High Beam Light
*
[LG07300( ALL)03/95]
This light comes on when the headlamps are
turned to high beam or when you flash the
lights.
[LG07400( ALL)05/92]
one inch art:0010125-A% [LG08300( BC )07/93]
Check Gauges Warning Light (if equipped)
[LG08310( BC )03/93]
one inch art:0010128-D*
[LG08400( BC )06/94]
This light will come on when the key is in the
ON position and the:
[LG08500( BC )04/89]
q
engine coolant temperature gauge is high, or
[LG08600( BC )04/89]
q
engine oil pressure gauge is low, or
[LG08700( BC )05/95]
q
when the fuel tank has reached empty
reserve.
[LG08825( BC )03/90]
This light serves as a reminder for you to check
the engine coolant temperature gauge, the
engine oil pressure gauge or the fuel gauge. It
will come on if there is a condition that needs
your attention.
[LG08850( BC )07/93]
SeeEngine Coolant Temperature Gauge, Engine Oil
Pressure Gauge,orFuel Gaugein this chapter for
more information.
File:rclgb.ex
Update:Mon Feb 19 10:51:57 1996

63 %
*
[LG11005( ALL)03/95]
Check Engine Warning Light
*
[LG11015( ALL)03/95]
The Powertrain On-Board Diagnostic II (OBD II)
system consists of the hardware and software
necessary to monitor the operation of the
powertrain. The OBD II system is designed to
check the function of the vehicle's powertrain
control system during normal operation. If an
emission problem is detected, the Check Engine
Warning Light (in the cluster) is turned on.
*
[LG11020( ALL)03/95]
Modification or additions to the vehicle may
cause incorrect operation of the OBD II system.
Additions such as burglar alarms, cellular
phones, and CB radios must be carefully
installed. Do not install these devices by tapping
into or running wires close to powertrain control
system wires or components.
*
[LG11050( ALL)03/95]
The light comes on briefly when you turn the
ignition key toON, but it should turn off when
the engine starts. If the light does not come on
when you turn the ignition toONor if it comes
on and stays on when you are driving, have
your vehicle serviced as soon as possible. This
indicates a possible problem with one of the
vehicle's emission control systems. You do not
need to have your vehicle towed in.
*
[LG11055( ALL)04/95]
If the light turns on and off at one (1) second
intervals while you are driving the vehicle, it
means that the engine is misfiring. If this
condition persists, damage could occur to the
engine or catalytic convertor. Have your vehicle
serviced at the first opportunity. You do not
need to have your vehicle towed in.
File:rclgb.ex
Update:Mon Feb 19 10:51:57 1996

69 % [LG16220( ALL)05/94]
Battery Voltage Gauge (If Equipped)
*
[LG16225( ALL)05/94]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[LG16230( ALL)05/94]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
(when the engine is off, or idling at a low
speed), the pointer may move toward the lower
end of the NORMAL band.
*
[LG16260( ALL)05/94]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
[LG16285( BC )05/95]
one third page art:0010655-D
Battery voltage gauge
%*
[LG16300( ALL)05/94]
Engine Oil Pressure Gauge
[LG16500( ALL)05/94]
This gauge indicates the engine oil pressure, not
the oil level. However, if your engine's oil level
is low, it could affect the oil pressure. With the
engine running, the pointer should move into
the NORMAL band. If the pointer drops below
the NORMAL band while the engine is running,
you have lost oil pressure and continued
operation will cause severe engine damage.
File:rclgb.ex
Update:Mon Feb 19 10:51:57 1996

71
% [LG17205( BC )03/95]
Indicator Lamp Module
(If equipped)
[LG17208( BC )05/94]
The following warning lights are on the
indicator lamp module. All of the warning lights
alert you to possible problems. Some of the
lights listed are optional. The following section
details what each of these indicators mean.
[LG17210( BC )03/95]
one third page art:0011215-A
The indicator lamp module
% [LG17215( BC )04/95]
Door Ajar Light (If equipped)
[LG17220( BC )06/92]
This light tells you when any door is not
completely shut. It glows when the key is in the
ON position.
[LG17225( BC )03/94]
one inch art:0010126-B
The door ajar light
File:rclgb.ex
Update:Mon Feb 19 10:51:57 1996

81
% [IP31700(MBC )05/95]
Rear Window Defroster
(If equipped)
*
[IP32000( ALL)12/91]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window.
[IP32600( BC )01/89]
The button for the rear window defroster is
located on the lower right side of the instrument
panel, just left of the climate control panel.
[IP32700( BC )06/93]
one third page art:0010190-B
The button that controls the rear window defroster
[IP33000( ALL)12/94]
Clear away any snow that is on the rear
window before using the defroster. With the
engine running, push the defrost button.
[IP33100( ALL)12/94]
After approximately 10 minutes, the defroster
will turn off. If the window is still not clear,
turn the defroster on again.
[IP33200( ALL)12/94]
The defroster will turn off when the ignition key
is turned to the OFF position.
*
[IP33300( ALL)02/95]
The heating elements are bonded to the inside of
the rear window. Do not use sharp objects to
scrape the inside of the rear window or use
abrasive cleaners to clean it. Doing so could
damage the heating elements.
File:rcipb.ex
Update:Mon Feb 19 10:51:01 1996

84 [IP36130( BCGV)05/95]Chime for headlamps on
*
[IP36160( BCGV)05/95]
This chime sounds if the driver or any passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until you
close the door, turn off the lamps or turn the
ignition to the ON position.
%*
[IP36200( ALL)05/95]
Cleaning the Exterior Lamps
*
[IP36300( ALL)05/95]
Do not use dry paper towel, chemical solvents
or abrasive cleaners to clean the lamps, as these
may cause scratches or crack the lamps.
%*
[IP36900( BC )02/95]
Setting the Autolamp Delay System
(If equipped)
*
[IP37100( BCGV)02/95]
The autolamp sets the headlamps to turn on and
off automatically. You can use the autolamp to:
*
[IP37300( BCGV)01/95]
q
turn on the lamps automatically at night
*
[IP37400( BCGV)01/95]
q
turn off the lamps automatically during
daylight
*
[IP37500( BCGV)01/95]
q
keep the lamps on for up to three minutes
after you turn the key to OFF.
[IP37900( BC )05/95]
one third page art:0010199-D
The controls for the autolamp
File:rcipb.ex
Update:Mon Feb 19 10:51:01 1996

85
*
[IP38200( BC )01/95]
To set the autolamp:
*
[IP38300( BC )05/95]
1. Make sure the headlamp knob is in the OFF
position. If the knob for the headlamps is
ON, you cancel the autolamp.
*
[IP38400( BC )01/95]
2. Turn the ignition key to ON or start your
vehicle.
[IP38500( BC )06/93]
3. Find the autolamp thumbwheel to the right
of the panel dim thumbwheel.
[IP38900( BC )11/92]
4. Turn the thumbwheel up to the beginning of
the MAX position (within the DELAY range).
*
[IP39200( BC )01/95]
5. The autolamp automatically turns the lamps
on and off for you.
*
[IP39275( BCGV)01/95]
Do not put any articles on top of the photocell
that is located in the top left corner of the
instrument panel. This photocell controls the
autolamp. If you cover it, the photocell reacts as
if it is nighttime, and the lamps turn on.
*
[IP39300( BC )01/95]
To turn the autolamp off, move the thumbwheel
back to OFF.
*
[IP39500( BCGV)12/92]
You can set the autolamp so the lamps stay on
for up to three minutes after you turn your
vehicle off.
[IP39600( BC )12/94]
To keep the lamps on after you leave your
vehicle, turn the thumbwheel as far into the
MAX range as you want.
[IP40000( BC )12/94]
If you move the thumbwheel only slightly into
the DELAY area, your lamps will stay on for
only a moment after you turn your vehicle off.
The further you move the thumbwheel into the
DELAY area (toward the MAX position), the
longer the lamps will stay on after you turn
your vehicle off.
File:rcipb.ex
Update:Mon Feb 19 10:51:01 1996

87 [IP45450( BCGV)07/93]
Using the Automatic Illuminated Entry
System (If equipped)
[IP45600( BCGV)03/91]
The interior lights turn on when you lift the
outside door handle on either front door, when
any button of the keyless entry system is pushed
or when you press UNLOCK, TRUNK, or
PANIC on a programmed remote entry
transmitter if your vehicle is equipped with
remote entry.
[IP45900( BCGV)01/89]
These lights automatically turn off after 25
seconds or when you turn the ignition key to
ON or ACC. The inside lights will not turn off if
you have turned them on manually or if a door
is open.
[IP46000( BCGV)01/89]
Tips on the illuminated entry system:
[IP46100( BCGV)01/89]
q
The illuminated entry timer will not turn off
the courtesy lamp if that lamp has been
turned on manually or by the door switch.
[IP46200( BCGV)01/89]
q
Occasionally, you will need to clean the lens
of the door lock assembly. Use Ford
Multi-Purpose Cleaner Concentrate, a mild
soap, or household ammonia and water
solution. Apply with a soft cloth or cotton
swab, followed by a clear water rinse.
