1996 Mercury Villager keyless

120
*
[IP16000(ALL)04/95]
Illuminated Entry System (If equipped)
[IP16100(ALL)06/95]
If your vehicle is equipped with this option, the interior
courtesy lamps (footwell, stepwell, and dome lamps) will light
when either of the front doors or the sliding door is opened. If
you have the optional Keyless Entry System the lamps will also
light whenever any keypad or remote keyless entry transmitter
button is pressed. One of the stepwell lamps is located near the
sliding door entrance and there is one on each front door. The
footwell lamps are located below the instrument panel near the
driver's and front passenger's feet. When the liftgate is opened,
the optional liftgate lamp, rear dome lamp and sliding door
stepwell lamp are illuminated.
[IP16200(ALL)01/93]
The lamps that have the time delay feature will automatically
dim until they turn completely off approximately 15 seconds
after the doors are closed. When the key is placed in the
ignition and turned to the ON position, the lamps will turn off.
[IP16300(ALL)09/93]
Overhead Map Lamps (If equipped)
[IP16400(ALL)01/93]
The power sunroof overhead console also contains the overhead
map lamps.
[IP16500(ALL)09/93]
10-1/2 pica
art:0040082-A
The overhead map lamps
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996

Features
141
*
[FV04600(ALL)01/93]
You can manually lock and unlock the doors using the manual
door locks to override the power locks.
[FV04700(ALL)09/93]
Keyless Entry System (If equipped)
[FV04800(ALL)06/95]
If you have chosen the keyless entry system option for your
vehicle, you can lock or unlock the doors and liftgate without
using a key. The keypad is above the outside door handle on
the driver's side. You can also use it to arm or disarm the
anti-theft system (if equipped). For more information on the
anti-theft system, refer to the Index.
[FV04900(ALL)09/93]
13-1/2 pica
art:0040096-C
The keyless entry system keypad
[FV05000(ALL)04/95]
The keypad will light when you push any of its buttons. In
addition, pushing any of the buttons will also activate the
illuminated entry system. For more information on the
illuminated entry system, refer to the Index.
*
[FV05100(ALL)01/93]
Do not push the keypad buttons with a key, ball-point pen,
pencil, or any other hard object since they could damage the
buttons.
File:08vxfvn.ex
Update:Mon Jun 3 14:49:33 1996

142
%*
[FV05200(ALL)02/95]
Using the Keyless Entry System
*
[FV05300(ALL)02/95]
To operate the Keyless Entry System, you must be familiar with
the ªpersonal codeº and the ªpermanent code.º The personal
code is a code number that you select that is easy for you to
remember. This is the number that you enter on the keypad to
unlock the door. The personal code can be changed as often as
you like.
[FV05400(ALL)01/93]
The permanent code is a number that is assigned to your
vehicle. It does not unlock the door but is used to program
your personal code into the system. Once you have
programmed your personal code you will not need the
permanent code again until you wish to change your personal
code.
[FV05500(ALL)01/93]
The permanent code is taped to the computer module behind
the center console of your vehicle. It is also taped to your
Keyless Entry System Owner's Card. For your convenience,
three additional pieces of tape with the permanent code have
been included in the glove box. Place these additional pieces of
tape in safe locations where you can refer to them when
necessary. Do not put them in any location that is accessible to
unauthorized persons, since this would allow them entrance to
your vehicle.
[FV05600(ALL)01/93]
Valid and Invalid Codes
[FV05700(ALL)01/93]
To help protect your vehicle from theft, certain codes that are
easily figured out cannot be registered for your personal code.
Some of the codes that cannot be registered for your personal
code include: the permanent code, five numbers consisting of
the same button, five consecutive numbers and a sequential
combination of numbers. The keyless entry system reads 1/2
and 9/0 as sequential numbers.
File:08vxfvn.ex
Update:Mon Jun 3 14:49:33 1996

144
[FV07100(ALL)01/93]
Changing Your Personal Code
[FV07200(ALL)01/93]
To change your personal code, simply repeat the steps for
entering your personal code using a new series of numbers; the
previous personal code will be erased and replaced by the new
code.
%*
[FV07300(ALL)01/93]
Unlocking the Doors with the Keyless Entry System
[FV07400(ALL)01/93]
To unlock the driver's door, simply enter your personal code.
[FV07500(ALL)05/93]
To unlock the passenger's door and the sliding door, enter your
personal code and press the 3/4 button within five seconds.
[FV07600(ALL)07/93]
To unlock the liftgate, press the 5/6 button within five seconds
of unlocking the driver's door.
[FV07700(ALL)01/93]
Locking the Doors
[FV07800(ALL)05/93]
To lock all of the doors, press the 7/8 and 9/10 buttons at the
same time. To prevent you from locking your keys in your
vehicle, this feature will not operate if the key is in the ignition.
It also will not operate if the front doors, sliding door or the
liftgate are open.
[FV07900(ALL)01/93]
Illuminated Entry System (Available with Keyless Entry
System)
[FV08000(ALL)04/95]
Refer toEntry system, illuminatedin the Index for details.
[FV08010(ALL)06/95]
Remote Keyless Entry System (If equipped)
[FV08020(ALL)06/95]
Your vehicle may be equipped with a remote keyless entry
system. This option will allow you to open your vehicle using a
remote transmitter from distances of up to 49 feet (15 meters)
away. The remote feature will operate only when the ignition is
in the OFF position.
[FV08030(ALL)06/95]
The transmitter can unlock the driver's door, unlock all doors,
lock all doors, and activate the vehicle's anti-theft system (if
equipped).
File:08vxfvn.ex
Update:Mon Jun 3 14:49:33 1996

Features
145
[FV08035(ALL)06/95]
13-1/2 pica
art:0040304-A
Remote keyless entry transmitter
[FV08040(ALL)06/95]
By pressing the UNLOCK button on the transmitter once, you
can unlock the driver side door. Pressing the UNLOCK button a
second time within six (6) seconds of unlocking the driver's
door will unlock the other doors. The interior lamp will turn on
and stay on for thirty (30) seconds.
[FV08050(ALL)06/95]
By pressing the LOCK button on the transmitter once, all the
doors will lock, the parking lamps flash twice and the horn
chirps. When the LOCK button is pushed with all the doors
locked, the parking lamps flash twice and the horn chirps to
confirm that the doors are already locked.
[FV08060(ALL)06/95]
Using the Panic Alarm
[FV08070(ALL)06/95]
If you are near your vehicle and feel threatened, you may
activate the alarm to call attention to it.
[FV08080(ALL)06/95]
To activate the PANIC alarm, push and hold the PANIC button
on the remote for longer than 1.5 seconds. The horn will sound
and the headlamps and tail lights will flash for thirty (30)
seconds. To turn off the alarm, press the LOCK or UNLOCK
buttons or hold the PANIC button down for longer than 1.5
seconds.
File:08vxfvn.ex
Update:Mon Jun 3 14:49:33 1996

Features
149
[FV08375(ALL)06/95]
13-1/2 pica
art:0040329-A
Anti-theft indicator light
[FV08380(ALL)06/95]
NOTE: If your vehicle is equipped with a factory installed
keyless entry system or remote keyless entry system
(or both), the system can be armed by closing all the
doors and pressing the LOCK button on the remote
transmitter or by pressing the 7/8 and 9/10 buttons on
the keyless entry keypad.
[FV08390(ALL)06/95]3.
Close all doors. The anti-theft indicator light will stay on for
approximately 30 seconds and then flash once every 2.5
seconds.
[FV08400(ALL)06/95]
NOTE: Be sure to close all the doors completely. If the doors
are not completely closed, the alarm indicator light
will remain on steadily. The anti-theft system is
armed only when the anti-theft indicator light remains
on steadily for approximately 30 seconds after the last
door is closed, and then flashes every 2.5 seconds.
File:08vxfvn.ex
Update:Mon Jun 3 14:49:33 1996

150
[FV08410(ALL)06/95]
Disarming an untriggered anti-theft system
[FV08420(ALL)06/95]
Unlock either door with the door key or by pressing the
UNLOCK button on the remote keyless entry transmitter (if
equipped) or by entering your personal code on the keyles entry
keypad (if equipped). This will disarm the system. When you
unlock the door with the key, make sure you fully rotate the
key in the lock. If you do not, the system may not disarm, and
will trigger when a door is opened.
[FV08430(ALL)06/95]
If the system is armed and you remain in your vehicle, simply
insert the key into the ignition and turn it to ACC. This disarms
the system and allows you to open the door to exit without
triggering the system. Remember to rearm the system by using
the power door lock, the remote transmitter (if equipped), or
the keyless entry keypad (if equipped) to lock the doors.
[FV08440(ALL)06/95]
The remote keyless entry system is designed to work with the
factory installed anti-theft system. It may not work with other
anti-theft systems.
[FV08450(ALL)06/95]
Triggering the anti-theft system
[FV08460(ALL)06/95]
The armed system will be triggered if:
[FV08470(ALL)06/95]
n
any door is opened without using the door key, the keyless
entry keypad (if equipped), or the remote keyless entry
transmitter (if equipped)
[FV08480(ALL)06/95]
n
the liftgate is opened or unlocked
[FV08490(ALL)06/95]
n
the hood is opened
File:08vxfvn.ex
Update:Mon Jun 3 14:49:33 1996

Features
151
[FV08500(ALL)06/95]
Disarming a triggered anti-theft system
[FV08510(ALL)06/95]
The alarm can be disarmed by using one of the following
methods:
[FV08520(ALL)06/95]
n
unlocking the driver or passenger doors
[FV08530(ALL)06/95]
n
unlocking the doors using the keyless entry keypad (if
equipped) or with the remote keyless entry transmitter (if
equipped)
[FV08540(ALL)06/95]
n
putting the key in the ignition and turning it to the ACC
position
[FV08550(ALL)06/95]
NOTE: The flashing lights and honking horn will shut off
automatically within 2 minutes 30 seconds after the
system is triggered. It will trigger again if another
intrusion occurs. However, the starter circuit remains
disabled until the system is disarmed.
[FV08560(ALL)06/95]
NOTE: Both remote keyless entry systems will only operate
with the ignition in the OFF position.
File:08vxfvn.ex
Update:Mon Jun 3 14:49:33 1996
