1996 FORD THUNDERBIRD key

128
%*
[FV32875( ALL)01/95]
Storage Compartments
[FV32905( BC )07/93]
In addition to the console, your vehicle may
have several small storage compartments:
[FV33000( BCGV)11/94]
q
a glove compartment that locks. Use the
round key to lock and unlock it.
*
[FV33100( BCGV)01/95]
q
two map pockets on the panels of the front
doors.
*
[FV33300( ALL)05/95]
RWARNING
Do not put objects on the ledge between
the back seat and the rear window, as
they can become dangerous projectiles and
injure someone.
File:rcfvb.ex
Update:Mon Feb 19 10:50:02 1996

129
%*
[FV33400( ALL)01/95]
Trunk
*
[FV33500( ALL)01/95]
Opening the Trunk Manually
[FV34000( BC )05/94]
The trunk in your vehicle gives you plenty of
room for storage Ð 15.1 cubic feet (.42 cubic
meters).
%*
[FV34600( ALL)03/95]
To open and close the trunk from the outside:
[FV34950( BCGV)03/95]
1. Insert the key into the lock on the trunk.
[FV35100( ALL)11/90]
2. Turn the key to the right until the trunk
opens.
[FV35300( ALL)11/90]
3. Remove the key before you close and lock
the lid.
[FV35450( ALL)06/93]
4. Shut the trunk lid completely.
% [FV36200( ALL)03/95]
Using the Remote Control for the
Trunk (If equipped)
[FV36500( BC )07/93]
With the ignition switch in the ON or ACC
position, you can use the remote control under
your console armrest to unlock and open the
trunk.
[FV36700( BC )05/95]
quarter page art:0010359-C
The trunk release button located under the armrest
File:rcfvb.ex
Update:Mon Feb 19 10:50:02 1996

139
*
[AS07750(MBC )04/95]
How to stop and restart the CD player
*
[AS07800(MBC )04/95]
When a disc is loaded, the unit automatically
enters the play mode and the play indicator
a
illuminates. To stop temporarily, press the
ªPLAY/STOPº button or the ªAM/FMº button.
The stop indicator
Xin the display illuminates
and operation returns to the radio mode. To
resume CD play, press the ªPLAY/STOPº
button once again.
*
[AS07850(MBC )04/95]
NOTE: If the ignition key is turned OFF
during play and then is set to the ON
or ACCESSORY position, the CD
player will resume playing in the mode
it was in when ignition was turned off.
*
[AS07900(MBC )05/95]
How to fast forward or reverse your CD
player
*
[AS07950(MBC )05/95]
To quickly search for a particular point in a
selection, press the ªFFº button (to fast forward)
or the ªREVº button (to reverse). While either
button is pressed, the disc goes forward or
backward at two different speeds depending on
how long the button is held down. (Pressing
either button for more than approximately three
seconds will speed up the process.) Release the
button at the desired point (found by watching
the elapsed playing time in the display or by
listening to the sound during fast forward or
reverse). When you have reached the beginning
of track 1, the CD player will begin playing.
*
[AS08000(MBC )04/95]
When you have reached the end of the disc by
keeping the fast forward button pressed, the
display will show ªENDº and the player will go
into pause mode. Push the ªPLAY/STOPº
button to begin playing the first track of the
disc, press the ªREVº button to back up from
the end of the disc, or use the ªSEEKº function
to locate a desired track.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

165
Driving Your Thunderbird
%*
[DR00500( ALL)03/93]
Driving with an Automatic
Overdrive Transmission
[DR00510(MBC )05/94]
The gearshift lever is floor mounted.
*
[DR00700( BCGV)01/95]
The automatic overdrive transmission operates
very much like a regular automatic transmission,
except it offers the extra overdrive feature.
%*
[DR00800( ALL)01/95]
Putting Your Vehicle in Gear
*
[DR00950( ALL)01/93]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
[DR00965(MBC )03/95]
To move the shifter out of P (Park), the ignition
key must be turned to either the OFF or the ON
position and the thumb button must be pushed
in. This vehicle is also equipped with the brake
shift interlock safety feature which prevents
shifting the transmission out of the P (Park)
position without the brake pedal being
depressed if the key is in the ON position.
*
[DR00975( ALL)03/95]
To operate:
*
[DR00980( ALL)01/95]
1. Start the engine.
*
[DR00985( ALL)01/95]
2. Depress and hold the brake pedal.
*
[DR00990( ALL)01/95]
3. Move the gearshift lever out of P (Park).
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

166 %
*
[DR00995( ALL)04/95]
Your vehicle is equipped with a Brake Shift
Interlock safety feature. This feature prevents the
gearshift from being moved from the P (Park)
position until the brake pedal is depressed. This
feature is active when the ignition is in the ON
position. If the gearshift lever CANNOT be
moved from P (Park) with the brake pedal
depressed:
*
[DR01000( ALL)01/95]
1. Turn the engine off and remove the ignition
key.
*
[DR01005( ALL)01/95]
2. Apply parking brake.
*
[DR01010( ALL)01/95]
3. Reinsert the ignition key and turn clockwise
to the first position (OFF).
*
[DR01020( ALL)01/95]
4. Depress the brake pedal, move the gearshift
lever to N (Neutral) and start the engine.
*
[DR01025( ALL)05/95]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
*
[DR01027( ALL)05/95]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledServicing Your
Thunderbirdin this Owner Guide for instructions
on checking and replacing fuses.
[DR01030(MBC )05/94]
The console-mounted gearshift will lock in
P (Park) when you turn the key to the LOCK
position. When the gearshift is in any position
except P (Park), the ignition key cannot be
turned to LOCK or removed from the steering
column. TO REMOVE THE KEY, the gearshift
lever must be in P (Park).
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

174
*
[DR11700( ALL)03/95]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
%*
[DR11800( ALL)03/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes louder or more frequent, have your
brakes inspected by your dealer or a qualified
service technician.
[DR11900( ALL)05/94]
Ford Motor Company has not found any
detrimental effects of popular mobile radio
transmitting equipment installed on vehicles
with the anti-lock brake system, if the equipment
is installed according to the manufacturer's
instructions. However, if mobile radio
transmitting equipment is installed in your
vehicle and, if either the anti-lock brake system
cycles or the check anti-lock light comes on at
any time other than right after you turn the key
to ON or during a sudden stop, have your
mobile radio dealer inspect the installation.
%*
[DR12000( ALL)03/95]
Parking Brake
*
[DR12050( ALL)01/95]
The parking brake should be used whenever
you park your vehicle.
[DR12500( BCGV)03/95]
The parking brake pedal is suspended just below
the bottom of the instrument panel to the left of
the brake pedal.
[DR12900( BC )03/95]
To set the parking brake while parking your
vehicle, apply the brake pedal with your right
foot and hold it while you push the parking
brake down firmly with your left foot. The brake
system warning light will glow.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

200 %
*
[RE12700(MBC )03/95]
Anti-Theft Wheel Lug Nuts (If equipped)
*
[RE12800( BC )01/95]
If your vehicle has this option, one of the lug
nuts on each wheel locks and must be unlocked
with a special key. The key and registration card
are attached to the lug wrench and stored with
the spare tire. If you lose the key, send the
registration card to the manufacturer (not the
dealer) to get a replacement key.
*
[RE12850(MBC )03/95]
NOTE: If entire lug wrench/lug nut key
assembly is lost, see your nearest Ford
or Lincoln-Mercury dealer who has
access to a master set of keys.
*
[RE12875(MBC )03/95]
DO NOT USE A POWER IMPACT WRENCH
ON THE LUG NUT KEY.
[RE13000(MBC )03/95]
quarter page art:0010357-B
The anti-theft lug nut and key
*
[RE13100(MBC )03/95]
Removing the anti-theft lug nut
*
[RE13300(MBC )03/95]
Insert the key over the locking lug nut. Make
sure that you hold the key square to the lug nut.
If you hold the key on an angle, you may
damage the key and the lug nut.
*
[RE13400(MBC )03/95]
Place the lug nut wrench over the lug nut key
and apply pressure on the key with the wrench.
Turn the wrench in a counterclockwise direction
to remove the lug nut.
File:rcreb.ex
Update:Mon Feb 19 10:48:15 1996

201
*
[RE13500(MBC )03/95]
Replacing the anti-theft lug nut
*
[RE13600(MBC )03/95]
Insert the key over the locking lug nut. Place the
lug nut wrench over the lug nut key and, while
applying pressure on the key, install the lug nut.
*
[RE13800( ALL)02/95]
If the Engine Cranks But Does
Not Start or Does Not Start After
a Collision
*
[RE13810( ALL)04/95]
The Fuel Pump Shut-off Switch
*
[RE13900( ALL)03/95]
If the engine cranks but does not start or if you
have had a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device that stops the fuel pump
when your vehicle has been involved in a
substantial jolt.
*
[RE14000( ALL)01/95]
For information on how to check and reset the
fuel pump shut-off switch, seeFuel pump shut-off
switchin the Index.
%
*
[RE14100( ALL)05/95]
Towing Your Vehicle
*
[RE14201( ALL)05/95]
If you need to have your vehicle towed, contact
a professional towing service or, if you are a
member, your roadside assistance center.
Recommended towing options include wheel lift
towing or flat bed towing.
[RE14210( BC)01/96]
DO NOT TOW WITH SLINGBELT EQUIPMENT
WHEN TOWING YOUR THUNDERBIRD FROM
THE REAR. Ford Motor Company has not
developed or approved a T-hook sling-type
procedure. When slingbelt towing from the front,
the towbar will deform the soft fascia (bumper).
However, it will return to an acceptable shape.
In both cases, wheel lift or flatbed equipment is
recommended.
File:rcreb.ex
Update:Mon Feb 19 10:48:15 1996
