1996 HONDA ODYSSEY buttons

The Seat Belt System and How It Works

RELEASE

BUTTON

RELEASE
BUTTON
5. If you are sitting in one of the front seats and the shoulder belt
crosses your neck, you should
adjust the anchor height by
squeezing the two buttons and
sliding the anchor up or down. To unlatch the seat belt, push the
red PRESS button on the buckle.Guide the belt across your body to
the door pillar.
After you exit the vehicle, make sure the seat belt is out of the way and
will not get closed in the door. Wearing the Lap Belt
1. Pull the latch plate across your hips and insert it into the buckle
marked CENTER.
If the belt is too short, hold the
latch plate at a right angle and pull to extend the belt. Insert the latch
plate into the buckle.

CONTINUED

Driver and Passenger SafetyProCarManuals.comMain Menu s t Table of Contents

Controls Near the Steering Wheel

The two levers on the steering column contain controls for driving
features you use most often. The left lever controls the turn signals,
headlights, and high beams. The right lever controls the windshield
wipers.
The rear window defogger switch and hazard warning switch are on
the dashboard under the center air
vent.
The controls near the left air vent are for the sunroof, cruise control
and instrument panel brightness.
The lever on the underside of the steering column allows you to tilt the
steering wheel.

Instruments and Controls

HAZARD WARNING LIGHT

SHIFT LEVER
REAR WINDOW

DEFOGGER
HORN
BUTTONS

SUNROOF

SWITCH

CRUISE
CONTROL

INSTRUMENT
BRIGHTNESS
HEADLIGHTS/

TURN SIGNALS
TILT

ADJUSTMENT
WINDSHIELD

WIPERS/WASHERSProCarManuals.comMain Menu s t Table of Contents

Steering Wheel Controls

Even with the cruise control turnedon, you can still use the accelerator

pedal to speed up for passing. After
completing the pass, take your foot
off the accelerator pedal. The car

will return to the set cruising speed.

Resting your foot on the brake or clutch pedal will cause the cruise

control to cancel.
Cancelling the Cruise Control

Any of these actions cause the cruise
control to cancel.
Tap the brake pedal.

Press the SET/decel and RE-

SUME/accel buttons at the same

time.
Press the Cruise Control Master

Switch.

When you tap the brake pedal, or press the SET and RESUME buttonsat the same time, the CRUISECONTROL light on the instrument
panel will go out and the car will
begin to slow down. You can use the accelerator pedal in the normal way. If you use the brake pedal to cancel
cruise control, the system retains the
previously-set cruising speed. To
return to that speed, accelerate to
above 25 mph (40 km/h) and press
the RESUME/accel button until theCRUISE CONTROL light comes on.
The car will accelerate to the same cruising speed as before.
If you cancel cruise control by
pressing the SET and RESUME
buttons at the same time, the
previously-set cruising speed is erased. To use the cruise control,
accelerate to the desired cruisingspeed and press the SET/decel

button.

Pressing the Cruise Control Master
Switch turns the system completely off and erases the previous cruisingspeed from memory. To use the

system again, refer to Using the
Cruise Control.

Instruments and ControlsProCarManuals.comMain Menu s t Table of Contents

Heating and Cooling

Proper use of the Heating and

Cooling system can make the

interior dry and comfortable, and

keep the windows clear for best

visibility.

What Each Control Does Fan Control Lever
Sliding this lever to the right
increases the fan's speed, which
increases air flow.
Temperature Control Lever
Sliding this lever to the right

increases the temperature of the air

flow.

Air Conditioning (A/C) Button This button turns the air condi- tioning ON and OFF. The indicatorin the button lights when the A/C is
on.
Fresh Air and Recirculation
Buttons
These two buttons control the source of air going into the system. In Fresh Air mode air
comes from outside the car. In
Recirculation mode the
interior air recycles through the
system.

Comfort and Convenience Features TEMPERATURE CONTROL LEVER
FAN CONTROL
LEVER AIR CONDITIONING
BUTTON
MODE BUTTONS
RECIRCULATION
BUTTONFRESH AIR BUTTONProCarManuals.comMain Menu s t Table of Contents

Heating and Cooling

Mode Buttons
These buttons let you select which vents the air flows from. Air flows from the center
and corner vents in the dashboard. Air flow is divided between
the vents in the dashboard and the
floor vents. Air flows from the floor

vents.
Air flow is divided between
the floor vents and the defroster
vents at the base of the windshield. Air flows from the defroster
vents at the base of the windshield.
Comfort and Convenience FeaturesProCarManuals.comMain Menu s t Table of Contents

Heating and Cooling
It is best to leave the system in mode under almost all
conditions. Keeping the system in mode, particularly with the
A/C off, can cause the windows to fog up. Switch to mode when
you are driving through smoky or dusty conditions, then switch back to mode when the condition

clears.

The outside air intakes for the heating and cooling system are atthe base of the windshield. Keep
these clear of leaves and other
debris.
Ventilation

The flow-through ventilation system draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear side

panels.
1. Slide the temperature control lever
all the way to the left.
Make sure the A/C is off. 2. Select and
3. Set the fan to the desired speed.
CONTINUED

Comfort and Convenience Features

MODE BUTTONS

RECIRCULATION
BUTTON
FRESH AIR BUTTON

AIR CONDITIONINGBUTTON

FAN CONTROL

LEVER

TEMPERATURE CONTROL LEVERProCarManuals.comMain Menu s t Table of Contents

Heating and Cooling

To Cool with A/C
1. Turn on the A/C by pressing the button. The light in the button
should come on.
2. Make sure the temperature control lever is all the way to the

left.
3. Select and

4. Set the fan to the desired speed.

If the interior is very warm from

being parked in the sun, you can cool
it down more rapidly by setting up

the controls this way:

1. Start the engine.

2. Turn on the A/C by pressing the
button. Make sure the tempera-

ture control lever is all the way to

the left.

3. Set the fan to maximum speed.

4. Open the windows partially. Select
and
When the interior has cooled down
to a more comfortable temperature,
close the windows and set thecontrols as described for normal
cooling.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page 38) when driving in stop-and-go
traffic or climbing a long, steep hill. If it moves near the red zone, turnoff the A/C until the gauge reads
normally.
Comfort and Convenience Features
MODE BUTTONS

RECIRCULATION
BUTTON
FRESH AIR BUTTON

AIR CONDITIONINGBUTTON

FAN CONTROL
LEVER
TEMPERATURE CONTROL LEVERProCarManuals.comMain Menu s t Table of Contents

Heating and Cooling

To remove exterior frost or ice from the windshield and side windowsafter the car has been sitting out in
cold weather:
1. Start the engine.
2. Select
and
3. Switch the fan and temperature
controls to maximum.
To rapidly remove exterior frost or ice from the windshield (on very cold days), first select Once the
windshield is clear, select to
avoid fogging the windows.
TEMPERATURE CONTROL LEVER
Comfort and Convenience Features MODE BUTTONS

RECIRCULATION

BUTTON
FRESH AIR BUTTON
FAN CONTROL

LEVER
AIR CONDITIONING
