265
*
[RE16800(BEF )12/91]
3. Use the tapered end of the lug nut wrench
to unscrew wheel ornaments attached by
retaining screws. Remove any wheel trim.
Insert the tapered end of the lug nut wrench
behind wheel covers or hubcaps and twist
off.
*
[RE16900(BEF )10/89]
4. Loosen the wheel nuts by pulling up on the
handle of the lug nut wrench about one-half
turn (counterclockwise). Do not remove the
wheel lug nuts until you raise the tire off the
ground.
%*
[RE16950(BEF )05/95]
Removing and Replacing the Tire
[RE17100(B F )02/95]
1. Insert the jack handle into the jack and use
the handle to slide the jack under the
vehicle.
*
[RE17175(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE17200(BEF )05/95]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

271
*
[RE21151(BEF )10/92]
one third page art:0020939-B
*
[RE21200( F )08/91]
b. Turn the jack handle clockwise until the
wheel is completely off the ground.
*
[RE21400(BEF )01/95]
3. Remove the lug nuts with the lug nut
wrench.
*
[RE21500(BEF )01/95]
4. Replace the flat tire with the spare tire.
*
[RE21600( EFM)01/89]
If your vehicle has dual rear wheels, there are
locating pins on the hubs and wheels with
corresponding holes. When you put the wheel
back on, make sure the pins are lined up with
the proper holes.
[RE21800( EF )02/95]
If your vehicle has single rear wheels, thread the
lug nuts on the wheel studs with the beveled
face toward the wheel. Use the lug nut wrench
to screw the lug nut snugly against the wheel
but do not tighten.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

272
*
[RE21900( EF )01/89]
If your vehicle has dual rear wheels, thread the
two-element swiveling lug nut on the wheel
studs with the flange face toward the wheel. Use
the lug nut wrench to screw the lug nut snugly
against the wheel but do not tighten.
*
[RE22000( EF )05/90]
quarter page art:0020310-A
Single rear wheel nut
*
[RE22100( EFM)05/90]
quarter page art:0020311-A
Dual rear wheel nut
*
[RE22200(BEF )01/95]
5. Lower the vehicle by turning the jack handle
counterclockwise.
*
[RE22300(BEF )01/95]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration.
File:ltref.ex
Update:Thu May 9 15:24:41 1996

304
*
[SV02950(BEF )03/95]
Opening the Hood
*
[SV03000(B F )12/91]
1. Pull the hood release handle, located next to
the parking brake pedal.
*
[SV03050(BEF )12/91]
2. While applying downward pressure on the
hood, push the hood latch handle located
behind the grille near the center front of the
vehicle to the left.
*
[SV03150(B F )01/89]
3. As you open the hood to its fullest extent, a
clock spring will assist you and ªsnapº into
position. The clock spring lift secures the
hood at its fullest height.
*
[SV03300(BEF )03/91]
one third page art:0020333-A
Hood release handle
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

311
*
[SV06475( F )10/90]
one third page art:0020753-A
Fuel filler door
*
[SV06550(BEF )02/91]
Opening the Fuel Filler Door
*
[SV06600(BEF )10/94]
To open the fuel filler door of your vehicle, just
insert your finger in the divot and pull the door
open all the way.
*
[SV06700( ALL)01/95]
Removing the fuel cap
*
[SV06750( ALL)01/95]
The proper instructions for removing the fuel
cap are as follows:
*
[SV06800( ALL)03/90]
q
Unscrew the fuel cap by exerting pressure on
the plastic lock bar and rotating the fuel cap
counterclockwise.
*
[SV06850( ALL)12/91]
q
Turn the fuel cap 1/2 to 3/4 of a turn until a
hissing sound is heard. Wait until the hissing
sound stops and then continue rotating
counterclockwise to remove the fuel cap.
*
[SV06900( ALL)03/93]
q
Make sure that you follow the above fuel cap
removal instructions and use caution. Such
caution will minimize the possibility of fuel
spraying during removal of the fuel cap.
*
[SV06950( ALL)03/91]
To replace and secure the fuel cap; place it in
position and rotate it clockwise until it clicks
(ratchets). Doing so will not damage or break
the fuel cap. The ratcheting mechanism allows
the fuel cap to be sealed without overtightening.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

317
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
*
[SV10300( ALL)02/95]
Filling the fuel tank
*
[SV10400( ALL)04/94]
RWARNING
Do not overfill the fuel tank. The pressure
in an overfilled tank may cause leakage
and lead to fuel spray and fire.
*
[SV10500( ALL)01/95]
To fill the fuel tank properly:
*
[SV10550( ALL)01/95]
NOTE: Extinguish all lit cigarettes, other
smoking materials, and any open
flames before fueling your vehicle.
*
[SV10600( ALL)01/95]
1. Remove the fuel cap by following the
instructions above underRemoving the Fuel
Capin this chapter. Proceed to add fuel to
the tank only if your vehicle is on level
ground.
*
[SV10700( ALL)03/95]
2. Make sure that you pump unleaded fuel and
put the nozzle all the way inside the fuel
filler pipe.
*
[SV10800( ALL)05/95]
3. If you spill any fuel on the body of your
vehicle, clean it off immediately. The fuel
may dull or soften the paint if you do not
wash it off.
%*
[SV10900( ALL)05/95]
4. Replace the fuel cap completely when you
are finished. Turn it clockwise 1/4 turn until
it is tight. It will click when it is fully
tightened.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

326
*
[SV18500( ALL)05/95]
RWARNING
Never remove the coolant recovery cap
while the engine is running or hot.
*
[SV18600( ALL)05/95]
RWARNING
Follow these steps to minimize risk of
personal injury.
*
[SV18700( ALL)03/95]
1. Before you remove the cap, turn the engine
off and let it cool. Even when the engine is
cool, be careful when you remove the
radiator cap.
*
[SV18800( ALL)03/95]
2. When the engine is cool, wrap a thick cloth
around the cap and turn it slowly
counterclockwise to the first stop.
*
[SV18900( ALL)03/95]
3. Step back while the pressure releases.
*
[SV19000( ALL)04/95]
4. When you are sure that all the pressure has
been released, use the cloth to press, turn,
and remove cap.
*
[SV19100( ALL)03/95]
5. Stand away from the radiator opening. Hot
steam may blow out or hot engine coolant
may even splash out.
*
[SV19500( ALL)01/93]
Freezing Protection
*
[SV19600( ALL)03/91]
The factory-installed solution of Ford Premium
Cooling System Fluid and water will protect
your vehicle tos35ÊF (s37ÊC).Check the freeze
protection rating of the engine coolant at least
once a year, just before winter.
*
[SV19701( ALL)02/95]
Add engine coolant only to the recovery
reservoir.If the coolant level is low, add to the
reservoir a 50/50 mixture of water and the type
of engine coolant that Ford specifies. You may
add water by itself only in an emergency, but
you should replace it with a 50/50 mixture as
soon as possible.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

329
*
[SV20700( ALL)05/95]
Engine coolant drain and flush
*
[SV20800( ALL)10/89]
To drain your vehicle's engine coolant:
*
[SV20900( ALL)03/94]
1. Turn off the engine and let it cool. Fully
depressurize the engine cooling system by
covering the radiator cap with a thick cloth
and turning it slowly counterclockwise to the
first stop. Step back while the pressure
releases.
*
[SV20950( ALL)05/90]
2. Remove the cap.
*
[SV21000(B FM)05/90]
3. Attach a small hose to the drain tube at the
bottom of the radiator.
*
[SV21200( ALL)05/90]
4. Let the engine coolant drain into a suitable
container. Disconnect the lower radiator hose
at the radiator connector and drain any
remaining engine coolant into a container.
*
[SV21225( ALL)05/94]
5. Reconnect the lower radiator hose and close
the radiator drain cock.
*
[SV21250( ALL)10/94]
Proper procedures for flushing the cooling
system can be found in theTruck Service Manual.
*
[SV21300( ALL)02/95]
Engine coolant refill procedure
*
[SV21400( ALL)10/89]
After you have drained the engine cooling
system:
*
[SV21500( ALL)01/89]
1. Fill the radiator with a 50/50 mixture of the
specified engine coolant concentrate and
water. Allow several minutes for trapped air
to escape (bubble out) and for engine coolant
to flow through the radiator.
*
[SV21900( ALL)03/94]
2. Replace the radiator cap to its fully installed
position, then back off to the first stop. This
will prevent high pressure from building up
in the cooling system during this part of the
fill procedure.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
