2004 LAND CRUISER (EWD548U)
11 9
2. Control System
*SFI system
The SFI system monitors the engine condition through the signals input from each sensors to the engine control module.
The control signal is sent to the engine control module TERMINALS #1, #2, #3, #4, #5, #6, #7, #8 to operate the injector
(Fuel injection). The SFI system controls the fuel injection by the engine control module in response to the driving
conditions.
*ESA system
The ESA system monitors the engine condition through the signals input from each sensors to the engine control module.
The best ignition timing is decided according to this data and the data memorized in the engine control module. The
control signal is output to TERMINALS IGT1, IGT2, IGT3, IGT4, IGT5, IGT6, IGT7, IGT8, and these signals control the
igniter to provide the best ignition timing.
*Heated oxygen sensor heater control system
The heated oxygen sensor heater control system turns the heater on when the intake air volume is low (Temp. of exhaust
emission is low), and warms up the heated oxygen sensors to improve their detection performance. The engine control
module evaluates the signals from each sensors, and outputs current to TERMINALS HT1A, HT1B, HT2A, HT2B to
control the heater.
*Fuel pump control system
The engine control module supplies current to TERMINAL FPR, and controls the operation speed of the fuel pump by the
F/PUMP relay.
*ACIS
The ACIS includes a valve in the bulkhead separating the surge tank into two parts. This valve is opened and closed in
accordance with the driving conditions to control the intake manifold length in two stages, for increased engine output in all
ranges from low to high speeds.
*ETCS-i
The ETCS-i controls the engine output at its optimal level in accordance with the opening of the accelerator pedal, under
all driving conditions.
3. Diagnosis System
When there is a malfunction in the engine control module signal system, the malfunctioning system is recorded in the
memory. The malfunctioning system can be found by reading the code displayed on the malfunction indicator lamp.
4. Fail-Safe System
When a malfunction has occurred in any system, there is a possibility of causing engine trouble due to continued control
based on that system. In that case, the fail-safe system either controls the system using the data (Standard values)
recorded in the engine control module memory, or else stops the engine.
E2 Engine Coolant Temp. Sensor
1-2 : Approx. 15.0 kW (-20°C, -4°F)
: Approx. 2.45 kW (20°C, 68°F)
: Approx. 0.32 kW (80°C, 176°F)
E5 (A), E7 (C), E8 (D), E9 (E) Engine Control Module
BATT-E1 : Always 9.0-14.0 volts
+BM-E1 : Always 9.0-14.0 volts
IGSW-E1 : 9.0-14.0 volts with ignition SW at ON or ST position
+B, +B2-E1 : 9.0-14.0 volts with ignition SW at ON or ST position
VC-E2 : 4.5-5.5 volts with ignition SW on
VTA2-E2 : 2.0-2.9 volts with ignition SW on and accelerator pedal released
: 4.6-5.1 volts with ignition SW on and accelerator pedal depressed
VTA1-E2 : 0.4-1.0 volts with ignition SW on and accelerator pedal released
: 3.2-4.8 volts with ignition SW on and accelerator pedal depressed
THA-E2 : 0.5-3.4 volts with idling, intake air temp. 20°C (68°F)
THW-E2 : 0.2-1.0 volts with idling, engine coolant temp. 80°C (176°F)
W-E1 : 9.0-14.0 volts with idling
: Below 3.0 volts with ignition SW on
Service Hints

2004 LAND CRUISER (EWD548U)
218Electronically Controlled Transmission and A/T Indicator
Previous automatic transmissions have selected each gear shift using mechanically controlled throttle hydraulic pressure,
governor hydraulic pressure and lock-up hydraulic pressure. The electronically controlled transmission, however, electrically
controls the line pressure, throttle pressure, lock-up pressure and accumulator pressure etc. through the solenoid valve. The
electronically controlled transmission is a system which precisely controls gear shift timing and lock-up timing in response to
the vehicle's driving conditions and the engine condition detected by various sensors. It makes smooth driving possible by
shift selection for each gear which is the most appropriate to the driving conditions at that time, and by preventing downing,
squat and gear shift shock when starting off.
1. Gear Shift Operation
When driving, the engine warm up condition is input as a signal to TERMINAL THW of the engine control module from the
engine coolant temp. sensor and the vehicle speed signal from vehicle speed sensor is input to TERMINAL SP2+ of the
engine control module. At the same time, the throttle valve opening signal from the throttle position sensor is input to
TERMINALS VTA1 and VTA2 of the engine control module as throttle angle signal.
Based on these signals, the engine control module selects the best shift position for the driving conditions and sends current
to the electronically controlled transmission solenoid.
2. Line Hydraulic Pressure Control
The engine control module adjusts the line hydraulic pressure to the optimal level by controlling TERMINAL SLT+ of the
module according to the engine torque data. This realizes the smooth gear shifting.
3. High Response Gear Shifting Control
The engine control module performs the high response engine torque up control to control the ignition-timing lag as well as
opening the electronic throttle when shifting down. By doing this, the gear shifting is performed in a short period of time.
Moreover, the engine control module uses the orifice switching control, which optimizes the speed of applying and reducing
the hydraulic pressure. And it realizes the fine shifting condition by applying and reducing hydraulic pressure slowly when
the gear shifting shock is important and quickly when the high response is required.
4. Clutch Hydraulic Pressure Control
The engine control module controls the clutch operation in the optimal timing and with the best hydraulic pressure according
to the engine torque data and the number of the clutch revolution
5. Lock-Up and Flexible Lock-Up Control
The engine control module carries out the lock-up control by controlling the TERMINAL SLU+ of the module according to
the shift position, vehicle speed, throttle opening degree and running conditions. The engine control module also steadily
keeps applying the lock-up clutch a delicate slippage to improve the transmission efficiency (Fuel efficiency) of the torque
converter.
6. Stop Light SW Circuit
If the brake pedal is depressed (Stop light SW on) when driving in lock-up condition, a signal is input to TERMINAL STP of
the engine control module. The engine control module operates and cuts the current to the solenoid to release lock-up.
7. Ai-Shift Control
The engine control module judges whether the road is downslope or upslope by detecting the throttle opening degree or the
vehicle's speed. Moreover it can expect the winding roads by detecting the turning condition of the vehicle. The engine
control module keeps unnecessary shifting up from the fourth gear from operating and carries out the automatic shifting
down to the third gear in order to control the vehicle running according to the road conditions. The engine control module
also reads the driver's intention during driving from his (her) accelerating operation and the running conditions of the vehicle.
As a result of that, ideal shifting patters for each driver are automatically selected without any switching operations.
8. Electronically Controlled Transmission Pattern Select SW Circuit
When the electronically controlled transmission pattern select SW is switched to PWR, a signal is input to TERMINAL PWR
of the engine control module. This enables shift-up and shift-down at a higher speed range.
9. Transfer Shift Operation
When the transfer shift lever is moved to L position, a signal is input into TERMINAL L4 of the engine control module.
In addition when the transfer shift lever is moved to N position a signal is input to engine control module TERMINAL TFN.
The engine control module detects the transfer condition through this.
System Outline

2004 LAND CRUISER (EWD548U)
362Air Conditioning (Front)
1. Heater Blower Operation
Manual operation
When the blower speed is set ant any speed by the blower control SW, the A/C control assembly sends a signal to the
blower motor controller, and controls the blower motor speed.
Auto operation
When the auto SW is operated, the A/C control assembly sends signals to the blower motor controller, according to the
signals from respective sensors, commands from the temperature SW etc., and controls the blower motor automatically.
2. Air Inlet Control Servo Motor Control
When the FRESH/RECIRC select SW is switched to RECIRC, the motor in the air inlet control servo motor rotates to move
the damper to the RECIRC side. The damper position is recognized by the A/C control assembly TERMINAL TPI, and
rotates the motor until the damper reaches its position.
When the FRESH/RECIRC select SW is switched to FRESH, the motor in the air inlet control servo motor rotates to move
the damper to the FRESH side. The damper position is recognized by the A/C control assembly TERMINAL TPI, and rotates
the motor until the damper reaches its position.
When the FRESH/RECIRC select SW is set to auto, the exhaust gas sensor in the engine room detects the ingredient of the
exhaust emission, and switches the FRESH/RECIRC mode automatically.
3. Air Vent Mode Control Servo Motor
When the mode select SW in the A/C control assembly is pushed, a signal is sent from the A/C control assembly, and
activates the air vent mode control servo motor. This causes the servo motor to rotate to the position selected using the
mode select SW (FACE, BI-LEVEL, FOOT, FOOT/DEF, DEF), and moves the damper.
4. Air Mix Control Servo Motor
When the temperature control SW in the A/C control assembly is pushed, a signal is sent from the A/C control assembly, and
activates the air mix control servo motor. The motor and damper is moved until it reaches the temperature set by the
temperature control SW.
5. Air Conditioning Operation
The A/C control assembly receives various signals, i. e., the engine RPM from the crankshaft position sensor, outlet
temperature from the A/C ambient temp. sensor, coolant temperature from the engine coolant temp. sensor, and the lock
signal from the A/C compressor, etc. When the engine is started and the A/C SW is turned on, a signal is sent to the A/C
control assembly. As a result, the magnetic clutch is turned on and operates the compressor.
In addition, when the engine control module detects that the magnetic clutch is on and the A/C compressor is operating, it
controls the engine in the direction to avoid lowering the engine RPM during A/C operation.
When any of the following signals are sent to the A/C control assembly, the A/C is turned off.
*Coolant temp. is high.
*Outlet air temp. is low.
*Large difference between the engine speed and compressor speed.
*The refrigerant pressure is abnormally high or low.
A45 (A), A47 (C) A/C Control Assembly
(C)11-Ground : Always approx. 12 volts
(C)22-Ground : Approx. 12 volts with ignition SW at ON or ST position
(A)27-Ground : Approx. 12 volts with ignition SW at ON or ST position (w/o navigation system)
(C) 12, (C) 14, (C) 15, (C) 17, (C) 18-Ground : Always continuity
C28 Center Cluster Integration Panel (w/ Navigation System)
2-Ground : Approx. 12 volts with ignition SW at ON or ST position
16-Ground : Always continuity
System Outline
Service Hints

LU08Z-08
B04611
New O-Ring
B04612
LU-22
- LUBRICATIONOIL COOLER
1803 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL OIL COOLER
(a) Clean the oil cooler contact surface on the cooler mount-
ing.
(b) Install a new O-ring to the oil cooler.
(c) Apply a light coat of engine oil on the threads and under
the head of the union bolt.
(d) Install the plate washer and union bolt.
Torque: 68.6 N´m (700 kgf´cm, 51 ft´lbf)
(e) Connect the 2 oil cooler hoses to the oil cooler.
2. INSTALL OIL FILTER (See page LU-2)
3. FILL WITH ENGINE COOLANT
4. START ENGINE AND CHECK FOR ENGINE OIL
LEAKS
5. CHECK ENGINE OIL LEVEL

MA02R-05
MA-4
- MAINTENANCEUNDER HOOD
52 Author
: Date
:
2004 LAND CRUISER (RM1071U)
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTICE

Maintenance items may vary from country to country. Check the owner's manual supplement in which
the maintenance schedule is shown.

Every service item in the periodic maintenance schedule must be performed.

Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).

Maintenance services after the last period should be performed at the same interval as before unless
otherwise noted.

Failure to do even one item can cause the engine to run poorly and increase exhaust emissions.
2. WINDSHIELD WASHER FLUID
Check that there is sufficient fluid in the tank.
3. ENGINE COOLANT LEVEL
Check that the coolant level is between the LEVEL lines on the see-through reservoir at normal tem-
perature (20°C (68°F)).
4. RADIATOR AND HOSES
(a) Check that the front of the radiator is clean and not blocked with leaves, dirt or bugs.
(See page CO-14)
(b) Check the hoses for cracks, kinks, rot or loose connections.
5. BATTERY ELECTROLYTE LEVEL

Check the indicator.

When the indicator color is blue, the condition is satisfactory. A red color indicates that distilled water
must be added, and white indicates that charging is necessary.
6. BRAKE FLUID LEVELS
Check that the brake fluid level is near the upper level line on the see-through reservoir.
(See page BR-4)
7. ENGINE DRIVE BELTS
Check drive belt for fraying, cracks, wear or oiliness.
8. ENGINE OIL LEVEL
Check the level on the dipstick with the engine turned off.
9. POWER STEERING FLUID LEVEL

Check the level on the dipstick.

The level should be in the ºHOTº or ºCOLDº range depending on the fluid temperature.
10. AUTOMATIC TRANSMISSION FLUID LEVEL
Visually check the overflow plug and oil pan for fluid leaks or traces of fluid.
