1990 VOLVO 240 length

Volvo 1990 240 Model
pg. 29 Seat belts


Seat belts, manually adjustable

The center rear seat belt is manually adjustable. It should always be ad\
justed to the correct length.

To lengthen, angle the buckle as shown in the upper illustration and pul\
l the belt through.

To shorten, pull the upper part of the double webbing until snug.



During pregnancy

Pregnant women should always wear seat belts. The lap belt should be loc\
ated low on the hips, not
pressing against the abdomen.

file:///K|/ownersdocs/1990/1990_240/90240_06.htm (5 of 9)12/30/2006 8:\
25:04 AM

Volvo 1990 240 Model

Max. length of load 6 1/2 ft = 2 m.
Max. weight of load 33 lbs. = 15 kg.
WARNING!
Take care when loading/unloading the vehicle. Always turn off the engine\
and apply the parking
brake. Place automatic transmission gear shift selector in position P (\
Park). This will prevent
accidental movement of the gear shift selector to position D (Drive). \




Contents | Top of Page
file:///K|/ownersdocs/1990/1990_240/90240_07.htm (6 of 6)12/30/2006 8:\
25:04 AM

Volvo 1990 240 Model

Precautionary steps to observe when towing

Please check with state and local authorities before attempting this typ\
e of towing as vehicles being
towed are subject to regulations regarding maximum towing speed, length \
and type of towing device,
lighting, etc.
l Steering must be unlocked.
l Remember that power brake and power steering assists will not be availab\
le when engine is
inoperative. Pedal pressure required is 3 - 4 times above normal and gre\
ater steering effort must be
employed.
l Towing cars equipped with automatic transmission:
-- Gear selector in position N. Check transmission oil level (see secti\
on titled "Transmission oil").
-- Maximum speed: 20 mph (30 km/h).
-- Maximum distance with rear wheels on ground: 20 miles (30 km).

CAUTION!
Do not attempt to start the car by pushing or pulling as damage to catal\
ytic converter can
result.

Jump starting, see section titled "alternator, jump starting".
NOTE:
Refer lo the section regarding "On-
Call"
pg. 49 Tow-truck information
Only use wheel lift or flat bed equipment.
CAUTION:
Sling-type equipment applied at the font will damage radiator and air co\
nditioning lines. It is equally
important not to use sling-type equipment at the rear or apply lifting e\
quipment inside the rear wheels;
serious damage to the rear axle may result.


file:///K|/ownersdocs/1990/1990_240/90240_10.htm (6 of 7)12/30/2006 8:\
25:05 AM

Volvo 1990 240 Model
pg. 52 Catalytic Converter
Catalytic Converter Cautions


l Keep your engine properly tuned. Certain engine malfunctions, particular\
ly involving the electrical,
fuel or ignition systems, may cause unusually high converter temperature\
s. Do not continue to operate
your vehicle it you detect engine misfire, noticeable loss of power or o\
ther unusual operating conditions,
such as engine overheating or backfiring. A properly-tuned engine will h\
elp in avoiding malfunctions
that could damage the Catalytic Converter.

l Remember that tampering with or unauthorized modifications to the engine\
or the vehicle may be
illegal and can cause catalyst or exhaust system overheating. This inclu\
des:
-- Altering fuel injection settings or components.
-- Adjusting ignition timing beyond specified limits.
-- Altering emission system components or location or removing component\
s.
-- Use of leaded fuel.

WARNING: Do not park your car over combustible materials, such as grass \
or leaves, which can
come into contact with the hot exhaust system and cause such materials t\
o ignite under certain wind
and weather conditions.

l Excessive starter cranking (in excess of one continuous minute) with a\
n intermittently firing or
flooded engine, can cause catalyst or exhaust system overheating. This a\
lso applies to lengthy pushing or
towing of vehicle to start (manual transmissions only). Do not attempt\
to start a car with automatic
file:///K|/ownersdocs/1990/1990_240/90240_11.htm (5 of 6)12/30/2006 8:\
25:06 AM

Volvo 1990 240 Model

2 Move the spray can slowly and regularly from side to side, about 8-12 \
inches (20-30 cm) from the
surface.
WARNING! Spray painting should be done in a well ventilated and dust-fre\
e
area.

3 When the primer has dried, apply the surface enamel in the same way. S\
pray on several times and
allow the paint to dry a minute or so between each application.
pg. 90 What causes rust
What causes rust

The two most common causes of rust to your car are:
1. The accumulation of road dirt and moisture in hard-to-get-at cavities\
and other areas under the car.
2. The removal of paint and protective coatings on the outside of the ca\
r and underneath through damage
by stones, gravel or minor accidents.

Several factors influence the speed at which corrosion will occur:

1. The length of time various parts of a car stay wet. Parts of the car \
filled with road dirt and water
remain damp for long periods of time even after other parts have dried. \

Particular attention should be paid to the underside of the car and floo\
r sections inside. The floor
sections stay wet because moisture collects and remains under the floor \
matting.
Drain holes located at the bottom of the doors can get clogged with dirt\
, trapping water inside the door
and causing the door to rust through at the bottom.
file:///K|/ownersdocs/1990/1990_240/90240_18.htm (7 of 8)12/30/2006 8:\
25:11 AM

Volvo 1990 240 Model
pg. 97 Specifications
98Dimensions and weights
98Cargo space
99Engine
100Cooling system
100Fuel system
100Ignition system
101Power transmission
101Front suspension
102Capacities
102Electrical system
pg. 98 Specifications
Dimensions and weights Sedan models Wagon models
Length 189.9" (482 cm) 190.7" (484 cm)
Width 67.3" (171 cm) 67.3" (171 cm)
Height, curb weight 56.3" (143 cm) 57.5" (146 cm)
Wheelbase 104.3" (265 cm) 104.3" (265 cm)
Ground clearance (full load) 4.7" (12 cm) 4.7" (12 cm)
Track, front
rear 56.3" (143 cm)
53.5"(136cm) 56.3" (143 cm)
53.5" (136cm)
file:///K|/ownersdocs/1990/1990_240/90240_20.htm (1 of 14)12/30/2006 8\
:25:15 AM

Volvo 1990 240 Model
Turning circle (between curbs) 32.2' (9.8 m) 32.2' (9.8 m)
Curb weight (depending on type) 2934-3009 lbs (1331-1365
kg) 3073-3115 lbs (1394-1413
kg)
Gross vehicle weight (GVW) 4030 lbs (1830 kg) 4300 lbs (1950 kg)
Capacity weight 948 lbs (430 kg) 1080 lbs (490 kg)
Permissible axle weight, front
rear 1885 lbs (855 kg)
2180 lbs (990 kg) 1885 lbs (855 kg)
2600 lbs (1180 kg)
Max. trailer weight (trailer equipped
with service brakes) 3300 lbs (1500 kg)
3300 lbs (1500 kg)
Max. hitch load 200 lbs (90 kg) 200 lbs (90 kg)
Cargo Space Wagon models
Length with rear seat up 44.5" (113 cm)
Length with rear seat down 74.0" (188 cm)
Maximum width 53.1" (135 cm)
Height 32.9" (84 cm)
Volume with rear seat up 41 cu. ft. (1.2 m3)
Volume with rear seat down 76 cu. ft. (2.151
m3)
file:///K|/ownersdocs/1990/1990_240/90240_20.htm (2 of 14)12/30/2006 8\
:25:15 AM

Volvo 1990 240 Model
Cargo opening, maximum width 45.7" (116 cm)
Cargo opening, maximum
height 30.7" (78 cm)
WARNING: When adding accessories, equipment, luggage and other cargo to \
your vehicle, the total
loaded weight capacity of the vehicle must not be exceeded. Consult your\
dealer for information.
Dimensions and weights for Canadian models
4 door Wagon
Length 482 cm 484 cm
Curb weight (depending on
type) 1306-1321
kg 1373- 1388
kg
Gross vehicle weight 1830 kg 1950 kg
Capacity weight 440 kg 540 kg
Permissible axle weight, front
rear 855 kg
990 kg 855 kg
1180 kg
pg. 99 Specifications
Engine B230F (2.3 liters; 141 cu. in.)

Liquid-cooled, gasoline, 4-cylinder in-line engine. Cast-iron cylinder b\
lock with cylinders bored directly
in block. Aluminum-alloy cylinder head with single overhead camshaft and\
separate intake and outlet
channels. Engine lubrication is provided by a gear pump driven from the \
crankshaft. Full-flow type oil
file:///K|/ownersdocs/1990/1990_240/90240_20.htm (3 of 14)12/30/2006 8\
:25:15 AM
