2023 TOYOTA COROLLA CROSS instrument panel

2995-1. Using the air conditioning system and defogger
5
Interior features
■Adjusting the position of
and opening and closing
the air outlets
Front center
Direct air flow to the left or right, up
or down
Front right-hand side
1 Direct air flow to the left or
right, up or down
2 Close the vent
3 Open the vent
Front left-hand side
1 Direct air flow to the left or right, up or down
2 Close the vent
3 Open the vent
Rear
1 Direct air flow to the left or
right, up or down
2 Turn the knob to open or
close the vents
WARNING
■To prevent the windshield
defogger from operating
improperly
Do not place anything on the
instrument panel which may cover
the air outlets. Otherwise, air flow
may be obstructed, preventing the
windshield defoggers from defog-
ging.

3316-1. Maintenance and care
6
Maintenance and care
Remove dirt and dust using a
vacuum cleaner. Wipe dirty
surfaces with a cloth damp-
ened with lukewarm water.
 If dirt cannot be removed,
wipe it off with a soft cloth
dampened with neutral deter-
gent diluted to approximately
1%.
Wring out any excess water
from the cloth and thoroughly
wipe off remaining traces of
detergent and water.
■Shampooing the carpets
There are several commercial foam-
ing-type cleaners available. Use a
sponge or brush to apply the foam.
Rub in overlapping circles. Do not
use water. Wipe dirty surfaces and
let them dry. Excellent results are
obtained by keeping the carpet as
dry as possible.
■Handling the seat belts
Clean with mild soap and lukewarm
water using a cloth or sponge. Also
check the belts periodically for
excessive wear, fraying or cuts.
Cleaning and protect-
ing the vehicle interior
Perform cleaning in a man-
ner appropriate to each
component and its material.
Protecting the vehicle
interior
WARNING
■Water in the vehicle
●Do not splash or spill liquid in
the vehicle.
Doing so may cause electrical
components, etc. to malfunc-
tion or catch fire.
●Do not get any of the SRS com-
ponents or wiring in the vehicle
interior wet.
(  P. 2 9 )
An electrical ma lfunction may
cause the airbags to deploy or
not function properly, resulting
in death or serious injury.
●Vehicles with wireless charger:
Do not let the wireless charger
(  P.310) get wet. Failure to do
so may cause t he charger to
become hot and cause burns or
could cause electric shock
resulting in death or serious
injury.
■Cleaning the interior (espe-
cially instrument panel)
Do not use polish wax or polish
cleaner. The instrument panel
may reflect off the windshield,
obstructing the driver’s view and
leading to an accident, resulting in
death or serious injury.
NOTICE
■Cleaning detergents
●Do not use the following types
of detergent, as they may dis-
color the vehicle interior or
cause streaks or damage to
painted surfaces:
• Areas other than the seats and steering wheel: Organic sub-
stances such as benzene or
gasoline, alkaline or acidic solu-
tions, dye, and bleach

3326-1. Maintenance and care
Remove dirt using a
water-dampened soft cloth or
synthetic chamois.
 Wipe the surface with a dry,
soft cloth to remove any
remaining moisture.
■Cleaning the areas with
satin-finish metal accents
The metal areas use a layer of real
metal for the surface. It is necessary
to clean them regularly. If dirty areas
are left uncleaned for long periods
of time, they may be difficult to
clean.
 Remove dirt and dust using a
vacuum cleaner.
 Wipe off any excess dirt and
dust with a soft cloth damp-
ened with diluted detergent.
Use a diluted water solution of
approximately 5% neutral wool
detergent.
NOTICE
• Seats: Alkaline or acidic solu-
tions, such as thinner, benzene,
and alcohol
• Steering wheel: Organic sub- stances, such as thinner, and
cleaner that contains alcohol
●Do not use polish wax or polish
cleaner. The instrument panel’s
or other interior part’s painted
surface may be damaged.
■Preventing damage to leather
surfaces
Observe the following precautions
to avoid damage to and deteriora-
tion of leather surfaces:
●Remove any dust or dirt from
leather surfaces immediately.
●Do not expose the vehicle to
direct sunlight for extended peri-
ods of time. Park the vehicle in
the shade, especially during
summer.
●Do not place items made of
vinyl, plastic, or containing wax
on the upholstery, as they may
stick to the leather surface if the
vehicle interior heats up signifi-
cantly.
■Water on the floor
Do not wash the vehicle floor with
water.
Vehicle systems such as the
audio system may be damaged if
water comes into contact with
electrical components such as the
audio system above or under the
floor of the vehicle. Water may
also cause the body to rust.
■When cleaning the inside of
the windshield
Do not allow glass cleaner to con-
tact the lens. Also, do not touch
the lens. (
P.192)
■Cleaning the inside of the rear
window
●Do not use glass cleaner to
clean the rear window, as this
may cause damage to the rear
window defogger heater wires.
Use a cloth dampened with
lukewarm water to gently wipe
the window clean. Wipe the win-
dow in strokes running parallel
to the heater wires.
●Be careful not to scratch or
damage the heater wires.
Cleaning the areas with
satin-finish metal accents
Cleaning the leather areas

4298-1. Specifications
8
Vehicle specifications
■Vehicle identification num-
ber
The vehicle identification num-
ber (VIN) is the legal identifier
for your vehicle. This is the pri-
mary identification number for
your Toyota. It is used in regis-
tering the ownership of your
vehicle.
This number is stamped on the
top left of the instrument panel.
This number is also on the Certi- fication Label.
■Engine number
The engine number is stamped
on the engine block as shown.
Vehicle identification
Engine
Model2.0 L 4-cylinder (M20A-FKS)
Ty p e4-cylinder in line , 4-cycle, gasoline
Bore and stroke3.17  3.84 in. (80.5  97.6 mm)
Displacement121.3 cu. in. (1987 cm3)
Valve clearanceAutomatic adjustment
Drive belt tensionAutomatic adjustment

476Alphabetical Index
BatteryBattery checking................... 348
If the battery is discharged ... 419
Preparing and c hecking before
winter.................................. 279
Warning light ........................ 392
Blind Spot Monitor (BSM) ...... 243
Bottle holders ......................... 305
Brake Brake hold ............................ 175
Fluid ............................. 347, 433
Parking brake ....................... 172
Warning light ........................ 391
Brake assist ............................ 274
Break-in tips ........ ................... 142
Brightness control Instrument panel light control78, 81
BSM (Blind Spot Monitor) ...... 243
C
Care Exterior ................................. 328
Interior .................................. 331
Seat belts ............................. 331
Wheels and wheel ornaments........................................... 328
Cargo capacity ....................... 150
Cargo hooks ........................... 307
Child restraint system Fixed with a LATCH system ... 56
Fixed with a seat belt ............. 52
Front passenger occupant clas-sification system ................... 37
Points to remember ................ 43
Riding with children ................ 42
Types of child restraint system installation met hod ............... 45
Using an anchor bracket ........ 61
Child safety Airbag precautions ................. 32
Back door precautions ......... 108 Battery precautions ......349, 422
Child restraint system .............45
Heated steering wheel and seat
heater precautio ns..............300
How your child should wear the seat belt ................................26
Moon roof precautions..........136
Power window lock switch ....134
Power window precautions...133
Rear door child-protectors ....107
Removed electronic key battery precautions .........................370
Seat belt extender precautions .............................................26
Seat belt precautions..............42
Child-protectors......................107
Cleaning Exterior .................................328
Interior ..................................331
Seat belts .............................331
Wheels and wheel ornaments...........................................328
Clock ................... .....76, 78, 79, 81
Coat hooks ..............................319
Condenser ............. ..................347
Console box ............................306
Consumption screen ................95
Continuously variable transmis- sion ........................................168If th e s hif t le ver ca n no t b e s hif te d from P .................................169
M mode ................................170
Cooling system .......................346 Engine overheating ..............423
Cruise control .........................231
Cup holders.............................305
Current fuel consumption..83, 90
Curtain shield airbags ..............29
Customizable featu res ...........449
D
Daytime running light system179

479Alphabetical Index
Fuel gauge ....................... 76, 79
Fuel pump shut off system ... 390
Information ........................... 436
Refueling .............................. 188
Type ..................................... 430
Warning light ........................ 394
Fuel consumption Average fuel economy ..... 83, 90
Current fuel consumption . 83, 90
Fuel economy ......... ............ 83, 90
Fuel filler door Refueling .............................. 188
Fuel gauge .......................... 76, 79
Fuel pump shut off system.... 390
Fuses ....................................... 371
G
Garage door opener ............... 320
Gauges ................................ 76, 79
Glove box ................................ 305
Glove box light ....................... 305
H
Head restraints ....................... 126
Headlight aim .......................... 373
Headlights Adaptive Front-lighting System (AFS) .................................. 180
Automatic High Beam system ........................................... 181
Light switch .......................... 178
Replacing light bulbs ............ 375
Headlights/daytime running lightsReplacing light bulbs ............ 375
Heated steering wheel ........... 300
Heaters Automatic air conditioning sys-tem ..................................... 292
Heated steering wheel ......... 300 Manual air conditioning system
...........................................286
Outside rear view mirrors ...288, 295
Seat heaters ....... ..................300
High mounted stoplight Replacing light bulbs ............375
Hill-start assist control...........274
Hood Open.....................................342
Hooks Coat hooks ...........................319
Retaining hooks (floor mat) ....22
Horn .........................................128
I
I/M test .....................................338
Identification Engine ..................................429
Vehicle ..................................429
Ignition switch (engine switch) .......................................162, 163Auto power off fun ction .........167
Changing the engine switch modes.................................166
If your vehicle has to be stopped in an emergency .................382
Illuminated entry system .......303
Indicators ..................................74
Initialization Items to initialize ...................459
Maintenance .........................335
Power windows ....................132
Tire pressure w arning system
...........................................356
Inside rear view m irror ...........129
Instrument panel light control78, 81
Interior lights...........................302 Front interior light .................302
Rear interior light ..................302
Wattage ................................435

481Alphabetical Index
M
MaintenanceDo-it-yourself maintenance .. 340
General maintenance ........... 336
Maintenance data................. 428
Maintenance requirements... 334
Malfunction indicator lamp.... 392
Manual air conditioning system ............................................... 286
Menu icons ......................... 82, 89
Meter Clock ................................ 76, 79
Indicators................................ 74
Instrument panel light control78, 81
Meter control switches ..... 82, 89
Meters .............................. 76, 79
Multi-information display .. 82, 89
Settings ............................ 86, 93
Warning lights....................... 391
Warning message ................ 401
Mirrors Inside rear view mirror.......... 129
Outside rear view mirror defog-gers ............................ 288, 295
Outside rear view mirrors ..... 130
Vanity mirrors ....................... 318
Moon roof Door lock linked moon roof oper-ation ................................... 135
Jam protection function ........ 135
Operation ............................. 135
Multi-information display Audio system-linked display . 85, 92
AWD Control .......................... 86
Clock ................................ 78, 81
Cruise control ....................... 231
Driving information display83, 90
Driving support system informa- tion display ..................... 85, 91 Dynamic radar cruise control 223
Eco Driving Indicator ........84, 90
Fuel economy ...................83, 90
Menu icons .......................82, 89
Meter control switches......82, 89
Navigation system-linked display
.......................................85, 91
Settings ............................86, 93
Stop & Start system information .............................................87
Suggestion function ..........87, 94
Tire pressure ...... ............86, 353
Vehicle information display85, 92
Warning message.................401
N
Navigation system-linked display ...........................................85, 91
Noise from under ve hicle...........5
O
Odometer.............................77, 80
Odometer and trip meter display
Display change button ......77, 80
Display items ....................77, 81
Oil Engine oil..............................430
Rear differential oil................433
Open tray .................................306
Opener Back door ..................... 111, 112
Fuel filler door.......................188
Hood .....................................342
Outside rear view mirrors Adjustment ...........................131
BSM (Blind Spot M onitor) .....243
Folding..................................131
Outside rear view mirror defog- gers ............................288, 295
RCTA function.......................248
Safe Exit Assist.....................254

484Alphabetical Index
Meter control switches ..... 82, 89
Stop & Start system System information display .... 87
Warning light ........................ 396
Stop & Start system information display ..................................... 87
Stop light Replacing light bulbs ............ 375
Storage features ..................... 304
Stuck If the vehicle becomes stuck 425
Suggestion function........... 87, 94
Sun visors ............................... 318
Sunshade Roof...................................... 135
Switches Automatic High Beam system........................................... 181
Brake Hold switch ................ 175
Cruise control switch ............ 231
Display change button...... 77, 80
Door lock switches ............... 107
Dynamic radar cruise control switch ................................. 223
Emergency flashers switch .. 382
Engine switch ............... 162, 163
Garage door opener switches ........................................... 320
Heated steering wheel switch ........................................... 300
Ignition switch............... 162, 163
Instrument panel light control switches ......................... 78, 81
Light switches....................... 178
LTA (Lane Tracing Assist) switch ........................................... 211
Meter control switches ..... 82, 89
Moon roof switches .............. 135
Outside rear view mirror switches ............................. 130
Parking brake switch ............ 172 PKSB (Parking Support Brake)
switch .................................266
Power door lock switch.........107
Power window switches .......132
Rear window and outside rear view mirror defoggers switch...........................................292
Seat heater switches ............300
“SOS” button ..........................64
Stop & Start cancel switch ....238
Vehicle-to-vehicle distance switch .........................223, 225
VSC OFF switch ...................275
Window lock switch ..............134
Windshield wiper and washer switch .................................184
T
Tachometer .........................76, 79
Tail lights Light switch...........................178
Replacing light bulbs ............375
Wattage ................................435
Tail lights/rear side marker lights Replacing light bulbs ............374
Theft deterrent system Alarm ......................................69
Engine immobilizer system .....68
Tire inflation pres sure ............363
Maintenance data .................434
Warning light.........................395
Tire information ......................438 Glossary ...............................442
Size ......................................440
Tire identification number .....440
Uniform Tire Quality Grading 441
Tire pressure display .............353
Tire pressure warning system Function................................353
Initializing..............................356
Installing tire p ressure warning
valves and transmitters ......355
