2023 TOYOTA RAV4 PRIME navigation

5638-2. Steps to take in an emergency
8
When trouble arises
Perform the following steps and fit
tire chains to the front tires:
1Replace a rear tire with the com-
pact spare tire.
2 Replace the flat front tire with the
tire removed from the rear of the
vehicle.
3 Fit tire chains to the front tires.
WARNING
■When using the compact
spare tire
●Remember that the compact
spare tire provided is specifi-
cally designed for use with your
vehicle. Do not use your com-
pact spare tire on another vehi-
cle.
●Do not use more than one com-
pact spare tire simultaneously.
●Replace the compact spare tire
with a standard tire as soon as
possible.
●Avoid sudden acceleration,
abrupt steering, sudden brak-
ing and shifting operations that
cause sudden engine braking.
■When the compact spare tire
is attached
The vehicle speed may not be
correctly detecte d, and the follow-
ing systems may not operate cor-
rectly:
• ABS & Brake assist
• VSC/Trailer Sway Control
• TRAC
• Dynamic radar cruise control
with full-speed range
• PCS (Pre-Collision System)
• EPS
• LTA (Lane Tracing Assist)
• Tire pressure warning system (if equipped)
• AHB (Automatic High Beam)
• BSM
• RCTA
• PKSB (if equipped)
• Intuitive parking assist (if equipped)
• Rear view monitor system (if equipped)
• Panoramic view monitor (if equipped)
• Toyota parking assist monitor (if equipped)
• Navigation system (if equipped)
Also, not only c an the following
system not be utilized fully, but it
may actually negatively affect the
drive-train components:
• E-Four (Electronic On-Demand AWD system)
■Speed limit when using the
compact spare tire
Do not drive at speeds in excess
of 50 mph (80 km /h) when a com-
pact spare tire is installed on the
vehicle.
The compact spare tire is not
designed for driving at high
speeds. Failure to observe this
precaution may lead to an acci-
dent causing death or serious
injury.
■After using the tools and jack
Before driving, ma ke sure all the
tools and jack are securely in
place in their storage location to
reduce the possibility of personal
injury during a collision or sudden
braking.

5999-2. Customization
9
Vehicle specifications
9-2.Customization
■Changing using the Multi-
media Display
1 Select on the main menu.
2 Select “Vehicle customize”.
3 Select the item to change the
settings of from the list.
Various setting can be changed.
Refer to the list o f settings that can
be changed for details.
For functions that can be turned
on/off, select (ON)/
(OFF).
The settings, such as the volume
and sensor sensitivity can be
changed by dragging the round
icon on the display.
■Changing using the multi-
information display (with 7-
inch display)
1 Press or of the meter
control switches and select
. 2
Press or of the meter
control switches, select the
item.
3 To switch the function on and
off, press to switch to the
desired setting.
4 To perform detailed setting of
functions that support
detailed settings, press and
hold and display the set-
ting screen.
The method of pe rforming detailed
setting differs for each screen.
Please refer to the advice sentence
displayed on the screen.
To go back to the p revious screen
or exit the customize mode, press
.
■Changing using the multi-
information display (with
12.3-inch display)
1 Press and hold to display
the cursor on the content dis-
play area (center) of the
multi-information display.
2 Press or of the meter
control switches to select
and then press .
3 Press or of the meter
control switches, select the
item.
4 To switch the function on and
off, press to switch to the
desired setting.
5 To perform detailed setting of
functions that support
Customizable features
Your vehicle includes a vari-
ety of electronic features
that can be personalized to
suit your preferences. The
settings of these features
can be changed using the
multi-information display,
navigation/multimedia sys-
tem, or at your Toyota
dealer.
Customizing vehicle fea-
tures

6009-2. Customization
detailed settings, press and
hold and display the set-
ting screen.
The method of performing detailed
setting differs for each screen.
Please refer to the advice sentence
displayed on the screen.
To go back to the previous screen
or exit the customize mode, press
.
■When customizing using the
navigation/multimedia system
or multi-information display
Stop the vehicle i n a safe place,
apply the parking brake, and shift
the shift lever to P. Also, to prevent
12-volt battery discharge, leave the
hybrid system operating while cus-
tomizing the features.
Some function settings are changed simultaneously with other fu nc-
tions being customized. Contact y our Toyota dealer for further
details.
Vehicles with navigation system or multimedia system: Settings
that can be changed using the navigation system or multimedia s ys-
tem
Settings that can be changed using the multi-information displa y
Settings that can be changed by your Toyota dealer
Definition of symbols: O = Available, – =Not available
■Predictive efficient drive (if equipped)* (  P.83)
*: This function can only be used in the mainland U.S.A. It canno t be used
in other states and territories, including Alaska and Hawaii.
WARNING
■During customization
As the hybrid system needs to be
operating during customization,
ensure that the vehicle is parked
in a place with adequate ventila-
tion. In a closed area such as a
garage, exhaust gases including
harmful carbon monoxide (CO)
may collect and enter the vehicle.
This may lead to death or a seri-
ous health hazard.
NOTICE
■During customization
To prevent 12-vo lt battery dis-
charge, ensure that the hybrid
system is operating while custom-
izing features.
Customizable Features
FunctionDefault settingCustomized
setting
Predictive efficient driveOnOffO––
A
B
C
ABC

Alphabetical Index643
Head-up display ................... 208
Hybrid System Indicator175, 181
Indicators.............................. 170
Instrument panel light control177
Meter control switches . 185, 197
Meters .................................. 178
Multi-information display .... 185, 196
Settings ................ 191, 203, 600
Units ............................. 194, 601
Warning lights .............. 168, 541
Warning messages ..... 195, 206, 552
Meter control switches .. 185, 197
Mirrors Digital Rear-view Mirror........ 258
Inside rear view mirror.......... 257
Outside rear view mirror defog-gers .................................... 424
Outside rear view mirrors ..... 268
Vanity mirrors ....................... 445
Moon roof Door lock linked moon roof oper-ation ................................... 273
Jam protection function ........ 273
Operation ............................. 273
Warning message ................ 274
Multi-information display..... 196, 207, 601Audio system-linked display190, 202
BSM (Blind Spot Monitor)..... 379
Changing the display.... 185, 198
Convenience Services (Sugges- tion function)....... 195, 207, 601
Display contents ........... 185, 196
Driving informatio n display . 186,
198
Driving support system informa- tion display ................. 190, 202
Dynamic radar cruise control with full-speed range .......... 366 Energy monitor .....................212
Hybrid System Indicator .......175
Intuitive parking assist-sensor
...........................................387
Language .....................194, 601
LTA (Lane Traci ng Assist) ....357
Menu icons ...........................186
Meter control switches..185, 197
Navigation system-linked display ...........................................190
Parking Support Brake function ...........................................397
PCS (Pre-Collisio n System) .340
Pop-up display......................194
RSA (Road Sign Assist) .......363
Settings ................191, 203, 600
Tire pressure ...... ..................500
Units .............................194, 601
Vehicle information display.190, 202
Warning message display ..195, 206
Warning messages ...............552
“My Room Mode” ...................148
N
Navigation system-linked display ...............................................190
Noise from under ve hicle...........6
Normal mode...........................404
O
Odometer.........................173, 183 “ODO TRIP” switch ...............177
Odometer and trip meter display “ODO TRIP” switch .......177, 184
Display items ................177, 183
“ODO TRIP” switch ........177, 184
Oil Engine oil..............................582
Opener

650Alphabetical Index
Load limits ............................ 292
Weight .................................. 580
Wheels ..................................... 511 Replacing wheels ................. 511
Size ...................................... 585
Window glasses Power windows .................... 270
Window lock switch ............... 272
Windows Power windows .................... 270
Rear window defogger ......... 424
Washer ......................... 327, 330
Windshield defogger .............. 424
Windshield wiper de-icer ....... 429
Windshield wipers Intermittent windshield wipers........................................... 327
Position ........................ 327, 330
Rain-sensing windshield wipers ........................................... 327
Replacing the wiper insert .... 519
Winter driving tips .................. 413
Wiper insert ............................ 519
Wireless charger .................... 447
Wireless remote c ontrol ........ 220
Battery-saving function......... 242
Locking/Unlocking ................ 220
Panic mode .......................... 220
Remote Air Conditioning System ........................................... 431
Replacing the battery ........... 522
For information regarding the equipment listed
below, refer to “MULTIME-
DIA OWNER’S MANUAL”.
· Navigation system
· Audio system
· Rear view monitor system · Toyota parking assist monitor
· Panoramic view monitor
