Page 348 of 401
![FORD F150 1996 10.G Owners Manual 349
*
[SV35800( ALL)03/91]
Driveline Universal Joint and
Slip Yoke
*
[SV36000(BEF )06/93]
The universal joints that come standard with
your vehicle do not require lubrication. If your
original equipme FORD F150 1996 10.G Owners Manual 349
*
[SV35800( ALL)03/91]
Driveline Universal Joint and
Slip Yoke
*
[SV36000(BEF )06/93]
The universal joints that come standard with
your vehicle do not require lubrication. If your
original equipme](/manual-img/11/5014/w960_5014-347.png)
349
*
[SV35800( ALL)03/91]
Driveline Universal Joint and
Slip Yoke
*
[SV36000(BEF )06/93]
The universal joints that come standard with
your vehicle do not require lubrication. If your
original equipment universal joints are replaced
with universal joints equipped with grease
fittings, lubrication will be necessary at the
intervals shown in theMaintenance Schedule and
Recordbooklet.
*
[SV36100(B F )06/93]
Your vehicle may be equipped with a constant
velocity or double cardan joint at the transfer
case end of the driveshaft. The front driveshaft
double cardan joint may be fitted with a flush
type grease fitting that requires an adapter to
permit proper lubrication. Lubricate the drive
joint according to the intervals shown in the
Maintenance Schedule and Recordbooklet.
*
[SV36200(B F )05/90]
quarter page art:0020379-A
Double cardan joint
*
[SV36300( ALL)03/95]
Brake Fluid
*
[SV36350( ALL)05/90]
Your vehicle is equipped with a brake fluid level
indicator in the master cylinder which lights the
BRAKE warning light on the instrument panel
when the brake fluid level is low.
*
[SV36400( ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
Page 362 of 401
363 %
*
[SV42200( ALL)05/95]
Checking and Replacing Fuses
*
[SV42300( ALL)02/95]
If you need to check a fuse, follow these steps:
*
[SV42800(B F )03/91]
1. In order to find the fuse panel, you must
first remove the cover from the lower edge
of the instrument panel. You can do this by
pulling on handle to disengage the fasteners.
*
[SV42900(B F )03/91]
one third page art:0020475-B
Fuse panel cover
*
[SV43300( ALL)10/94]
2. On the fuse panel cover, find the number of
the fuse you want to check. The diagram on
the cover tells you where to locate the fuse
on the panel.
*
[SV43350(B FM)10/92]
The underside of the cover also contains a
fuse pulling tool in case you need to replace
a blown fuse.
*
[SV43400( ALL)10/92]
3. Check the fuse to see if it is blown. Look
through the clear side of the fuse to see if
the metal wire inside is separated. If it is,
the fuse is blown and should be replaced.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
Page 366 of 401
![FORD F150 1996 10.G Owners Manual 367
*
[SV46300(BEF )03/95]
Removing the headlamp bulb
*
[SV46400(BEF )01/95]
1. Make sure that the headlamp switch on the
instrument panel is in the OFF position.
*
[SV46501(B F )12/91]
2. Lift the ho FORD F150 1996 10.G Owners Manual 367
*
[SV46300(BEF )03/95]
Removing the headlamp bulb
*
[SV46400(BEF )01/95]
1. Make sure that the headlamp switch on the
instrument panel is in the OFF position.
*
[SV46501(B F )12/91]
2. Lift the ho](/manual-img/11/5014/w960_5014-365.png)
367
*
[SV46300(BEF )03/95]
Removing the headlamp bulb
*
[SV46400(BEF )01/95]
1. Make sure that the headlamp switch on the
instrument panel is in the OFF position.
*
[SV46501(B F )12/91]
2. Lift the hood and behind the headlamp
remove the electrical connector by grasping
the wires and pulling rearward.
*
[SV46700(B F )04/95]
3. Remove the bulb retaining ring by turning it
1/8 of a turn to free it from the socket. Then
slide the ring off the plastic base. Keep the
ring.You must use it again to hold the new
bulb in place.
*
[SV46800(B F )04/95]
4. Carefully remove the bulb assembly from its
socket by gently pulling it rearward without
turning.
*
[SV46900(BEF )03/95]
Installing the headlamp bulb
*
[SV47000(BEF )02/95]
1. With the flat side of the bulb's plastic base
facing upward, insert the glass end of the
bulb into the socket. You may need to turn
the bulb left or right to line up the grooves
in the plastic base with the tabs in the
socket. When the grooves are aligned, push
the bulb into the socket until the plastic base
contacts the rear of the socket.
*
[SV47100(BEF )02/95]
2. Slip the bulb retaining ring over the plastic
base until it contacts the rear of the socket.
Lock the ring into the socket by rotating it
clockwise until you feel a ªstopº.
*
[SV47200(B F )02/95]
3. Push the electrical connector into the rear of
the plastic base until it snaps, locking it into
position.
*
[SV47300(BEF )02/95]
4. Turn the headlamps on and make sure that
they work properly. If the headlamp was
correctly aligned before you changed the
bulb, you should not need to align it again.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
Page 400 of 401
401
*
[QI05300( F )05/94]
full page art:0021050-C
Instrument panel
File:ltqif.ex
Update:Thu May 9 15:23:25 1996
