1996 HONDA ODYSSEY key

Automatic Transmission

Park (P) — This position mechani- cally locks the transmission. Use
Park whenever you are turning off or starting the engine. To shift out of
Park, you must press on the brake
pedal and have your foot off the accelerator pedal. Pull the shift lever
towards you, then move it out of Park.
If you have done all of the above andstill cannot move the lever out of
Park, see Shift Lock Release on page

123.

You must also pull the shift lever towards you to shift into Park. To
avoid transmission damage, come toa complete stop before shifting into
Park. The shift lever must be in Park
before you can remove the key from the ignition switch. Reverse (R) — To shift to Reverse
from Park, see the explanation under
Park. To shift to Reverse fromNeutral, come to a complete stop and
then shift. Pull the shift lever
towards you before shifting into
Reverse from Neutral.

Driving
CONTINUEDProCarManuals.comMain Menu s t Table of Contents

Automatic Transmission

Maximum Speeds

The speeds in this table are the maximums for the given position. If
you exceed these speeds, you will feel the engine cut in and out. This iscaused by a limiter in the engine'scomputer controls. The engine will
run normally when you reduce speed
or shift.
Shift Lock Release

This allows you to move the shift lever out of Park if the normalmethod of pushing on the brake
pedal and pulling the shift lever does
not work.
1. Set the Parking brake.
2. Remove the key from the ignition
switch.

3. Insert the key in the Shift Lock Release slot on the steering

column.

4. Push down on the key while you pull the shift lever towards you
and move the shift lever out of
Park to Neutral.
SHIFT LOCK RELEASE SLOT
5. Remove the key from the Shift Lock Release slot. Depress the
brake pedal and restart the engine.
If you need to use the Shift Lock
Release, it could mean your car is
developing a problem. Have the car
checked by your Honda dealer.

DrivingProCarManuals.comMain Menu s t Table of Contents

If Your Engine Won't Start
Diagnosing why your engine won't start falls into two areas, depending
on what you hear when you turn the
key to START (III): You hear nothing, or almost
nothing. The engine's starter
motor does not operate at all, oroperates very slowly. You can hear the starter motor
operating normally, but the engine
does not start up and run. Nothing Happens or the Starter
Motor Operates Very Slowly
When you turn the ignition switch to START (III), you do not hear the
normal noise of the engine trying to start. You may hear a clicking sound
or series of clicks, or nothing at all.Check these things:
Check the transmission interlock.
The transmission must be in Park or Neutral or the starter will not

operate.
Turn the ignition switch to ON (II).
Turn on the headlights and check their brightness. If the headlights are very dim or don't light at all,
the battery is discharged. See
Jump Starting on page 200. Turn the ignition switch to START
(III). If the headlights do not dim,
check the condition of the fuses. If
the fuses are OK, there is proba-
bly something wrong with the electrical circuit for the ignition
switch or starter motor. You will
need a qualified technician todetermine the problem. (See
Towing on page 213.)
If the headlights dim noticeably or
go out when you try to start theengine, either the battery is dis-
charged or the connections are
corroded. Check the condition of
the battery and terminal connec- tions (see page 162 ). You can
then try jump starting the car from a booster battery (see page 200 ).
Taking Care of the UnexpectedProCarManuals.comMain Menu s t Table of Contents

Index

Accessories
Installation.................................. 115

ACCESSORY (Ignition Key
Position)........................................ 50

Adding Automatic Transmission
Fluid........................................ 155
Brake Fluid................................. 156

Engine Coolant........................... 151

Engine Oil................................... 146

Power Steering Fluid................. 157
Windshield Washer Fluid......... 154

Additional Safety Information........ 18

Door Locks................................... 19Driving with Pets......................... 19
Head Restraint Position.............. 18
Seat-back Position........................ 18

Storing Cargo Safely................... 19

Additives, Engine Oil..................... 148
Adjustments
Mirrors.......................................... 64

Head Restraints........................... 56
Seats.............................................. 54

Steering Wheel............................ 44
Airbag (SRS).................................... 12

Air Cleaner..................................... 158

Air Conditioning............................... 74
Maintenance............................... 168

Usage............................................. 74

Air Outlets (Vents).......................... 76

Air Pressure, Tires........................ 170
Alcohol and Drugs........................... 28

Alcohol in Gasoline........................ 108
Antifreeze....................................... 150

Anti-lock Brakes (ABS)
Description................................. 220

Indicator Light..................... 35, 125

Operation.................................... 125

Anti-theft Steering Column Lock.. 49

Appearance Care........................... 183

Ashtray.............................................. 69

Audio System................................... 83

Automatic Speed Control................ 48
Automatic Transmission............... 120
Capacity, Fluid........................... 218

Checking Fluid Level................ 155
Shifting........................................ 120
Shift Lever Positions................. 120
Shift Lock Release..................... 123 Battery
Charging System Light............... 34
Jump Starting............................. 200 Maintenance............................... 162

Specifications............................. 219

Before Driving............................... 107
Belts, Seat........................................... 5
Beverage Holder.............................. 66
Body Repair.................................... 189
Brakes Anti-lock System (ABS)............ 125Break-in, New Linings .............. 108

Fluid............................................ 156

Light, Burned-out...................... 179

Parking.......................................... 65

System Indicator.......................... 34
Wear Indicators......................... 124
Brakes, ABS Description................................. 220Operation.................................... 125
System Indicator.................. 35, 125
Braking System.............................. 124
CONTINUEDProCarManuals.comMain Menu s t

Index

Fluids
Automatic Transmission........... 155

Brake........................................... 156

Power Steering........................... 157

Windshield Washer................... 154

FM Stereo Radio
Reception.................................... 97

Folding the Second Seats ............... 58

Folding the Third Seats.................. 60

Foreign Countries, Driving in...... 109

Four-way Flashers......................... 43

Front End, Towing by Emergency
Wrecker.................................... 213

Fuel.................................................. 108
Fill Door and Cap....................... 110

Gauge.......................................... 38

Octane Requirement................. 108

Oxygenated................................ 108

Tank, Filling the......................... 110

Fuses, Checking the...................... 209

Gas Mileage, Improving................ 114

Gasohol........................................... 108

Gasoline.......................................... 108
Gauge.......................................... 38

Octane Requirement................. 108

Tank, Filling the......................... 110

Gas Station Procedures................. 110

Gauges Engine Coolant Temperature .... 38

Fuel.............................................. 38

Gearshift Lever Positions............. 120 Glass Cleaning............................... 187
Glove Box......................................... 53
Halogen Headlight Bulbs.............. 177
Hazard Warning Flashers............. 43

Headlights....................................... 40
Aiming......................................... 175Daytime Running Lights............. 40
High Beam Indicator................... 36High Beams, Turning on............ 40
Low Beams, Turning on............. 40
Reminder Chime.......................... 40 Replacing Halogen Bulbs ......... 177

Turning on.................................. 40

Head Restraints............................... 56
Heating and Cooling........................ 74 High Altitude, Starting at............ 119
High-Low Beam Switch............... 40

Hood, Opening the ...................... 111

Horn............................................... 39

Hot Coolant, Warning about...... 151 Hydroplaning................................ 127
Identification Number, Vehicle.. 216
If Your Car Has to be Towed..... 213Ignition
Keys............................................. 49

Switch.......................................... 49

Timing Control System............. 225
Indicator Lights, Instrument

Panel............................................. 33

Infant Restraint............................... 22 Inflation, Proper Tire .................... 170
Inside Mirror................................... 64

Inspection, Tire.............................. 171

Instrument Panel............................. 33

Instrument Panel Brightness........ 41
Interior Cleaning............................ 186
Interior Lights................................. 70

Introduction...................................... iProCarManuals.comMain Menu s t

Index
Jacking up the Car......................... 195

Jack, Tire........................................ 193
Jump Starting................................. 200
Keys................................................... 49
Label, Certification........................ 216
Lane Change, Signaling.................. 41Lap Belt............................................... 7
Lap/Shoulder Belts........................... 6
Leaking of Exhaust into Car.......... 29
Lighter, Cigarette............................ 69
Lights Headlight Aiming...................... 175Bulb Replacement..................... 177

Indicator........................................ 33

Parking.......................................... 40
Turn Signal................................... 41
Loading Cargo................................ 116
LOCK (Ignition Key Position)....... 50 Locks
Anti-theft Steering Column........ 49
Fuel Fill Door............................. 110Glove Box..................................... 53
Power Door.................................. 50
Tailgate......................................... 52
Low Coolant Level......................... 150 Low Oil Pressure Indicator.... 34, 204
Lubricant Specifications Chart.... 218
Luggage.......................................... 116
Maintenance................................... 135 Periodic Items............................ 144

Record.................................. 142-143

Required Indicator....................... 38
Safety........................................... 136Schedule.............................. 138-141
Malfunction Indicator Lamp.. 34, 206 Maximum Speeds.......................... 123
Meters, Gauges................................ 37
Methanol in Gasoline.................... 109

Mirrors, Adjusting...........................
64

Neutral Gea r
Position.................... 122
New Vehicle Break-in ................... 108
NOTICE, Explanation of................... ii
Numbers, Identification................ 216

Occupant Protection System............ 4
Octane Requirement, Gasoline.... 108

Odometer.......................................... 37

Odometer, Trip................................ 37

Oil Change, How to......................... 148

Change, When to....................... 140

Checking Engine....................... 146
Pressure Indicator....................... 34

Selecting Proper Viscosity
Chart....................................... 148

ON (Ignition Key Position)............ 50

Opening the Hood......................... 111

Operation in Foreign Countries... 109

CONTINUEDProCarManuals.comMain Menu s t

Index
Seats
Reclining the Second Seat.......... 59

Removing the Second Seats....... 57

Third Seat Access...................... 56

Serial Number................................ 216

Service Intervals*.......................... 140

Service Manual.............................. 233

Service Station Procedures.......... 110
Setting the Clock............................. 66

Shifting the Automatic
Transmission.............................. 120

Shift Lever Position Indicator...... 120
Side Marker Lights, Bulb
Replacement in.......................... 178

Signaling Turns................................ 41
Snow Tires...................................... 174

Solvent-type Cleaners.................... 184
Sound System................................... 83

Spare Tire
Inflating....................................... 192

Specifications............................. 219

Spark Plugs, Replacing................. 160
Specifications Charts..................... 218

Speed Control...................................
46

Speedometer.................................... 3 7

SR
S Indicator............................. 16,

34

START (Ignitio
n
Key Position)..... 50
Starting the Engine........................ 119 In Cold Weather at HighAltitude................................... 119
With a Dead Battery................. 200
Steam Coming from Engine......... 202

Steering Wheel
Adjustment................................... 44
Anti-theft Column Lock.............. 49
Stereo Sound System...................... 83 Storing Your Car............................ 182

Sunroof............................................. 63
Closing Manually....................... 207
Operation......................................

63

Supplemental Restrain t
System
Service Precautions..................... 17
Servicing....................................... 16
SRS Indicator.......................... 16, 34
System

Components................... .
12

Synthetic Oil................................... 148
Tailgate........................................... 52

Taillights, Changing Bulbs in....... 179
Taking Care of the Unexpected.. 191 Tape Player................................ 87, 99
Technical Descriptions Anti-lock Brake System............ 220Emission Control Systems........ 224
Three Way Catalytic

Converter................................ 226

Tire Information........................

221

Temperature Gauge....................... .
38
Tether Attachment Points.............. 26 Three Way Catalytic Converter... 226
Time, Setting the...........................

66

Tire Chains.................................... .
174
Tire, How to Change a Flat.......... 193
Tires................................................ 169 Air Pressure............................... 170
Checking Wear.......................... 171
Compact Spare........................... 192
DOT Tire Quality Grading....... 222
Inflation....................................... 170
CONTINUED
ProCarManuals.comMain Menu s t

Index

Transmission
Checking Fluid Level................ 155
Fluid Selection............................ 155
Identification Number............... 216
Shifting the Automatic.............. 120

Treadwear...................................... 222

Trip Meter........................................ 37 Turn Signals..................................... 41
Tires Inspection................................... 171
Replacing.................................... 172Rotating....................................... 172
Snow............................................ 174

Specifications............................. 219

Tools, Tire Changing.................... 193 Torn Seat Belts................................ 11
Towing A Trailer...................................... 128
Emergency Wrecker................. 213

Underside, Cleaning...................... 188

Unexpected, Taking Care
of the........................................... 191

Uniform Tire Quality Grading..... 222
Unleaded Gasoline......................... 108

Upholstery Cleaning...................... 186

Used Oil, How to Dispose of........ 150
Warning Beepers Key in Ignition..............................
50

Seat Belts..................................... .
34

WARNING, Explanation of.............. ii Warning Labels, Location of.......... 30
Warranty Coverages*................... 228
Washer, Windshield Checking the Fluid Level......... 154
Operation...................................... 42

Washing.......................................... 184
Waxing and Polishing................... 184

Wheels
Adjusting the Steering............. 44
Alignment and Balance............ 171Compact Spare.......................... 192
Wrench...................................... 195
Windows Cleaning..................................... 187
Operating the Power................. 62
Rear, Defogger........................... 43
Windshield Cleaning...................................... 42
Defroster..................................... 79
Wipers, Windshield
Changing Blades....................... 165

Operation.................................... 42

Rear Windshield Wiper and
Washer................................... 43

Worn Tires.................................. 171

Wrecker, Emergency Towing.... 213
* : U. S. and Canada only

Vanity Mirror................................... 68

Vehicle Capacity Load .................. 116

Vehicle Dimensions....................... 218

Vehicle Identification Number..... 216

Vehicle Storage.............................. 182
Ventilation......................................... 76

VIN.................................................. 216
Vinyl Cleaning................................ 186

Viscosity, Oil................................... 148ProCarManuals.comMain Menu s t
