1995 Lexus LS400 lexus LS400 1995 Engine / 1995 LS400: IN CASE OF AN EMERGENCY

IN CASE OF AN EMERGENCY
167 Pry off the wheel ornament, using the screwdriver as shown.
To avoid personal injury, do not attempt to pull off the ornament
by hand.
4. Loosen all the wheel nuts.
Always loosen the wheel nuts before raising the vehicle.
Turn the nuts counterclockwise to loosen them. To get
maximum leverage, fit the wrench to the nut so that the handle
is on the right side, as shown above. Grab the wrench near the
end of the handle and pull up on the handle. Be careful that the
wrench does not slip off the nut.
Do not remove the nuts yet − just unscrew them about one−half
turn.
5. Position the jack at the jack points as shown.
Make sure the jack is positioned on a level and solid surface.
6. After making sure no one is in the vehicle, raise it high
enough so that the spare tire can be installed.
Allow for the fact that you need more ground clearance when
putting on the spare tire than when removing the flat tire.

IN CASE OF AN EMERGENCY
168To raise the vehicle, insert the jack handle into the jack (it is a
loose fit) and turn it clockwise. As the jack touches the vehicle
and begins to lift, double−check that it is properly positioned.
CAUTION
Never get under the vehicle when it is supported by the
jack alone.
7. Remove the wheel nuts and remove the flat tire.
Lift the flat tire straight off and put it aside.
Before putting on the wheel, remove any corrosion on the
mounting surfaces with a wire brush or such. Installation of
wheels without good metal−to−metal contact at the mounting
surface can cause wheel nuts to loosen and eventually cause
a wheel to come off while driving.
8. Reinstall all the wheel nuts finger tight.

IN CASE OF AN EMERGENCY
169 Align the holes in the wheel with then bolts. Then lift up the
wheel and get at least the top bolt started through its hole.
Wiggle the tire and press it back over the other bolts.
Reinstall the wheel nuts and tighten them as much as you can
by hand. Press the tire back and see if you can tighten them
more.
9. Lower the vehicle completely and tighten the wheel
nuts.
Turn the jack handle counterclockwise to lower the vehicle.
Use only the wheel nut wrench to tighten the nuts. Do not use
other tools or any additional leverage other than your hands,
such as a hammer, pipe or your foot. Make sure the wrench is
securely engaged over the nut.
Tighten each nut a little at a time in the order shown. Repeat
the process until all the nuts are tight.
CAUTION
As soon as possible after changing wheels, have the
wheel nuts tightened by torque wrench at 103 N.m (10.5
kgf.m, 76 ft.lb.).
10. Reinstall the wheel ornament.
Put the wheel ornament into position and then tap it firmly with
the side or heel of your hand to snap it into place.
11. After changing the wheel, check the air pressure of the
replaced tire. Stow all the tools, jack and flat tire securely.
If the pressure of the replaced tire is low, drive slowly to the
nearest service station and fill to the correct pressure.
Do not forget to reinstall the tire valve cap as dirt and moisture
could get into the valve core and possible cause air leakage.
If the cap is missing, put a new one on as soon as possible.

IN CASE OF AN EMERGENCY
170This is the same procedure for changing or rotating your tires.
CAUTION
Before driving, make sure all the tools, jack and flat tire
are securely in place in their storage location to reduce
the possibility of personal injury during a collision or
sudden braking.
IF YOUR VEHICLE NEEDS TO BE
TOWED
If towing is necessary, we recommend you have it done by
your Lexus dealer or a commercial tow truck service.
Proper equipment will help ensure that your vehicle is not
damaged while being towed. Commercial operators are
generally aware of the state / provincial and local laws
pertaining to towing.
Your vehicle can be damaged if it is towed incorrectly. Although
most operators know the correct procedure, it is possible to
make a mistake. To avoid damage to your vehicle, make sure
the following few precautions are observed. If necessary, show
this page to the tow truck driver.
TOWING PRECAUTIONS:
Use a safety chain system for all towing, and abide by the
state / provincial and local laws. The wheels and axle on the
ground must be in good condition. If they are damaged, use a
towing dolly.

IN CASE OF AN EMERGENCY
171 1. Using flat bed truck
Lexus recommends this as the best method for your vehicle.
Tie down points
If your Lexus is transported by a flat bed, it should be tied
down at locations A and B as shown above.

IN CASE OF AN EMERGENCY
172
Rear emergency towing eyelets
NOTICE

Do not use the rear emergency towing eyelets.

For vehicles sold in U.S.A., before your vehicle is
transported by flat bed, the height control switch, if
so equipped, must be in the “HIGH” mode.

Tie down angle
If you use chains or wires to tie down your vehicle, the
angles shaded black must be at 45.

IN CASE OF AN EMERGENCY
173 2. Towing with wheel lift type truck

From front
Use a towing dolly under the rear wheels.
NOTICE
Never tow a vehicle with an automatic transmission
from the front with rear wheels on the ground, as this
may cause serious damage to the transmission.

From rear
Place the ignition key in the “ACC” position.
NOTICE
Do not tow with the key removed or in the “LOCK”
position, as the steering lock mechanism is not strong
enough to hold the front wheels straight.

IN CASE OF AN EMERGENCY
1743. Towing with a sling type truck

From front
Follow the instructions for towing from front in “2. Towing with
wheel lift type truck”.

From rear
NOTICE
Do not tow with a sling type truck. This may cause body
damage.
Emergency towing
If towing service is not available in an emergency, your
vehicle may be temporarily towed by a cable secured to
one of the eyelets under the front or rear of the vehicle.
A driver must be in the vehicle to steer it and operate the
brakes. Towing in this manner may be done only on
hard−surfaced roads for a short distance and at low speeds.
Also, the wheels, axles, drive train, steering and brakes must
all be in good condition.
Before towing, release the parking brake and put the
transmission in “N”. The ignition key must be in “ACC” (engine
off) or “ON” (engine running).
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work, so steering and
braking will be much harder than usual.
