1996 Mercury Villager headlamp

118
[IP15000(ALL)09/93]
13-1/2 pica
art:0040081-B
Autolamp photodiode location
[IP15100(ALL)01/93]
To turn the autolamp off, move the thumbwheel all the way to
the left.
[IP15200(ALL)04/95]
You can set the autolamp so the headlamps stay on for
approximately three minutes after you turn off your ignition.
The farther the thumbwheel is moved to the right, the longer
the headlamps stay on.
[IP15300(ALL)01/93]
The chime will sound when the autolamp system turns the
headlamps on and the driver's door is open.
[IP15400(ALL)01/93]
Interior Lamps
[IP15500(ALL)07/93]
The front dome lamp is located overhead between the driver
and front passenger seats. However, if your vehicle is equipped
with a power sun roof, the dome lamp is located behind the
driver's seat.
[IP15600(ALL)01/93]
The rear dome lamp is located overhead near the rear seating
positions.
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996

123
Steering Column Controls
*
[SC00900(ALL)01/95]
The controls on the steering column and wheel are designed to
give you easy access to the controls while you are driving.
*
[SC01000(ALL)01/93]
Turn Signal Lever
*
[SC01100(ALL)01/95]
You can use the turn signal lever on the left side of the steering
column to:
*
[SC01200(ALL)01/93]
n
operate the turn signals.
*
[SC01300(ALL)01/93]
n
turn the headlamps to high beam.
*
[SC01400(ALL)01/93]
n
flash the headlamps.
*
[SC01500(ALL)01/93]
n
turn the windshield wipers and washer on/off.
*
[SC01600(ALL)01/95]
Turn Signals
[SC01700(ALL)02/95]
Move the lever up to signal a right turn. Move it down to
signal a left turn. The corresponding indicator light in the
instrument cluster will flash.
*
[SC01900(ALL)11/93]
7-1/2 pica art:0040085-D
The turn signal lever
[SC02000(ALL)02/95]
If the turn signal stays on after you turn, move the lever back
to the center (off) position.
[SC02100(ALL)02/95]
For lane changes, move the lever far enough to signal but not to
latch. The lever will return to the off position when you release
it.
File:07vxscn.ex
Update:Mon Jun 3 14:47:35 1996

124
*
[SC02200(ALL)05/94]
If the turn indicator light in the instrument panel does not
illuminate or remains on (does not flash) when you signal a
turn, the turn signaling system is malfunctioning. Have this
condition corrected as soon as possible, and use the accepted
hand signals until the turn signal system is repaired.
[SC02225(ALL)01/93]
Cornering Lights
[SC02250(ALL)06/95]
Your vehicle is equipped with special cornering lights designed
to provide additional illumination toward the direction you are
turning. The corresponding light comes on when a turn is
signaled.
*
[SC02300(ALL)05/95]
High Beams and Flashing the Lamps
*
[SC02400(ALL)01/93]
To turn on the high beams, turn the headlamps on and push
the turn signal lever away from you until it latches. When the
high beams are on, the high beam indicator light on the
instrument panel is illuminated.
*
[SC02500(ALL)01/93]
To return to the low beam setting, pull the turn signal lever
toward you until it latches back into the neutral position. The
high beam indicator light turns off.
*
[SC02600(ALL)11/93]
7-1/2 pica art:0040086-D
High beam and flash-to-pass operation
*
[SC02800(ALL)01/93]
To flash the headlamps, pull the turn signal lever toward you
for a moment and then release it. The high beam headlamps
will flash whether the headlamps are on or off.
File:07vxscn.ex
Update:Mon Jun 3 14:47:35 1996

Features
145
[FV08035(ALL)06/95]
13-1/2 pica
art:0040304-A
Remote keyless entry transmitter
[FV08040(ALL)06/95]
By pressing the UNLOCK button on the transmitter once, you
can unlock the driver side door. Pressing the UNLOCK button a
second time within six (6) seconds of unlocking the driver's
door will unlock the other doors. The interior lamp will turn on
and stay on for thirty (30) seconds.
[FV08050(ALL)06/95]
By pressing the LOCK button on the transmitter once, all the
doors will lock, the parking lamps flash twice and the horn
chirps. When the LOCK button is pushed with all the doors
locked, the parking lamps flash twice and the horn chirps to
confirm that the doors are already locked.
[FV08060(ALL)06/95]
Using the Panic Alarm
[FV08070(ALL)06/95]
If you are near your vehicle and feel threatened, you may
activate the alarm to call attention to it.
[FV08080(ALL)06/95]
To activate the PANIC alarm, push and hold the PANIC button
on the remote for longer than 1.5 seconds. The horn will sound
and the headlamps and tail lights will flash for thirty (30)
seconds. To turn off the alarm, press the LOCK or UNLOCK
buttons or hold the PANIC button down for longer than 1.5
seconds.
File:08vxfvn.ex
Update:Mon Jun 3 14:49:33 1996

148
[FV08230(ALL)06/95]2.
Insert and remove key from ignition six times within ten (10)
seconds. The instrument panel lights will flash twice.
[FV08240(ALL)06/95]3.
Turn ignition key to the ACC position.
[FV08250(ALL)06/95]4.
Press the LOCK button on the remote transmitter once.
[FV08260(ALL)06/95]5.
To enter additional remote controllers (including the
original), unlock, then lock the driver's door using the power
door lock switch.
[FV08270(ALL)06/95]6.
Press the LOCK button on a new remote transmitter. The
instrument panel lights will flash twice, indicating code is
entered.
[FV08280(ALL)06/95]7.
Repeat steps 5 and 6 as needed (up to four remote
transmitters may be programmed).
[FV08290(ALL)06/95]
Anti-Theft System (If equipped)
[FV08300(ALL)06/95]
This system helps protect your vehicle against break-ins or theft
by monitoring all doors and the liftgate lock cylinder.
[FV08310(ALL)06/95]
When an unauthorized entry occurs, the system triggers and
will:
[FV08320(ALL)06/95]
n
flash the headlamps and hazard lamps
[FV08330(ALL)06/95]
n
honk the horn
[FV08340(ALL)06/95]
n
disable the starting circuit to prevent the vehicle from being
started
[FV08350(ALL)06/95]
To arm the system
[FV08360(ALL)06/95]1.
Remove the key from the ignition.
[FV08370(ALL)06/95]2.
Lock the doors by using either the power door lock switch
or by turning the key in either the driver or passenger door
lock cylinder. The parking lights will flash and the horn
chirps to let you know that the system has been armed. The
anti-theft indicator light on the right side of the steering
wheel will light and remain on.
File:08vxfvn.ex
Update:Mon Jun 3 14:49:33 1996

295
Servicing Your Villager
%*
[SV01300(ALL)03/95]
Service Made Easy
*
[SV01400(ALL)01/95]
Ford has two goals for servicing your vehicle.
*
[SV01500(ALL)01/95]1.
When we can, we design parts that do not need to be
serviced.
*
[SV01600(ALL)01/95]2.
We want to make servicing your vehicle as easy as possible.
To help you:
*
[SV01700(ALL)01/93]
n
We highlight do-it-yourself items in yellow in your engine
compartment so that you can find them easily.
*
[SV01800(ALL)01/95]
n
When possible, we design parts Ð such as the headlamp
bulbs Ð that can be replaced without tools.
[SV01900(ALL)09/93]
n
We give you a Maintenance Schedule that makes tracking
routine service for your vehicle easy. The Maintenance
Schedule is located in theMaintenance Schedule and Record
booklet.
*
[SV02000(ALL)01/95]
This chapter tells you about the basic parts that you need to
check and service regularly.
[SV02150(ALL)02/95]
If your vehicle needs professional servicing, your dealership can
provide the parts and service required. Check yourWarranty
Information Bookletto find out which parts and services are
covered. Also see theCustomer Assistancechapter of this
Owner's Manual.
[SV02225(ALL)02/95]
Ford Motor Company recommends that the Owner Maintenance
Checks listed in theMaintenance Schedule and Recordbooklet be
performed for the proper operation of your vehicle. In addition
to the conditions listed in the Owner Maintenance Checklist, be
alert for any unusual noise, vibration, or other indication that
your vehicle may need service. If you do notice something
unusual, see that your vehicle is serviced promptly.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

348
%*
[SV38700(ALL)03/95]
Lights and Bulb Replacement
*
[SV38800(ALL)01/95]
It is a good idea to check the operation of the following lights
frequently:
*
[SV38900(ALL)01/95]
n
headlamps
*
[SV38950(ALL)02/95]
n
high-mount brakelamp
*
[SV39000(ALL)01/95]
n
tail lamps
*
[SV39100(ALL)01/95]
n
brakelamps
*
[SV39200(ALL)01/95]
n
hazard flasher
*
[SV39300(ALL)01/95]
n
turn signals
*
[SV39400(ALL)01/95]
n
license plate lamp
%*
[SV39500(ALL)01/95]
The alignment of your headlamps should be checked if:
*
[SV39600(ALL)01/95]
n
oncoming motorists frequently signal you to turn off your
vehicle's high beams when you do not have the high beams
on
*
[SV39700(ALL)01/95]
n
the headlamps do not seem to give you enough light to see
clearly at night
*
[SV39800(ALL)01/93]
n
the headlamp beams are not pointed slightly down and to
the right
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996

350
[SV40600(ALL)09/93]
13-1/2 pica
art:0040222-B
The headlamp bulb assembly
[SV40700(ALL)01/93]3.
Remove the bulb retaining ring by turning it
counterclockwise 1/8 of a turn to free it from the socket.
Then slide the ring off the plastic base. Keep the ring.You
must use it again to hold the new bulb in place.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996
