1996 Mercury Grand Marquis Owner's Manuals

134
*
[FV08930( GV)01/95]
NOTE: All transmitters to be used on your
vehicle must be
programmed/reprogrammed at the same
time.
%
*
[FV08950( ALL)02/95]
Windows
%*
[FV08980( BCGV)02/95]
Using the Power Windows
*
[FV09000( GV)02/95]
Each door has a power control that opens and
closes the window on that door. The driver's
door has a master control panel that operates all
four windows.
*
[FV09050( ALL)01/95]
Power windows can only be opened or closed
when the ignition switch is in the ON or ACC
position.
*
[FV09075(MBCGV )05/95]
RWARNING
Do not let children play with the power
windows. They may seriously hurt
themselves. Make sure occupants are clear
of the window(s) before closing.
[FV09300( GV)05/94]
one third page art:0010234-D
The master controls on the driver's door
*
[FV09400(M GV)05/95]
To lock out all window switches except the
master controls, press the window lock switch
once. To restore control to the individual
windows, press the switch again.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

135 %
*
[FV09500(M GV)05/95]
There is also an Express Down feature on the
driver's power window.
[FV09600(M GV)05/95]
To operate, actuate driver's power window
switch to the down position for less than 0.4
seconds; the window will then open
automatically. To terminate automatic operation
before the window completely opens, operate the
switch again, for less than 0.4 seconds, to either
the up or down position. Actuating the switch
for greater than 0.4 seconds provides
conventional power window operation. Closing
of the power window is conventional operation
only.
%
*
[FV15700( ALL)01/95]
Seats
%*
[FV15710( ALL)04/95]
Head Restraints
*
[FV15720( ALL)04/95]
If you use them properly, head restraints will
help protect your head and neck in a collision.
*
[FV15730( ALL)05/95]
A head restraint helps protect you best if you
position it behind your head and not behind
your neck.
*
[FV15740( ALL)02/95]
Standard head restraints
*
[FV15750( ALL)01/95]
You can adjust the head restraints for your
comfort and protection.
[FV15770( ALL)05/92]
one third page art:0010048-C
Adjusting the head restraint
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

136 % [FV15850( GV)03/94]Adjusting the Front Passenger Seat
Manually
*
[FV16000( ALL)02/89]
In the front seats, you can move the whole seat
forward or backward or tilt the back of the seat
forward or backward.
*
[FV16150( GV)01/95]
To move the seat forward or backward:
[FV16200( BCGV)04/95]
1. Find the adjustment bar underneath the front
part of the seat.
[FV16400( BCGV)04/95]
2. Lift the bar to unlatch the seat.
*
[FV16600( ALL)04/95]
3. Move the seat to the desired position.
[FV16700( BCGV)04/95]
4. Release the bar to latch the seat in its new
position. Make sure the seat locks securely in
place.
[FV17050( GV)05/92]
one third page art:0010173-B
The front seat adjustment bar
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

137 [FV17150( GV)05/92]
To recline the front seat:
*
[FV17200( ALL)01/95]
1. On the side of the seat, find the handle for
the recliner.
*
[FV17300( ALL)04/95]
2. Lift the handle up and hold it in place.
*
[FV17400( ALL)01/95]
3. Lean against the back of the seat and adjust
it to the position you want. You can tilt the
seat back or bring it forward.
*
[FV17500( ALL)04/95]
4. Release the handle to lock the seat in its new
position.
*
[FV17600( ALL)05/95]
RWARNING
Never adjust the driver's seat or seatback
when the vehicle is moving.
*
[FV17700( ALL)05/95]
RWARNING
To reduce the risk of serious injury in a
collision, always drive and ride with your
seatback upright and the lap belt snug
and low across the hips.
[FV17800( GV)03/94]
one third page art:0010254-B
The seatback recliner handle
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

138 %
*
[FV18500( BCGV)05/95]
Using the Power Seats (If equipped)
[FV18700( GV)10/94]
If your vehicle has power seats, you can adjust
them in several directions. The controls are
located on the driver and passenger door trim
panels or on the side of the driver's seat.
[FV18810( GV)10/94]
one third page art:0011313-A
The power seat controls on the driver's seat Ð Base models
*
[FV18850( ALL)05/95]
RWARNING
Do not pile cargo higher than the
seatbacks to avoid injuring people in a
collision or sudden stop.
% [FV18920( GV)10/90]
Power Seat Recliner/Lumbar Option
[FV18960( GV)10/90]
The arrows on the power seat control panel
indicate the direction the seat or seatback will
move. To adjust the seat or seatback move the
control knob in the desired direction.
[FV18980( GV)03/94]
The power lumbar switch controls the inflation
of the lumbar support pad in the seatback. To
inflate the lumbar pad, push the forward portion
of the switch. To deflate the pad, press the rear
portion of the switch.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

139 [FV18990( GV)05/95]
one third page art:0010686-B
The power lumbar switch
%*
[FV20500( ALL)04/95]
Cleaning the Seats
*
[FV20600( ALL)05/95]
Leather and vinyl
*
[FV20650( ALL)05/95]
For routine cleaning, wipe the surface with a
soft, damp cloth. For more thorough cleaning,
wipe the surface with a leather and vinyl cleaner
or a mild soap.
%*
[FV20700( ALL)04/95]
Fabric
*
[FV20750( ALL)04/95]
Remove dust and loose dirt with a whisk broom
or a vacuum cleaner. Remove fresh spots
immediately. Follow the directions that come
with the cleaner.
*
[FV20775( ALL)04/95]
NOTE: Before using any cleaner, test it on a
small, hidden area of fabric. If the
fabric's color or texture is adversely
affected by a particular cleaner, do not
use it.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

140
%*
[FV20800( ALL)01/95]
Mirrors
*
[FV20850( ALL)03/95]
You can adjust your rearview mirror in any
direction. The special swivel bracket lets you
move the mirror up or down and from side to
side.
[FV21000( ALL)03/95]
RWARNING
Make sure you can see clearly through the
rearview mirror at all times. Do not block
your vision. If you cannot see through the
mirror, it could result in a collision,
injuring yourself and others.
%*
[FV21500( GV)01/95]
Automatic Dimming Inside Rearview
Mirror (If equipped)
[FV22620( GV)10/94]
quarter page art:0010037-C
The automatic non-glare mirror
*
[FV22630( GV)01/95]
The electronic day/night mirror will change
from the normal state to the non-glare state
when bright lights (glare) reach the mirror. This
mirror functions at night, and has a limited
function at dusk or dawn. From the non-glare
state, the mirror will return to the normal state
after a short delay. The delay starts when the
glare goes away. The delay prevents excessive
changing of the mirror as traffic moves behind
and around the vehicle, or on rolling hills and
curves.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996

141 [FV22650( GV)10/94]
To turn the mirror on, push the ON/OFF
switch, located on the bottom of the mirror, to
latch it in the ON position. The switch will
illuminate and the mirror will be in the
automatic dimming mode. To turn the switch
illumination and automatic dimming feature off,
push the ON/OFF switch again.
*
[FV22660( GV)01/95]
The electronic mirror measures the brightness of
the light coming in from the rear of the vehicle.
It automatically makes a correction in the glare
state. The mirror may be turned off in either the
normal or non-glare position.
[FV22685( GV)03/95]
There are two light sensors (photocells) in this
mirror. The sensor that detects rear glare is
located inside a window in the center of the
mirror. The second light sensor which
determines outside light level is located on the
backside of the mirror case.
*
[FV22690( GV)01/95]
One important safety feature is that the mirror
automatically returns to the normal position
whenever the vehicle is placed in R (Reverse)
(when the mirror is in the ON position). This
feature ensures a bright clear view in the mirror
when backing up.
% [FV24100( BCGV)07/93]
Adjusting the Dual Electric Remote
Control Mirrors
[FV24150( GV)11/90]
Your vehicle is equipped with electric remote
control side view mirrors; the switch for
controlling their operation is a control knob in
the armrest.
%*
[FV24400( ALL)01/95]
Do not clean the housing or glass of any mirror
with harsh abrasives, fuel or other
petroleum-based cleaning products.
File:rcfvg.ex
Update:Tue Jan 30 07:53:46 1996
