1996 FORD ASPIRE tow

36 [SR17310(ALL)07/95]
half page art:0032275-AChecking that retractor is in automatic locking mode
[SR17325(ALL)05/95]
8. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
[SR17350(ALL)05/95]
NOTE: To remove the retractor from the
automatic lock mode, allow the seat belt to
retract fully to its stowed position and the
retractor will automatically switch back to the
vehicle sensitive locking mode for normal adult
usage.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996

42
*
[ST02100(ALL)09/93]
LOCK locks the steering wheel. It also locks the
gearshift lever in P (Park) (automatic transaxle).
*
[ST02200(ALL)01/95]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
*
[ST02300(ALL)05/95]
If your key is stuck in the LOCK position and
will not turn, move your steering wheel left or
right until the key turns freely.
[ST02325(ALL)09/93]
If your vehicle has a manual transaxle, you must
push the key toward the steering column to
rotate the switch to the LOCK position.
%*
[ST02350(ALL)03/95]
ACC (accessory) allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running.
*
[ST02400(ALL)05/95]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[ST02500(ALL)03/95]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

52
*
[ST09470(ALL)03/95]
Once the shut-off switch is triggered, you must
reset the switch by hand before you can start
your vehicle.
[ST09480(ALL)02/95]
The reset switch on your vehicle is located in a
small compartment on the left side of the
luggage compartment.
[ST09490(ALL)02/95]
half page art:0032161-C
The location of the fuel pump shut-off switch (U.S. vehicle
shown Ð Canadian vehicles similar)
*
[ST09500(ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the
switch or try to start your vehicle. Have
all the passengers get out of the vehicle
and call the local fire department or a
towing service.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

53
*
[ST09510(ALL)10/95]
If your engine cranks but does not start after a
collision or major jolt:
*
[ST09520(ALL)02/95]
1. Turn the key in the ignition to the LOCK
position.
*
[ST09530(ALL)03/95]
2. Check under the vehicle for leaking fuel.
[ST09540(ALL)02/95]
3. If you do not see or smell fuel, remove the
door covering the fuel pump shut-off switch
compartment by pressing the tab toward the
rear seat. Push down the red reset button on
the fuel pump shut-off switch.
*
[ST09550(ALL)02/95]
4. Attempt to start your vehicle. If the vehicle
starts, let it run a few seconds, then turn the
key to the LOCK position.
*
[ST09560(ALL)03/95]
5. Check under the vehicle again for leaking
fuel.If you see or smell fuel, do not start
your vehicle again.If you do not see or
smell fuel, you can try to start your vehicle
again.
*
[ST09600(ALL)09/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
%*
[ST11700(ALL)05/95]
Guarding Against Exhaust Fumes
*
[ST11800(ALL)02/95]
Carbon monoxide, although colorless and
odorless, is present in exhaust fumes. Take
precautions to avoid its dangerous effects.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

62
*
[LG04500(ALL)01/95]
High Beam Light
*
[LG04600(ALL)03/95]
This light comes on when the headlamps are
turned to high beam or when you flash the
lights.
*
[LG04700(ALL)01/92]
one inch art:0030174-A
High beam light
*
[LG05300(ALL)03/95]
Check Engine Warning Light
*
[LG05400(ALL)05/95]
This light comes on when the electronic engine
control system is not working properly. This is
the computer system that controls the operating
conditions of the engine.
*
[LG05450(ALL)09/93]
one inch art:0030175-B
Check engine warning light
*
[LG05600(ALL)05/95]
This light comes on briefly when you turn the
ignition to the ON position, but should turn off
when the engine starts. If the light does not
come on when you turn the ignition to the ON
position or if it comes on and stays on when
you are driving, have your vehicle serviced as
soon as possible. This indicates a possible
problem with one of the engine's emission
control systems.You do not need to have your
vehicle towed in.
File:05iclgf.ex
Update:Wed Jan 24 14:32:51 1996

72
*
[IP03600(ALL)06/94]
Turning On the Heat
[IP03675(ALL)08/91]
1. Move the temperature control lever all the
way into the red area.
[IP03700(ALL)07/95]
2. Move the function selector lever to direct air
to the floorR.
[IP03725(ALL)07/95]
3. Leave the air door control lever in the fresh
air positionNor the windows may fog
up in cold weather.
[IP03750(ALL)07/95]
4. Set the fan speed
Hto the desired speed.
[IP03775(ALL)02/95]
As the interior warms up, select a slower fan
speed or move the temperature control lever
toward the blue area to keep a comfortable
setting.
*
[IP04300(ALL)01/89]
Defrosting the Windshield and Side
Windows
[IP04350(ALL)02/95]
1. Set the temperature control lever all the way
to the right in the red area.
[IP04375(ALL)07/95]
2. Set the function selector lever to theV
(defrost) position.
[IP04400(ALL)07/95]
3. Set the air door control lever to the right
N(fresh air) position.
[IP04450(ALL)07/95]
4. Set the
H(fan speed) to the highest speed.
The fan speed can be adjusted to maintain
fog free windows after they are cleared.
*
[IP04700(ALL)01/89]
Heating and Defrosting at the Same Time
[IP04750(ALL)08/91]
1. Set the desired temperature and fan speed.
[IP04800(ALL)07/95]
2. Move the function selector lever to theS
(mix) position and move the air door control
lever to the right.
File:06icipf.ex
Update:Wed Jan 24 14:47:07 1996

73
*
[IP05200(ALL)01/94]
Ventilating Your Vehicle With Outside Air
*
[IP05300(ALL)06/95]
On mild days, you may want to ventilate your
vehicle with outside air. To open the vents:
[IP05400(ALL)07/95]
1. Move the function selector lever to theQ
(panel) position.
[IP05500(ALL)07/95]
2. Move the air door control lever to theN
(fresh air) position.
*
[IP05600(ALL)07/95]
3. Set the fan
Hspeed as desired.
*
[IP05800(ALL)12/91]
Tips for Controlling the Temperature in
Your Vehicle
*
[IP05900(ALL)03/94]
q
To vary the temperature inside your vehicle,
move the temperature selector toward the red
area for warmer air and toward the blue area
for cooler air.
*
[IP06000(ALL)03/94]
q
If you drive with the fan off and the
windows closed, the windows may fog up.
To prevent fogging:
[IP06100(ALL)07/95]
1. Set the function selector lever to theV
(defrost) position.
*
[IP06200(ALL)01/89]
2. Set the desired temperature.
*
[IP06300(ALL)07/95]
3. Set the desired
Hspeed.
[IP06350(ALL)07/95]
4. Always use theN(fresh air) setting on
the air door control lever.
*
[IP06400(ALL)12/91]
q
Do not put objects under the front seats that
will interfere with the flow of air to the back
seats.
*
[IP06500(ALL)12/03]
q
Remove any snow, ice, or leaves from the
area below the windshield on the outside of
your vehicle. They could block the air intake.
File:06icipf.ex
Update:Wed Jan 24 14:47:07 1996

79 [IP22900(ALL)05/93]
quarter page art:0030053-A
Interior courtesy lamp
[IP22950(ALL)07/93]
Do not leave the dome light on for long periods
of time when the engine is not running, or the
battery may discharge.
*
[IP24200(ALL)05/95]
Radio
*
[IP24300(ALL)07/95]
For information about the radio in your vehicle,
refer to theAudio SystemsChapter in this owner
guide.
*
[IP24320(ALL)05/92]
Radio Antenna
[IP24340(ALL)05/91]
The radio antenna is mounted near the top of
the windshield on the driver's side of the
vehicle. The antenna can be extended by pulling
it upward away from its base. To retract the
antenna, push it in toward its base.
[IP24360(ALL)05/91]
NOTE: To receive the best reception, the
antenna must be fully extended. If the
antenna is not fully extended, the
result may be weak or noisy radio
reception.
[IP24380(ALL)03/94]
NOTE: The radio antenna must be pushed in
prior to entering a car wash. If you do
not push in the antenna before
entering a car wash it could result in
damage to the antenna, antenna base,
or vehicle.
File:06icipf.ex
