................... 1-30
Interior light................................................ 1-29
Light bulbs ................................................. 7-22
Other lights ................................................ 7-23
Spot light ................................................... 1-30
Vanity mirror light ...................................... 1-30
10-2
Z01.2.1/R50-DX

Seat belt
2-point type with retractor (Center
position of rear seat) ................................. 2-28
3-point type with retractor ......................... 2-25
Precautions on seat belt usage ................ 2-24
Seat belt extenders ................................... 2-29
Seat belt maintenance .............................. 2-30
Seat belts ......................................... 2-24, 2-25
Semiautomatic air conditioner .......................... 3-7
Spare tire carrier ............................................... 2-7
Spark plug replacement .................................. 7-14
Speedometer and odometer ............................. 1-3
Spot light ......................................................... 1-30
Starting
Before starting the engine ........................... 4-6
Jump starting ..................................... 5-7, 7-13
Precautions when starting and driving ........ 4-2
Push starting ............................................... 5-8
Starting the engine .................................... 4-11
Steering
Power steering fluid................................... 7-11
Tilting steering wheel ................................ 2-36
Sun visor ......................................................... 2-37
Sunroof ........................................................... 1-28
Supplemental air bag warning light ................ 2-22
Supplemental restraint system (Supplemental air
bag system) .................................................... 2-18
Switch
Front fog light switch ................................. 1-19
Hazard warning flasher switch .................. 1-19
Headlight and turn signal switch ............... 1-15
Ignition switch .............................................. 4-4
Rear window defogger switch ................... 1-18Rear window wiper and washer
switch......................................................... 1-17
Windshield wiper and washer switch ........ 1-16
T
Tachometer ....................................................... 1-4
Theft warning (If so equipped)........................ 1-13
Three-way catalyst ............................................ 4-3
Tilting steering wheel ...................................... 2-36
Timing belt ...................................................... 9-10
Tire
Flat tire ........................................................ 5-2
Spare tire carrier ......................................... 2-7
Tire placard ............................................... 9-14
Wheels and tires .............................. 7-26, 9-11
Tonneau cover ................................................ 1-26
Tow truck towing ............................................. 5-10
Towing
2-wheel drive models ................................ 5-10
4-wheel drive models ................................ 5-11
Tow truck towing ....................................... 5-10
Towing load/specification chart ................. 9-18
Towing point .............................................. 5-12
Trailer towing ............................................. 9-16
Trailer towing .................................................. 9-16
Transfer case shifting procedures for
4-wheel drive vehicles .................................... 4-16
Transmission
Automatic transmission fluid ....................... 7-9
Driving with automatic transmission............ 4-6
Driving with manual transmission ............. 4-10V
Vanity mirror light ............................................ 1-30
Vehicle identification ....................................... 9-13
Vehicle identification number (Chassis
number) ..................................................... 9-13
Vehicle identification number plate ........... 9-13
Vehicle loading ............................................... 9-20
Vehicle loading information............................. 9-15
W
Warning
Hazard warning flasher switch .................. 1-19
Supplemental air bag warning light........... 2-22
Theft warning (If so equipped) .................. 1-13
Warning labels........................................... 2-22
Warning/indicator light and buzzer.............. 1-9
Wheels and tires ................................... 7-26, 9-11
When traveling or registering your vehicle in an-
other country ................................................... 9-12
Window washer fluid ....................................... 7-12
Windshield wiper and washer switch.............. 1-16
Wiper
Rear window wiper and washer
switch......................................................... 1-17
Windshield wiper and washer switch ........ 1-16
Wiper blade ............................................... 7-17
10-4
Z01.2.1/R50-DX
