1996 FORD TAURUS fluid

73
*
[LG02400(ALL)01/95]
Indicator Lights and Chimes
%*
[LG02500(ALL)07/95]
Safety Belt Warning Light and Chime
*
[LG02510(ALL)09/95]
This warning light and chime remind you to
fasten your safety belt. The following conditions
will take place:
[LG02550(ALL)12/95]
q
If the driver's safety belt is not buckled when
the key is turned to the ON position, the
light will activate for 1 to 2 minutes and the
chime will sound for 4 to 8 seconds.
*
[LG02600(ALL)03/95]
q
If the driver's safety belt is buckled while the
light is on or the chime is sounding, both the
light and the chime will turn off.
[LG02650(ALL)12/95]
q
If the driver's safety belt is buckled before the
key is turned to the ON position, the light
will briefly activate, then shut off and the
chime will not activate.
[LG02700(ALL)02/95]
one inch art:0000107-B
Safety belt warning light
%*
[LG02900(ALL)06/95]
Brake System Warning Light
*
[LG03000(ALL)03/95]
The warning light for the brakes can show two
things Ð that the parking brake is not fully
released, or that the brake fluid level is low in
the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by
your dealer or a qualified service technician.
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com

87 [LG14750(ALL)12/95]
Low Coolant Light and Chime
[LG14850(ALL)04/95]
This light indicates that the level of the engine
coolant is low inside the coolant reservoir.
[LG14950(ALL)04/95]
one inch art:0000114-C
Low coolant light
[LG15000(ALL)12/95]
This light comes on for a few seconds when
your ignition key is turned to the ON position,
but should turn off when the engine starts. If the
coolant is low, the light will come on and a
single chime will sound. If this light stays on,
check the level of coolant inside the coolant
reservoir. For instructions on adding coolant
mixture, seeEngine coolantin the Index.
% [LG15150(ALL)12/95]
Low Washer Fluid Light
*
[LG15250(ALL)02/95]
This light comes on if the reservoir is less than a
quarter full when you turn on the windshield
washers.
[LG15350(ALL)04/95]
one inch art:0000118-B
Low washer fluid light
% [LG16100(ALL)12/95]
Rear Lamp Out Indicator
[LG16200(ALL)12/95]
This light indicates that a rear tail lamp or
brakelamp is not functioning. It comes on
momentarily when the ignition is turned to the
ON position, then goes out.
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com

117 %
*
[SC04100(ALL)08/95]
Variable Interval Wipers
*
[SC04300(ALL)01/95]
In addition to two speed wipers, your vehicle
has wipers that you can set to operate at
varying intervals. For example, you can set the
interval so they wipe less often when it drizzles
or more often in heavier rain.
[SC04500(ALL)04/95]
one third page art:0001412-B
The variable interval wiper on the turn signal lever
*
[SC04925(ALL)03/94]
To set the interval wipers, turn the knob at the
end of the turn signal lever toward or away
from you until the wipers are going at the
desired interval.
*
[SC04950(ALL)08/95]
Windshield Washer
[SC05000(ALL)05/94]
To clean the windshield, push in the end of the
wiper switch knob. For a constant spray, keep
the knob pushed in. After you release the knob,
the wipers operate for two to three cycles before
turning off (if the wipers were off) or returning
to HI, LO, or the interval setting selected.
[SC05050(ALL)04/95]
For information about the rear washer on the
wagon, seeWindshield washer fluid and wipersin
the Index.
File:07fcsct.ex
Update:Mon Jan 22 15:52:32 1996
ProCarManuals.com

118
*
[SC05100(ALL)03/95]
If the washer does not work, check the washer
fluid level and fill it if it is low. See theServicing
Your Tauruschapter. If there is enough fluid,
consult your nearest Ford or Lincoln-Mercury
dealer.
*
[SC05300(ALL)08/95]
Do not try to clean the windshield when the
washer fluid container is empty or activate the
washers at any time for more than 15 seconds
continuously. This could damage the washer
pump system.
*
[SC05350(ALL)08/95]
RWARNING
In freezing weather, the washer solution
may freeze on the windshield and obscure
your vision. Always warm up the
windshield with the defroster before you
use the washer fluid. If you cannot see
through the windshield clearly, it can
increase the risk of being involved in a
collision.
*
[SC05500(ALL)08/95]
For information about refilling the washer fluid
or replacing your windshield wiper blades, see
Windshield washer fluid and Wipersin the Index.
%
*
[SC05520(ALL)03/95]
Hazard Flasher
[SC05540(ALL)05/89]
one third page art:0000238-A
Using the hazard flasher switch
File:07fcsct.ex
Update:Mon Jan 22 15:52:32 1996
ProCarManuals.com

256
*
[SV01250(ALL)03/95]
Ford Motor Company recommends that you
perform the Owner Maintenance Checks listed in
theMaintenance Schedule and Recordbooklet.
These services are important for the proper
operation of your vehicle. In addition to the
conditions listed in the Owner Maintenance
Checklist, be alert for any unusual noise,
vibration, or other indication that your vehicle
may need service. If you do notice something
unusual, see that your vehicle is serviced
promptly.
[SV01275(ALL)03/95]
Use only recommended fuels, lubricants, fluids,
and service parts conforming to specifications.
Motorcraft parts are designed and built to
provide the best performance in your vehicle.
Using these parts for replacement is your
assurance that Ford-built quality stays in your
vehicle.
%*
[SV01300(ALL)09/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
%
*
[SV01600(ALL)06/95]
Precautions When Servicing Your
Vehicle
*
[SV01700(ALL)06/95]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
[SV01800(ALL)10/95]
q
Do not work on a hot engine. The engine
cooling fans may come on unexpectedly.
Always turn the engine off and let it cool.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

264 %
*
[SV05075(ALL)04/95]
Cleaning the Engine
*
[SV06000(ALL)07/95]
A clean engine is more efficient because the
engine is able to cool properly. A build up of
grease and dirt acts as an insulator, keeping the
engine warmer than normal.
*
[SV06020(ALL)07/95]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[SV06040(ALL)08/95]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[SV06060(ALL)07/95]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[SV06080(ALL)04/95]
q
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%
*
[SV06100(ALL)03/95]
Filling the Fuel Tank
[SV06800(ALL)04/95]
1. Turn the engine off. After opening the fuel
door, remove the cap carefully and slowly
by turning it counterclockwise 1/4 turn until
it stops. Pull to remove the cap. A tether
attaches the cap to the fuel filler pipe.
[SV06825(ALL)04/95]
one inch art:0001470-AFile:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

272
*
[SV13605(ALL)02/95]
Self-Service Pointers
*
[SV13611(ALL)01/95]
If you choose to do your own fueling, you
should also perform a few simple maintenance
routines. This extra effort will save you
additional money and contribute to the driving
efficiency of your vehicle.
*
[SV13615(ALL)01/95]
The following procedures require only a tire
gauge, a rag, an oil can spout and windshield
washer fluid.
*
[SV13620(ALL)01/95]
q
Check the engine oil at every refueling stop
*
[SV13625(ALL)01/95]
q
Clean the windshield, outside mirrors and
headlights
*
[SV13630(ALL)01/95]
q
Check windshield washer fluid
*
[SV13633(ALL)02/95]
q
Check tires for excessive wear or worn edges
*
[SV13636(ALL)01/95]
q
Check the tire pressure at least monthly
%
*
[SV13638(ALL)02/95]
Engine Oil Recommendations
*
[SV13639(ALL)09/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[SV13650(ALL)03/95]
one third page art:0060021-E
The API Certification Mark
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

275 %
*
[SV16300(ALL)06/95]
Changing the Engine Oil and the Oil Filter
*
[SV16400(ALL)04/95]
Change the engine oil and oil filter per the
following, whichever occurs first.
[SV16500(ALL)04/95]
one third page art:0060618-C*
[SV16550(ALL)03/95]
Refer to the Maintenance Schedule and Record
Booklet for additional information.
%*
[SV16600(ALL)09/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV16700(ALL)07/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
[SV16800(ALL)07/95]
Protect your skin by washing with mild soap
and water.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com
