1990 HONDA PRELUDE mirror

Do not wear the shoulder portion of the belt under your arm or
out of position. Such use could increase the chance and amount of injury in an accident.
Never use one belt for more than one person, child or adult.
Comfort clips sold on the open market are not recommended
since they could impair the function and safety of the belts.
Front Seat Belt Warning Light and Warning Beeper
There are four warning lights in the car. Two of them are in the
instrument panel and the other two lights are in the ceiling behind
the rearview mirror. Each warning light will go on for about two seconds, when the ignition switch is turned on.
WARNING LIGHT
WARNING LIGHT
Warning Light indicators Either Door Open — The warning light will come on if either
door is open. The beeper will sound for approximately six seconds while the light is ON. Confirm which door is open and close the door
completely. If either door is opened while the car is being driven, the
beeper and all four warning lights will come on. Stop the car immediately and close whichever door is open. The warning light

should go off.

(cont'd)

PASSENGER'S BELT UNLATCHED
DRIVER'S BELT UNLATCHED
EITHER DOOR OPEN
DRIVER'S BELT
UNLATCHEDProCarManuals.comMain Menu t s

Mirrors

Rearview Mirrors Keep the inside and outside mirrors clean and adjusted for best
visibility. Be sure to adjust mirrors before you start.
The inside mirror has day and night positions. The night positionreduces glare from the headlights
of vehicles behind you. Flip the
small tab on the bottom of the mirror forward or backward to
select day or night position.
(2.0
S,2.0
Si)

The outside mirror can be
adjusted by moving the knob
located on each door.
Power Mirrors (Si)With the ignition switch in the "II" position, move the main switch
to L (for driver's side) or R (for passenger's side), then use the adjustment switch to adjust the mirror to the correct angle. After
the mirrors have been adjusted, return the main switch to the center (off) position.
NOTE:Be sure to adjust mirror angles before you start driving.
DAY/NIGHT

ADJUSTMENT
TAB

KNOB

MAIN SWITCH ADJUSTMENT SWITCHProCarManuals.comMain Menu s t

Four Wheel Steering (cont'd)

CAUTION:

If the car is very close to a wall or other obstacle, the rear of the
body can swing enough to contact the obstacle when turning very sharply. Go slowly, and use both outside mirrors.

Conventional steering
4WSProCarManuals.comMain Menu t s

Safety Items
Before driving away, check that: The doors are closed properly. The mirrors are properly adjusted, and the windows clean.
The driver and passengers are wearing properly adjusted seat
belts.
The head restraints are properly adjusted.
The warning and indicator lights are operating properly.
The brake pedal feels normal.
All luggage and cargo is secured.
Nothing is interfering with the driver's feet or blocking vision to

the rear.

While driving remember to: Always drive defensively; expect the unexpected. Reduce your speed during night hours and bad weather.
Follow at a safe distance; don't tailgate.
Get off the highway when you are tired; stop and take a rest.
When stopping for repairs: Park the car well off the road.
Turn on the hazard warning flasher. Use flares or other warning devices to warn other motorists.
After parking your car: Apply the parking brake and shift to first gear if equipped withmanual transmission, or PARK on automatic transmission

equipped cars.
Make sure the windows are closed and all doors are locked.
If parked on a hill:
Turn the front wheels away from the curb if facing uphill.
Turn the front wheels toward the curb if facing downhill. Never leave children unattended in a parked car.
Take your
keys.ProCarManuals.comMain Menu t s

Break-in Schedule

Do not tow a trailer during the 600 mile (1,000 km) break-in period:

see page 2.

Maintenance
If you tow a trailer, your vehicle will require more frequent
maintenance due to the additional load. Refer to the "Maintenance
Schedule under severe driving conditions" on page 80 for specific
information.

Before Towing

With the car and trailer completely loaded and parked on a level surface, confirm that the tongue loading is correct. If the car has an
abnormal nose-up or nose-down attitude, check for improper cargo

distribution. Check also for excessive cargo weight, worn
suspension or other causes and correct the problem before driving.
Be sure the cargo is secured so it will not shift while driving. Check
that your rearview mirrors conform to any federal, state, or local regulations. If not, install rearview mirrors designed for towing.Before towing a trailer, practice turning, stopping and reversing with
a trailor in an area away from traffic until you learn the technique.
(cont'd)
ProCarManuals.comMain Menu t s

Towing a Trailer (cont'd)

Towing Safety

Stopping distance will be increased when towing a trailer. For
each 10 mph (16 km/h) of speed, allow at least two car lengths between you and the vehicle ahead. Avoid sudden braking
which may cause trailer jackknifing and loss of control.
Avoid jerky starts and sudden acceleration. If your car has amanual transmission, always start out in first gear and release
the clutch at moderate engine rpm.
Avoid rapid lane changing and sharp turns. The trailer could hit your car in a tight turn. Slow down before making a turn.
Remember, the total length of your car plus trailer will require a
wider turning circle.
Crosswinds may adversely affect handling of your car and
trailer, Use the rearview mirrors frequently to warn you of approaching large vehicles that may pass you causing your car
and trailer to sway. When being passed, firmly grip the steering wheel and be prepared to reduce speed immediately but
gradually. Never increase speed. Steer straight ahead.
Towing a trailer in bad weather will magnify any difficulty in
controlling the car caused by the weather itself. Avoid sudden maneuvers: slow down and use extra caution.
Be careful when passing other vehicles. Passing requires
considerable distance because of the added weight and length

of your trailer.ProCarManuals.comMain Menu t s

Keys
Door Locks ..................................3
Glove box ..................................39
Trunk Lid Lock ............................4
Ignition ........................................58

Key Reminder Beeper...............58Keys.............................................3
Lap/Shoulder Belts
................................Se
e "Seat Belts"

Light

Bulb Replacement...................103
Fuse Replacement ..................101
Light Reminder
Chime ..............30

Operation.................................30

Warning and Indicator Light
......................................................21
Locks

Fuel Filler Door ..........................56
Doors..........................................3

Glove Bo
x ..................................39

Trunk Lid......................................4

Anti-theft Steering

Column

Lock.......................................58

Lumbar Support,Driver's .................7
Maintenace Schedule
and

Records......................................76

Manual Transmission Maximum Allowable Speeds
....................................................66

Oil........................................86
Recommended Shift
Speeds

....................................................66

Shifting.....................................65

Meters Gauges.......See
"Gauges"
Mirrors Power Mirrors ...........................29
Rear View Mirrors ....................29 Numbers, Identification................ 127

Octane Rating,
Gasoline

.......................................... See "Fuel"
Odometer ........................................20Oil

Engine Oil ...................................83

Fluid Locations ..........................82Transmission Oil/Fluid ..............86Oil Pressure Warning Light.......22
Power Steering Fluid ................97
Operation In
Foreign Countries

..........................................................56

Panel Brightness Control ...............33
Parking Brake.................................
39

Power

Mirrors .......................................29
Steering .....................................
97

Windows................................40

PGM-FI System............................131
Pressures, Tire Inflation...............105
Preventive Service.......................

112
(cont'd)
Radiator Coolant .............................88

Radio ................................................47

Rear View Mirrors ..........................29
Rear Window Defogger ..................28
Reminder Lights
..........................See "Warning lights"ProCarManuals.comMain Menu t s
