1996 CADILLAC DEVILLE sensor

Downloaded from www.Manualslib.com manuals search engine SERVICE BRAKE FLUID SWITCH - 37: A high
level of brake fluid causes this message to display if the
ignition is in the
RUN position. Have the brake system
serviced by a Cadillac technician as soon as possible.
If
the brake warning light is on, refer to the directions
listed in that 'part.
SERVICE CHARGING SYSTEM - 102: This
message will display when a problem with
the charging
system has been detected. Have your vehicle serviced at
your Cadillac dealership.
SERVICE ELECTRICAL SYSTEM - 106: This
message will display if
an electrical problem has
occurred within the PCM. Have your vehicle service by your Cadillac dealership.
SERVICE EMISSIONS SYSTEM - 104: A problem
in the emissions system has occurred when this message
appears. Have your Cadillac dealership service your vehicle.
SERVICE ENGINE COOLING SYSTEM - 103: A
problem within the engine cooling system has been
detected when this message displays. See your Cadillac
dealership
for service.
SERVICE FUEL SYSTEM - 101: The PCM
has detected a problem within the fuel system when
this message appears. See
your Cadillac dealership
for service.
SERVICE IDLE CONTROL SYSTEM - 107: A
problem with the idle control has occurred when this message displays. Bring your vehicle
to your Cadillac
dealership for service.
SERVICE IGNITION SYSTEM - 105: This
message displays when a failure in the ignition system
has been detected. Have your vehicle serviced by your Cadillac dealership.
SERVICE RIDE CONTROL - 84: This message is
displayed to indicate that the suspension system is not
operating properly.
To correct this problem have your
vehicle serviced at your Cadillac dealership.
SERVICE TRANSMISSION - 100: If a problem is
detected with the transaxle, this message will appear. Have your vehicle checked by your CadilIac dealership.
SPEED SENSOR FAULT - 109: A circuit problem with
the vehicle speed sensor will trigger this message to appear.
Have your Cadillac dealership service your vehicle.
2-80
-.
-4

Downloaded from www.Manualslib.com manuals search engine TRANSMISSION HOT - 112: This messages indicates
that the transmission fluid in your vehicle is too hot
(message -apppears when fluid temperature has reached
266 "F (1 30°C) for 15 minutes or when the temperature
reaches
291 OF (144°C) for 32 seconds). Have your
vehicle serviced immediately.
TRUNK OPEN - 24: This message indicates that the
trunk is open when the ignition is in RUN.
TURN SIGNAL ON - 20: This message is a reminder,
after driving about
a mile, that you have the turn signal on.
VEHICLE SPEED LIMITED TO XXX MPH
(KM/H) - 113: A failure in the suspension control
system has occurred when this message appears. The
PCM determines the speed your vehicle is limited to.
Have your Cadillac serviced if this message appears.
VERY LOW REFRIGERANT A/C COMPRESSOR
OFF - 12: This message means that the air conditioning
system detects a refrigerant level that is low enough to
:awe damage to the
A/C compressor. To avoid damage
:he
A/C compressor automatically turns off and the
Electronic Climate Control will automatically switch ?om
AUTO to AC and remain there. Have the A/C
iystem serviced if this message appears.
Traction Active
When your traction control system is limiting wheel spin,
the
TRACTION ACTIVE message will be displayed.
Slippery road conditions may exist if this message is
displayed,
so adjust your driving accordingly. This
message
will stay on for a few seconds after the traction
control system
stops limiting wheel spin.
Trip Computer
Road Sensing Suspension
The Road Sensing Suspension (RSS)(DeVille) and the Continuous Variable-Road Sensing Suspension
(CV-RSS)(Concours) automatically adjust the ride of
your vehicle, with the
CV-RSS having a wider range of
control. Automatic ride control is achieved through the
RSS controller, a computer used to control and monitor
the suspension system. The controller receives inputs
from various sensors to determine the proper system
response.
If the controller detects a problem within the
system, the DIC
will display a SERVICE RIDE
CONTROL message. If this message appears, have
your vehicle serviced at your Cadillac dealership.
Z-82

Downloaded from www.Manualslib.com manuals search engine Fan Button
The button with the fan symbol adjusts the fan speed. Press the up
arrow to increase fan speed and the down
arrow to decrease fan speed.
Temperature Button
The red and blue temperature buttons adjust the air
temperature coming through the system. Press the blue
button for a eooler setting or the red button for a warmer setting. The outside temperature is always displayed
when your vehicle is running.
You can change it from
Fahrenheit to Celsius by pressing the
ENGNET
(English/metric) button on the DIC.
Mode Controls
The AUTO/ECON button automatically controls the
direction
of air delivery for air conditioning and non-air
conditioning modes.
Automatic Operation
When the system is set for AUTO, sensors will control
the air delivery mode.
Air will come from the floor,
middle or windshield outlets. The fan speed will vary as
the system maintains the selected temperature setting. Be
careful not to put anything over the solar sensor
located in the middle of the instrument panel near the
windshield. This sensor
is used by the automatic system
to regulate temperature.
To find your comfort zone, start with 75°F (24°C)
setting, allow about 20 minutes for the system to
regulate. Press the red or blue temperature buttons to
adjust the temperature if necessary. If you choose
60°F
(1 6" C), the system will remain at that maximum cooling
setting
and will not regulate fan speed. If you choose the
temperature of
90°F (32"C), the system will remain at
that maximum heating setting and will not regulate
fan
speed. Choosing either maximum setting will not cause
the system to heat or cool any faster.
With this setting,
the air conditioning compressor
automatically cycles when needed to cool the air. In cold
weather, when the system senses the need for heat, the
airflow will be directed
out the floor outlets. As. the
interior temperature approaches a desired setting, the
blower speed will decrease.
To maintain interior
comfort, the airflow may move to the instrument panel
air outlets and floor outlets
(BI-LEVEL mode). On
bright, sunny days in cold weather, the airflow may
come
out of the A/C outlets (A/C mode) to maintain
comfort and prevent stuffiness.

Downloaded from www.Manualslib.com manuals search engine Electronic Solar Sensor
The sensor monitors the sun’s solar radiation and is
located
on top of the instrument panel near the
windshield. The
ECC system uses this information to
automatically
make the necessary temperature and
airflow adjustments to maintain your
comfort.
Air Conditioning
On hot days, open the windows long enough to let hot
inside
air escape. This reduces the time it takes for your
vehicle to cool down. Then keep your windows closed for the air conditioner to work its best.
Press the
AUTO/ECON button to assist in cooling air
and in maintaining proper airflow. Adjust the
temperature
to a comfortable setting by pressing the
blue button to cool your vehicle
and pressing the red
button to
warm your vehicle. Press the fan button arrows
up or down
to adjust the fan speed.
When the air conditioner is on, you may sometimes
notice slight changes in your vehicle’s engine speed and
power. This is normal because the system is designed to
cycle the compressor on and off to keep the desired
temperature.
3-5

Downloaded from www.Manualslib.com manuals search engine Air Cleaner
.. .. .
..
.. ..
The air filter is located next to the windshield washer
fluid reservoir on
the driver's side of the engine. Be sure
the engine has cooled before following these
steps to
replace the air filter:
1
1. Disconnect the Intake
Air Temperature (IAT)
sensor from
the base of
the
air cleaner.
"1
,
2. With a screwdriver,
loosen the air duct
clamp, which is located
at the mass
airflow
sensor end of the
air duct.
3. Disconnect the air duct from the mass aifflow sensor.
i-
6-14

Downloaded from www.Manualslib.com manuals search engine P
c
4. Unhook both air cleaner cover latches. One latch is
located near
the radiator hose (not shown) and the
other latch is located next to the
IAT sensor.
5. Pivot the air cleaner and air duct assembly towaras
the front
of the vehicle. Remove the cover.
6. Take out the air filter and remove any loose debris
that
may be found laying in the air cleaner base.
7. Install a new air filter element. See “Normal
Maintenance Replacement Parts” in the Index.

Downloaded from www.Manualslib.com manuals search engine Follow these steps to reinstall the air cleaner assembly:
1.
2.
3.
4.
5.
Slide the air cleaner lid into the slots in the front
edge of the
air cleaner base.
Pivot the air cleaner cover and the
air duct assembly
downward. Make sure that both latches are secure
and fully engaged.
Reinstall the clean air duct
over the mass airflow
sensor. Make sure that the duct is secure around the
entire outer edge of the sensor.
Tighten the air duct clamp. Reconnect the
IAT sensor.
Refer to the Maintenance Schedule
to determine when to
replace the air filter.
See “Scheduled Maintenance Services”
in the
Maintenance Schedule booklet.
I A CAUTION:
Operating the engine with the air cleaner off can
cause you or others to be burned. The
air cleaner
not only cleans the air, it stops flames if the
engine backfires.
If it isn’t there, and the engine
backfires, you could be burned. Don’t drive with
it
off, and be careful working on the engine with
the
air cleaner off.
NOTICE:
If the air cleaner is off, a backfire can cause a
damaging engine fire. And, dirt can easily get
into your engine, which will damage it.
Always
have the air cleaner in place when you’re driving.
6-16

Downloaded from www.Manualslib.com manuals search engine c
Fuse
MIRROR
FOG/DRL
[GN 0 mG)*
CRANK
ABS
IGN 1
WIPERS
OXY SEN2"
Usage
Inadvertent Power Relay, Outside
Rearview Mirror, Data Line Connector
(DLC), Flash-to-Pass
Module
Daytime Running Lamp
(DRL)
Relay (Domestic Only), Fog Lm
Relay (Optional), Headlamp
Switch, Right and Left Front Fog
Lamps (Optional)
Powertrain Control Module
(PC1
Sensing and Diagnostic Module
(SDM)
Anti-Lock Brake System/Anti-SI
Regulation-5 (ABS/ASR-5) Controller
Rear Ignition-
1 Relay, Front Fog
Lamp Relay, Rear Lamp Relay
(Export), Controlled Power
Back-up Relay,
DRL Relay
(Domestic Only)
Accessory Relay, Wiper Switch,
Cluster, Wiper
Motor, wiper Pump I
02 Sensor Rear, Catalytic
Converter (CAT) Rear
09 Sensor 1
~ ~ ~ ~ ~~~
OXY SENl*
=PUMP*
[NJ*
rnJ*
CRUISE
DISTR"
PCM
(IGN)*
PCM (BAT)*
A/C COMP
Usage
02 Sensor Front, CAT Front 02
Sensor
Engine
Oil Pressure Indicator, PCM,
Fuel Pump Relay, Fuel Pump
Injectors
2,3,5,8
Injectors 1,4,6,7
Stepper Motor Cruise Control,
Park-Neutral Position Switch,
Back-up Lamps, Electrochromatic
Mirror, Brake-Transaxle Shift
Interlock (BTSI)
Electronic Ignition Control
Powertrain Control Module (PCM)
Transaxle Shift Solenoids, Mass Airflow,
Low Refrigerant Cutoff
Switch, Canister Purge, PCM,
Linear Exhaust Gas Recirculation (EGR), Power Steering Press
Switch, Front Ignition-
1 Relay
PCM
AC Compressor Relay, Cooling
Fan Relays
1,2,3, Compressor
BD
11 related fuses or circuit breakers.
