Passenger compartment
If the electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are OFF.
2. Remove the fuse box cover.
3. Remove the fuse with the fuse puller.
4. If the fuse is open, replace it with a new
fuse.
Never use a fuse of higher amperage
rating than that specified on the fuse box
cover.5. If a new fuse opens again, have the
electrical system checked and repaired
by your NISSAN dealer.
HEADLIGHTS
Sealed beam type
The headlight is a sealed beam type. The
lens, reflector and filament are of a unitized
construction.
Removing and replacing
1. Disconnect the negative (-) battery cable.
2. Remove the clips attaching the radiator
grille, remove the front clearance lights,
then remove the grille by pulling it up-
ward.
ADI0723ADI0724
FUSES LIGHT BULBS
7-20
ZX

3. Remove the screws holding the headlight
retaining ring and take off the headlight.
4. After removing the headlight from the
headlight housing, remove the wiring
connector from the rear end of the bulb.
Be careful not to disturb the aiming ad-
justment screws.
5. When installing the new unit, be sure that
TOP in raised letters on the lens is on the
upper side.
cUse the same number and wattage as
originally installed:Halogen light
Wattage 65/35
Bulb No. H6059
Incandescent light
Wattage 65/55
Bulb No. 6052
cWhen aiming adjustment is neces-
sary, contact your NISSAN dealer.
DI0075
7-21
ZX

Increasing fuel economy............................ 4-13
Indicator lights and chimes
(See warning/indicator lights and chimes)
Inside mirror ............................................... 2-27
Instrument brightness control .................... 1-12
Interior light and cargo light ....................... 1-14
J
Jack
Pantograph type ..................................... 5-5
Screw type .............................................. 5-6
Jump seat .................................................. 2-11
Jump starting ............................................... 5-8
K
Key ............................................................... 2-2
L
Labels
Air conditioner specification label ......... 9-14
Emission control information label........ 9-14
Engine serial number ........................... 9-13
F.M.V.S.S. certification label ................ 9-13
Vehicle identification number plate ...... 9-12
Warning labels (for SRS) ..................... 2-15
Light
Supplemental air bag warning light ...... 2-15
Bulb check/instrument panel .................. 1-6Bulb replacement.................................. 7-22
Headlight and turn signal switch .......... 1-10
Headlights ............................................. 7-20
Interior light and cargo light .................. 1-14
Light bulbs ............................................ 7-20
Map light ............................................... 1-14
Warning/indicator lights and chimes ...... 1-6
Lock
Door locks............................................... 2-2
Free-running lock (see hubs)
Glove box lock ........................................ 2-4
Power door lock...................................... 2-3
Luggage (see vehicle loading information). 9-15
M
Maintenance
General maintenance ............................. 8-2
Inside the vehicle.................................... 8-3
Maintenance precautions ....................... 7-2
Outside the vehicle ................................. 8-2
Periodic maintenance schedules ............ 8-5
Seat belt maintenance.......................... 2-21
Under the hood and vehicle ................... 8-4
Manual antenna ......................................... 3-20
Manual-lock free-running hubs .................. 4-19
Manual window .......................................... 1-15
Map light .................................................... 1-14
Mirror
Inside mirror.......................................... 2-27
Outside mirror remote control ............. 2-26
Outside mirrors ..................................... 2-26Vanity mirror ......................................... 2-27
O
Octane rating (see fuel)
Odometer ..................................................... 1-3
Oil
Capacities and recommended
fuel/lubricants.......................................... 9-2
Changing engine oil................................ 7-7
Changing engine oil filter........................ 7-8
Checking engine oil level ....................... 7-6
Engine oil ................................................ 7-6
Engine oil and oil filter
recommendation ..................................... 9-6
Opera window ............................................ 1-17
Outside mirror remote control .................. 2-26
Outside mirrors .......................................... 2-26
Overdrive switch .......................................... 4-8
Overheat
If your vehicle overheats ........................ 5-9
Owner's manual order form ....................... 9-26
P
Pantograph type jack ................................... 5-5
Parking
Parking brake check ............................. 7-17
Parking brake operation ....................... 4-11
Parking/parking on hills ........................ 4-24
Periodic maintenance schedules ................. 8-5
10-3
ZX
