Introductory Information
*
[IN00300(ALL)04/95]
Ford's Commitment to You
*
[IN00400(ALL)04/95]
At Ford Motor Company, excellence is the
continuous commitment to achieve the best
result possible. It is dedication to learning what
you want, determination to develop the right
concept, and execution of that concept with care,
precision, and attention to detail. In short,
excellence means being the standard by which
others are judged.
*
[IN00500(ALL)04/95]
Our Guiding Principles
*
[IN00600(ALL)04/95]
q
Quality comes first.For your satisfaction, the
quality of our products and services must be
our number one priority.
*
[IN00700(ALL)04/95]
q
You are the focus of everything we do.Our
work must be done with you in mind,
providing better products and services than
our competition.
*
[IN00750(ALL)04/95]
q
Continuous improvement is essential to our
success.We must strive for excellence in
everything we do: in our products Ð in their
safety and value Ð and in our services, our
human relations, our competitiveness, and
our profitability.
*
[IN00800(ALL)04/95]
q
Employee involvement is our way of life.
We are a team. We must treat one another
with trust and respect.
File:fcins.ex
Update:Tue Aug 8 11:13:48 1995

12
*
[SR04000(ALL)02/95]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
*
[SR04100(ALL)08/95]
Pull the combination lap/shoulder belt from the
retractor so that the shoulder portion of the belt
crosses your shoulder and chest. Be sure the belt
is not twisted. If it is, remove the twist. Insert
the belt tongue into the proper buckle until you
hear a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
*
[SR04200(ALL)01/95]
quarter page art:0010018-B
Fastening the front seat combination lap and shoulder belt
*
[SR04300(ALL)02/95]
NOTE: Be sure to read and understand
Important Safety Belt Informationat
the beginning of this chapter.
[SR04500(ALL)02/95]
one third page art:0000685-I
Unfastening the combination lap and shoulder belts Ð
front and rear outboard seating positions
File:fcsrs.ex
Update:Wed Dec 20 09:34:02 1995

16 [SR06060(ALL)04/95]Your vehicle is equipped with safety seat belts
containing a cinch tongue at the rear-facing
seating positions.
*
[SR06075(ALL)03/95]
The locking cinch tongue will slide up and
down the belt webbing when the belt is in the
stowed position or while putting seat belts on.
When the locking cinch tongue of the
lap/shoulder combination seat belt is latched
into the buckle, the cinch tongue will allow the
lap portion to become shorter, but locks the
webbing in place to restrict it from becoming
longer.
*
[SR06125(ALL)03/95]
Before you can reach and latch a combination
lap and shoulder belt having a cinch tongue into
the buckle, you may have to lengthen the lap
belt portion of it. To lengthen the lap belt, pull
some webbing out of the shoulder belt retractor.
While holding the webbing below the tongue,
grasp the tip (metal portion) of the tongue so
that it is parallel to the webbing and slide the
tongue upward. Provide enough lap belt length
so that the tongue can reach the buckle.
*
[SR06151(ALL)03/95]
NOTE: If you grasp the tongue by the tongue
cover to lengthen the belt, the tongue
cover will grab the webbing, making it
difficult to slide.
*
[SR06175(ALL)03/95]
To fasten a cinch tongue, pull the combination
lap and shoulder belt from the retractor so that
the shoulder belt portion of the safety belt
crosses your shoulder and chest. Be sure the belt
is not twisted. If the belt is twisted remove the
twist. Insert the belt tongue into the proper
buckle for your seating position until you hear a
snap and feel it latch. Make sure the tongue is
securely fastened to the buckle by pulling of the
tongue.
File:fcsrs.ex
Update:Wed Dec 20 09:34:02 1995

18the safety belt will become locked and help
reduce your forward movement.
[SR06500(ALL)03/95]
To unfasten the belt, push the red release button
on the end of the buckle. This allows the tongue
to unlatch from the buckle. While the belt
retracts, guide the tongue to its original position
to prevent it from striking you or the vehicle.
[SR06550(ALL)02/95]
one third page art:0000029-F
Unfastening the combination lap and shoulder belts for the
rear-facing third seat (wagon)
[SR06560(ALL)04/95]
Center Occupant Rear Safety Belt (Sedan)
[SR06565(ALL)04/95]
The safety belt in the center rear seating position
has a detachable shoulder belt.
[SR06570(ALL)04/95]
To attach the shoulder belt to the lap belt, pull
the shoulder belt out from the retractor in the
seatback and insert the lap belt connecting pin
into the wide end of the key-slot on the
shoulder belt as shown in Figure 1. Pull the
connecting pin into the narrow end of the
key-slot until you hear a snap and feel it latch.
See Figure 2. Make sure the shoulder belt is
securely fastened to the lap belt by pulling up
on the shoulder belt.
File:fcsrs.ex
Update:Wed Dec 20 09:34:02 1995

20 [SR06585(ALL)04/95]
RWARNING
The rear center lap belt must be
tightened separately from the
shoulder strap. The lap belt must fit
snugly, and as low as possible
around the hips. Do not wear around
your waist. For information about
adjusting the belt, see ªLAP BELTSº
in this chapter.
[SR06590(ALL)04/95]
Detach the shoulder belt before folding down
the passenger side rear seat. To detach the
shoulder belt, slide the connecting pin to the
wide end of the key-slot and lift the shoulder
belt off the connecting pin. As the shoulder belt
retracts, guide the belt so that it does not strike
you or the vehicle.
%
*
[SR06601(ALL)04/95]
Lap Belts
[SR06650(ALL)03/95]
The lap belts in the center front seating position
(if equipped) and center rear seat (wagon) do
not adjust automatically. You must adjust them
to fit snugly and as low as possible around your
hips. Do not wear the lap belt around your
waist.
[SR06675(ALL)04/95]
The front center seat belt buckle and tongue are
stowed in a pocket between the seat cushion and
seatback. Remove them from the stowage pocket
before fastening.
*
[SR06700(ALL)03/95]
Pull the belt across your hips andinsert the
tongue into the correct buckleon your seat
until you hear a snap and feel it lock. Make sure
the buckle is securely fastened.
%*
[SR06750(ALL)02/95]
If you need to lengthen the belt, unfasten it and
tip the belt tongue at a right angle to the belt.
Pull the belt tongue over your lap until it
reaches the buckle.
File:fcsrs.ex
Update:Wed Dec 20 09:34:02 1995

25
*
[SR16000(ALL)01/95]
RWARNING
If a passenger is not properly seated
and restrained, an inflating air bag
could cause serious injury.
*
[SR16100(ALL)11/94]
RWARNING
Rear-facing infant seats should never
be placed in the front seat.
*
[SR16200(ALL)03/95]
In rear-facing infant seats, the infant's head is
closer to the air bag. The force of the rapidly
inflating air bag could push the top of the
rear-facing seat against the vehicle seatback or
center armrests (if so equipped), or center
console (if so equipped). REAR-FACING
INFANT CARRIERS MUST ALWAYS BE
SECURED IN THE REAR SEAT, and other child
safety seats and infant seats should be secured in
the rear seat whenever possible.
File:fcsrs.ex
Update:Wed Dec 20 09:34:02 1995

34 %
*
[SR22000(ALL)01/95]
Safety Seats for Children
*
[SR22100(ALL)01/95]
Use a safety seat that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
[SR22125(ALL)04/95]
Ford recommends the use of a child safety seat
having a top tether strap. Install the child safety
seat in a seating position which is capable of
providing a tether anchorage. For more
information on top tether straps seeAttaching
Safety Seats With Tether Strapsin this chapter.
*
[SR22150(ALL)02/95]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position, and make sure the tongue is securely
fastened in the buckle.
%*
[SR22400(ALL)01/95]
RWARNING
Your vehicle is equipped with a right
front passenger air bag.
REAR-FACING INFANT SEATS
SHOULD NEVER BE USED IN THE
FRONT SEAT, BECAUSE THE
FORCE OF THE RAPIDLY
INFLATING PASSENGER AIR BAG
COULD PUSH THE TOP OF THE
REAR-FACING SEAT AGAINST THE
VEHICLE SEATBACK, OR CENTER
CONSOLE (IF SO EQUIPPED), OR
CENTER ARMRESTS (IF SO
EQUIPPED). ALWAYS PLACE
REAR-FACING INFANT SEATS IN
THE REAR SEAT. When using
forward-facing child seats in the front
seat, always move the passenger seat
as far back from the instrument panel
as possible. Failure to follow these
warnings could result in injury to the
child.
File:fcsrs.ex
Update:Wed Dec 20 09:34:02 1995

35
*
[SR22500(ALL)01/95]
RWARNING
All child restraint systems are
designed to be secured in vehicle
seats by lap belts or by the lap
portion of a lap-shoulder belt. If you
do not properly secure the safety seat
to the vehicle, the risk is greater that
a child, occupying the seat during a
collision or sudden stop, will be
injured. An unsecured safety seat
could also injure other passengers in
the vehicle.
*
[SR22600(ALL)01/95]
RWARNING
Carefully follow all of the
manufacturer's instructions that come
with the safety seat that you put in
your vehicle. Make sure that the
shoulder belt (if provided at the
seating position where the safety seat
is being used) does not cross or rest
in front of the child's face or neck. If
you do not install and use the safety
seat properly, the child may be
injured in a sudden stop or collision.
[SR22700(ALL)04/95]
RWARNING
If you have a wagon, never use child
safety seats in the third seat. Safety
seats for children are not intended
for use in rear facing seats.
File:fcsrs.ex
Update:Wed Dec 20 09:34:02 1995
