2023 TOYOTA SEQUOIA HYBRID torque

5518-1. Specifications
Owners Manual_USA_M0C043_en
8
Vehicle specifications
■Oil capacity (Drain and refill
[Reference
*])
*: The engine oil capacity is a refer- ence quantity to be used when
changing the engine oil. Warm up
and turn off the engine, wait more
than 8 minutes, and check the oil
level on the dipstick.
■Engine oil selection
“Toyota Genuine Motor Oil” is
used in your Toyota vehicle. Use
Toyota approved “Toyota Genu-
ine Motor Oil” or equivalent to
satisfy the following grade and
viscosity.
Oil grade: ILSAC GF-6A multigrade engine
oil
Recommended viscosity: SAE
0W-20
Outside temperature
SAE 0W-20 is the best choice
for good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Electric motor (traction motor)
Ty p ePermanent magnet synchronous motor
Maximum output36 kW
Maximum torque184 ft·lbf (250 N ·m, 25.5 kgf·m)
Hybrid battery (traction battery)
Ty p eNickel-Metal hydride battery
Voltage7.2 V/module
Capacity6.5 Ah
Quantity40 modules
Nominal voltage288 V
Lubrication system
With filter7.7 qt. (7.3 L, 6.4 Imp.
qt.)
Without
filter7.4 qt. (7.0 L, 6.2 Imp.
qt.)

5558-1. Specifications
Owners Manual_USA_M0C043_en
8
Vehicle specifications
18-inch tires (type A)
*: When vehicle is loaded or towing a trailer: Add 3 psi (20 kPa, 0.2 kgf/cm2
or bar) to the recommended cold tire inflation pressure.
18-inch tires (type B)
*: When vehicle is loaded or towing a trailer: Add 3 psi (20 kPa, 0.2 kgf/cm2
or bar) to the recommended cold tire inflation pressure.
Steering
Free playLess than 1.2 in. (30 mm)
Tires and wheels
Tire size265/70R18 116T, 245/75R18 112T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
*
35 psi (240 kPa, 2.4 kgf/cm2 or bar)
36 psi (250 kPa, 2.5 kgf/cm
2 or bar) (spare)
Wheel size18  7 1/2 J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)
Tire size265/70R18 116T, 265/70R18 116T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
*35 psi (240 kPa, 2.4 kgf/cm2 or bar)
Wheel size18  7 1/2 J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)

5568-1. Specifications
Owners Manual_USA_M0C043_en
18-inch tires (type C)
*: When vehicle is loaded or towing a trailer: Add 3 psi (20 kPa, 0.2 kgf/cm2
or bar) to the recommended cold tire inflation pressure.
20-inch tires
*: When vehicle is loaded or towing a trailer: Add 3 psi (20 kPa, 0.2 kgf/cm2
or bar) to the recommended cold tire inflation pressure.
22-inch tires
Tire size285/65R18 116T, 265/70R18 116T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
*35 psi (240 kPa, 2.4 kgf/cm2 or bar)
Wheel size18  8 1/2 J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)
Tire size265/60R20 112H, 245/75R18 112T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
*36 psi (250 kPa, 2.5 kgf/cm2 or bar)
Wheel size20  8J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)
Tire size265/50R22 112H, 245/75R18 112T (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Front:
38 psi (260 kPa, 2.6 kgf/cm
2 or bar)
Rear:
42 psi (290 kPa, 2.9 kgf/cm
2 or bar)
Spare:
36 psi (250 kPa, 2.5 kgf/cm
2 or bar)

5578-1. Specifications
Owners Manual_USA_M0C043_en
8
Vehicle specifications
A: Wedge base bulbs (amber)
Wheel size22  8J, 18  7J (spare)
Wheel nut torque
Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)
Light bulbs
Light bulbsBulb No.WTy pe
ExteriorFront turn signal/parking
lights7444NA28/8A
